Cooling System (R18A1 Engine): Component Locations Honda Civic VIII рестайлинг

Component Location Index

Note. Refer to the COOLING SYSTEM (SUPPLEMENTAL) (GX) article for additional information for the GX model.

Scheme 37

Scheme 38

1. Remove the radiator cap (A). Wet the seal with engine coolant, then install it on a commercially available pressure tester (B).
2. Apply a pressure of 93-123 kPa (0.95-1.25 kgf/cm 2 , 14-18 psi).
3. Check for a drop in pressure.
4. If the pressure drops, replace the cap.

Scheme 39

1. Wait until the engine is cool, then carefully remove the radiator cap, and fill the radiator with engine coolant to the top of the filler neck.
2. Attach a commercially available pressure tester (A) to the radiator, and apply a pressure of 93-123 kPa (0.95-1.25 kgf/cm 2 , 14-18 psi).
3. Inspect for engine coolant leaks, and a drop in pressure.
4. Remove the pressure tester.
5. Install the radiator cap.

Scheme 40

1. Disconnect the 2P connectors from the radiator fan motor (A) and condenser fan motor (B).
2. Test each motor by connecting battery power to the No. 2 terminal and ground to the No. 1 terminal.
3. If either motor fails to run, or does not run smoothly, replace it (see «RADIATOR AND FAN REPLACEMENT»(ref-255494-S05124613592007060300000) ).
