ODS Unit Initialization

When a seat-back cover, seat-back cushion, and/or ODS unit is replaced, do this procedure to initialize the ODS unit.

Note. A new (uninitialized) ODS unit installed with a faulty OPDS sensor can cause DTC 85-71. Before initializing the ODS unit, make sure the battery is fully charged.

Scheme 275

Scheme 275: ODS Unit Initialization
Scheme 275: ODS Unit Initialization
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(ref-355246-S08796912752010012100000) ).
  2. Make sure the front passenger's seat is dry. Set the seat-back in a normal position, and make sure there is nothing on the seat.
  3. Make sure the ignition switch is in LOCK (0) and the MES connector is not shorted.
  4. Connect the HDS to the data link connector (DLC) (A).
  5. Turn the ignition switch to ON (II).
  6. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(ref-355245-S06359967292010012100000) ).
  7. From the HDS Main Menu, select SRS, then SRS, then Adjustments. In the Adjustment Menu, select ODS INIT. Follow the screen prompts to initialize the ODS.
  8. Turn the ignition switch to LOCK (0).
  9. Disconnect the HDS from the DLC.

Note. If the ODS system fails to initialize after several attempts, replace the OPDS sensor/seat-back and retry. If the ODS unit continues to fail to initialize, replace the ODS unit (see ODS UNIT REPLACEMENT ).
