Design Specifications
| Item | Measurement | Qualification | Specification |
|---|---|---|---|
| DIMENSIONS | Overall length | 4,537 mm (178.6 in.) | |
| Overall width | 1,782 mm (70.2 in.) | ||
| Overall height | 1,682 mm (66.2 in.) | ||
| Wheelbase | 2,620 mm (103.1 in.) | ||
| Track | Front | 1,533 mm (60.4 in.) | |
| Rear | 1,538 mm (60.6 in.) | ||
| Ground clearance | 205 mm (8.07 in.) | ||
| Seating capacity | Five (5) | ||
| WEIGHT (U.S.A.) | Gross Vehicle Weight Rating (GVWR) | 4,320 lbs | |
| WEIGHT (CANADA) | Gross Vehicle Weight Rating (GVWR) | 1,960 kg | |
| ENGINE | Type | Water cooled, 4-stroke DOHC i-VTEC engine | |
| Cylinder arrangement | Inline 4-cylinder, transverse | ||
| Bore and stroke | 87 x 99 mm (3.43 x 3.90 in.) | ||
| Displacement | 2,354 cm 3 (144 cu in.) | ||
| Compression ratio | 9.6 | ||
| Valve train | Chain drive, DOHC VTEC 4 valves per cylinder | ||
| Lubrication system | Forced, wet sump, with trochoid pump | ||
| Oil pump displacement | At 6,000 rpm | 54.3 l (57.4 US qt)/minute | |
| Water pump displacement | At 6,000 rpm | 82 l (87 US qt)/minute | |
| Fuel required | UNLEADED gasoline with 86 pump octane number or higher | ||
| STARTER | Type | Gear reduction | |
| Normal output | 1.6 kW | ||
| Normal voltage | 12V | ||
| Hour rating | 30 seconds | ||
| Direction of rotation | Clockwise as viewed from gear end | ||
| CLUTCH | Clutch type | M/T | Single plate dry, diaphragm spring |
| A/T | 3-element torque converter with lock-up clutch | ||
| Clutch friction material surface area | M/T | 174 cm 2 (26.97 sq in.) | |
| MANUAL TRANSMISSION | Type | Synchronized, 5-speed forward, 1 reverse | |
| Primary reduction | Direct 1:1 | ||
| Gear ratio | 1st | 3.533 | |
| 2nd | 1.880 | ||
| 3rd | 1.212 | ||
| 4th | 0.921 | ||
| 5th | 0.738 | ||
| Reverse | 3.583 | ||
| Transfer gear | Type | Hypoid gear | |
| Gear ratio | 0.904 | ||
| Final reduction | Type | Single helical gear | |
| Gear ratio | 4.765 | ||
| AUTOMATIC TRANSMISSION | Type | Electronically controlled automatic, 4-speed forward, 1 reverse | |
| Primary reduction | Direct 1:1 | ||
| Gear ratio | 1st | 2.684 | |
| 2nd | 1.535 | ||
| 3rd | 0.974 | ||
| 4th | 0.638 | ||
| Reverse | 2.000 | ||
| Transfer gear | Type | Single helical gear | |
| Gear ratio | 4.765 | ||
| Differential final gears | Type | Single helical gear | |
| Gear ratio | 4.438 | ||
| STEERING | Type | Power-assisted rack and pinion | |
| Overall ratio | 15.06 | ||
| Turns, lock-to-lock | 2.64 | ||
| Steering wheel diameter | 360 mm (14.2 in.) | ||
| SUSPENSION | Type | Front | Independent strut with stabilizer, coil spring |
| Rear | Double wishbone | ||
| Shock absorber | Front | Telescopic, hydraulic, nitrogen gas-filled | |
| Rear | Telescopic, hydraulic, nitrogen gas-filled | ||
| WHEEL ALIGNMENT | Camber | Front | 0° |
| Rear | 1° | ||
| Caster | Front | 1°45' | |
| Total toe | Front | 0 mm (0 in.) | |
| Rear | 2 mm (1/16 in.) | ||
| BRAKES | Type of service brake | Front | Power-assisted self-adjusting ventilated disc |
| Rear | Power-assisted self-adjusting solid disc | ||
| Type of parking brake | Mechanical actuating, rear wheels | ||
| Pad friction surface area | Front | 42 cm 2 (6.5 sq in.) x 2 | |
| Rear | 21 cm 2 , 3.3 sq in.) x 2 | ||
| Shoe friction surface area | Rear | 49.0 cm 2 (7.60 sq in.) x 2 | |
| TIRES | Size | P205/70R15 95S | |
| AIR CONDITIONING | Compressor | Type | Scroll |
| Number of cylinder | |||
| Capacity | 108 m l (6.59 cu in.)/rev. | ||
| Maximum speed | 12,000 rpm | ||
| Lubricant capacity | 130 m l (4 1/3 fl oz) | ||
| Lubricant type | KEIHIN SP-10 (P/N 38897-P13-A01AH or 38899-P13-A01) | ||
| Condenser | Type | Corrugated fin | |
| Evaporator | Type | Corrugated fin | |
| Blower | Type | Radial fan | |
| Motor type | 220 W/12 V | ||
| Speed control | Infinite variable | ||
| Maximum capacity | 480 m 3 (16.900 cu ft)/h | ||
| Temperature control | Air-mix type | ||
| Compressor clutch | Type | Dry, single plate, poly-V belt drive | |
| Electrical power consumption at 68°F (20°C) | 42 W maximum at 12 V | ||
| Refrigerant | Type | HFC-134a (R-134a) | |
| Capacity | 480-530 g (17.0-18.7 oz) | ||
| ELECTRICAL RATINGS | Battery | 12 V - 36 AH/5 hours | |
| Starter | 12 V - 1.1 kW, 1.2 kW | ||
| Alternator | 12 V - 90A | ||
| Fuses | Under-hood fuse/relay box | 100A, 50A, 40A, 30A, 20A, 15A, 10A | |
| Under-dash fuse/relay box | 20A, 15A, 10A, 7.5A | ||
| Light bulbs | Headlight (high beam) | 12 V - 60 W | |
| Headlight (low beam) | 12 V - 55 W | ||
| Front turn signal/ Front side marker lights | 12 V - 21/5 W | ||
| Front parking lights | 12 V - 3 CP | ||
| Rear turn signal lights | 12 V - 21 W | ||
| Taillights | 12 V - 3 CP | ||
| Brake/taillights | 12 V - 21/5 W | ||
| High-mount brake light | 12 V - 21 W | ||
| Back-up lights | 12 V - 21 W | ||
| License plate light | 12 V - 5 W | ||
| Ceiling lights | 12 V - 8 W | ||
| Glove box light | 12 V - 3.4 W | ||
| Spotlights | 12 V - 4 CP | ||
| Gauge lights | 12 V - 1.4 W | ||
| Indicator lights | LED, 12 V - 1.4 W |
Design Specifications Table
