Audio: Other Honda Element YH2 рестайлинг 2

Disconnecting

To disconnect the connector, pull the lever (A) while pushing the lock tab (B) down, then pull the connector (C).

Scheme 18

Connecting

To connect the connector, push the connector into the connector sleeve (A). As the connector is pressed in, the lever (B) moves to the locked position.

Scheme 19

GA-Net Bus Configuration

The GA-Net bus passes audio commands throughout the audio components. These commands include hard button signals, audio/XM selections, and XM station and music title names. Because the entire bus is "daisy chained" between components (see diagram below), any open or short in the GA-Net bus harness will cause any or all of these functions to become inoperative. The addition of any audio accessory must maintain the continuity of the GA-Net bus by installing the "Y" cable included with the accessory kit.

Scheme 20

USB Adapter

'09-11 audio system with navigation can play digital music from portable audio players, a USB device, etc. when the device is plugged into the USB port. The audio-navigation unit uses the GA-NET to allow you to control the device from the audio-navigation unit when searching and playing the files. Not all players and player functions work with the USB adapter. Please see the Owner's Manual for more information.

USB Function

Music files can be stored on portable USB devices (flash drives and approved iPod products) and played through the audio-navigation unit by using the USB adapter. Although a customer can create many different folder levels on their USB device, the audio unit only recognizes two levels and automatically sorts the music to meet this requirement.

To play the music files, use the dial selector to find the folder where the music file is located, then select the album or music file (see the Owner's Manual for more information about selecting and playing USB files and approved iPod products).

USB Device Requirements

1. 2.0 High speed USB capable (maximum speed is 480 Mbps)
2. At least 256MB storage capacity
3. USB formatted to be compatible with Windows-based operating systems
4. If the USB has a security feature, like write protection, it must be turned off

There are many different USB drives, manufacturers, and configurations with new devices being released every day, which makes it impossible to test all USB devices with the audio system. Even if the USB device has all these requirements, it may not be compatible.

To check if a USB device is compatible with the vehicle, test the USB device in a known-good vehicle of the same model and year. If the USB device does not work on the known-good vehicle, assume that it is faulty or not compatible. A USB device may work on a later year of the same model vehicle because the audio-navigation unit software is constantly updated.

The audio-navigation unit displays the folder differently than what you may see on your PC because the audio-navigation unit only recognizes two folder levels. The audio-navigation unit overwrites the data for the track order when you connect the USB device. The audio-navigation unit does not modify the music files or the structure on the USB device.

Hard drives do not support overwriting the data for the track order, which is why they are not recommended.

Reconnecting the USB Device

When you disconnect a USB device, the data for the track order remains in the audio-navigation unit's memory so when you reconnect the same USB device, the audio-navigation unit continues playing from the location where it was disconnected. If a new USB device is connected, the data for the track order is rewritten and you need to select the album or music file.

USB DEVICE TABLE

USB Music Search

When you plug in a USB device, the audio-navigation unit automatically searches the USB device for playable music files. See the Owner's Manual for more information about navigating USB menus and selecting music.

When you plug in a USB device, the audio-navigation unit automatically searches the USB device for playable music files. See the Owner's Manual for more information about navigating USB menus, selecting music, and music file compatibility.

The audio-navigation unit organizes the playable music folders and files that appear on the USB device. If there are any music files that are not located in a folder, the audio-navigation unit automatically creates a folder titled ROOT, and lists all these playable music files in it. If your customer complains that they can not find some songs loaded on their USB device, recommend that they check the ROOT folder for the missing music files. If all the music files on the USB are in folders, the ROOT folder does not appear.

When there are music files not located in a folder, the audio-navigation unit automatically creates a folder named ROOT (A).

Scheme 21

Select the Track List button to see the ROOT folder (A) which is automatically created only when there are music files not located in folders.

Scheme 22

All the music files not located in folders are listed under the ROOT folder.

Scheme 23

Muting Logic

The navigation system allows voice control of the audio, the XM, the PC card, and the CD player. Voice control commands are communicated on the GA-Net (audio-navigation unit). When using the navigation TALK/BACK button, the audio is muted on all speakers and you get navigation sound on the front channels. When using the navigation or route guidance (RG), the front speakers give the navigation sound and the rear speakers continue to play. For more information, see the navigation section. The outline of the interruption function is shown in this table below.

AUDIO OUTPUT CONTENT TABLE

Scheme 24

Scheme 25

Note. All items may not apply to this vehicle. See the Owner's Manual for more information.

AUDIO GLOSSARY TABLE

Scheme 26

AUDIO-NAVIGATION UNIT CONNECTOR A (24P)

Scheme 27

AUDIO-NAVIGATION UNIT CONNECTOR CONNECTOR A TABLE

AUDIO-NAVIGATION UNIT CONNECTOR B (24P)

Scheme 28

AUDIO-NAVIGATION UNIT CONNECTOR B (24P) TABLE

AUDIO-NAVIGATION UNIT CONNECTOR D (14P)

Scheme 29

AUDIO-NAVIGATION UNIT CONNECTOR D (14P) TABLE

AUDIO-NAVIGATION UNIT CONNECTOR E (3P)

Scheme 30

AUDIO-NAVIGATION UNIT CONNECTOR E (3P) TABLE

Scheme 31

AUDIO UNIT CONNECTOR A (20P)

Scheme 32

AUDIO UNIT CONNECTOR A (20P) TABLE

AUDIO UNIT CONNECTOR B (8P)

Scheme 33

AUDIO UNIT CONNECTOR B (8P) TABLE

AUDIO UNIT CONNECTOR C (6P)

Scheme 34

AUDIO UNIT CONNECTOR C (6P) TABLE

AUDIO UNIT CONNECTOR D (14P)

Scheme 35

AUDIO UNIT CONNECTOR D (14P) TABLE

AUDIO UNIT CONNECTOR E (3P)

Scheme 36

AUDIO UNIT CONNECTOR E (3P) TABLE

Scheme 37

AUDIO UNIT CONNECTOR A (20P)

Scheme 38

AUDIO UNIT CONNECTOR A (20P) TABLE

AUDIO UNIT CONNECTOR E (3P)

AUDIO UNIT CONNECTOR E (3P) TABLE

Scheme 39

AUDIO AMPLIFIER CONNECTOR A (14P)

Scheme 40

CONNECTOR REFERENCE TABLE

AUDIO AMPLIFIER CONNECTOR B (16P) (WITH NAVIGATION)

Scheme 41

CONNECTOR REFERENCE TABLE

AUDIO AMPLIFIER CONNECTOR B (16P) (WITHOUT NAVIGATION)

Scheme 42

CONNECTOR REFERENCE TABLE

Scheme 43

XM RECEIVER CONNECTOR A (14P) (WITH NAVIGATION)

Scheme 44

CONNECTOR REFERENCE TABLE

XM RECEIVER CONNECTOR A (14P) (WITHOUT NAVIGATION)

Scheme 45

CONNECTOR REFERENCE TABLE

XM RECEIVER CONNECTOR B (2P)

Scheme 46

CONNECTOR REFERENCE TABLE

Scheme 47

USB ADAPTER CONTROL UNIT CONNECTOR A (14P)

Scheme 48

USB ADAPTER CONTROL UNIT CONNECTOR A (14P) TABLE

USB ADAPTER CONTROL UNIT CONNECTOR B (5P)

Scheme 49

USB ADAPTER CONTROL UNIT CONNECTOR B (5P) TABLE

Scheme 50

AUXILIARY JACK ASSEMBLY 5P CONNECTOR

Scheme 51

CONNECTOR REFERENCE TABLE

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Self-Diagnostic Function

The audio system has a self-diagnostic function.

Scheme 58

Scheme 59

Scheme 60

1. Turn the ignition switch to ON (II).
2. Make sure the audio system is turned off.
3. Push and hold the preset No. 1 and No. 6 buttons.
4. While holding the buttons, push the PWR knob to ON.
5. Release the buttons and the self-diagnosis begins.
6. When you are in the self-diagnostic mode, pressing a preset button starts the diagnostic mode that is assigned to that preset button. Display Specifications NOTE: Any other diagnostic screens shown are for the audio manufactures use only. Entire LCD lighting (press No. 2 button)/lights-outs mode (press No. 3 button) Entire LCD lighting (press No. 2 button)/light-out (press No. 3 button) mode: Turns on/off the entire LCD to show if a LCD segment is stuck on or dead (off). If a LCD segment is stuck on, or is dead, replace the audio unit. I2C-BUS communication verification status (No. 4 button) NOTE: If any of the buses are faulty (NG), replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ).
7. The self-diagnostic function ends when you turn the audio unit OFF, or turn the ignition switch OFF.

Note. This procedure can only be done when the power has been disconnected from the audio unit, and the audio unit displays CODE when the radio is turned on.

With the audio unit turned off, push and hold the preset buttons No. 1, No. 6 and the PWR knob.

The audio unit displays the eight digits of the serial number (example 12345678). Use all eight digits as the serial number when using the interactive network (iN) to get the 5 digit anti-theft code.

Error Codes

The audio system displays error codes when a problem is detected with the audio unit, the audio disc, or the anti-theft code.

CD Error Codes

CD ERROR CODES TABLE

XM Error Codes

XM ERROR CODES TABLE

AUDIO UNIT ERROR CODES TABLE

USB Error Codes (With Navigation)

USB ERROR CODES TABLE

Poor AM or FM Radio Reception Or Interference (With Navigation)

Note. Check the vehicle battery condition first. Check the radio reception in an open area. Poor reception/interference can be caused by the following: The radio station is far away. A tall building, a mountain, or a high-voltage power line is nearby. Aftermarket window tint. Check for aftermarket accessories including cell phones and chargers plugged into the vehicle accessory power sockets.

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

1. Turn the ignition switch to ON (II).
2. Do «SEEK STOP TEST»(ref-290858-S37850896242008072200000) . Is the test vehicle within 10 % of the known-good vehicle? YES - Multipath interference or weak station. Operation is normal. NO - Go to step 3 .
3. Check if the radio reception/interference is the same in several locations. Is the reception/interference the same? YES - Go to step 4 . NO - Multipath interference or weak station. Operation is normal.
4. Check the reception/interference while the engine is running. Is there noise with the engine running? YES - Check the antenna and radio grounds. If OK, check the charging system and the ignition system. NO - Go to step 5 .
5. Turn the ignition switch to LOCK (0).
6. Check the AM/FM/XM antenna mast for cracks, or other damage. Make sure that the AM/FM/XM antenna mast isn't loose. NOTE: Do not use any tools to tighten the AM/FM/XM antenna mast. Is there any damage? YES - Replace the AM/FM/XM antenna mast (see «AM/FM/XM ANTENNA REPLACEMENT»(ref-290858-S42714499972008072200000) ). NO - Go to step 7 .
7. Disconnect the AM/FM/XM antenna 3P connector from the AM/FM/XM antenna.
8. Turn the ignition switch to ON (II).
9. Turn on the audio-navigation unit.
10. Measure the voltage between AM/FM/XM antenna 3P connector No. 3 terminal and body ground. Is there battery voltage? YES - Go to step 15 . NO - Go to step 11 .
11. Turn the ignition switch to LOCK (0).
12. Disconnect audio-navigation unit connector E (3P).
13. Check for continuity between audio-navigation unit connector E (3P) terminal No. 3 and the AM/FM/XM antenna 3P connector terminal No. 3. Is there continuity? YES - Go to step 14 . NO - Repair open in the wire between the audio unit and the AM/FM/XM antenna. Also check the AM/FM antenna lead/sub lead connector.
14. Check for continuity between the audio-navigation unit connector E (3P) terminal No. 3 and body ground. Is there continuity? YES - Repair short to body ground in the wire between the audio-navigation unit and AM/FM/XM antenna. NO - Replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ).
15. Turn the ignition switch to LOCK (0).
16. Disconnect audio-navigation unit connector E (3P).
17. Check for continuity between audio-navigation unit connector E (3P) terminal No. 1 and AM/FM/XM antenna 3P connector terminal No. 1 Is there continuity? YES - Go to step 18 . NO - Replace the AM/FM antenna lead and/or sublead.
18. Check for continuity between audio-navigation unit connector E (3P) terminal No. 1 and body ground. Is there continuity? YES - Replace the AM/FM antenna lead and/or sublead. NO - Go to step 19 .
19. Check for continuity between audio-navigation unit connector E (3P) terminal No. 2 and AM/FM/XM antenna 3P connector terminal No. 2. Is there continuity? YES - Go to step 20 . NO - Replace the AM/FM antenna lead and/or sublead.
20. Check for continuity between audio-navigation unit connector E (3P) terminals No. 1 and No. 2. Is there continuity? YES - Replace the AM/FM antenna lead and/or sublead. NO - Go to step 21 .
21. Substitute a known-good AM/FM antenna lead and/or sublead, and check the radio reception. Is the reception normal? YES - Replace the AM/FM antenna lead and/or sublead. NO - Substitute a known-good AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(ref-290858-S42714499972008072200000) ) and recheck. If the reception is still poor, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ).

Poor AM Or FM Radio Reception Or Interference (Without Navigation With XM)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the radio reception in an open area. Poor reception/interference can be caused by the following: The radio station is far away. A tall building, a mountain, or a high-voltage power line is nearby. Aftermarket window tint. Check for aftermarket accessories including cell phones and chargers plugged into the vehicle accessory power sockets.

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

1. Turn the ignition switch to ON (II).
2. Do «SEEK STOP TEST»(ref-290858-S37850896242008072200000) . Is the test vehicle within 10% of the known-good vehicle? YES - Multipath interference or weak station. Operation is normal. NO - Go to step 3 .
3. Check if the radio reception/interference is the same in several locations. Is the reception/interference the same? YES - Go to step 4 . NO - Multipath interference or weak station. Operation is normal.
4. Check the reception/interference while the engine is running. Is there noise with the engine running? YES - Check the antenna and radio grounds. If OK, check the charging system and the ignition system. NO - Go to step 5 .
5. Turn the ignition switch to LOCK (0).
6. Check the AM/FM/XM antenna mast for cracks, or other damage. Make sure that the AM/FM/XM antenna mast isn't loose. NOTE: Do not use any tools to tighten the AM/FM/XM antenna mast. Is there any damage? YES - Replace the AM/FM/XM antenna mast (see «AM/FM/XM ANTENNA REPLACEMENT»(ref-290858-S42714499972008072200000) ). NO - Go to step 7 .
7. Disconnect the AM/FM antenna 1P connector from the AM/FM antenna.
8. Turn the ignition switch to ON (II).
9. Turn on the audio unit.
10. Measure the voltage between AM/FM/XM antenna 3P connector terminal No. 3 and body ground. Is there battery voltage? YES - Go to step 15 . NO - Go to step 11 .
11. Turn the ignition switch to LOCK (0).
12. Disconnect audio unit connector E (3P).
13. Check for continuity between audio unit connector E (3P) terminal No. 3 and AM/FM/XM antenna 3P connector terminal No. 3. Is there continuity? YES - Go to step 14 . NO - Repair an open in the wire between the audio unit and the AM/FM/XM antenna. Also check the AM/FM antenna lead/sublead connector.
14. Check for continuity between audio unit connector E (3P) terminal No. 3 and body ground. Is there continuity? YES - Repair short to body ground in the wire between the audio unit and AM/FM antenna. NO - Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ).
15. Turn the ignition switch to LOCK (0).
16. Disconnect audio unit connector E (3P).
17. Check for continuity between audio unit connector E (3P) terminal No. 1 and AM/FM/XM antenna 3P connector terminal No. 1. Is there continuity? YES - Go to step 18 . NO - Replace the AM/FM antenna lead and/or sublead.
18. Check for continuity between audio unit connector E (3P) terminal No. 1 and body ground. Is there continuity? YES - Replace the AM/FM antenna lead and/or sublead. NO - Go to step 19 .
19. Check for continuity between audio unit connector E (3P) terminal No. 2 and AM/FM/XM antenna 3P connector terminal No. 2. Is there continuity? YES - Go to step 20 . NO - Replace the AM/FM antenna lead and/or sublead.
20. Check for continuity between audio unit connector E (3P) terminals No. 1 and No. 2. Is there continuity? YES - Replace the AM/FM antenna lead and/or sublead. NO - Go to step 21 .
21. Substitute a known-good AM/FM antenna lead and/or sublead, and check the radio operation. Is the reception normal? YES - Replace the AM/FM antenna lead and/or sublead. NO - Substitute a known-good AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(ref-290858-S42714499972008072200000) ) and recheck. If the reception is still poor, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ).

Poor AM Or FM Radio Reception Or Interference (Without XM)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the radio reception in an open area. Poor reception/interference can be caused by the following: The radio station is far away. A tall building, a mountain, or a high-voltage power line is nearby. Aftermarket window tint. Check for aftermarket accessories including cell phones and chargers plugged into the vehicle accessory power sockets.

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

1. Turn the ignition switch to ON (II).
2. Do «SEEK STOP TEST»(ref-290858-S37850896242008072200000) . Is the test vehicle within 10% of the known-good vehicle? YES - Multipath interference or weak station. Operation is normal. NO - Go to step 3 .
3. Check if the radio reception/interference is the same in several locations. Is the reception/interference the same? YES - Go to step 4 . NO - Multipath interference or weak station. Operation is normal.
4. Check the reception/interference while the engine is running. Is there noise with the engine running? YES - Check the antenna and radio grounds. If OK, check the charging system and the ignition system. NO - Go to step 5 .
5. Turn the ignition switch to LOCK (0).
6. Check the AM/FM/XM antenna mast for cracks, or other damage. Make sure that the AM/FM/XM antenna mast isn't loose. NOTE: Do not use any tools to tighten the AM/FM/XM antenna mast. Is there any damage? YES - Replace the AM/FM/XM antenna mast (see «AM/FM/XM ANTENNA REPLACEMENT»(ref-290858-S42714499972008072200000) ). NO - Go to step 7 .
7. Disconnect the AM/FM antenna 1P connector from the AM/FM antenna.
8. Turn the ignition switch to ON (II).
9. Turn on the audio unit.
10. Measure the voltage between AM/FM/XM antenna 1P connector terminal and body ground. Is there battery voltage? YES - Go to step 15 . NO - Go to step 11 .
11. Turn the ignition switch to LOCK (0).
12. Disconnect audio unit connector A (20P). NOTE: Eject all the CDs before removing the audio unit to prevent damaging the CD player's load mechanism.
13. Check for continuity between audio unit connector A (20P) terminal No. 1 and AM/FM antenna 1P connector terminal. Is there continuity? YES - Go to step 14 . NO - Repair open in the wire between the audio unit and the AM/FM antenna. Also check the AM/FM antenna lead/sublead connector.
14. Check for continuity between audio unit connector A (20P) terminal No. 1 and body ground. Is there continuity? YES - Repair short to body ground in the wire between the audio unit and AM/FM antenna. NO - Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ).
15. Turn the ignition switch to LOCK (0).
16. Remove the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ), and disconnect AM/FM antenna sublead from the radio unit..
17. Check for continuity between the AM/FM antenna sublead center pin at the audio unit side and the AM/FM antenna lead center pin at the AM/FM antenna side. Is there continuity? YES - Go to step 18 . NO - Replace the AM/FM antenna lead and/or sublead.
18. Check for continuity between the AM/FM antenna sublead shield surface of the audio unit side and the AM/FM antenna lead shield surface of the AM/FM antenna side. Is there continuity? YES - Go to step 19 . NO - Replace the AM/FM antenna lead and/or sublead.
19. Check for continuity between the AM/FM antenna sublead center pin at the audio unit side and the body ground. Is there continuity? YES - Replace the AM/FM antenna lead and/or sublead. NO - Go to step 20 .
20. Check for continuity between the AM/FM antenna sublead center pin and the shield surface of the audio unit side. Is there continuity? YES - Replace the AM/FM antenna lead and/or sublead. NO - Go to step 21 .
21. Substitute a known-good AM/FM antenna lead and/or sublead, and check the radio operation. Is the reception normal? YES - Replace the AM/FM antenna lead and/or sublead. NO - Substitute a known-good AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(ref-290858-S42714499972008072200000) ) and recheck. If the reception is still poor, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 80

Scheme 81

1. Turn the ignition switch to ON (II).
2. Push the power switch ON to see if the audio-navigation unit turns ON. Does the audio-navigation unit display operate properly, and does the audio sound normal? YES - Intermittent failure, the system is OK at this time. NO - Go to step 3 .
3. Turn the ignition switch to LOCK (0).
4. Check the No. 9 (10 A) fuse in the under-hood fuse/relay box and the No. 8 (7.5 A) fuse in the under-dash fuse/relay box. Are the fuses OK? YES - Go to step 5 . NO - Replace the fuse(s), and recheck.
5. Remove the audio-navigation unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ). Check that the audio-navigation unit is properly connected. Is it connected properly? YES - Go to step 6 . NO - Reconnect the connector, and recheck the function.
6. Disconnect audio-navigation unit connector A (24P).
7. Turn the ignition switch to ON (II).
8. Measure the voltage between body ground and audio-navigation unit connector A (24P) terminals No. 14 and No. 24. Is there battery voltage on the both terminals? YES - Go to step 9 . NO - Repair an open in the wire(s) between the No. 9 (10 A) fuse in the under-hood fuse/relay box and No. 8 (7.5 A) in the under-dash fuse/relay box and the audio-navigation unit.
9. Turn the ignition switch to LOCK (0).
10. Reconnect audio-navigation unit connector A (24P).
11. Turn the ignition switch to ON (II).
12. Measure the voltage between audio-navigation unit connector A (24P) terminal No. 12 and body ground. Is there less than 0.1 V on both terminals? YES - Replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ). NO - Repair open in the wire between audio unit connector A (20P) No. 20 terminal and body ground (G503).

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 82

Scheme 83

1. Turn the ignition switch to ON (II).
2. Push the power switch ON to see if the audio unit turns ON. Does the audio unit operate properly, and does the audio sound normal? YES - Intermittent failure, the system is OK at this time. NO - Go to step 3 .
3. Turn the ignition switch to LOCK (0).
4. Check the No. 9 (10 A) fuse in the under-hood fuse/relay box and the No. 8 (7.5 A) fuse in the under-dash fuse/relay box. Are the fuses OK? YES - Go to step 5 . NO - Replace the fuse(s), and recheck.
5. Remove the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ). Check that the audio-navigation unit is properly connected. Is it connected properly? YES - Go to step 6 . NO - Reconnect the connector, and recheck the function.
6. Disconnect audio unit connector A (20P). NOTE: Eject all the discs before removing the audio unit to prevent damaging the CD player's load mechanism.
7. Turn the ignition switch to ON (II).
8. Measure the voltage between body ground and audio unit connector A (20P) terminals No. 2 and No. 10 individually. Is there battery voltage on both terminals? YES - Go to step 9 . NO - Repair an open in the wire(s) between the No. 9 (10 A) fuse in the under-hood fuse/relay box and the No. 8 (7.5 A) fuse in the under-dash fuse/relay box and the audio unit.
9. Turn the ignition switch to LOCK (0).
10. Reconnect audio unit connector A (20P).
11. Turn the ignition switch to ON (II).
12. Measure the voltage between audio unit connector A (20P) terminal No. 20 and body ground. Is there less than 0.1 V? YES - Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ). NO - Repair open in the wire between audio unit connector A (20P) terminal No. 20 and body ground (G503).

Note. Check for aftermarket accessories plugged into the vehicle's accessory power sockets. Check the connectors for poor connections or loose terminals.

Scheme 84

1. Turn the ignition switch to ON (II).
2. Push the power switch OFF or turn the ignition switch to LOCK (0) to see if the audio-navigation unit turns OFF. Is the audio-navigation unit OFF? YES - Operation is normal. NO - Go to step 3 .
3. Turn the ignition switch to LOCK (0).
4. Disconnect audio-navigation unit connector A (24P). NOTE: Eject all the discs before removing the audio-navigation unit to prevent damaging the CD player's load mechanism.
5. Measure the voltage between audio-navigation unit connector A (24P) terminal No. 14 and body ground. Is there battery voltage? YES - Check for short to power on YEL/RED wire. NO - Replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ).

Note. Check for aftermarket accessories plugged into the vehicle's accessory power sockets. Check the connectors for poor connections or loose terminals.

Scheme 85

1. Turn the ignition switch to ON (II).
2. Push the power switch OFF or turn the ignition switch to LOCK (0) to see if the audio unit turns OFF. Is the audio unit OFF? YES - Operation is normal. NO - Go to step 3 .
3. Turn the ignition switch to LOCK (0).
4. Disconnect audio unit connector A (20P). NOTE: Eject all the discs before removing the audio unit to prevent damaging the CD player's load mechanism.
5. Measure the voltage between audio unit connector A (20P) terminal No. 2 and body ground. Is there voltage? YES - Check for short to power on YEL/RED wire. NO - Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ).

No Sound Is Heard From Speaker(s) (Display Is Normal) (With Navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Set the fader and balance positions to the center. Before performing symptom troubleshooting, do the power switch will not turn on troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH NAVIGATION) ).

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

1. Turn the ignition switch to ON (II).
2. Check for sound in each mode (AM, FM, XM, and CD). Is the sound OK in each mode? YES - Intermittent failure. The system is OK at this time. Check for loose connections at the audio-navigation unit and speaker(s). NO - Go to step 3 .
3. Check that the volume button is not set to the min level. Is it at the MIN level? YES - Raise the volume level, and recheck the function. NO - Go to step 4 .
4. On the steering wheel, check the navigation talk command. Is the navigation talk command function set? YES - Cancel the navigation talk command by pressing the navigation BACK button, then recheck the function. NO - Go to step 5 .
5. Turn the ignition switch to LOCK (0).
6. Check the speaker(s) with no sound for any damage. Is there any damage? YES - Substitute the speaker and recheck. NO - Go to step 7 .
7. Remove the speaker(s) with no sound (see «SPEAKER REPLACEMENT»(ref-290858-S00968531992008072200000) ), and disconnect its connector.
8. Check the speaker 2P connector and the subwoofer 4P connector for a loose or poor connection. Reconnect the connector and recheck the symptom; does it still fail? YES - Go to step 9 . NO - Operation is normal.
9. Make sure the ignition switch is turned to LOCK (0).
10. Disconnect stereo amplifier connector A (14P), and connector B (16P).
11. Measure the voltage between stereo amplifier connector A (14P) terminal No. 11 and body ground. Is there battery voltage? YES - Go to step 12 . NO - Repair short in the wires between the audio unit and speaker.
12. Turn the ignition switch to ON (II), and push the PWR button on the audio-navigation unit.
13. Measure the voltage between stereo amplifier connector B (16P) terminal No. 8 and body ground. Is there battery voltage? YES - Go to step 14 . NO - Repair an open in the wire between audio-navigation unit connector A (24P) terminal No. 17 and stereo amplifier connector B (16P) terminal No. 8.
14. Turn the ignition switch to LOCK (0).
15. Reconnect stereo amplifier connector A (14P), and connector B (16P)
16. Turn the ignition switch to ON (II).
17. Measure the voltage between stereo amplifier connector A (14P) terminal No. 10 and body ground. Is there less than 0.1 V on both terminals? YES - Go to step 18 . NO - Repair an open or high resistance in the wire between stereo amplifier connector B (16P) terminal No. 10 and body ground (G503).
18. Turn the ignition switch to LOCK (0).
19. Disconnect stereo amplifier connector A (14P).
20. Check for continuity between the stereo amplifier connector A (14P) and body ground according to the table below. STEREO AMPLIFIER CONNECTOR TERMINALS TABLE Stereo Amplifier Connector Wire Color A6 GRN/BLK A13 GRN A7 GRN/YEL A14 BLU/YEL A4 BLU/WHT A3 BLU/BLK A5 PNK A12 BLU/YEL A1 BLU A8 GRY/BLK A2 BRN A9 RED Is there continuity? YES - Repair short to body ground in the wire(s) between the stereo amplifier and the speaker. NO - Go to step 21 .
21. Disconnect the connector(s) to the speaker(s).
22. Connect the speaker connector terminal (+) and (-) with a jumper wire.
23. Check for continuity between both pairs of speaker wires (+) and (-) at the stereo amplifier connector A (14P). TERMINALS REFERENCE TABLE Speaker Terminal Wire color Driver's door speaker, left tweeter A6 (+) GRN/BLK A13 (-) GRN Front passenger's door speaker, right tweeter A7 (+) GRN/YEL A14 (-) BLU/YEL Left rear door speaker A4 (+) BLU/WHT A3 (-) BLU/BLK Right rear door speaker A5 (+) PNK A12 (-) BLU/YEL Subwoofer A1 (+) BLU A8 (-) GRY/BLK Subwoofer A2 (+) BRN A9 (-) RED Is there continuity? YES - Repair short to body ground in the wire between the audio unit and the speaker. NO - Go to step 24 .
24. Disconnect the jumper wire.
25. Disconnect audio-navigation unit connector A (24P).
26. Check for continuity between the audio-navigation unit connector A (24P) and body ground according to the table below. CONNECTOR REFERENCE TABLE Audio-Navigation Unit Connector Wire color A6 BLK A7 BLU A10 GRN A11 RED A18 BRN A19 YEL A22 ORN A23 WHT Is there continuity? YES - There is a short to body ground in the wire(s) between the stereo amplifier and the audio-navigation unit. Replace the affected shielded harness. NO - Go to step 27 .
27. Check for continuity between the audio-navigation unit connector A (24P) according to the table below. TERMINALS REFERENCE From terminal To terminals A6 A7, A10, A11, A18, A19, A21, A22, A23 A7 A10, A11, A18, A19, A21, A22, A23 A10 A11, A18, A19, A21, A21, A22, A23 A11 A18, A19, A21, A22, A23 A18 A19, A21, A22, A23 A19 A21, A22, A23 A21 A22, A23 A22 A23 Is there continuity? YES - Go to step 28 . NO - Open in the wire(s) between the stereo amplifier and the audio unit. Replace the affected shielded harness.
28. Check for continuity between audio-navigation unit connector A (24P) and stereo amplifier connector B (16P) according to the table below. CONNECTOR REFERENCE TABLE Audio-Navigation Unit Connector Stereo Amplifier Connector Wire Color A6 B13 BLK A7 B5 BLU A10 B12 GRN A11 B4 RED A18 B15 BRN A19 B7 YEL A22 B14 ORN A23 B6 WHT Is there continuity? YES - Go to step 29 . NO - There is an open in the wire(s) between the stereo amplifier and the audio-navigation unit. Replace the affected shielded harness.
29. Substitute a known-good speaker(s) (see «SPEAKER REPLACEMENT»(ref-290858-S00968531992008072200000) ). Is the symptom goes away? YES - Replace the original speaker(s). NO - Substitute a known-good stereo amplifier (see «STEREO AMPLIFIER REPLACEMENT»(ref-290858-S37903854202008072200000) ), and recheck. If the symptom/indication goes away, replace the original stereo amplifier. If the symptom is still present, substitute a known-good audio-navigation unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit

No Sound Is Heard From Speaker(s) (Display Is Normal) (Without Navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Set the fader and balance positions to the center. Before performing symptom troubleshooting, do the power switch will not turn on troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITHOUT NAVIGATION) ).

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

Scheme 103

1. Turn the ignition switch to ON (II).
2. Check for sound in each mode (AM, FM, XM, and CD). Is the sound OK in each mode? YES - Intermittent failure. The system is OK at this time. Check for loose connections at the audio-navigation unit and speaker(s). NO - Go to step 3 .
3. Check that the volume button is not set to the min level. Is it at the MIN level? YES - Raise the volume level, and recheck the function. NO - Go to step 4 .
4. Turn the ignition switch to LOCK (0).
5. Check the speakers(s) with no sound for any damage. Is there any damage? YES - Substitute the speaker, and recheck. NO - Go to step 6 .
6. Remove the speaker(s) with no sound (see «SPEAKER REPLACEMENT»(ref-290858-S00968531992008072200000) ), and disconnect its connector.
7. Check the speaker 2P connector and the subwoofer 4P connector for a loose or poor connection. Reconnect the connector, and recheck the symptom; does it still fail? YES - Go to step 8 . NO - Operation is normal.
8. Make sure the ignition switch is in LOCK (0).
9. Remove the audio unit, and disconnect audio unit connector A (20P). NOTE: Eject all the CDs before removing the audio unit to prevent damaging the CD player's load mechanism.
10. Check for continuity between the audio unit connector A (20P) and body ground according to the table below. CONNECTOR REFERENCE TABLE Audio Unit Connector Wire color A5 PNK A6 BLU/WHT A7 GRN/YEL A8 GRN/BLK A15 BLU/YEL A16 BLU/BLK A17 BLU/YEL A18 GRN Is there continuity? YES - Repair short to body ground in the wire(s) between the audio unit and the speaker. NO - Go to step 11 .
11. Disconnect the connection(s) to the speaker(s).
12. Connect the speaker connector terminal (+) and (-) with a jumper wire.
13. Check for continuity between both pairs of speaker wires (+) and (-) at the audio unit connector A (20P). Is there continuity? YES - Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ), and recheck. If the symptom/indication goes away, replace the original audio unit. NO - Repair open in the wire(s) betwenn the audio unit and the speaker.
14. Disconnect stereo amplifier connector A (14P).
15. Measuring the voltage between stereo amplifier connector A (14P) No. 11 terminal and body ground Is there battery voltage? YES - Go to step 16 NO - Repair open in the wire between No. 7 (20A) fuse in the under-dash fuse box and stereo amplifier connector A (14P) No. 11 terminal.
16. Turn the ignition switch to LOCK (0).
17. Disconnect stereo amplifier connector B (16P).
18. Turn the ignition switch to ON (II), and push the PWR button on the audio unit.
19. Measure the voltage between stereo amplifier connector B (16P) terminal No. 1 and body ground. Is there battery voltage? YES - Go to step 20 . NO - Repair open in the wire between audio unit connector A (20P) terminal No. 1 and stereo amplifier connector B (16P) terminal No. 1.
20. Turn the ignition switch to LOCK (0).
21. Reconnect stereo amplifier connector A (14P), and connector B (16P).
22. Turn the ignition switch to ON (II).
23. Measure the voltage between stereo amplifier connector A (14P) terminal No. 10 and body ground. Is there less than 0.1 V on both terminals? YES - Go to step 24 . NO - Repair open in the wire between stereo amplifer connector B (16P) terminal No. 10 and body ground (G503).
24. Turn the ignition switch to LOCK (0).
25. Disconnect stereo amplifer connector A (14P).
26. Check for continuity between the stereo amplifier connector A (14P) and body ground according to the table below. CONNECTOR REFERENCE TABLE Stereo Amplifier Connector Wire Color A6 GRN/BLK A13 GRN A7 GRN/YEL A14 BLU/YEL A4 BLU/WHT A3 BLU/BLK A5 PNK A12 BLU/YEL A1 BLU A8 GRY/BLK A2 BRN A9 RED Is there continuity? YES - Repair a short to body ground in the wire(s) between the stereo amplifier and the speaker. NO - Go to step 27 .
27. Disconnect the connector(s) from the speaker(s).
28. Connect the speaker connector terminal (+) and (-) with a jumper wire.
29. Check for continuity between both pairs of speaker wires (+) and (-) at the stereo amplifier connector A (14P). SPEAKER TERMINAL REFERENCE TABLE Speaker Terminal Wire Color Driver's door speaker A6 GRN/BLK A13 GRN Left tweeter A6 GRN/BLK A13 GRN Front passenger's door speaker A7 GRN/YEL A14 BLU/YEL Right tweeter A7 GRN/YEL A14 BLU/YEL Left rear door speaker A4 BLU/WHT A3 BLU/BLK Right rear door speaker A5 PNK A12 BLU/YEL Subwoofer A1 BLU A8 GRY/BLK Subwoofer A2 BRN A9 RED Is there continuity? YES - Go to step 30 . NO - Repair open in the wire between the stereo amplifier and the speaker.
30. Disconnect the jumper wire.
31. Disconnect audio-navigation unit connector A (20P). NOTE: Eject all the CDs before removing the audio unit to prevent damaging the CD player's load mechanism.
32. Check for continuity between audio unit connector A (20P) and body ground according to the table below. AUDIO UNIT CONNECTOR REFERENCE TABLE Audio Unit Connector Wire Color A6 RED A5 BLU A8 WHT A7 YEL A16 GRN A15 BLK A18 ORN A17 BRN Is there continuity? YES - There is a short to body ground in the wire(s) between the stereo amplifier and the audio unit. Replace the affected shielded harness. NO - Go to step 33 .
33. Check for continuity between the audio unit connector A (20P) according to the table below. TERMINAL REFERENCE TABLE From Terminal To Terminals A5 A6, A7, A8, A11, A15, A16, A17, A18 A6 A7, A8, A11, A15, A16, A17, A18 A7 A8, A11, A15, A16, A17, A18 A8 A11, A15, A16, A17, A18 A11 A15, A16, A17, A18 A15 A16, A17, A18 A16 A17, A18 A17 A18 Is there continuity between any of the terminals? YES - There is a short in the wire(s) between the stereo amplifier and the audio unit. Replace the affected shielded harness. NO - Go to step 34 .
34. Check for continuity between audio unit connector A (20P) and stereo amplifier connector B (16P) according to the table below. TERMINAL REFERENCE TABLE Audio Unit Connector Stereo Amplifier Connector Wire Color A5 B5 BLU A6 B4 RED A7 B7 YEL A8 B6 WHT A15 B13 BLK A16 B12 GRN A17 B15 BRN A18 B14 ORN Is there continuity? YES - Go to step 35 . NO - There is an open in the wire(s) between the stereo amplifier and the audio unit. Replace the affected shielded harness.
35. Disconnect audio unit connector B (8P).
36. Check for continuity between audio unit connector B (8P) and body ground according to the table below. AUDIO UNIT CONNECTOR REFERENCE TABLE Audio Unit Connector Wire Color B4 RED/BLU B8 RED/WHT Is there continuity? YES - There is a short to body ground in the wire(s) between the stereo amplifier and the audio unit. Replace the affected shielded harness. NO - Go to step 37 .
37. Check for continuity between audio unit connector B (8P) and body ground according to the table below. TERMINAL REFERENCE TABLE From Terminal To Terminals B4 B7, B8 B7 B8 Is there continuity between any of the terminals? YES - There is a short in the wire(s) between the stereo amplifier and the audio unit. Replace the affected shielded harness. NO - Go to step 38 .
38. Check for continuity between audio unit connector B (8P) and stereo amplifier connector B (16P) according to the table below. TERMINAL REFERENCE TABLE Audio Unit Connector Stereo Amplifier Connector Wire Color B4 B2 RED/BLU B8 B10 RED/WHT Is there continuity? YES - Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ), and recheck. If the symptom/indication goes away, replace the original audio unit. If symptom is still present, substitute a known-good stereo amplifier (see «STEREO AMPLIFIER REPLACEMENT»(ref-290858-S37903854202008072200000) ), and recheck. If the symptom/indication goes away, replace the original stereo amplifier. NO - There is an open in the wire(s) between the stereo amplifier and the audio unit. Replace the affected shielded harness.

Auxiliary Input Sound Is Low Or Cannot Be Heard

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Use auxiliary stereo cables with 3.5 mm ends only. Auxiliary accessories may be played on the audio unit using the auxiliary input.

Scheme 104

Scheme 105

Scheme 106

1. Turn the ignition switch to ON (II).
2. Turn on the audio system and connect an auxiliary accessory to the auxiliary input jack.
3. Check the volume operation. Is the sound normal? YES - Operation is normal at this time. NO - Go to step 4 .
4. Make sure the auxiliary accessory volume is set to high. Is the volume set to high? YES - Go to step 5 . NO - Raise the auxiliary accessory volume to high. Make sure the audio system volume is turned down before rechecking.
5. Substitute a known-good auxiliary audio accessory and/or auxiliary stereo cable, and recheck. Does the auxiliary audio accessory operate properly? YES - Original auxiliary audio accessory or auxiliary stereo cable is faulty. NO - Go to step 6 .
6. Turn the ignition switch to LOCK (0).
7. Remove the auxiliary jack assembly (see «AUXILIARY JACK ASSEMBLY REPLACEMENT»(ref-290858-S38116922162008072200000) ), and check that the auxiliary jack assembly is properly connected. Is the auxiliary jack assembly connected properly? YES - With navigation: go to step 8 . Without navigation: go to step 13 . NO - Reconnect the connector, and recheck the function.
8. Disconnect auxiliary jack assembly 5P connector.
9. Disconnect audio-navigation unit connector B (24P).
10. Check for continuity between body ground and audio-navigation unit connector B (24P) according to the table. AUDIO-NAVIGATION UNIT CONNECTOR REFERENCE TABLE Audio-Navigation Unit Connector Wire Color B1 GRN B3 BLU B13 WHT B14 BRN B15 YEL Is there continuity? YES - There is a short to body ground in the wire(s) between the audio-navigation unit and the auxiliary jack assembly. Replace the affected shielded harness. NO - Go to step 11 .
11. Check for continuity between audio-navigation unit connector B (24P) according to the table below. TERMINAL REFERENCE TABLE From Terminal To Terminal B1 B2, B3, B13, B14, B15 B2 B3, B13, B14, B15 B3 B13, B14, B15 B13 B14, B15 B14 B15 Is there continuity? YES - There is a short in the wire(s) between the audio-navigation unit and the auxiliary jack assembly. Replace the affected shielded harness. NO - Go to step 12 .
12. Check for continuity between audio-navigation unit connector B (24P) and auxiliary jack assembly 5P connector according to the table below. AUDIO-NAVIGATION UNIT CONNECTOR REFERENCE TABLE Audio-Navigation Unit Connector Auxiliary Jack Assembly Connector Wire Color B1 3 GRN B3 2 BLU B13 4 WHT B14 5 BRN B15 1 YEL Is there continuity? YES - Substitute a known-good auxiliary jack assembly (see «AUXILIARY JACK ASSEMBLY REPLACEMENT»(ref-290858-S38116922162008072200000) ), and recheck. If the symptom/indication is still present, replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ). NO - There is an open in the wire(s) between the audio-navigation unit and the auxiliary jack assembly. Replace the affected shielded harness.
13. Disconnect the auxiliary jack assembly 5P connector.
14. Disconnect audio unit connector C (6P).
15. Check for continuity between body ground and audio unit connector C (6P) according to the table below. TERMINAL REFERENCE TABLE Audio Unit Connector Wire Color C1 YEL C2 BLU C3 BRN C4 GRN C5 WHT Is there continuity? YES - There is a short to body ground in the wire(s) between the audio unit and the auxiliary jack assembly. Replace the affected shielded harness. NO - Go to step 16 .
16. Check for continuity between audio unit connector C (6P) according to the table below. TERMINAL REFERENCE TABLE From Terminal To Terminal C1 C2, C3, C4, C5, C6 C2 C3, C4, C5, C6 C3 C4, C5, C6 C4 C5, C6 C5 C6 Is there continuity? YES - There is a short to body ground in the wire(s) between the audio unit and the auxiliary jack assembly. Replace the affected shielded harness. NO - Go to step 17 .
17. Check for continuity between audio unit connector C (6P) and the auxiliary jack assembly 5P connector according to the table below. AUDIO-NAVIGATION UNIT CONNECTOR REFERENCE TABLE Audio Unit Connector Auxiliary Jack Assembly Connector Wire Color C1 1 YEL C2 2 BLU C3 5 BRN C4 3 GRN C5 4 WHT Is there continuity? YES - Substitute a known-good auxiliary jack assembly (see «AUXILIARY JACK ASSEMBLY REPLACEMENT»(ref-290858-S38116922162008072200000) ), and recheck. If the symptom/indication goes away, replace the original auxiliary jack assembly. If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ). NO - There is an open in the wire(s) between the audio unit and the auxiliary jack assembly. Replace affected shielded harness

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

1. Check for sound in each mode (AM, FM, XM, and CD). Is there sound from the speakers, and is the sound quality normal in each mode? YES - Intermittent failure. The system is OK at this time. Check for loose connections at the audio-navigation unit, the audio unit, the stereo amplifier, and each speaker. NO - Speakers all work, sound quality is poor. If the sound quality is poor only with the XM radio, or the XM radio does not function, go to poor or no sound with XM radio (see «POOR OR NO SOUND WITH XM RADIO (AUDIO-NAVIGATION UNIT DOES DISPLAY XM CHANNELS) (WITH NAVIGATION)»(ref-290858-S15331769342008072200000) ). If the sound quality is poor only with AM or FM radio, go to poor AM or FM radio reception or interference (see «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (WITH NAVIGATION)»(ref-290858-S34766439632008072200000) , «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (WITHOUT NAVIGATION WITH XM)»(ref-290858-S03758243432008072200000) , «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (WITHOUT XM)»(ref-290858-S18681098572009120300000) ). If the sound is poor in all modes, go to «SOUND QUALITY DIAGNOSIS»(ref-290858-S05590639322008072200000) ).

Radio Preset Memory Is Lost

Note. If only the XM stations are lost, go to XM RADIO PRESET MEMORY IS LOST .

1. Set each of the radio station preset buttons. Do each of the buttons set properly? YES - Go to step 2 . NO - With navigation: Replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION . Without navigation: Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ).
2. Turn the ignition switch to LOCK (0) for 1 minute, then turn it back to ON (II).
3. Test the preset buttons for proper recall operation. Do the preset buttons recall the set radio stations? YES - System is normal at this time. Check the connections at the audio-navigation unit or the audio unit. NO - With navigation: Replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION . Without navigation: Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ).

Volume Does Not Change

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Set the fader and balance positions to the center.

1. Listen for sound from the speakers. Is the sound normal? YES - Go to step 2 . NO - Go to «AUDIO SYSTEM SOUND IS WEAK OR DISTORTED (DISPLAY IS NORMAL)»(ref-290858-S34266124922008072200000) or «NO SOUND IS HEARD FROM SPEAKER(S) (DISPLAY IS NORMAL) (WITH NAVIGATION)»(ref-290858-S35853501342008072200000) and «NO SOUND IS HEARD FROM SPEAKER(S) (DISPLAY IS NORMAL) (WITHOUT NAVIGATION)»(ref-290858-S41775157902009120300000) .
2. Operate the volume knob to see if the volume changes. Does the volume change? YES - Operation is normal. NO - With navigation: Replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION . Without navigation: Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ).

Volume Does Not Increase With Speed (With Navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 107

1. Test-drive the vehicle at highway speeds, and monitor if the volume increases. Does the volume increase? YES - Intermittent failure, the system is OK at this time. NO - Go to step 2 .
2. Verify the SVC mode setting in the audio-navigation unit sound set-up. Is the SVC set to off? YES - Change the setting to Mid, and recheck. NO - Go to step 3 .
3. Go to Navigation System Diagnostic Mode, and use CAR STATUS diagnosis to check the vehicle speed pulse signal. Is the vehicle speed signal OK? YES - Substitute a known-good audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit NO - Go to step 4 .
4. Turn the ignition switch to LOCK (0).
5. Remove the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ) and disconnect audio-navigation unit connector A (24P). NOTE: Eject all the discs before removing the audio-navigation unit to prevent damaging the CD player's load mechanism.
6. Drive the vehicle, and have an assistant measure voltage at audio-navigation unit connector A (24P) terminal No. 15. Is there a 0-5 V Pulse? YES - Replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ). NO - Repair an open or shorts in the wire between audio-navigation unit connector A (24P) terminal No. 15 and PCM connector E (31P) terminal No. 26. If no opens or shorts are found, update the PCM if it does not have the latest software, or substitute a known-good PCM.

Volume Is Too High Or Too Low When Driving At Freeway Speeds (With Navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

1. Test-drive the vehicle at highway speeds and monitor volume level. Is the volume level too high, or too low? YES - Go to step 2 . NO - Intermittent failure, the system is OK at this time.
2. Change the SVC mode setting in sound set-up to Mid. Is the volume level still too high, or too low? YES - Replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ). NO - Improper SVC setting for customers sound taste

Radio Tuner Does Not Change Stations

1. Check the audio information on the display panel. Does the audio information display properly? YES - Go to step 2 . NO - Go to «POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND)»(ref-290858-S16550024792008072200000) .
2. Operate the tuning knob to see if the radio station changes. Does the radio station change? YES - Intermittent failure: The tuning knob is OK at this time. NO - With navigation: Replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION . Without navigation: Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ).

Navigation Unit Button Illumination Does Not Work (With Navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 108

Scheme 109

1. Turn the ignition switch to ON (II).
2. Turn the combination lighting switch to the parking light position.
3. Check the illumination of the audio-navigation unit buttons. Are the buttons illuminated? YES - Intermittent problem: the audio-navigation unit is OK at this time. Check for loose or poor connections at the audio-navigation unit connector A (24P). NO - Go to step 4 .
4. Check the illumination of several other buttons not related to the navigation system. Are the buttons illuminated? YES - Go to step 5 NO - Troubleshoot the interior lights. Start by checking the No. 14 (7.5 A) fuse in the under-dash fuse/relay box. If the fuse is OK, check for an open in the wire between the under-dash fuse/relay box and the audio-navigation unit.
5. Turn the ignition switch to LOCK (0).
6. Disconnect audio-navigation unit connector A (24P). NOTE: Eject all the discs before removing the audio-navigation unit to prevent damaging the CD player's load mechanism.
7. Disconnect gauge control module 36P connector.
8. Check for continuity between audio-navigation unit connector A (24P) terminal No. 1 and gauge control module 36P connector terminal No. 26. Is there continuity? YES - Go to step 9 . NO - Repair an open in the wire between the gauge control module and the audio-navigation unit.
9. Turn the ignition switch to ON (II).
10. With the headlight switch still on, measure the voltage between audio-navigation unit connector A (24P) terminal No. 13 and body ground. Is there battery voltage? YES - Check the connections at audio-navigation unit connector A (24P). If all connections are OK, replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ). NO - Repair an open in the wire between the under-dash fuse/relay box and the audio-navigation unit.

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 110

Scheme 111

1. Turn the ignition switch to ON (II).
2. Turn the combination lighting switch to the parking light position.
3. Check the illumination of the audio unit buttons. Are the buttons illuminated? YES - Intermittent problem: the audio unit is OK at this time. Check for loose or poor connections at audio unit connector A (20P). NO - Go to step 4
4. Check the illumination of several other buttons not related to the audio system. Are the buttons illuminated? YES - Go to step 5 NO - Troubleshoot the interior lights. Start by checking the No. 14 (7.5 A) fuse in the under-dash fuse/relay box. If the fuse is OK, check for an open in the wire between the under-dash fuse/relay box and the audio unit.
5. Turn the ignition switch to LOCK (0).
6. Disconnect audio unit connector A (20P). NOTE: Eject all the discs before removing the audio unit to prevent the CD player's load mechanism.
7. Disconnect the gauge control module 36P connector.
8. Check for continuity between audio unit connector A (20P) terminal No. 19 and gauge control module 36P connector terminal No. 26. Is there continuity? YES - Go to step 9 . NO - Repair an open in the wire between the gauge control module and the audio unit.
9. Turn the ignition switch to ON (II).
10. With the headlight switch still on, measure the voltage between audio unit connector A (20P) terminal No. 9 and body ground. Is there battery voltage? YES - Check the connections at audio unit connector A (20P). If all the connections are OK, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ). NO - Repair an open in the wire between the under-dash fuse/relay box and the audio unit.

Display Does Not Dim Or Brighten With Dimmer (Without Navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 112

1. Turn the ignition switch ON (II).
2. Turn the combination light switch ON and OFF to see if the symptom can be duplicated. Can you duplicate the problem? YES - Go to step 3 . NO - Operation is normal.
3. Turn the combination light switch OFF.
4. Operate the illumination control dial. Does the illumination control dial function normally? YES - Operation is normal. NO - Go to step 5 .
5. Turn the ignition switch to LOCK (0).
6. disconnect and check audio unit connector A (20P) for loose or a poor connection. NOTE: Eject all the CDs before remove the audio unit to prevent damaging the CD player's load mechanism. Reconnect audio unit connector A (20P) and recheck the symptom; does it still appear? YES - Go to step 7 . NO - Operation is normal.
7. Turn the ignition switch to ON (II).
8. Measure the voltage between audio unit connector A (20P) No. 9 and No. 19 terminals. Operate the dash lights brightness controller buttons to see if the voltage changes. Does the voltage change? YES - Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ), and recheck. If the symptom/indication goes away, replace the original audio unit. NO - Repair open in the wire between the under-dash fuse/relay box and the gauge control module.

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Disc labels should not be used in the audio unit. They may jam and damage the player mechanism. Make sure the disc is compatible with the system (see the Owner's Manual for more information).

1. Insert a known-good disc to see if the symptom can be duplicated. Does the disc load? YES - Operation is normal. If the disc loads normally, but will not play, go to «AUDIO DISC DOES NOT PLAY»(ref-290858-S24505740682008072200000) . NO - Go to step 2 .
2. Insert another disc. Does the disc load? YES - The original disc is faulty. NO - With navigation: Replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ). Without navigation: Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Disc labels should not be used in the audio-navigation unit. They may damage the player mechanism.

1. Turn on the audio unit. Does the system turn on? YES - Go to step 2 . NO - Go to «AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH NAVIGATION)»(ref-290858-S16550024792008072200000) ); With navigation: Replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ). Without navigation: Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ).
2. Check to see if the disc ejects correctly with no binding by pushing the EJECT button. Does the disc eject? YES - Operation is normal. NO - With navigation: Replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ). Without navigation: Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Disc labels should not be used in the audio-navigation unit. They may damage the player mechanism.

1. Try loading a known-good disc. Does the disc load? YES - Go to step 2 . NO - Go to «AUDIO DISC DOES NOT LOAD»(ref-290858-S28556009152008072200000) .
2. Insert the audio diagnostic CD (T/N: 07AAZ-SDBA100) in the audio-navigation unit or audio unit. Does the disc play? YES - The original disc is faulty, or has an unreadable format. NO - With navigation: Replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ). Without navigation: Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ).

1. Confirm the vehicles tires are properly inflated.
2. Check the customers CD for scratches, fingerprints, and marks. NOTE: The following test should be performed with audio unit bass and treble set to customers listening performance. When comparing to known-good vehicles, comparison should be performed on same model and trim level.
3. Test drive to identify when customers CD skips. The audio diagnostic CD (T/N: 07AAZ-SDBA100) can be used if customers CD is not available. Use tracks 10-12. Does the CD skip? YES - Go to step 4 . NO - Operation is normal.
4. Compare the customers CD that is skipping in a known-good vehicle under the same conditions. Does the CD skip in the known-good vehicle under the same conditions? YES - Operation is normal. NO - Go to step 5 . NOTE: The following test should be performed with vehicle parked and engine running.
5. Insert the diagnostic skip test CD (T/N: 07AAZ-SDBA300) (ABEXTCD721). Play tracks 2-11 and note the track number(s) where the CD starts skipping. Do the same test on a known-good vehicle. Does the CD skip on same track number(s) as known-good vehicle? YES - Operation is normal. NO - Go to step 6 .
6. Insert the diagnostic skip test CD (T/N: 07AAZ-SDBA200) (ABEX TCD 725B) play tracks 7-11 and tracks 13-15 and note the track number(s) where the CD starts skipping. Perform the same test on a known-good vehicle. Does the CD skip on same track number(s) as known-good vehicle? YES - Operation is normal. NO - With navigation: Replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ). Without navigation: Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 113

Scheme 114

1. Check the audio-navigation unit operation. Is the audio-navigation unit operation OK? YES - Go to step 2 . NO - Replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ).
2. Do «AUDIO REMOTE SWITCH TEST/REPLACEMENT»(ref-290858-S31206574482008072200000) ). Is the audio remote switch OK? YES - Go to step 3 . NO - Replace the audio remote-navigation voice control switch.
3. Replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION )
4. Measure the resistance between audio unit connector A (20P) No. 3 and No. 14 terminals as specified in the table below. AUDIO REMOTE SWITCH TABLE Button held down VOL DOWN VOL UP CH MODE No button pressed Resistance about 50 ohms about 300 ohms about 900 ohms about 2.4 Kohms about 10 kohms Is the resistance OK? YES - Go to step 5 . NO - Repair open or high resistance in the circuit between the audio unit and the audio remote switch. If the wires are OK, replace the cable reel (see «CABLE REEL REPLACEMENT»(ref-355246-S18349873202010012100000) ).
5. Check for continuity between body ground and audio-navigation unit connector A (24P) terminals No. 5 and No. 16 individually. Is there continuity? YES - Repair short to body ground in the circuit between audio unit and the audio remote switch. If the wires are OK, replace the cable reel (see «CABLE REEL REPLACEMENT»(ref-355246-S18349873202010012100000) ). NO - Replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 115

Scheme 116

1. Check the audio unit operation.
2. Do «AUDIO REMOTE SWITCH TEST/REPLACEMENT»(ref-290858-S31206574482008072200000) ). Is the audio remote switch OK? YES - Go to step 3 . NO - Replace the audio remote switch.
3. Remove the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ).
4. Measure the resistance between audio unit connector A (20P) terminals No. 3 and No. 14 as specified in the table below. AUDIO REMOTE SWITCH TABLE Button held down VOL DOWN VOL UP CH MODE No button pressed Resistance about 50 ohms about 300 ohms about 900 ohms about 2.4 Kohms about 10 kohms Is the resistance OK? YES - Go to step 5 . NO - Repair open or high resistance in the circuit between the audio unit and the audio remote switch. If the wires are OK, replace the cable reel (see «CABLE REEL REPLACEMENT»(ref-355246-S18349873202010012100000) ).
5. Check for continuity between audio unit connector A (20P) terminals No. 3 and No. 14 and body ground individually. Is there continuity? YES - Repair short to body ground in the circuit between audio unit and the audio remote switch. If the wires are OK, replace the cable reel (see «CABLE REEL REPLACEMENT»(ref-355246-S18349873202010012100000) ). NO - Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Disc labels should not be used in the audio-navigation unit or audio unit. They may damage the player mechanism. Make sure the disc is compatible with the system (see the Owner's Manual for more information).

1. Press the OPEN/CLOSE button to open the navigation display.
2. Try inserting an audio CD. Does the player accept the CD? YES - The system is OK at this time. NO - Go to step 3 .
3. Press the CD eject button. Does the player eject the CD? YES - The system is OK at this time. NO - Replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ).

Unfortunately there are no error messages, and no diagnostics for the PC card. There are many reasons why a card won't play audio files in the audio-navigation unit.

1. The card may not be fully inserted into the slot. Eject the card, and inspect for warping or damage to the edge connector. Never use excessive force to insert a card. This can result in damage to the pins in the rear of the slot.
2. The customer's card may contain audio files that are not recognized by the system. Only MP3, and WMA music files are played.
3. The flash card type may not be accepted by the system. Only Compact Flash and ATA cards have been tested.
4. The card's PCMCIA adaptor may be preventing a known-good card from playing. New PCMCIA adaptors are constantly being released, and have not been tested.
5. The card's capacity may exceed 1 GB. Only cards with capacities of up to 1 GB (1, 000 MB) have been tested.
6. There may not be any files on the card. Some cards have write protection, make sure it is turned off before putting files on the card.
7. Although flash memory chips are reliable, occasionally they develop bad sectors or other formatting errors that prevents them from playing. The customer should re-format the card using the FAT, or FAT32 format.
8. The card may have been damaged by heat. Suggest that the customer remove their card when exiting the vehicle.
9. The customer may have formatted the card using the format NTFS. Only the formats FAT, and FAT32 are accepted by the system.
10. Hard Disc Drive (HDD) cards may not work properly in the system and can overheat and quit functioning, particularly in a hot vehicle. They are not recommended.
11. The filing structure of the card may exceed the specification of 8 folder levels deep, 99 folders maximum, and 999 total tracks maximum. If any of these limitations is exceeded, the system may not properly display or play the tracks.

Note. A delay when first inserting a card is normal. The system is reading the File Tag information for album names, artist, and song titles and there is no hour glass, The delay length depends on the number of tracks, and the complexity of the folder structure.

See the audio section glossary for an explanation of the terms used above.

USB Input Sound Is Low Or Cannot Be Heard (With Navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Not all players and player functions work with the USB adapter. Please see the Owner's Manual for more information.

Scheme 117

Scheme 118

1. Turn the ignition switch ON (II).
2. Check to see if there is a specific speaker that has no sound. Do all speakers make a sound? YES - Go to step 3 . NO - Go to «NO SOUND IS HEARD FROM SPEAKER(S) (DISPLAY IS NORMAL) (WITH NAVIGATION)»(ref-290858-S35853501342008072200000) .
3. Turn the ignition switch to LOCK (0).
4. On the customer's vehicle, connect the customer's USB device to the USB adapter.
5. Turn the ignition switch to ON (II).
6. Turn on the audio system.
7. Press the AUX button until USB appears on the navigation display.
8. Check if the USB device can be operated with the audio-navigation unit (Folders of Files UP/DOWN, etc.). Can you operate the USB device, and is the sound normal? YES - Intermittent failure. The USB device is OK at this time. NO - If you can operate the USB device, but there is no sound, go to step 9 . If you cannot operate the USB device, go to «USB DEVICE DOES NOT FUNCTION (WITH NAVIGATION)»(ref-290858-S23478524672009120400000) .
9. Turn the ignition switch to LOCK (0).
10. Connect the customer's USB device to a known-good vehicle (same year/trim) that is equipped with a USB adapter, and check the USB device operation. Is the USB device working properly in the known-good vehicle? YES - Go to step 11 . NO - USB device is faulty. Also check the USB adapter 5P connector condition.
11. Return to the customer's vehicle.
12. Disconnect audio-navigation unit connector D (14P).
13. Disconnect USB adapter unit connector A (14P).
14. Disconnect XM receiver connector A (14P).
15. Check for continuity between audio-navigation unit connector D (14P) and body ground according to the table below. AUDIO-NAVIGATION UNIT CONNECTOR REFERENCE TABLE Audio-Navigation Unit Connector Wire Color D5 WHT D6 RED D13 BLU D14 GRN Is there any continuity? YES - Short to body ground in the wire(s) between the audio-navigation unit and the USB adapter unit. Replace the affected shielded harness. NO - Go to step 16 .
16. Check for continuity between the terminals of audio-navigation unit connector D (14P) according to the table below. TERMINAL REFERENCE TABLE From Terminal To Terminals D4 (GRY) D5 (WHT), D6 (RED), D13 (BLU), D14 (GRN) D5 (WHT) D6 (RED), D13 (BLU), D14 (GRN) D6 (RED) D13 (BLU), D14 (GRN) D13 (BLU) D14 (GRN) Is there continuity between any of the terminals? YES - Short in the wires between the audio-navigation unit and the USB adapter unit. Replace the affected shielded harness. NO - Go to step 17 .
17. Check for continuity between audio-navigation unit connector D (14P) and USB adapter unit connector A (14P) according to the table below. CONNECTOR REFERENCE TABLE Audio-Navigation Unit Connector USB Adapter Unit Connector Wire Color D5 A5 WHT D6 A6 RED D13 A13 BLU D14 A14 GRN Is there continuity? YES - Substitute a known-good USB adapter control unit (see «USB ADAPTER UNIT REPLACEMENT»(ref-290858-S40307803492009120100000) ), then reconnect all of the connectors, and recheck. If the symptom/indication goes away, replace the original USB adapter control unit. If the symptom/indication is still present, replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ). NO - Open in the wire(s) between the audio-navigation unit and the USB adapter unit. Replace the affected shielded harness.

USB Device Does Not Function (With Navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Check the USB device requirement: Mass-storage class ready digital audio player with USB 2.0 port More than 256 MB of RAM Support MP3, WMA, and AAC (encorded with the iTunes) files, DRM files are not supported Not all players and player functions work with the USB adapter. Please see the Owner's Manual for more information. Always test the customers USB device in a known-good vehicle of the same year and trim (if possible). Technologies change and are updated frequently which may result that USB devices may work in newer vehicles, but not in order vehicles of the same model.

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

1. Turn the ignition switch to ON (II).
2. Turn on the audio system.
3. Press the AUX button to select USB mode. NOTE: Do not connect the USB device. Is USB NO DATA displayed in the navigation display? YES - Go to step 4 . NO - Go to step 17 .
4. Turn the ignition switch to LOCK (0).
5. Connect the customer's USB device to a known-good vehicle (same year/trim) that is equipped with a USB adapter, and check the USB device operation. Is the USB device working properly in the known-good vehicle? YES - Go to step 6 . NO - If the audio-navigation unit displays UNSUPPORTED or MEDIA ERROR, the USB device may not be unsupported or is defective. If the audio-HVAC displays USB NO MUSIC, the USB device may have no music files or wrong type music files are on the device. See the Owner's Manual for details on USB device requirements and approved file types.
6. On the customer's vehicle, connect the customer's USB device to the USB adapter.
7. Turn the ignition switch to ON (II).
8. Turn on the audio system.
9. Check the USB device operation in the customer's vehicle. Does the USB device work properly in the customer's vehicle? YES - The system is OK at this time. Inspect the connectors of the USB device, USB port and USB adapter for wear. NO - Go to step 10 .
10. Check the navigation system for hard error codes (see HOW TO CHECK ERROR HISTORY ). Are there any DTC's related to the audio or XM systems? YES - Do the appropriate DTC troubleshooting in the navigation section, and recheck. NO - Go to step 11 .
11. Turn the ignition switch to LOCK (0).
12. On the customer's vehicle, remove the USB device.
13. Turn the ignition switch to ON (II).
14. Turn the ignition switch to LOCK (0).
15. Disconnect USB adapter control unit connector B (5P).
16. Check for continuity between terminals of USB adapter control unit connector B (5P) and the USB port 5P connector according to the table below. USB ADAPTER CONNECTOR REFERENCE TABLE USB Adapter Unit Connector USB Adapter Connector B1 1 B2 2 B3 3 B4 4 B5 5 Is there continuity? YES - Substitute a known-good USB adapter cable, and recheck. If the symptom/indication goes away, replace the original USB adapter cable. If the symptom/indication still present, go to step 18 . NO - There is an open in the wire(s) between the USB adapter unit and the USB adapter. Replace the affected shielded harness.
17. Turn the ignition switch to LOCK (0).
18. Measure the voltage between body ground and USB adapter unit connector A (14P) terminal No. 1. Is there battery voltage? YES - Go to step 19 . NO - Repair open in the wire between the No. 9 (10A) fuse in the under-hood fuse/relay box and XM receiver connector A (14P) terminal No. 1.
19. Measure the voltage between body ground and USB adapter control unit connector A (14P) terminal No. 2. Is there battery voltage? YES - Go to step 20 . NO - Substitute a known-good USB adapter unit (see «USB ADAPTER UNIT REPLACEMENT»(ref-290858-S40307803492009120100000) ), and recheck.
20. Turn the ignition switch to ON (II).
21. Measure the voltage between body ground and USB adapter control unit connector A (14P) terminal No. 2. Is there about 0.1 V? YES - Go to step 25 . NO - Go to step 22 .
22. Turn the ignition switch to LOCK (0).
23. Disconnect USB adapter unit connector A (14P) and audio-navigation unit connector D (14P).
24. Check for continuity between USB adapter unit connector A (14P) terminal No. 2 and audio-navigation unit connector D (14P) terminal No. 2. Is there continuity? YES - Substitute a known-good audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ), reconnect all the connectors, and recheck. NO - Repair the open on the wire between the USB adapter unit and the audio-navigation unit.
25. Measure the voltage between USB adapter unit connector A (14P) terminal No. 11 and body ground. Is there continuity? YES - Go to step 26 . NO - Repair open in the wire between the USB adapter unit connector A (14P) terminal No. 11 and body ground (G503).
26. Turn the ignition switch to LOCK (0).
27. Disconnect USB adapter unit connector A (14P) and audio-navigation unit connector D (14P)
28. Check for continuity between terminals of audio-navigation unit connector D (14P) and USB adapter unit connector A (14P) according to the table below. CONNECTOR AND WIRE COLOR REFERENCE TABLE Audio-Navigation Unit Connector USB Adapter Unit Connector Wire Color D9 A9 BLU D10 A10 PNK Is there continuity? YES - Substitute a known-good USB adapter control unit (see «USB ADAPTER UNIT REPLACEMENT»(ref-290858-S40307803492009120100000) ), then reconnect all of the connectors, and recheck. If the symptom/indication goes away, replace the original USB adapter control unit. If the symptom/indication is still present, replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ). NO - There is an open in the wire(s) between the audio-navigation unit and the USB adapter control unit. Replace the affected shielded harness.

Error Code: XM NO SIGNAL or XM ANTENNA Is Displayed

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Check XM radio reception in an open area. Poor reception/interference can be caused by tall buildings, mountains, or high-voltage power lines.

1. Check the connector at the XM receiver. Is the connector connected? YES - Go to step 2 . NO - Reconnect the connector. If the error message does not go away, go to step 2 .
2. Check the connector at the XM antenna. Is the connector connected? YES - Go to step 3 . NO - Reconnect the connector. If the error message does not go away, go to step 3 .
3. Check the pin locations in the XM receiver connector and the XM antenna connector. Are the pins in the correct locations? YES - Go to step 4 . NO - Correct the pin locations. If the error message does not go away, go to step 4 .
4. Substitute a known-good AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(ref-290858-S42714499972008072200000) ). Is the error message gone? YES - Replace the original AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(ref-290858-S42714499972008072200000) ). NO - Go to step 5 .
5. Substitute a known-good XM receiver (see «XM RECEIVER REPLACEMENT»(ref-290858-S14568267052008072200000) ). Is the error message gone? YES - Replace the original XM receiver (see «XM RECEIVER REPLACEMENT»(ref-290858-S14568267052008072200000) ). NO - Replace the XM antenna lead.

XM Radio Display Is Blank And No Station Information Is Displayed (With Navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 124

Scheme 125

Scheme 126

1. Turn the ignition switch to ON (II).
2. With navigation: Check for the navigation system hard error codes. Without navigation: Go to step 3 . Are there any DTC's related to the audio or the XM system? YES - Do the appropriate DTC troubleshooting in the navigation section, and recheck. NO - Go to step 3 .
3. Turn the ignition switch to LOCK (0).
4. Measure the voltage between body ground and XM receiver connector A (14P) terminals No. 1 and No. 7 individually. Is there battery voltage? YES - Go to step 6 . NO - Repair an open in the wire between the No. 9 (10 A) fuse in the under-hood fuse/relay box and XM receiver connector A (14P) terminals No. 1 and/or No. 7.
5. Turn the ignition switch to ON (II).
6. Measure the voltage between XM receiver connector A (14P) terminal No. 2 and body ground. Is there less than 0.1 V? YES - Go to step 7 . NO - Repair open in the wire between the XM receiver connector A (14P) terminal No. 11 and body ground (G551).
7. Turn the ignition switch to LOCK (0).
8. Measure the voltage between XM receiver connector A (14P) terminal No. 2 and body ground. Is there battery voltage? YES - Go to step 9 . NO - Substitute a known-good XM receiver (see «XM RECEIVER REPLACEMENT»(ref-290858-S14568267052008072200000) ), and recheck. If 10 V or more are present, replace the original XM receiver.
9. Turn the ignition switch to ON (II).
10. Measure the voltage between the audio-navigation unit connector D (14P) terminal No. 2 and body ground. Is there less than 0.1 V? YES - Substitute a known-good XM receiver (see «XM RECEIVER REPLACEMENT»(ref-290858-S14568267052008072200000) ), and recheck. If the symptom goes away, replace the original XM receiver. NO - Substitute a known-good audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ), and recheck. If 0.5 V or less are present, replace the original audio-navigation unit.

XM Radio Display Is Blank And No Station Information Is Displayed (Without Navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 127

Scheme 128

Scheme 129

Scheme 130

1. Measure the voltage between body ground and XM receiver connector A (14P) terminals No. 1 and No. 7 individually. Is there battery voltage? YES - Go to step 2 NO - Repair an open in the wire between the No. 9 (10 A) fuse in the under-hood fuse/relay box and XM receiver connector A (14P) terminals No. 1 and/or No. 7.
2. Turn the ignition switch to ON (II).
3. Measure the voltage between XM receiver connector A (14P) terminal No. 11 and body ground. Is there less than 0.1 V? YES - Go to step 4 NO - Repair open in the wire between the XM receiver connector A (14P) terminal No. 11 and body ground (G551).
4. Turn the ignition switch to LOCK (0).
5. Measure the voltage between XM receiver connector A (14P) terminal No. 2 and body ground. Is there battery voltage? YES - Go to step 6 . NO - Substitute a known-good XM receiver (see «XM RECEIVER REPLACEMENT»(ref-290858-S14568267052008072200000) ), and recheck. If 10 V or more are present, replace the original XM receiver.
6. Turn the ignition switch to ON (II).
7. Measure the voltage between the audio unit connector D (14P) terminal No. 2 and body ground. Is there less than 0.1 V? YES - Go to step 8 NO - Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ), and recheck. If 0.5 V or more are present, replace the original audio unit.
8. Turn the ignition switch to LOCK (0).
9. Disconnect audio unit connector D (14P)
10. Disconnect XM receiver connector A (14P).
11. Check for continuity between audio unit connector D (14P) and body ground according to the table below. CONNECTOR REFERENCE TABLE Audio Unit Connector Wire Color D9 BLU D10 PNK Is there continuity? YES - There is a short to body ground in the wire(s) between the audio unit and the XM receiver. Replace the affacted shielded harness. NO - Go to step 12 .
12. Check for continuity between the audio unit connector D (14P) according to the table below. TERMINAL REFERENCE TABLE From Terminal To Terminal D3 D9, D10 D9 D10 Is there continuity between any of the terminals? YES - There is a short to body ground in the wire(s) between the audio unit and the XM receiver. Replace the affected shielded harness. NO - Go to step 13 .
13. Check for continuity between audio unit connector D (14P) and XM receiver connector A (14P) according to the table below. TERMINAL REFERENCE TABLE Audio Unit Connector XM Receiver Connector Wire Color D3 A3 BRN D9 A9 BLU D10 A10 PNK Is there continuity? YES - Substitute a known-good XM receiver (see «XM RECEIVER REPLACEMENT»(ref-290858-S14568267052008072200000) ), then reconnect all of the connectors, and recheck. If the symptom/indication goes away, replace the original XM receiver. If the symptom/indication goes away, replace the original XM receiver. If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ). NO - There is an open in the wire(s) between the audio unit and the XM receiver. Replace the affected shielded harness.

XM Radio Preset Memory Is Lost

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. If you can only tune to channel 000, 001, 174, and 247, make sure the audio unit is set to channel mode (see Owner's Manual), if it is set to channel mode, call XM Satellite Radio customer support and check the account activation status.

Scheme 131

Scheme 132

1. Turn the ignition switch ON (II).
2. Turn on the audio unit and set each of the XM radio channel preset buttons. Do each of the XM radio channel preset buttons set properly? YES - Go to step 3 . NO - With navigation: Replace audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ) Without navigation: Replace audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ).
3. Turn the ignition switch to LOCK (0) for 1 minute, then turn it back to ON (II).
4. Test all of the XM radio channel preset buttons for proper recall operation. Do the preset buttons recall the set radio stations? YES - System is normal at this time. Check the connections at the audio-navigation unit or the audio unit. NO - Go to step 5 .
5. Turn the ignition switch to LOCK (0).
6. Measure the voltage between body ground and XM receiver connector A (14P) terminals No. 1 and No. 7 individually. Is there battery voltage? YES - Go to step 7 . NO - Repair open in the wire between the under-dash fuse/relay box and XM receiver connector A (14P) No. 1 terminal.
7. Measure the voltage between XM receiver connector A (14P) No. 11 terminal and body ground. Is there less than 0.1 V? YES - Replace the XM receiver (see «XM RECEIVER REPLACEMENT»(ref-290858-S14568267052008072200000) ). NO - Repair open in the wire between XM receiver connector A (14P) No. 11 terminal and body ground (G551) (see «FLOOR WIRE HARNESS (RIGHT BRANCH)»(ref-355248-S24564008992010012100000) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. If you can only tune to channel 000, 001, 174, and 247, make sure the audio-navigation unit is set to channel mode (see Owner's Manual), if it is set to channel mode, call XM Satellite Radio customer support and check the account activation status.

Scheme 133

Scheme 134

1. Turn the ignition switch to ON (II).
2. Turn on the audio system, and select XM radio.
3. Check for an error message on the display. Are there any messages displayed? YES - Go to «ERROR CODES»(ref-290858-S24831908172008072200000) . NO - Go to step 4 .
4. Turn the ignition switch to LOCK (0).
5. Disconnect audio-navigation unit connector D (14P). NOTE: Eject all the CDs before remove the audio-navigation unit to prevent damaging the player's load mechanism.
6. Disconnect XM receiver connector A (14P) and USB adapter unit connector A (14P).
7. Check for continuity between audio-navigation unit connector D (14P) and body ground according to the table below. CONNECTOR REFERENCE TABLE Audio-Navigation Unit Connector Wire Color D5 WHT D6 RED D13 BLU D14 GRN Is there continuity? YES - Short to body ground in the wire(s) between the audio-navigation unit, the USB adapter unit, and the XM receiver. Replace the affected shielded harness. NO - Go to step 8 .
8. Check for continuity between the audio-navigation unit connector D (14P) according to the table below. TERMINALS REFERENCE TABLE From Terminal To Terminals D4 D5, D6, D13, D14 D5 D6, D13, D14 D6 D13, D14 D13 D14 Is there continuity between any of the terminals? YES - Short in the wire(s) between the audio-navigation unit, the USB adapter unit, and the XM receiver. Replace the affected shielded harness. NO - Go to step 9 .
9. Check for continuity between XM receiver connector A (14P) and audio-navigation unit connector D (14P) according to the table below. CONNECTOR REFERENCE TABLE XM Receiver Connector Audio-Navigation Unit Connector Wire Color A6 D6 RED A14 D14 GRN A5 D5 WHT A13 D13 BLU Is there continuity? YES - Substitute a known-good XM receiver (see «XM RECEIVER REPLACEMENT»(ref-290858-S14568267052008072200000) ), then reconnect the all connectors and recheck. If the symptom/indication goes away, replace the original XM receiver. If the symptom/indication is still present, replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ). NO - There is an open in the wire(s) between the audio-navigation unit and XM receiver. Replace the affected shielded harness.

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. If you can only tune to channel 000, 001, 174, and 247, make sure the audio unit is set to channel mode (see Owner's Manual), if it is set to channel mode, call XM Satellite Radio customer support and check the account activation status.

Scheme 135

Scheme 136

Scheme 137

1. Turn the ignition switch to ON (II).
2. Turn on the audio system, and select XM radio.
3. Check for an error message on the display. Are there any messages displayed? YES - Go to «ERROR CODES»(ref-290858-S24831908172008072200000) . NO - Go to step 4 .
4. Turn the ignition switch to LOCK (0).
5. Disconnect audio unit connector D (14P).
6. Disconnect XM receiver connector A (14P).
7. Check for continuity between audio unit connector D (14P) and body ground according to the table below. CONNECTOR REFERENCE TABLE Audio Unit Connector Wire Color D5 WHT D6 RED D13 BLU D14 GRN Is there continuity? YES - Short to body ground in the wire(s) between the audio unit and the XM receiver. Replace the affected shielded harness. NO - Go to step 8 .
8. Check for continuity between the audio unit connector D (14P) according to the table below. TERMINAL REFERENCE TABLE From Terminal To Terminals D4 D5, D6, D13, D14 D5 D6, D13, D14 D6 D13, D14 D13 D14 Is there continuity between any of the terminals? YES - Short in the wire(s) between the audio unit and the XM receiver. Replace the affected shielded harness. NO - Go to step 9 .
9. Check for continuity between XM receiver connector A (14P) and audio unit connector D (14P) according to the table below. CONNECTOR REFERENCE TABLE XM Receiver Connector Audio Unit Connector Wire Color A6 D6 RED A14 D14 GRN A5 D5 WHT A13 D13 BLU Is there continuity? YES - Substitute a known-good XM receiver (see «XM RECEIVER REPLACEMENT»(ref-290858-S14568267052008072200000) ), then reconnect the all connectors and recheck. If the symptom/indication goes away, replace the original XM receiver. If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-290858-S15738518602008072200000) ). NO - There is an open in the wire(s) between the audio unit and XM receiver. Replace the affected shielded harness.

Left/Right Channel ID

Do this test to confirm proper channel routing.

1. Insert the audio diagnostic CD (T/N: 07AAZ-SDBA100) into the audio unit.
2. Play track No. 1 (left, both, right channel ID) at a normal, or slightly higher than normal, volume level.
3. The voice should be audible only from the channel or channels when indicated. If the channel ID is correct for each side, go to the phase test. If the channel ID is not correct, check for; Shorted speaker wire Faulty amplifier (with premium sound system) Faulty audio unit

Frequency Sweep

Do this test to find rattles or reverberation that may cause a perception of poor sound quality.

1. Insert the audio diagnostic CD (T/N: 07AAZ-SDBA100) into the audio unit.
2. Play track No. 13 (sweep from 500 Hz to 35 Hz) at a normal, or slightly higher than normal, volume level.
3. Listen to each speaker for poor sound quality or reverberations caused by specific frequencies. Use the voice-over to estimate the frequency that causes the vibration. Use the audio unit's fader and balance settings to help isolate the channel with the problem. If you hear vibrations or poor sound quality, go to step 4 . If you do not hear any vibrations or poor sound quality, go to sound judging.
4. Choose the appropriate track from No. 14 to 25 (small range frequency sweep) or 26 to 53 (single frequencies) to recreate the frequency that caused the poor sound quality or vibration located in step 3 this aids in diagnosis of the problem. NOTE: When you get to the track that recreates the problem, select the repeat function on the audio unit, this will help you isolate the cause.
5. Replace or insulate the source of the vibrations or, if the speaker is the source of the poor sound quality, replace it.

Sound Judging

1. Do this test to compare overall sound quality, imaging, and dynamics between the customer's vehicle and a known-good vehicle. Only use a vehicle of the same model and trim level for this test.
2. Make sure the vehicle is using only OEM speakers.

1. In the customer's vehicle, set the bass, treble, fader, and balance settings to the customer's normal settings that were written down before beginning testing.
2. Insert the audio diagnostic CD (T/N: 07AAZ-SDBA100) into the audio unit.
3. Play tracks No. 7 to 12 (sound quality, midland, dynamics, and imaging demonstration tracks) at a normal, or slightly higher than normal, volume level. Write down the volume setting.
4. Listen to areas of the track that stand out as being either very clear, or poorer than other areas of the track.
5. Insert the audio diagnostic CD (T/N: 07AAZ-SDBA100) into the audio unit of a known-good vehicle.
6. Play the tracks at the same volume level and the same bass, treble, balance, and fader settings as used in step 3 in the customer's vehicle.
7. Listen to the same area of the track that stood out as being either very clear or poorer than other areas of the track.
8. Compare the customer's vehicle's sound quality results to the known-good vehicle's results. If the sound quality in the customer's vehicle is comparable to the sound quality in the known-good vehicle, then the customer's vehicle is operating as designed. If the sound quality is not comparable, check these items in order. Loose or improperly installed speakers or other hardware that may become excited by the vibrations generated by the speakers Poor power or ground to the stereo amplifier Damaged speaker(s) Faulty amplifier Faulty audio unit
