Pgm-Fi System (K24Z1): Removal & Installation Honda CR-V III рестайлинг

A/F Sensor Replacement

Special Tools Required

O2 Sensor Wrench Snap-on S3176 or equivalent, commercially available

Scheme 206

1. Disconnect the A/F sensor 4P connector (A), then remove the A/F sensor (B).
2. Install the parts in the reverse order of removal.

Secondary HO2S Replacement

Special Tools Required

O2 Sensor Wrench Snap-on S3176 or equivalent, commercially available

Scheme 207

1. Disconnect the secondary HO2S 4P connector (A), then remove the secondary HO2S (B).
2. Install the parts in the reverse order of removal.

Scheme 208

1. Remove the EGR valve (see «EGR VALVE REPLACEMENT»(ref-371388-S34303206542010091000000) ).
2. Disconnect the CMP sensor B connector (A).
3. Remove CMP sensor B (B).
4. Install the parts in the reverse order of removal with a new O-ring (C).

Scheme 209

1. Disconnect the CKP sensor connector (A).
2. Remove the CKP sensor (B).
3. Install the parts in the reverse order of removal with a new O-ring (C).
4. Do the CKP pattern clear/CKP pattern learn procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(ref-371340-S26102443592010091000000) ).

Scheme 210

1. Disconnect the MAP sensor connector (A).
2. Remove the MAP sensor (B).
3. Install the parts in the reverse order of removal with a new O-ring (C).

Scheme 211

1. Disconnect the MAF sensor/IAT sensor connector (A).
2. Remove the screws (B).
3. Remove the MAF sensor/IAT sensor (C).
4. Install the parts in the reverse order of removal with a new O-ring (D).

Scheme 212

1. Drain the engine coolant (see «COOLANT CHECK»(ref-371337-S12927460352010091000000) ).
2. Remove the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(ref-371350-S29576328562010091000000) ).
3. Disconnect the ECT sensor 1 connector (A).
4. Remove ECT sensor 1 (B).
5. Install the parts in the reverse order of removal with a new O-ring (C), then refill the radiator with engine coolant (see «COOLANT CHECK»(ref-371337-S12927460352010091000000) ).

Scheme 213

1. Remove the splash shield.
2. Drain the engine coolant (see «COOLANT CHECK»(ref-371337-S12927460352010091000000) ).
3. Disconnect the ECT sensor 2 connector (A), then remove ECT sensor 2 (B).
4. Install ECT sensor 2 with a new O-ring (C).
5. Install the splash shield.
6. Refill the radiator with engine coolant (see «COOLANT CHECK»(ref-371337-S12927460352010091000000) ).

Scheme 214

1. Lift the vehicle, and support it with jackstands.
2. Disconnect the knock sensor connector (A).
3. Remove the knock sensor (B).
4. Install the parts in the reverse order of removal.

PCM Replacement

Special Tools Required

1. Honda Diagnostic System (HDS) tablet tester
2. Honda Interface Module (HIM) and an iN workstation with the latest HDS software version
3. HDS pocket tester
4. GNA600 and an iN workstation with the latest HDS software version

Any one of the above updating tools can be used.

Note. Make sure the HDS is loaded with the latest software version. If you are replacing the PCM after substituting a known-good PCM, reinstall the original PCM, then do this procedure. During the procedure, if any READ DATA, WRITE DATA, or other data checks fail, note the failure, then continue.

Scheme 215

Scheme 216

Scheme 217

1. Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard.
2. Turn the ignition switch to ON (II).
3. Make sure the HDS communicates with the PCM and other vehicle systems. If it doesn't, go to the DLC circuit troubleshooting (see «DLC Circuit Troubleshooting»(ref-371341-S10753660292010091000000) ). If you are returning from DLC circuit troubleshooting, skip steps 4 through 9, 19 through 25, and 28 through 30, and do this after replacing the PCM; Replace the engine oil (see «ENGINE OIL REPLACEMENT»(ref-371342-S30440727742010091000000) ) and the engine oil filter (see «ENGINE OIL FILTER REPLACEMENT»(ref-371342-S26106735712010091000000) ). Replace the ATF (see «ATF REPLACEMENT»(ref-371338-S09977727542010091000000) ). Clean the throttle body (see «THROTTLE BODY CLEANING»(ref-371350-S15298715792010091000000) ).
4. Select the PGM-FI system with the HDS.
5. Select the INSPECTION MENU with the HDS.
6. Select the ETCS TEST, then select the TP POSITION CHECK, and follow the screen prompts. NOTE: If the TP POSITION CHECK indicates FAILED, continue with this procedure.
7. Select the REPLACE PCM MENU, then select READ DATA and follow the screen prompts. NOTE: Doing this step copies (READS) the engine oil life data from the original PCM so you can later download (WRITES) it into the new PCM. If READ DATA indicates FAILED, continue with this procedure.
8. Select the A/T system with the HDS.
9. Select the REPLACE TCM/PCM MENU, then select READ DATA and follow the screen prompts. NOTE: Doing this step copies (READS) the ATF life data from the original PCM so you can later download (WRITES) it into the new PCM. If READ DATA indicates FAILED, continue with this procedure.
10. Turn the ignition switch to LOCK (0).
11. Remove the under-hood fuse/relay box (A).
12. Remove the harness bracket (B).
13. Loosen the battery hold down bolt (D), and reposition the battery away from the PCM.
14. Remove the PCM cover (C).
15. Remove the bolts (D), then remove the PCM (E).
16. Disconnect PCM connectors A, B, and C. NOTE: PCM connectors A, B, and C have symbols (A=•, B=delta, C=o) embossed on them for identification.
17. Install the parts in the reverse order of removal.
18. Turn the ignition switch to ON (II).
19. Manually input the VIN to the PCM with the HDS. NOTE: DTC P0630 VIN Not Programmed or Mismatch may be stored because the VIN has not been programmed into the PCM; ignore it, and continue this procedure.
20. If the READ DATA (engine oil life) failed in step 8, Go to step 23 . Otherwise, Go to step 21.
21. Select the PGM-FI system with the HDS.
22. Select the REPLACE PCM MENU, then select WRITE DATA, and follow the screen prompts. NOTE: If the WRITE DATA indicates FAILED, continue with this procedure.
23. If the READ DATA (ATF life) failed in step 10, Go to step 25 . Otherwise Go to step 24.
24. Select the A/T SYSTEM with the HDS.
25. Select the REPLACE TCM/PCM MENU, then select WRITE DATA, and follow the screen prompts. NOTE: If the WRITE DATA indicates FAILED, continue with this procedure.
26. Select the IMMOBI system with the HDS.
27. Enter the immobilizer PCM code that you got from the iN, and use the PCM replacement procedure in the IMMOBI MENU of the HDS; it allows you to start the engine.
28. If the TP POSITION CHECK failed in step 6 clean the throttle body (see «THROTTLE BODY CLEANING»(ref-371350-S15298715792010091000000) ), then Go to step 29.
29. If the READ DATA failed in step 7 or the WRITE DATA failed in step 22, replace the engine oil (see «ENGINE OIL REPLACEMENT»(ref-371342-S30440727742010091000000) ), and engine oil filter (see «ENGINE OIL FILTER REPLACEMENT»(ref-371342-S26106735712010091000000) ), then Go to step 30.
30. If the READ DATA failed in step 10 or the WRITE DATA failed in step 25, replace the ATF (see «ATF REPLACEMENT»(ref-371338-S09977727542010091000000) ), then Go to step 31.
31. Select the PGM-FI system, and reset the PCM with the HDS.
32. Update the PCM if it does not have the latest software (see «PCM Update»(ref-371341-S07894970022010091000000) ).
33. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-371367-S09688273002010091000000) ).
34. Do the CKP pattern clear/CKP pattern learn procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(ref-371340-S26102443592010091000000) ).
