Deployment Tool Check Honda Crosstour I

SRS (Supplemental Restraint System) 22 illustrations ~1423 words

Deployment Tool Check

  1. Connect the yellow clips to both switch protector handles on the tool.
  2. Then connect the red lead to the positive battery post and the black lead to the negative battery post.
  3. Push the operation switch: The green light should come on, indicating that the tool is operating properly and is ready for use. If the red light stays on, the tool is faulty, and another one must be used for the procedure.
  4. Disconnect the tool clips and connectors from the protector handles and the battery.

Scheme 274

Scheme 274: Removal
Scheme 274: Removal

Scheme 275

Scheme 275
Scheme 275

Scheme 276

Scheme 276
Scheme 276
  1. Set the front wheels are aligned straight ahead.
  2. Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-360074-S34095844792010042600000) ), then wait at least 3 minutes before starting work.
  3. Remove the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(ref-360084-S33647640922010042600000) ).
  4. Disconnect the cable reel connector C (20P) on the cable reel subharness from the cable reel (A).
  5. Loosen the steering wheel bolt (B) three turns.
  6. Install a commercially available steering wheel puller on the steering wheel (see step 5 on 1 «STEERING WHEEL REMOVAL»(ref-360060-S07211135332010042600000) ).
  7. Remove the steering wheel puller, then remove the steering wheel bolt and steering wheel from the steering column.
  8. Remove the upper and lower column covers (see «COLUMN COVER REMOVAL/INSRALLATION»(ref-360087-S08368203492010042600000) ).
  9. Disconnect the cable reel connector B (4P) on the dashboard wire harness and cable reel connector A (20P) on the dashboard wire harness from the cable rest (C).
  10. Release the upper lock tab (A) under the cable reel connector with a 90 ° hook shaped tool (B). Slide the tool below the cable reel connector just above the lock tab. Release the lower lock tab (C), and slide the cable reel off the column.

Scheme 277

Scheme 277: Installation
Scheme 277: Installation

Scheme 278

Scheme 278
Scheme 278

Scheme 279

Scheme 279
Scheme 279

Scheme 280

Scheme 280
Scheme 280

Scheme 281

Scheme 281
Scheme 281
  1. Before installing the steering wheel, make sure the front wheels are aligned straight ahead.
  2. Set the turn signal canceling sleeve (A) so that the projections (B) are aligned vertically.
  3. Carefully install the cable reel (C) on the steering column shaft. Then connect the cable reel connector A (20P) on the dashboard wire harness and cable reel connector B (4P) on the dashboard wire harness to the cable reel.
  4. Install the upper and lower column covers (see «COLUMN COVER REMOVAL/INSRALLATION»(ref-360087-S08368203492010042600000) ).
  5. Before installing the steering wheel, make sure the front wheels are pointing ahead, then center the cable reel (A). Do this by first rotating the cable reel clockwise until it stops. Then rotate it counterclockwise (about three turns) until the arrow mark (B) on the cable reel label points straight up.
  6. Position the two tabs (A) of the turn signal canceling sleeve (B) as shown, and install the steering wheel on to the steering column shaft, making sure the steering wheel hub (C) engages the pins (D) of the cable reel and tabs of the turn signal canceling sleeve. Do not tap on the steering wheel or steering column shaft when installing the steering wheel.
  7. Install the steering wheel bolt (A), and tighten it to the specified torque, then connect the cable reel connector C (20P) (B) to the cable reel. Make sure the wire harness is routed and fastened properly.
  8. Install the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(ref-360084-S33647640922010042600000) ).
  9. Do the battery terminal reconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-360074-S34095844792010042600000) ).
  10. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(ref-360084-S05721145092010042600000) ).
  11. After installing the cable reel, confirm proper system operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Make sure the horn and turn signal switches work properly. Make sure the steering wheel switches work properly. Make sure the horn works properly.
  12. After installation, check the steering wheel spoke angle. If the steering spoke angles to the right and left are not equal (steering wheel is not centered), correct the engagement of the wheel/column shaft splines.

Scheme 282

Scheme 282: Removal
Scheme 282: Removal

Scheme 283

Scheme 283
Scheme 283

Scheme 284

Scheme 284
Scheme 284

Scheme 285

Scheme 285
Scheme 285
  1. Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-360074-S34095844792010042600000) ), then wait at least 3 minutes before starting work.
  2. Remove the driver's and passenger's dashboard center lower covers (see «WITH NAVIGATION SYSTEM»(ref-360087-S34319023992010042600000) ).
  3. Remove the clips (A), then remove the left and right heater ducts (B, C).
  4. Disconnect SRS unit connectors A (39P) and B (39P) from the SRS unit (C). NOTE: The SRS unit connectors have lever locks. Release the locks before disconnecting the connectors (see «LEVER-LOCKED CONNECTOR»(ref-360084-S21500200682010042600000) ).
  5. Remove the TORX bolts (A) using a TORX T30 bit.
  6. Remove the TORX bolt (A) using a TORX T30 bit.
  7. Remove the SRS unit (B) from the driver's side.

Scheme 286

Scheme 286: Installation
Scheme 286: Installation

Scheme 287

Scheme 287
Scheme 287

Scheme 288

Scheme 288
Scheme 288

Scheme 289

Scheme 289
Scheme 289
  1. Install the SRS unit (A) with a new TORX bolt (B) using a TORX T30 bit. NOTE: Be sure the SRS unit is sitting squarely against it's bracket before torquing the TORX bolt.
  2. Install the new TORX bolts (A) using a TORX T30 bit.
  3. Connect the SRS connectors A (39P) and B (39P) to the SRS unit (C); push them into position until they click and the lever locks are fully secured (see «LEVER-LOCKED CONNECTOR»(ref-360084-S21500200682010042600000) ).
  4. Install the left and right heater joint ducts (A, B), then install the clips (C).
  5. Do the battery terminal reconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-360074-S34095844792010042600000) ).
  6. Make sure the SRS unit has the latest software. If it does not have the latest, update the software in the SRS unit (see «SRS UNIT UPDATE»(ref-360084-S01561101962010042600000) ).
  7. Do the ODS unit initialization (see «ODS UNIT INITIALIZATION»(ref-360084-S15395049012010042600000) ).
  8. Check the operation of the ODS unit with the HDS (see «ODS UNIT OPERATION CHECK»(ref-360084-S29341467952010042600000) ).
  9. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.
  10. Reinstall all removed parts.

Scheme 290

Scheme 290: Removal
Scheme 290: Removal
  1. Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-360074-S34095844792010042600000) ), then wait at least 3 minutes before starting work.
  2. Remove the B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(ref-360104-S31903845592010042600000) ).
  3. Disconnect the side impact sensor (first) 4P connector (A) on the SRS floor wire harness.
  4. Remove the TORX bolt (B) using a TORX T30 bit, then remove the side impact sensor (first) (C).

Scheme 291

Scheme 291: Installation
Scheme 291: Installation
  1. Install the side impact sensor (first) (A) with a new TORX bolt (B), using a TORX T30 bit. Connect the side impact sensor (first) 4P connector (C) on the SRS floor wire harness.
  2. Do the battery terminal reconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-360074-S34095844792010042600000) ).
  3. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(ref-360084-S05721145092010042600000) ).
  4. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.
  5. Reinstall all removed parts.

Scheme 292

Scheme 292: Removal
Scheme 292: Removal
  1. Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-360074-S34095844792010042600000) ), then wait at least 3 minutes before starting work.
  2. Remove the seat side bolster (see «SEAT SIDE BOLSTER»(ref-360101-S22776350772010042600000) ).
  3. Disconnect the side impact sensor (second) 2P connector (A) on the SRS floor wire harness.
  4. Remove the TORX bolt (B) using a TORX T30 bit, then remove the side impact sensor (second) (C).

Scheme 293

Scheme 293: Installation
Scheme 293: Installation
  1. Install the side impact sensor (second) (A) with a new TORX bolt (B), using a TORX T30 bit. Connect the side impact sensor (second) 2P connector (C) on the SRS floor wire harness.
  2. Do the battery terminal reconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-360074-S34095844792010042600000) ).
  3. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(ref-360084-S05721145092010042600000) ).
  4. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.
  5. Reinstall all removed parts.

Scheme 294

Scheme 294: Removal
Scheme 294: Removal
  1. Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-360074-S34095844792010042600000) ), then wait at least 3 minutes before starting work.
  2. Remove the rear seat cushion (see «REAR SEAT CUSHION COVER REPLACEMENT»(ref-360101-S01210307882010042600000) ).
  3. Disconnect the rear safing sensor 2P connector (A).
  4. Remove the TORX bolt (B) using a TORX T30 bit, then remove the rear safing sensor (C).

Scheme 295

Scheme 295: Installation
Scheme 295: Installation
  1. Install the rear safing sensor (A) with a new TORX bolt (B), using a TORX T30 bit. Connect the rear safing sensor 2P connector (C).
  2. Do the battery terminal reconnection procedure (see «REMOVAL»(ref-360103-S14131928852010042600000) ).
  3. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(ref-360084-S05721145092010042600000) ).
  4. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.
  5. Reinstall all removed parts.
