Interior Lighting System (V6): Overview Honda Crosstour I

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

1. Turn the map light switch OFF.
2. Carefully pry the lens (A) off with a small screwdriver. Individual Map Light: 8 W x 2
3. Remove the screws, then remove the individual map lights (B).
4. Disconnect the connectors (C) from the map lights.
5. Check for continuity between the terminals in each switch position according to the table.
6. If the continuity is not as specified, check the bulb(s) (D). If the bulb(s) are OK, replace the map light.
7. Install the light in the reverse order of removal.
