Audio Systems: Removal & Installation Honda CR-V II

Audio Unit Removal/Installation

Note. Put on gloves to protect your hands. Take care not to scratch the dashboard and related parts.

Scheme 3

1. Make sure you have the anti-theft code for the radio, then write down the frequencies for the radio's preset buttons.
2. Remove the dashboard center panel (see «DASHBOARD CENTER PANEL REMOVAL/INSTALLATION»(ref-171400-S41818513292005020300000) ).
3. Remove the four mounting bolts, then remove the audio unit.
4. Disconnect the audio connector (A) and antenna lead (B).
5. Remove the eight mounting bolts securing the audio unit to the audio unit bracket.
6. Install the audio unit in the reverse order of removal, and note these items: Make sure the audio unit connector is plugged in properly, and the antenna lead is connected properly. Enter the anti-theft code for the radio, then enter the customer's radio station presets.

Scheme 4

Scheme 5

Antenna Replacement

Special Tools Required

Antenna nut wrench 07XAA-0010200

Scheme 6

Scheme 7

1. Remove the antenna mast (A).
2. Remove the antenna nut (B), spacer (C) and bushing (D).
3. Disconnect the antenna lead-sublead connector above the passenger's kick panel.
4. Remove the right inner fender.
5. Pull the antenna lead and grommet out of the A-pillar.
6. Remove the antenna housing bracket nut (A).
7. Remove the antenna base assembly.
8. Install the antenna in the reverse order of removal.

Scheme 8

1. Remove the door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(ref-171397-S34595084322005020300000) , «REAR DOOR PANEL REMOVAL/INSTALLATION»(ref-171397-S29512892252005020300000) ).
2. Push down on the clip, then pull the top of the speaker (A) straight out just enough to release the upper clip. If you pull the speaker out too far, you will damage the lower clips (C). Then lift the speaker straight up to release the lower clips.
3. Disconnect the 2P connector (B), and remove the speaker.
4. Install the speaker in the reverse order of removal.

Scheme 9

1. Remove the tweeter speaker grille (A) and tweeter (B) as an assembly.
2. Disconnect the 2P connector (C) from the tweeter.
3. Remove the tweeter speaker grille from the tweeter.
4. Install the tweeter in the reverse order of removal.
