Generators & Regulators: Diagnosis Honda CR-V II

Charging System Indicator Test

For charging system indicator test (Scheme 1)

Scheme 1

Alternator And Regulator Circuit Test

For alternator and regulator circuit test see, (Scheme 2).

Scheme 2

Alternator Control System Test

For alternator control system test (Scheme 3)

Scheme 3

Inspection

1. Check whether there is a change in the position of the auto-tensioner indicator before starting the engine and after starting the engine. If there is a change in the position, replace the auto-tensioner. see scheme 2
2. Check for abnormal noise from the tensioner pulley. If abnormal noise is heard, replace the tensioner pulley.
3. Remove the drive belt. See «DRIVE BELT»(ref-153319-S21662332882004060800000).
4. Move the auto-tensioner within its limit with the belt tension release tool in the direction shown. (Scheme 4) Check that the tensioner moves smoothly and without any abnormal noise. If the tensioner does not move smoothly or there is abnormal noise, replace the auto-tensioner.
5. Remove the auto-tensioner. See «REPLACEMENT»(ref-153319-S07005067092004060800000).
6. Install the tensioner pulley.
7. Clamp the auto-tensioner "A" by using two 8 mm bolts "B" and a vise "C". Do not clamp the auto-tensioner itself. (Scheme 5)
8. Set the torque wrench "D" on the pulley bolt.
9. Align the indicator "E" on the tensioner arm with center mark "F" on the tensioner base by using the torque wrench, and measure the torque. If the torque value of 20-36 ft.lbs (27-36 N.m) is out of specification, replace the auto-tensioner.

Scheme 4

Scheme 5
