Memorizing a Seat and Mirror Position
Move the seat and the mirrors to the desired position. Turn the ignition switch to ON (II).
Press and hold the SET button on the driver's position memory switch. A single beep is heard and both of the green LEDs begin to flash. Press No. 1 or No. 2 to match the remote that is to be used. There are two beeps confirming that the seat and the mirror are memorized. The green LED remains lit, unless the seat and the mirrors are moved from the memorized position.
Memorized Position Recall With the Remotes
After the seat and the mirror positions are memorized, the seat and mirror move to the position when the appropriate remote UNLOCK button is pressed and the driver's door is opened. When the seat and the mirrors move to the memorized position, the green LED corresponding with that remote stays lit until the position is changed or the key is turned to LOCK (0).
Scheme 275
Power Seat Position Sensors
Each motor has a sensor that detects motor rotation and sends a pulse to the power seat control unit when the motor rotates. The control unit stores the number of pulses in its memory, and the seat position is memorized.
Power Mirror Position Sensors
Using of a tilt position sensor and a swing position sensor, the power mirror control circuit in the power mirror control unit detects the voltage changes created by the mirrors moving. These voltage changes are stored in memory, and the power mirror positions are memorized for each stored driving position.
Reverse Mirror Control
When the vehicle is shifted to R or reverse (shift lever in R or reverse) with the power mirror selector switch in the Left (or Right) position, the driver's (or the passenger's) side mirror tilts down automatically to help the driver's view. The mirror returns to the previous position when the shift lever is shifted out of R or reverse. The reverse mirror control is cancelled if the power mirror selector switch is in the center position.
Power Door Lock Settings
The power door lock setting are customizable by the customer according to their preferences (refer to the Owner's Manual under door locks for more details). These setting are controlled independently by remotes (Driver 1 and Driver 2).
