Design Specifications
| Item | Measurement | Qualification | Specification |
|---|---|---|---|
| DIMENSIONS | Overall length | '06-08 models | 4, 489 mm (176.7 in) |
| '09-11 models | 4, 504 mm (177.3 in) | ||
| Overall width | 1, 752 mm (69.0 in) | ||
| Overall height | 1, 435 mm (56.5 in) | ||
| Wheelbase | 2, 700 mm (106.3 in) | ||
| Track | Front | 1, 499 mm (59.0 in) | |
| Rear | 1, 528 mm (60.2 in) | ||
| Ground clearance | 154 mm (6.1 in) | ||
| Seating capacity | Five (5) | ||
| WEIGHT | Gross Vehicle Weight Rating (GVWR) | 1, 730 kg (3, 815 lbs) | |
| ENGINE | Type | Water cooled, 4-stroke SOHC i-VTEC compressed natural gas engine | |
| Cylinder arrangement | Inline 4-cylinder, transverse | ||
| Bore and stroke | 81.0 x 87.3 mm (3.19 x 3.44 in) | ||
| Displacement | 1, 799 cm 3 (110 cu in) | ||
| Compression ratio | 12.5 | ||
| Valve train | Chain drive, SOHC i-VTEC 4 valves per cylinder | ||
| Lubrication system | Forced, wet sump, with trochoid pump | ||
| Fuel required | Compressed Natural Gas with SAE J1616 standards | ||
| STARTER | Type | Gear reduction | |
| Nominal output | 1.2 kW | ||
| Nominal voltage | 12 V | ||
| Hour rating | 30 seconds | ||
| Direction of rotation | Clockwise as viewed from drive end | ||
| AUTOMATIC TRANSMISSION | Type | Electronically-controlled automatic, five-speed forward, one reverse, three-element torque converter with lock-up clutch | |
| Primary reduction | Direct 1:1 | ||
| Gear ratio | 1st | 2.666 | |
| 2nd | 1.534 | ||
| 3rd | 1.021 | ||
| 4th | 0.720 | ||
| 5th | 0.524 | ||
| Reverse | 1.956 | ||
| Final reduction | Type | Single helical gear | |
| Gear ratio | 4.437 | ||
| STEERING | Type | Hydraulic power-assisted rack and pinion | |
| Overall ratio | 13.73 | ||
| Turns, lock-to-lock | 2.67 | ||
| Steering wheel diameter | 360 mm (14.2 in) | ||
| SUSPENSION | Type | Front | Independent MacPherson strut with stabilizer, coil spring |
| Rear | Independent double wishbone with stabilizer, coil spring | ||
| Shock absorber | Front and Rear | Telescopic, hydraulic, nitrogen gas-filled | |
| TIRES | Size | Front and Rear | P195/65R15 89H |
| Spare | T125/70D15 95M | ||
| WHEEL ALIGNMENT | Camber | Front | 0°00' |
| Rear (without "C" marks on the upper arm) | 1°30' | ||
| Rear (with "C" marks on the upper arm) | 0°45' | ||
| Caster | Front | 7°00' | |
| Total toe-in | Front | 0 mm (0 in) | |
| Rear | 2 mm (0.08 in) | ||
| Front wheel turning angle | Inward | 40°06' | |
| Outward (reference) | 31°55' | ||
| BRAKES | Type of service brake | Front | Power-assisted self-adjusting ventilated disc |
| Rear | Power-assisted self-adjusting drum | ||
| Type of parking brake | Mechanical actuating, rear wheels | ||
| Pad friction surface area | Front | 48.4 cm 2 (7.50 sq in) x 2 | |
| Shoe friction surface area | Rear | 73.9 cm 2 (11.45 sq in) x 2 | |
| AIR CONDITIONING | Compressor | Type | Scroll |
| Capacity | 77.1 mL (4.7 cu in)/rev | ||
| Maximum speed | 10, 000 rpm | ||
| Lubricant capacity | 75 mL (2 1/2 fl.oz) | ||
| Lubricant type | SP-10 | ||
| Condenser | Type | Corrugated fin | |
| Evaporator | Type | Corrugated fin | |
| Blower | Type | Stabilized swirling flow | |
| Motor type | 220W/12V | ||
| Speed control | Infinitely variable | ||
| Maximum capacity | 470 m 3 (16, 571 cu ft)/h | ||
| Temperature control | Air-mix type | ||
| Compressor clutch | Type | Dry, single plate, poly V-belt drive | |
| Electrical power consumption at 68 T (20°C) | 42 W maximum at 12 V | ||
| Refrigerant | Type | HFC-134a(R-134a) | |
| Capacity | 400-450 g (14.1-15.9 oz) | ||
| ELECTRICAL RATINGS | Battery | 12 V-45 Ah/20 HR (12 V-36 Ah/5 HR) | |
| Fuses | Under-hood fuse/relay box ('06-07 models) | 100 A, 80 A, 70 A, 50 A, 40 A, 30 A, 20 A, 15 A, 10 A, 7.5 A | |
| Under-hood fuse/relay box ('08-10 models) | 100 A, 70 A, 60 A, 50 A, 40 A, 30 A, 20 A, 15 A, 10 A, 7.5 A | ||
| Under-dash fuse/relay box | 30 A, 20 A, 15 A, 10 A, 7.5 A | ||
| Light bulbs | Headlight high beam | 12V-60W (HB3) | |
| Headlight low beam | 12V-51 W (HB4) | ||
| Front side marker/parking/turn signal lights | 12V-21/5W | ||
| Rear turn signal lights | 12V-21W | ||
| Brake/taillights | 12V-21/5W | ||
| Inner taillights | 12V-5W | ||
| Rear side marker lights | 12V-5W | ||
| High mount brake light | 12V-21 W | ||
| Back-up lights | 12V-21 W | ||
| License plate lights | 12V-5W | ||
| Ceiling light | 12V-8W | ||
| Front individual map lights | 12V-8W | ||
| Trunk light | 12V-5W | ||
| Gauge lights | LED (non-replaceable) | ||
| Indicator lights | LED, 14V-0.56W, 0.84W, 1.12 W | ||
| Washer reservoir | Capacity | 2.5 L (2.6 US qt) |
