Fuse/relay Boxes: Removal & Installation Honda CR-V IV

Fuses & Circuit Breakers 19 illustrations ~1090 words

Removal

SRS components are located in this area. Review the SRS COMPONENT LOCATIONS and the PRECAUTIONS AND PROCEDURES before doing repairs or service.

Scheme 37

Scheme 37: Removal
Scheme 37: Removal

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42
  1. Battery Terminal (SRS) - Disconnection Make sure the ignition switch is in LOCK (0). Disconnect and isolate the negative cable (A) from the battery. NOTE: Always disconnect the negative side first. Disconnect the positive cable (B) from the battery. Wait at least 3 minutes before starting work.
  2. Driver's Dashboard Undercover Turn the lock knob (A) 90 °, then gently pull down the front edge of the driver's dashboard undercover (B) to detach the clip (C). Pull away the undercover to release the pin (D) from the holder (E), then remove the driver's dashboard undercover.
  3. Driver's Dashboard Panel Assembly Carefully pry out the driver's dashboard panel assembly (A) with the appropriate trim tool to detach the clips (B). Disconnect the connector (C), then remove the driver's dashboard panel assembly.
  4. Driver's Dashboard Lower Cover Carefully pry out the driver's dashboard lower cover (A) with the appropriate trim tool to detach the clips (B). Disconnect the connector (C), then remove the driver's dashboard lower cover.
  5. Under-Dash Fuse/Relay Box Disconnect the connectors from the fuse side of the under-dash fuse/relay box (A). Detach the under-dash fuse/relay box. Disconnect the connectors from the back side of the under-dash fuse/relay box, then remove the under-dash fuse/relay box. Carefully remove the relays using a relay puller. NOTE: Do not use pliers. Pliers will damage the relays, which could cause the engine to stall or not start or cause other functions to fail.
  6. Under-Dash Fuse/Relay Box - Canada models Disconnect the connectors from the fuse side of the under-dash fuse/relay box (A). Remove the covers (B) from the under-dash fuse/relay box. Detach the under-dash fuse/relay box. Disconnect the connectors from the back side of the under-dash fuse/relay box, then remove the under-dash fuse/relay box. Carefully remove the relays using a relay puller. NOTE: Do not use pliers. Pliers will damage the relays, which could cause the engine to stall or not start or cause other functions to fail.

Installation

SRS components are located in this area. Review the SRS COMPONENT LOCATIONS and the PRECAUTIONS AND PROCEDURES before doing repairs or service.

Scheme 43

Scheme 43: Installation
Scheme 43: Installation

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49
  1. Under-Dash Fuse/Relay Box - Canada models NOTE: The imoes unit is built into the MICU, which is part of the under-dash fuse/relay box. Because of this construction, the imoes must be registered, or the vehicle will not start. Install the relays in the under-dash fuse/relay box (A). Connect the connectors to the back side of the under-dash fuse/relay box. Install the under-dash fuse/relay box. Install the covers (B) to the under-dash fuse/relay box. Connect the connectors to the fuse side of the under-dash fuse/relay box.
  2. Under-Dash Fuse/Relay Box NOTE: The imoes unit is built into the MICU, which is part of the under-dash fuse/relay box. Because of this construction, the imoes must be registered, or the vehicle will not start. Install the relays in the under-dash fuse/relay box (A). Connect the connectors to the back side of the under-dash fuse/relay box. Install the under-dash fuse/relay box. Connect the connectors to the fuse side of the under-dash fuse/relay box.
  3. Driver's Dashboard Lower Cover Connect the connector (A), then install the driver's dashboard lower cover (B). Make sure the clips (C) snap into place securely.
  4. Driver's Dashboard Panel Assembly Connect the connector (A), then install the driver's dashboard panel assembly (B). Make sure the clips (C) snap into place securely.
  5. Driver's Dashboard Undercover Install the driver's dashboard undercover (A). Make sure the clip (B) snap into place securely, and the pin (C) into the holder (D) securely. Turn the lock knob (E) 90 °.
  6. Battery Terminal (SRS) - Reconnection NOTE: If the battery performance is abnormal, test the battery. Clean the battery terminals. Connect the positive cable (A) to the battery. NOTE: Always connect the positive side first. Connect the negative cable (B) to the battery. Apply multipurpose grease to the terminals to prevent corrosion.
  7. HDS DLC - Connection Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard. Turn the ignition switch to ON (II). Make sure the HDS communicates with the vehicle. If it does not communicate, go to the DLC circuit troubleshooting.
  8. Under-Dash Fuse/Relay Box After Installation Check Select IMMOBI from the SYSTEM SELECTION MENU, then select IMMOBILIZER SET UP. Select REPLACE MPCS/MICU/IMOES, then select the suitable menu from the HDS indications. After registration, confirm that the vehicle will start. Confirm that all system work properly.

Scheme 50

Scheme 50: Removal
Scheme 50: Removal

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52
  1. Battery Terminal (SRS) - Disconnection Make sure the ignition switch is in LOCK (0). Disconnect and isolate the negative cable (A) from the battery. NOTE: Always disconnect the negative side first. Disconnect the positive cable (B) from the battery. Wait at least 3 minutes before starting work.
  2. Relay Control Module Remove the cover (A). Remove the relay control module (B) from the under-hood fuse/relay box. Disconnect the relay control module connectors.
  3. Under-Hood Fuse/Relay Box Assembly NOTE: The under-hood fuse/relay box is a part of the engine compartment wire harness, and it cannot be replaced by itself. Remove the alternator and battery cable (A) from the under-hood fuse/relay box (B). Release the tabs (C), then detach the under-hood fuse/relay box. Remove the bottom cover (D) and connector from the under-hood fuse/relay box. Carefully remove the relays using a relay puller. NOTE: Do not use pliers. Pliers will damage the relays, which could cause the engine to stall or not start or cause other functions to fail.

Scheme 53

Scheme 53: Installation
Scheme 53: Installation

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55
  1. Under-Hood Fuse/Relay Box Assembly NOTE: The under-hood fuse/relay box is a part of the engine compartment wire harness, and it cannot be replaced by itself. Install the relays, connector, and bottom cover (A) to the under-hood fuse/relay box (B). Install the under-hood fuse/relay box. Install the alternator and battery cable (C) to the under-hood fuse/relay box.
  2. Relay Control Module Connect the relay control module connectors. Install the relay control module (A) to the under-hood fuse/relay box. Install the cover (B).
  3. Battery Terminal (SRS) - Reconnection NOTE: If the battery performance is abnormal, test the battery. Clean the battery terminals. Connect the positive cable (A) to the battery. NOTE: Always connect the positive side first. Connect the negative cable (B) to the battery. Apply multipurpose grease to the terminals to prevent corrosion.
