Active Control Engine Mount (Acm) System (V6): Overview Honda Crosstour I

Mechanical 4 illustrations ~150 words

Scheme 176

Scheme 176: Component Location Index

Overview

The active control engine mount (ACM) system reduces the amount of engine vibration (that creates engine noise) which is transmitted to the passenger's compartment.

The ACM system consists of the engine mount actuators, the engine mount control unit, and the powertrain control module (PCM).

The PCM sends the crankshaft position (CKP) sensor information and the camshaft position (CMP) sensor information to the engine mount control unit. The engine mount control unit uses this information to predict the amount of vibration created by the engine.

The engine mount control unit sends current for driving the ACM actuator to the actuator to the actuator and it operates the plunger to reduce the amount of engine vibration.

Scheme 177

Scheme 177: Overview

Scheme 178

Scheme 178: Wire Side Of Female Terminals
CavityWire ColorTerminal NameConnects to
1GRNSOLRMRear engine mount actuator
2WHTSOLRPRear engine mount actuator
3BLUSOLFPFront engine mount actuator
4BLKPGBody ground to G302
5REDSOLFMFront engine mount actuator
6YELIGSOLNo. B14 (10 A) fuse in the driver's under-dash fuse/relay box
7REDCMPPCM (CMPOUT)
8*BRNSCPAPCM (CSSAMA)
9YELIG1No. B7 (15 A) fuse in the driver's under-dash fuse/relay box
10*LT BLUSCPCPCM (CSSAMC)
11BLKLGBody ground to G302
12PURCKPPCM (CKPOUT)
13WHTF-CAN HPCM (F-CAN H)
14Not usedNot used
15REDF-CAN LPCM (F-CAN L)
16BRNSOLRLYNo. B7 (15 A) fuse in the driver's under-dash fuse/relay box

ENGINE MOUNT CONTROL UNIT 16P CONNECTOR REFERENCE

*: '10 Model

Scheme 179

Scheme 179: Circuit Diagram
