Scheme 37
Scheme 38
Scheme 39
Scheme 40
Cargo Area Light (OFF Timer Operation)
The driver's MICU controls the cargo area light OFF timer based on tailgate actuator latch switch inputs.
| Input | Output | |
|---|---|---|
| Driver's MICU | Tailgate actuator latch switch | Cargo area lights |
Rear Window Defogger Timer Operation (With Climate Control)
The driver's MICU controls the rear window defogger timer based on ignition switch and rear window defogger switch inputs.
| Input | Output | |
|---|---|---|
| Driver's MICU | Ignition switch (IG1) | Rear window defogger relay |
| B-CAN | Rear window defogger switch |
Rear Window Defogger Timer Operation (Without Climate Control)
The driver's MICU controls the rear window defogger timer based on ignition switch and rear window defogger switch inputs.
| Input | Output | |
|---|---|---|
| Driver's MICU | Ignition switch (IG1) Rear window defogger switch | Rear window defogger relay |
Answer Back Response Operation
The driver's MICU controls the lighting system and horns based on keyless signals sent by B-CAN.
| Input | Output | |
|---|---|---|
| Driver's MICU | Headlight (low beam) Parking light Side marker light Taillights License plate lights Horns | |
| B-CAN | ANSWER BACK signal | Parking light Horn relay |
Door Lock Response Operation
The driver's MICU controls the door lock actuators LOCK, UNLOCK, DRIVER'S UNLOCK, TAILGATE UNLOCK based on B-CAN door lock switch signals.
| Input | Output | |
|---|---|---|
| Driver's MICU | Driver's door lock actuator (UNLOCK) Door lock actuators (LOCK) Door lock actuators (UNLOCK) Tailgate release actuator | |
| B-CAN | Door lock switch signals |
Auto Power Door Locks (LOCK Operation)
The driver's MICU controls the door lock actuators based on inputs from each switch.
| Input | Output | |
|---|---|---|
| Driver's MICU | IG1 power supply Transmission range switch (P position) Driver's door switch Left rear door switch Tailgate latch switch Left rear door lock knob switch (LOCK) | Door lock actuators (LOCK) |
| B-CAN | Front passenger's door switch Right rear door switch Driver's door lock knob switch (LOCK) Front passenger's door lock knob switch (LOCK) Right rear door lock knob switch (LOCK) Vehicle speed pulse signal Engine speed signal | Door lock actuators (LOCK) |
Auto Power Door Locks (UNLOCK Operation)
The driver's MICU controls the door lock actuators based on inputs from each switch.
| Input | Output | |
|---|---|---|
| Driver's MICU | IG1 power supply Transmission range switch (P position) Driver's door switch Left rear door switch Tailgate latch switch Brake pedal position switch Left rear door lock knob switch (UNLOCK) | Driver's door lock actuators (UNLOCK) Door lock actuators (UNLOCK) |
| B-CAN | Front passenger's door switch Right rear door switch Driver's door lock knob switch (UNLOCK) Front passenger's door lock knob switch (UNLOCK) Right rear door lock knob switch (UNLOCK) | Door lock actuators (UNLOCK) |
Washer Operation
The passenger's MICU controls the windshield washer motor and rear window washer motor based on inputs from the wiper switch.
| Input | Output | |
|---|---|---|
| Passenger's MICU | IG1 power supply | Rear window wiper motor relay Rear window washer motor relay Windshield washer motor relay |
| B-CAN | Rear window washer switch signal Windshield washer switch signal | Rear window washer motor relay signal Windshield washer motor relay signal |
