Ignition Switch: Diagnosis Honda Element YH2 рестайлинг 2

Key Interlock System Circuit Troubleshooting

See KEY INTERLOCK SYSTEM CIRCUIT TROUBLESHOOTING .

Key Interlock Solenoid Test

See KEY INTERLOCK SOLENOID TEST .

Park Pin Switch Test

See PARK PIN SWITCH TEST .

SRS components are located in this area. Review the SRS COMPONENT LOCATION INDEX and PRECAUTIONS AND PROCEDURES , before performing repairs or service.

Scheme 2

Scheme 3

1. Do the battery terminal disconnection procedure (see .
2. Remove the steering column upper and lower covers (see ).
3. Disconnect the 7P connector (A) from the ignition switch (B).
4. Check for continuity between the terminals in each switch position according to the table below.
5. If the continuity checks do not agree with the table below, replace the steering lock (ignition) switch (see «STEERING LOCK REPLACEMENT»(ref-290814-S40234601132008072200000) ).
6. After reconnecting the battery, enter the anti-theft codes for the audio system, then set the clock.

SRS components are located in this area. Review the SRS COMPONENT LOCATION INDEX and PRECAUTIONS AND PROCEDURES , before performing repairs or service.

Scheme 4

1. Do the battery terminal disconnection procedure (see «DISCONNECTION»(ref-290830-S11729868702009102900000) .
2. Remove the steering column upper and lower covers (see «REMOVAL»(ref-290814-S40186238222008072200000) ).
3. Disconnect the 7P connector (A) from the ignition switch (B).
4. Remove the two screws and the ignition switch.
5. Install the ignition switch in the reverse order of removal.
6. Do the battery terminal reconnection procedure (see «RECONNECTION»(ref-290830-S41579678952009102900000) .
