Power Windows: Maintenance Honda CR-V II

Resetting the Power Window Control Unit

Resetting the power window control unit is required after performing the following procedures

1. Disconnecting the battery
2. Removing the No. 6 (7.5A) and/or the No. 23 (20A) fuses from the under-dash fuse/relay box.
3. Disconnecting the driver's door wire harness

1. Turn the ignition switch ON (II).
2. Move the driver's window all the way down by holding the driver's switch firmly down; when the window reaches the bottom, hold the driver's window switch firmly down for 2 seconds.
3. Move the driver's window all the way up by holding the driver's switch firmly up; when the window reaches the top, hold the driver's window switch firmly up for 2 seconds.
4. If the window does not work in AUTO, turn the ignition switch OFF and repeat steps 1 through 3.

Scheme 19

Scheme 20

Scheme 21

1. Remove the tailgate lower trim panel (see «TRIM REMOVAL/INSTALLATION - TAILGATE AREA»(ref-171400-S02996671122005020300000) ).
2. Disconnect the 2P connector (A) from the latch switch (B).
3. Check for continuity between the No. 1 and No. 2 terminals. There should be continuity when the hatch glass is open. There should be no continuity when the hatch glass is closed.
4. If the continuity is not as specified, replace the latch switch.

Scheme 22

1. Remove the driver's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(ref-171397-S34595084322005020300000) ).
2. Disconnect the 2P connector from the opener switch.
3. Check for continuity between the No. 1 and No. 2 terminals. There should be continuity when the opener switch is pushed. There should be no continuity when the opener switch is released.
4. If the continuity is not as specified, replace the opener switch.
