Under-Hood Fuse/Relay Box
| Socket | Ref | Terminals | Connects to |
|---|---|---|---|
| A (electrical load detector (ELD)) | 11 | 3 | Left engine compartment wire harness (engine compartment branch) (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) (BD) ) |
| A/C compressor clutch relay | 16 | 4 | |
| A/C condenser fan motor relay | 7 | 4 | |
| B (Relay circuit board) | 14 | 14 | Left engine compartment wire harness (engine compartment branch) (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) (BD) ) |
| Blower motor relay | 1 | 4 | |
| D (Relay circuit board) | 13 | 10 | Left engine compartment wire harness (engine compartment branch) (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) (BD) ) |
| Electronic throttle control system (ETCS) control relay | 6 | 4 | |
| ELD | 12 | 3 | Connector A (3P) |
| Horn relay | 2 | 4 | |
| Ignition coil relay | 5 | 4 | |
| PGM-FI main relay 1 | 3 | 4 | |
| PGM-FI subrelay | 4 | 4 | |
| Rear window defogger relay | 8 | 4 | |
| Relay circuit board | 14 | Connector B (14P) and Connector D (10P) | |
| T1 | 15 | Starter cable (see CONNECTOR TO HARNESS INDEX ) | |
| T102 | 10 | Engine wire harness (see KNOCK SENSOR SUBHARNESS (ED) ) |
UNDER-HOOD FUSE/RELAY BOX REFERENCE
