Cooling System: Removal & Installation Honda CR-V II

Water Outlet Replacement

Replace the water outlet (A) with a new O-ring (B).

Scheme 15

Scheme 16

1. Drain the engine coolant (see «Coolant Check»(ref-171732-S30237916252005021000000) ).
2. Remove the bulkhead cover (see «REMOVAL»(ref-171634-S16753421762005021100000) ).
3. Remove the upper bracket cushion, then remove the bulkhead (see «REMOVAL»(ref-171634-S16753421762005021100000) ).
4. Remove the upper radiator hose and lower radiator hose.
5. Disconnect the fan motor connectors and radiator fan switch connector, then lift up the radiator.
6. Remove the fan shroud assemblies and other parts from the radiator.
7. Install the radiator in reverse order of removal. Make sure the upper and lower cushions are set securely.
8. Install the bulkhead in reverse order of removal. Apply body paint to the bulkhead mounting bolts.
9. Fill the radiator with engine coolant and bleed the air from the cooling system with the heater valve open (see step 8 on ).
