Audio: Diagnosis Honda Element YH2 рестайлинг

Symptom Troubleshooting Index

SYMPTOM TROUBLESHOOTING INDEX

Phase Test

Do this test to confirm proper speaker phasing.

1. Insert the audio diagnostic CD (T/N: 07AAZ-SDBA100) into the audio unit.
2. Play track No. 2 (phase) at a normal, or slightly higher than normal, volume level.
3. The voice should sound centered and focused when it is in-phase.
4. The voice should sound diffused, and have "less bass" when it is out of phase. If the voice changes from in-phase to out of phase as indicated by the prompt, the phasing is correct. Go to electrical noise test. If the voice always sounds out of phase, phasing is not correct. Check for; Crossed speaker wires Faulty amplifier Faulty audio unit

Electrical Noise Test

Do this test to check for electrical noise being induced into the audio system.

Note. Electrical noise may be caused by outside sources that cannot be handled by the audio system. Make sure you remove any cell phones and/or turn off any aftermarket device before beginning this test.

1. Insert the audio diagnostic CD (T/N: 07AAZ-SDBA100) into the audio unit.
2. Play track No. 4 (digital zero) at a normal, or slightly higher than normal, volume level.
3. Operate any electrical device that may create electrical noise in the audio system, including starting the engine.
4. Play track No. 5 (near digital zero) at a normal, or slightly higher than normal, volume level.
5. Operate any electrical device that may create electrical noise in the audio system, including starting the engine.
6. Play track No. 6 (SNR) at a normal, or slightly higher than normal, volume level.
7. Operate any electrical device that may create electrical noise in the audio system, including starting the engine. If no abnormal noise is heard, go to individual speaker test. If the noise is present only during the SNR track, replace the audio unit. If the noise is heard during the digital zero or near digital zero track, check for; Poor ground for the audio unit, amplifier, engine or battery cable Pinched or shorted speaker or amplifier wire Faulty amplifier Faulty audio unit Other faulty components causing excessive electrical noise (ignition coils, alternator, door lock actuators, etc.). Disconnect any suspect components, and then replay the tracks that were originally noisy. If the noise is gone, check the component's circuit and the component.

Individual Speaker Test

Do this test to identify a faulty speaker.

1. Insert the audio diagnostic CD (T/N: 07AAZ-SDBA100) into the audio unit.
2. Play track No. 30 (steady 300 Hz tone) at a normal, or slightly higher than normal, volume level.
3. Listen to each speaker for poor sound compared to the other speakers. Use the audio unit's fader and balance settings to help isolate the channel with the problem. If the sound quality produced by a specific speaker is poor, substitute it with a known-good speaker. If the poor sound quality continues, go to «SOUND BALANCE TEST»(ref-290858-S10757117472008072200000) . If the sound quality is OK, go to «SOUND BALANCE TEST»(ref-290858-S10757117472008072200000) .

Sound Balance Test

Perform this test to identify a faulty channel or speaker.

1. Insert the audio diagnostic CD (T/N: 07AAZ-SDBA100) into the audio unit.
2. Confirm the bass and treble are set to the center positions.
3. Play track No. 3 (pink noise) at a normal, or slightly higher then normal, volume level.
4. A "static" type sound should be heard through all speakers.
5. Insert the audio diagnostic CD (T/N: 07AAZ-SDBA100) into the audio unit of a known-good vehicle.
6. Set the bass and treble to the center position.
7. Play track No. 3 (pink noise) at the same level that was played in step 3 .
8. Compare the sounds made by the two vehicles. If the noise sounds made by the two vehicles are very similar, go to «FREQUENCY SWEEP»(ref-290858-S26541680052008072200000) . If the sound does not have as much bass, check the subwoofer and circuit. If the sound does not have enough "hiss," check the tweeters and their circuits.

Seek Stop Test

Do this test to check the performance of the audio unit's AM and FM reception. Refer to SYMPTOM TROUBLESHOOTING : audio sound weak or distorted, or NO SOUND IS HEARD FROM SPEAKER(S) (DISPLAY IS NORMAL) before continuing with this test.

Note. Window tint, aftermarket theft-recovery devices and other aftermarket accessories may reduce radio reception. Changes in cloud cover and other atmosphere conditions will affect the ability of the audio unit to receive radio signals.

1. Park the customer's vehicle in an open area away from buildings or other obstructions.
2. Park a known-good vehicle (same year, model, and trim level) next to the customer's vehicle, facing the same direction.
3. Start the engine in the customer's vehicle, and turn on the radio.
4. Set the FM receiver to 87.7 MHz.
5. Press the "Seek +" button and record the first station that the audio unit locks onto.
6. Press the "Seek +" button repeatedly, and write down each station that the audio unit locks onto until the station recorded in step 5 is reached again.
7. Set the AM receiver to 530 kHz.
8. Press the "Seek +" button, and record the first station that the audio unit locks on to.
9. Press the "Seek +" button repeatedly, and write down each station that the audio unit locks onto until the station recorded in step 8 is reached again.
10. Turn the ignition switch to LOCK (0).
11. Start the engine in the known-good vehicle, and then perform steps 4 through 10 on the known-good vehicle.
12. Compare the number of stations received in steps 6 and 9 in the customer's vehicle with the number of stations received in the known-good vehicle. If the number of stations received is the same, or within 10%, the audio unit's tuner performance is OK. The problem may be atmospheric conditions, multi path interference, or other obstructions to the radio signal. If the customer's vehicle receives fewer stations by at least 10%, go to step 2 of poor AM or FM radio reception of interference (see «SYMPTOM TROUBLESHOOTING»(ref-290858-S10397747942008072200000) ).

SRS components are located in this area. Review the SRS COMPONENT LOCATION INDEX and PRECAUTIONS AND PROCEDURES in the SRS before doing repairs or service.

Note. Eject all the CDs before remove the audio unit to prevent damaging the CD player's load mechanism. Put on gloves to protect your hands. Take care not to scratch the dashboard and related parts. If you are replacing the audio unit, write down the audio presets (if possible), and enter them into the new audio unit.

Scheme 4

1. Make sure you have the anti-theft code for the audio system.
2. Remove the dashboard center panel (see «CENTER PANEL REMOVAL/INSTALLATION»(ref-290806-S11341247832008072200000) ).
3. Remove the four mounting bolts, then remove the audio unit.
4. Disconnect the audio connectors (A) and AM/FM antenna sublead (B).
5. Remove the eight mounting bolts securing the audio unit to the audio unit bracket.
6. Install the audio unit in the reverse order of removal, and note these items: Make sure the audio unit connector is plugged in properly, and the AM/FM antenna sublead is connected properly. Enter the anti-theft code for the audio system. Set the clock.

Scheme 5

1. Remove the right kick panel (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(ref-290846-S09306060772008072200000) ).
2. Remove the stereo amplifier connectors (A) from the stereo amplifier (B).
3. Loosen the mounting nut (C), and remove the two mounting bolts (D).
4. Remove the harness band (E) and the stereo amplifier.
5. Install the stereo amplifier in the reverse order of removal.

Scheme 6

1. Remove the right rear side trim panel (see «TRIM REMOVAL/INSTALLATION - REAR SIDE AREA»(ref-290846-S31031747122008072200000) ).
2. Disconnect the XM receiver connector (A) and the XM antenna lead connector (B).
3. Remove the bolts and screws, then remove the XM receiver.
4. Install the XM receiver in the reverse order of removal.

Scheme 7

1. Remove the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ).
2. Removal the center panel (see «CENTER PANEL REMOVAL/INSTALLATION»(ref-290806-S11341247832008072200000) ).
3. Loosen the bolts (A), then pull out the USB adapter unit (B).
4. Disconnect the connectors from the USB adapter unit, and remove it.
5. Install the USB adapter unit in the reverse order of removal.

Scheme 8

1. Remove the speaker cover (A).
2. Remove the three screws, then disconnect the 2P connector (B) from the speaker (C).
3. Install the speaker in the reverse order of removal.

Scheme 9

1. Remove the A-pillar trim (see «A-PILLAR TRIM»(ref-290846-S08909876352008072200000) ).
2. Disconnect the 2P connector (A).
3. Remove the two mounting screws from the tweeter (B).
4. Install the tweeter in the reverse order of removal.

Scheme 10

1. SC model: Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(ref-290853-S34235352102008072200000) ).
2. Remove the dashboard center lower cover (see «CENTER LOWER COVER REMOVAL/INSTALLATION»(ref-290806-S10272235662008072200000) ).
3. Disconnect the 4P connector (A) from the subwoofer (B).
4. Remove the four mounting bolts from the subwoofer.
5. Install the subwoofer in the reverse order of removal.

Scheme 11

1. Open the glove box. Remove the glove box stop on each side, then hang the glove box down (see «GLOVE BOX REMOVAL/INSTALLATION»(ref-290806-S13331020522008072200000) ).
2. Disconnect the connector (A) and the remove the cover (B)
3. Remove the USB jack (C) from the cover, then remove the cap (D), and the USB adapter cable (E) from the USB jack.
4. Install the USB jack in the reverse order of removal

Scheme 12

1. Remove the glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(ref-290806-S13331020522008072200000) ).
2. Remove the front accessory power socket (see «ACCESSORY POWER SOCKET TEST/REPLACEMENT»(ref-290887-S19630950412008072200000) ).
3. Disconnect the 5P connector (A) from the auxiliary jack assembly (B).
4. Push out the auxiliary jack assembly (B) from behind the dashboard.
5. Install the auxiliary jack assembly in the reverse order of removal.

Scheme 13

1. Remove the console accessory power socket from the center console box (see «COMPONENT LOCATION INDEX»(ref-290887-S01816628372008072200000) ).
2. Carefully pry the auxiliary jack assembly (A) out from the center console box.
3. Disconnect the 5P connector (B) from the auxiliary jack assembly.
4. Install the auxiliary jack assembly in the reverse order of removal.

Scheme 14

1. Pull down the rear portion of the headliner (see «HEADLINER REMOVAL/INSTALLATION»(ref-290846-S08293290452008072200000) ).
2. Disconnect the AM/FM antenna lead jack (A) and 1P connector (B) from the roof antenna (C).
3. Remove the mounting nut (D) and the AM/FM antenna.
4. Install the antenna in the reverse order of removal.

Scheme 15

1. Pull down the rear portion of the headliner (see «HEADLINER REMOVAL/INSTALLATION»(ref-290846-S08293290452008072200000) ).
2. Disconnect the AM/FM antenna lead connector (A) and XM antenna lead connector (B) from the AM/FM/XM antenna (C).
3. Remove the mounting nut (D) and the AM/FM/XM antenna.
4. Install the antenna in the reverse order of removal.

SRS components are located in this area. Review the SRS COMPONENT LOCATION INDEX and PRECAUTIONS AND PROCEDURES in the SRS before doing repairs or service.

Scheme 16

1. Remove the driver's airbag assembly (see «DRIVER S AIRBAG REPLACEMENT»(ref-355246-S28837650052010012100000) ).
2. Remove the two screws and cover (A) from the steering wheel.
3. Remove the two screws from the audio remote switch (B).
4. Disconnect the 4P connector from the audio remote switch.
5. Measure the resistance between the No. 3 and No. 4 terminals in each switch position according to the table below. RESISTANCE REFERENCE TABLE Position Resistance No button pressed About 10 kohms MODE About 2.4 kohms CH About 900 ohms ↑ (VOL. UP) About 300 ohms ↓ (VOL. DOWN) About 50 ohms
6. If the resistance is not as specified, replace the audio remote switch.

Scheme 17

1. Remove the driver's airbag assembly (see «DRIVER S AIRBAG REPLACEMENT»(ref-355246-S28837650052010012100000) ).
2. Remove the two screws and cover (A) from the steering wheel.
3. Remove the two screws from the audio remote switch (B).
4. Disconnect the 5P connector from the audio remote switch.
5. Measure the resistance between the No. 1 and No. 3 terminals in each switch position according to the table below. RESISTANCE REFERENCE TABLE Position Resistance No button pressed About 10 kohms MODE About 2.4 kohms CH About 900 ohms ↑ (VOL. UP) About 300 ohms ↓ (VOL. DOWN) About 50 ohms
6. If the resistance is not as specified, replace the audio remote switch.
