Deployment Tool Check Honda Element YH2 рестайлинг 2

Deployment Tool Check

1. Connect the yellow clips to both switch protector handles on the tool and connect the red lead to the positive battery post and the black lead to the negative battery post.
2. Push the operation switch: green light means the tool is OK; a red light means the tool is faulty.
3. Disconnect the yellow clips from the switch protector handles, and the red and black leads from the battery.

Scheme 293

Scheme 294

Scheme 295

Scheme 296

1. Make sure the front wheels are aligned straight ahead.
2. Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-290830-S42473120772009102900000) ), then wait at least 3 minutes before starting work.
3. Remove the driver's airbag (see «DRIVER S AIRBAG REPLACEMENT»(ref-355246-S28837650052010012100000) ).
4. Disconnect the horn switch 1P connector (A) and steering wheel switch connectors (B) from the steering wheel, then remove the steering wheel bolt (C).
5. With the front wheels still straight ahead, remove the steering wheel with a steering wheel puller (see step 5 under «STEERING WHEEL REMOVAL»(ref-290814-S14157168212008072200000) ). Do not tap on the steering wheel or steering column shaft when removing the steering wheel.
6. Remove the driver's dashboard lower cover (A).
7. Remove the steering column cover screws (A), then remove the steering column covers (B, C).
8. Disconnect the dashboard wire harness B 5P connector (A) from the cable reel, then disconnect the dashboard wire harness B 4P connector (B) from the cable reel.
9. Release the lock tab (A) under the cable reel connector with a 90° hook shaped tool (B). Slide the tool below the cable reel connector just above the lock tab. Release the lower lock tab (C), and slide the cable reel off the column.

Scheme 297

Scheme 298

Scheme 299

Scheme 300

Scheme 301

1. Make sure the front wheels are aligned straight ahead.
2. Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-290830-S42473120772009102900000) ), then wait at least 3 minutes before starting work.
3. Remove the driver's airbag (see «DRIVER S AIRBAG REPLACEMENT»(ref-355246-S28837650052010012100000) ).
4. Disconnect the 13P connector (A) from the cable reel, then remove the steering wheel bolt (B).
5. With the front wheels still straight ahead, remove the steering wheel with a steering wheel puller (see step 5 under «STEERING WHEEL REMOVAL»(ref-290814-S14157168212008072200000) ). Do not tap on the steering wheel or steering column shaft when removing the steering wheel.
6. Remove the driver's dashboard lower cover (A).
7. Remove the steering column cover screws (A), then remove the steering column covers (B, C).
8. Disconnect the dashboard wire harness B 13P connector (A) from the cable reel, then disconnect the dashboard wire harness B 4P connector (B) from the cable reel.
9. Release the lock tab (A) under the cable reel connector with a 90° hook shaped tool (B). Slide the tool below the cable reel connector just above the lock tab. Release the lower lock tab (C), and slide the cable reel off the column.

Scheme 302

Scheme 303

Scheme 304

Scheme 305

Scheme 306

Scheme 307

1. Before installing the steering wheel, align the front wheels straight ahead.
2. If not already done, disconnect the negative cable from the battery, and wait at least 3 minutes.
3. Set the turn signal canceling sleeve (A) so the projections (B) are aligned vertically.
4. Carefully install the cable reel (A) on the steering column shaft. Then connect the 5P connector (B) and the dashboard wire harness B 4P connector (C).
5. Install the steering column covers.
6. If necessary, center the cable reel. (New replacement cable reels come centered.) Do this by first rotating the cable reel clockwise until it stops. Then rotate it counterclockwise about two and a half turns until the arrow mark (A) on the cable reel label points straight up.
7. Position the two tabs (A) of the turn signal canceling sleeve (B) as shown. Install the steering wheel on to the steering column shaft, making sure the steering wheel hub (C) engages the pins (D) of the cable reel and tabs of the canceling sleeve. Do not tap on the steering wheel or steering column shaft when installing the steering wheel.
8. Align the projections on the cable reel with the holes on the steering wheel, and install the steering wheel with a steering wheel bolt (A).
9. Install the driver's airbag (see «DRIVER S AIRBAG REPLACEMENT»(ref-355246-S28837650052010012100000) ).
10. Do the battery terminal reconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-290830-S42473120772009102900000) ).
11. Clear any DTCs (see «CLEAR THE DTC MEMORY WITH THE HDS»(ref-355246-S08796912752010012100000) ).
12. After installing the cable reel, confirm proper system operation

1. Turn the ignition switch to ON (II); the SRS indicator should come on for about 6 seconds and then go off.
2. After the SRS indicator has turned off, turn the steering wheel fully left and right to confirm the SRS indicator does not come on.
3. Make sure the horn and turn signal switches work properly.
4. Make sure the steering wheel switches work properly.

Scheme 308

Scheme 309

Scheme 310

Scheme 311

Scheme 312

1. Before installing the steering wheel, align the front wheels straight ahead.
2. If not already done, disconnect the negative cable from the battery, and wait at least 3 minutes.
3. Set the turn signal canceling sleeve (A) so the projections (B) are aligned vertically.
4. Carefully install the cable reel (A) on the steering column shaft. Then connect the 13P connector (B) and the dashboard wire harness B 4P connector (C).
5. Install the steering column covers.
6. If necessary, center the cable reel. (New replacement cable reels come centered.) Do this by first rotating the cable reel clockwise until it stops. Then rotate it counterclockwise about two and a half turns until the arrow mark (A) on the cable reel label points straight up.
7. Position the two tabs (A) of the turn signal canceling sleeve (B) as shown. Install the steering wheel on to the steering column shaft, making sure the steering wheel hub (C) engages the pins (D) of the cable reel and tabs of the canceling sleeve. Do not tap on the steering wheel or steering column shaft when installing the steering wheel.
8. Align the projections on the cable reel with the holes on the steering wheel, and install the steering wheel with a steering wheel bolt (A).
9. Install the driver's airbag (see «DRIVER S AIRBAG REPLACEMENT»(ref-355246-S28837650052010012100000) ).
10. Do the battery terminal reconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-290830-S42473120772009102900000) ).
11. Clear any DTCs (see «CLEAR THE DTC MEMORY WITH THE HDS»(ref-355246-S08796912752010012100000) ).
12. After installing the cable reel, confirm proper system operation

1. Turn the ignition switch to ON (II); the SRS indicator should come on for about 6 seconds and then go off.
2. After the SRS indicator has turned off, turn the steering wheel fully left and right to confirm the SRS indicator does not come on.
3. Make sure the horn and turn signal switches work properly.
4. Make sure the steering wheel switches work properly.
