Engine Block: Overview Honda Element YH2 рестайлинг

Scheme 195

Scheme 196

Scheme 197

Scheme 198

Scheme 199

1. Remove the oil pump (see «OIL PUMP REMOVAL»(ref-290812-S04770566862008072200000) ).
2. Remove the baffle plates (see step 8 ).
3. Measure the connecting rod end play with a feeler gauge between the connecting rod and crankshaft. Connecting Rod End Play Standard (New): 0.15-0.35 mm (0.006-0.014 in.) Service Limit: 0.40 mm (0.016 in.)
4. If the connecting rod end play is beyond the service limit, install a new connecting rod, and recheck. If it is still beyond the service limit, replace the crankshaft (see «CRANKSHAFT AND PISTON REMOVAL»(ref-290844-S11663048052008072200000) ).
5. Push the crankshaft firmly away from the dial indicator, and zero the dial against the end of the crankshaft. Then pull the crankshaft firmly back toward the indicator, the dial reading should not exceed the service limit. Crankshaft End Play Standard (New): 0.10-0.35 mm (0.004-0.014 in.) Service Limit: 0.45 mm (0.018 in.)
6. If the crankshaft end play is beyond the service limit, replace the thrust washers and recheck. If it is still beyond the service limit, replace the crankshaft (see «CRANKSHAFT AND PISTON REMOVAL»(ref-290844-S11663048052008072200000) ).

Scheme 200

Scheme 201

1. To check main bearing-to-journal oil clearance, remove the lower block and bearing halves (see «CRANKSHAFT AND PISTON REMOVAL»(ref-290844-S11663048052008072200000) ).
2. Clean each main journal and bearing half with a clean shop towel.
3. Place one strip of plastigage across each main journal.
4. Reinstall the bearings and lower block, then torque the bolts to 30 N.m (3.0 kgf.m, 22 lbf.ft). NOTE: Do not rotate the crankshaft during inspection.
5. Tighten the bearing cap bolts an additional 56°.
6. Remove the lower block and bearings again, and measure the widest part of the plastigage. Main Bearing-to-Journal Oil Clearance No. 1, 2, 4, 5 Journals: Standard (New): 0.017 - 0.041 mm (0.0007 - 0.0016 in.) Service Limit: 0.050 mm (0.0020 in.) No. 3 Journal: Standard (New): 0.025 - 0.049 mm (0.0010 - 0.0019 in.) Service Limit: 0.055 mm (0.0022 in.)
7. If the plastigage measures too wide or too narrow, remove the crankshaft, and remove the upper half of the bearing. Install a new, complete bearing with the appropriate color code(s), and recheck the clearance. Do not file, shim, or scrape the bearings or the caps to adjust clearance.
8. If the plastigage shows the clearance is still incorrect, try the next larger or smaller bearing (the color listed above or below the current one), and check again. If the proper clearance cannot be obtained by using the appropriate larger or smaller bearings, replace the crankshaft and start over.

Scheme 202

Scheme 203

Scheme 204

Scheme 205

Scheme 206

1. Numbers letters, or bars have been stamped on the end of the engine block as a code for the size of each of the five main journal bores. Write down the crank bore codes. If you can't read the codes because of accumulated dirt and dust, do not scrub them with a wire brush or scraper. Clean them only with solvent or detergent.
2. The main journal codes are stamped on the crankshaft in either location.
3. Use the crank bore codes and crank journal codes to select the appropriate replacement bearings from the following table. NOTE: The color code is on the edge of the bearing. When using bearing halves of different colors, it does not matter which color is used in the top or bottom.

Scheme 207

1. Remove the oil pump (see «OIL PUMP REMOVAL»(ref-290812-S04770566862008072200000) ).
2. Remove the baffle plates (see step 8 ).
3. Remove the connecting rod cap and bearing half.
4. Clean the crankshaft rod journal and bearing half with a clean shop towel.
5. Place plastigage across the rod journal.
6. Reinstall the bearing half and connecting rod cap, and torque the bolts to 20 N.m (2.0 kgf.m, 15 lbf.ft) + 90° using a commercially available torque angle gauge. NOTE: Do not rotate the crankshaft during inspection.
7. Remove the connecting rod cap and bearing half, and measure the widest part of the plastigage. Connecting Rod Bearing-to-Journal Oil Clearance Standard (New): 0.020-0.050 mm (0.0008-0.0020 in.) Service Limit: 0.060 mm (0.0024 in.)
8. If the plastigage measures too wide or too narrow, remove the upper half of the bearing, install a new, complete bearing with the appropriate color code(s), and recheck the clearance. Do not file, shim, or scrape the bearings or the caps to adjust clearance.
9. If the plastigage shows the clearance is still incorrect, try the next larger or smaller bearing (the color listed above or below the current one), and check clearance again. If the proper clearance cannot be obtained by using the appropriate larger or smaller bearing, replace the crankshaft and start over.

Scheme 208

Scheme 209

Scheme 210

Scheme 211

Scheme 212

1. Inspect each connecting rod for cracks and heat damage.
2. Each rod has a tolerance range from 0 to 0.024 mm (0.0009 in.), and in 0.006 mm (0.0002 in.) increments, depending on the size of its big end bore. It's then stamped with a number or bar (1, 2, 3, or 4/I, II, III, or IIII) indicating the range. You may find any combination of numbers and bars in any engine. (Half the number or bar is stamped on the bearing cap, the other half is on the rod.) If you can't read the code because of an accumulation of oil and varnish, do not scrub them with a wire brush or scraper. Clean them only with solvent or detergent. Normal Bore Size: 51.0 mm (2.01 in.)
3. The connecting rod journal codes are stamped on the crankshaft in either location.
4. Use the big end bore codes and rod journal codes to select appropriate replacement bearings from the following table. NOTE: The color code is on the edge of the bearing. When using bearing halves of different colors, it does not matter which color is used in the top or bottom.

Scheme 213

Scheme 214

Scheme 215

1. Drain the engine oil (see «ENGINE OIL REPLACEMENT»(ref-290812-S28045107832008072200000) ).
2. If the engine is still in the vehicle, remove the subframe. Attach the engine support hanger to the engine (see step 42 in «ENGINE REMOVAL»(ref-290840-S06166089872008072200000) ). Disconnect the suspension knuckle ball joints (see «LOWER ARM REPLACEMENT»(ref-290841-S10580983432008072200000) ). Remove the rear mount mounting bolts (see step 44 in «ENGINE REMOVAL»(ref-290840-S06166089872008072200000) ). Remove the front mount mounting bolt (see step 45 in «ENGINE REMOVAL»(ref-290840-S06166089872008072200000) ). A/T model: Remove the automatic transmission fluid (ATF) filter mounting bolt (see step 37 in «ENGINE REMOVAL»(ref-290840-S06166089872008072200000) ). Make the appropriate reference lines at positions A and B that line up with the center of the subframe mounting bolts (see step 46 in «ENGINE REMOVAL»(ref-290840-S06166089872008072200000) ). Attach the subframe adapter to the subframe, then attach the jack to the subframe adapter (see step 47 in «ENGINE REMOVAL»(ref-290840-S06166089872008072200000) ). Remove the front subframe mounting bolts, then lower the subframe (see step 49 in «ENGINE REMOVAL»(ref-290840-S06166089872008072200000) ).
3. M/T model: Remove the clutch cover.
4. Remove the bolts/nuts securing the oil pan.
5. Drive an oil pan seal cutter between the oil pan and engine block.
6. Cut the oil pan seal by striking the side of the cutter to slide the cutter along the oil pan.
7. Remove the oil pan.

Scheme 216

Scheme 217

Scheme 218

Scheme 219

Scheme 220

Scheme 221

Scheme 222

1. Remove the engine/transmission (see «ENGINE REMOVAL»(ref-290840-S06166089872008072200000) ).
2. Remove the transmission: Manual transmission (see «TRANSMISSION REMOVAL»(ref-290818-S20729458042008072200000) ) Automatic transmission (see «TRANSMISSION REMOVAL»(ref-355247-S27159294832010012100000) )
3. M/T model: Remove the pressure plate (see «PRESSURE PLATE AND CLUTCH DISC REMOVAL»(ref-290835-S13152441202008072200000) ), clutch disc (see «PRESSURE PLATE AND CLUTCH DISC REMOVAL»(ref-290835-S13152441202008072200000) ), and flywheel (see «FLYWHEEL REPLACEMENT»(ref-290835-S05244090342008072200000) ).
4. A/T model: Remove the drive plate (see «DRIVE PLATE REMOVAL AND INSTALLATION»(ref-355247-S06984316832010012100000) ).
5. Remove the oil pan (see «OIL PAN REMOVAL»(ref-290844-S36063753122008072200000) ).
6. Remove the oil pump (see «OIL PUMP REMOVAL»(ref-290812-S04770566862008072200000) ).
7. Remove the cylinder head (see «CYLINDER HEAD REMOVAL»(ref-290827-S10641636572008072200000) ).
8. Remove the baffle plates.
9. Remove the 8 mm bolts from the lower block in the criss-cross pattern shown below.
10. Remove the bearing cap bolts. To prevent warpage, loosen the bolts in sequence 1/3 turn at a time. Repeat the sequence until all bolts are loosened.
11. Remove the lower block and bearings. Keep all bearings in order.
12. Remove the connecting rod caps/bearing halves. Keep all connecting rod caps/bearing halves in order.
13. Lift the crankshaft out of the engine block, being careful not to damage the journals.
14. Remove the upper bearing halves from the connecting rods, and set them aside with their respective caps.
15. If you can feel a ridge of metal or hard carbon around the top of each cylinder, remove it with a ridge reamer (A). Follow the reamer manufacturer's instructions. If the ridge is not removed, it may damage the pistons as they are pushed out.
16. Use the wooden handle of a hammer (A) to drive out the piston/connecting rod assembly (B).
17. Reinstall the lower block and bearings on the engine block in the proper order.
18. Reinstall the connecting rod bearings and caps after removing each piston/connecting rod assembly.
19. Mark each piston/connecting rod assembly with its cylinder number to make sure they are reused in the original order. NOTE: The existing number on the connecting rod does not indicate its position in the engine block, it indicates the rod bore size.

Scheme 223

Scheme 224

1. Remove the crankshaft from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(ref-290844-S11663048052008072200000) ).
2. Clean the crankshaft oil passages with pipe cleaners or a suitable brush.
3. Clean the keyway and threads.
4. Measure the out-of round at the middle of each rod and main journal in two places. The difference between measurements on each journal must not be more than the service limit. '07-08 models Journal Out-of-Round Standard (New): 0.005 mm (0.0002 in.) max. Service Limit: 0.010 mm (0.0004 in.) '09-10 models Journal Out-of-Round Standard (New): 0.004 mm (0.0002 in.) max. Service Limit: 0.010 mm (0.0004 in.)
5. Measure the taper at the edges of each rod and main journal. The difference between measurements on each journal must not be more than the service limit. Journal Taper Standard (New): 0.005 mm (0.0002 in.) max. Service Limit: 0.010 mm (0.0004 in.)
6. Place the V-blocks on a flat surface.
7. Check the total runout with the crankshaft supported on V-blocks.
8. Measure the runout on all of the main journals. Rotate the crankshaft two complete revolutions. The difference between measurements on each journal must not be more than the service limit. Crankshaft Total Runout Standard (New): 0.03 mm (0.0012 in.) max. Service Limit: 0.04 mm (0.0016 in.)

Scheme 225

Scheme 226

Scheme 227

Scheme 228

1. Remove the crankshaft and pistons (see «CRANKSHAFT AND PISTON REMOVAL»(ref-290844-S11663048052008072200000) ).
2. Check the piston for distortion or cracks.
3. Measure the piston diameter at a point 13 mm (0.5 in.) from the bottom of the skirt. There are two standard-size pistons (No Letter or A, and B). The letter is stamped oh the top of the piston. Letters are also stamped on the engine block as cylinder bore sizes. Piston Diameter Standard (New): No Letter (or A): 86.980-86.990 mm (3.4244-3.4248 in.) B: 86.970-86.980 mm (3.4240-3.4244 in.) Service Limit: No Letter (or A): 86.930 mm (3.4224 in.) B: 86.920 mm (3.4220 in.) Oversize Piston Diameter 0.25: 87.230-87.240 mm (3.4342-3.4346 in.)
4. Measure the wear and taper in direction X and Y at three levels in each cylinder as shown. If measurements in any cylinder are beyond the Oversize Bore Service Limit, replace the engine block. If the engine block is to be rebored, refer to step 7 after reboring. Cylinder Bore Size Standard (New): A or I: 87.010-87.020 mm (3.4256-3.4260 in.) B or II: 87.000-87.010 mm (3.4252-3.4256 in.) Service Limit: 87.070 mm (3.4279 in.) Oversize 0.25: 87.250-87.260 mm (3.4350-3.4354 in.) Reboring Limit: 0.25 mm (0.01 in.) max. Bore Taper Limit: (Difference between first and third measurement) 0.05 mm (0.002 in.)
5. Scored or scratched cylinder bores must be honed.
6. Check the top of the engine block for warpage. Measure along the edges, and across the center as shown. Engine Block Warpage Standard (New): 0.07 mm (0.003 in.) max. Service Limit: 0.10 mm (0.004 in.)
7. Calculate the difference between the cylinder bore diameter and the piston diameter. If the clearance is near or exceeds the service limit, inspect the piston and cylinder bore for excessive wear. Piston-to-Cylinder Bore Clearance Standard (New): 0.020-0.040 mm (0.0008-0.0016 in.) Service Limit: 0.05 mm (0.002 in.)
