Fuse/relay Boxes: Overview Honda CR-V IV

Fuses & Circuit Breakers 11 illustrations ~149 words

Scheme 1

Scheme 1: Removal
Scheme 1: Removal

Scheme 2

Scheme 2
Scheme 2
  1. Battery Terminal - Disconnection Make sure the ignition switch is in LOCK (0). Disconnect and isolate the negative cable (A) from the battery. NOTE: Always disconnect the negative side first. Disconnect the positive cable (B) from the battery.
  2. ELD Remove the ELD (A).

Scheme 3

Scheme 3: Installation
Scheme 3: Installation

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5
  1. ELD Install the ELD (A).
  2. Battery Terminal - Reconnection NOTE: If the battery performance is abnormal, test the battery. Clean the battery terminals. Connect the positive cable (A) to the battery. NOTE: Always connect the positive side first. Connect the negative cable (B) to the battery. Apply multipurpose grease to the terminals to prevent corrosion.
Ref. No.Connector NameMale/FemaleConnector TypeNotes
ACenter Junction Box Connector A (6P)MaleComponent Connector
BCenter Junction Box Connector B(6P)MaleComponent Connector
CCenter Junction Box Connector C(8P)MaleComponent Connector
ECenter Junction Box Connector E (1 OP)MaleComponent Connector
FCenter Junction Box Connector F(8P)MaleComponent Connector
GCenter Junction Box Connector G (1 OP)MaleComponent Connector
HCenter Junction Box Connector H (1 OP)MaleComponent Connector

CONNECTOR DESCRIPTION

Scheme 6

Scheme 6
Scheme 6
Ref. No.Connector NameMale/FemaleConnector TypeNotes
ADriver's Junction Box 1 Connector A (4P)MaleComponent Connector
BDriver's Junction Box 1 Connector B(4P)MaleComponent Connector
CDriver's Junction Box 1 Connector C (4P)MaleComponent Connector
DDriver's Junction Box 1 Connector D (6P)MaleComponent Connector
EDriver's Junction Box 1 Connector E (6P)MaleComponent Connector
FDriver's Junction Box 1 Connector F(6P)MaleComponent Connector
GDriver's Junction Box 1 Connector G (6P)MaleComponent Connector
HDriver's Junction Box 1 Connector H (4P)MaleComponent Connector
JDriver's Junction Box 1 Connector J (8P)MaleComponent Connector
KDriver's Junction Box 1 Connector K (10P)MaleComponent Connector

CONNECTOR DESCRIPTION

Scheme 7

Scheme 7
Scheme 7
Ref. No.Connector NameMale/FemaleConnector TypeNotes
ADriver's Junction Box 2 Connector A (4P)MaleComponent Connector
BDriver's Junction Box 2 Connector B (4P)MaleComponent Connector
CDriver's Junction Box 2 Connector C (4P)MaleComponent Connector
DDriver's Junction Box 2 Connector D (6P)MaleComponent Connector
EDriver's Junction Box 2 Connector E (6P)MaleComponent Connector
FDriver's Junction Box 2 Connector F (6P)MaleComponent Connector
GDriver's Junction Box 2 Connector G (6P)MaleComponent Connector
HDriver's Junction Box 2 Connector H (4P)MaleComponent Connector
JDriver's Junction Box 2 Connector J (8P)MaleComponent Connector
KDriver's Junction Box 2 Connector K (10P)MaleComponent Connector

CONNECTOR DESCRIPTION

Scheme 8

Scheme 8
Scheme 8
Ref. No.AmpsNotes
B107.5A
B1120A
B1220A
B1420A
B1510A
B1620A
B1720A
B197.5A
B210A
B207.5A
B217.5A
B227.5A
B2310A
B247.5A
B2510A
B2720A
B2815A
B297.5A
B310A
B3010A
B3215A
B3315A
B3410A
B357.5A
B3715A
B3810A
B3910A
B415A
B407.5A
B4120A
B4220A
B4320A
B4420A
B4520A
B510A
B67.5A
B77.5A
B815A
B915A

FUSE DESCRIPTION

Ref. No.Relay NameNotes
L1PGM-FI Main Relay 2
L2Front Accessory Power Socket Relay
L3Starter Cut Relay
L4ETCS Control Relay
L5PGM-FI Main Relay 1
L6Power Window Relay

RELAY DESCRIPTION

Ref. No.Connector NameMale/FemaleConnector TypeNotes
AUnder-Dash Fuse/Relay Box Connector A (5P)MaleComponent Connector
BUnder-Dash Fuse/Relay Box Connector B (44P)MaleComponent Connector
CUnder-Dash Fuse/Relay Box Connector C (38P)MaleComponent Connector
DUnder-Dash Fuse/Relay Box Connector D (32P)MaleComponent Connector
GUnder-Dash Fuse/Relay Box Connector G (3P)MaleComponent Connector

CONNECTOR DESCRIPTION

Scheme 9

Scheme 9
Scheme 9
Ref. No.Component NameNotes
288Driver's MICU

COMPONENT DESCRIPTION

Ref. No.Connector NameMale/FemaleConnector TypeNotes
HUnder-Dash Fuse/Relay Box Connector H (4P)MaleComponent Connector
KUnder-Dash Fuse/Relay Box Connector K (12P)MaleComponent Connector
MUnder-Dash Fuse/Relay Box Connector M (7P)MaleComponent Connector
NUnder-Dash Fuse/Relay Box Connector N (13P)MaleComponent Connector
PUnder-Dash Fuse/Relay Box Connector P (20P)MaleComponent Connector
QUnder-Dash Fuse/Relay Box Connector Q (16P)MaleComponent Connector
RUnder-Dash Fuse/Relay Box Connector R (8P)MaleComponent Connector
SUnder-Dash Fuse/Relay Box Connector S (10P)MaleComponent Connector
TUnder-Dash Fuse/Relay Box Connector T (20P)MaleComponent Connector
WUnder-Dash Fuse/Relay Box Connector W (24P)MaleComponent Connector
XUnder-Dash Fuse/Relay Box Connector X (1 OP)MaleComponent Connector

CONNECTOR DESCRIPTION

Scheme 10

Scheme 10
Scheme 10
Ref. No.AmpsNotes
A1-170A
A1-340A
A1-420A
A1-530A
A1-6100A
A107.5A
A117.5A
A1220A
A1320A
A1410A
A1510A
A1610A
A1715A
A1815A
A2-150A
A2-1020A
A2-1120A
A2-260A
A2-360A
A2-430A
A2-630A
A2-840A
A2-930A
A2215A
A2315A
A2415A
A2515A
A2620A
A277.5A
A287.5A
A2910A
A87.5A

FUSE DESCRIPTION

Ref. No.Relay NameNotes
M1Blower Motor Relay
M3A/C Condenser Fan Relay
M4Ignition Coil Relay
M5Front Fog Light Relay
M6PGM-FI Subrelay
M7Rear Window Defogger Relay

RELAY DESCRIPTION

Ref. No.Component NameNotes
235ELD
237Fan Control Relay
243Horn Relay
250Radiator Fan Relay
251A/C Compressor Clutch Relay
252Relay Circuit Board
289Diode B
290Diode A

COMPONENT DESCRIPTION

Ref. No.Connector NameMale/FemaleConnector TypeNotes
T1T1Component Connector
T101T101Component Connector

CONNECTOR DESCRIPTION

Scheme 11

Scheme 11
Scheme 11
Ref. No.Connector NameMale/FemaleConnector TypeNotes
EJ09ELD 3P ConnectorFemaleComponent Connector
EJ28Relay Holder AComponent Connector
EJ29Relay Holder BComponent Connector
EJ30Relay Holder CComponent Connector
EJ31Relay Circuit Board Connector A (16P)FemaleComponent Connector
EJ32Relay Circuit Board Connector B (1 OP)FemaleComponent Connector

CONNECTOR DESCRIPTION
