ROCKER ARM & SHAFT DISASSEMBLY/REASSEMBLY

Note. Identify parts as they are removed to ensure reinstallation in original location. Inspect the rocker shafts and rocker arms (see ROCKER ARM & SHAFT INSPECTION ). The rocker arms must be installed in the same positions if reused. When removing or installing the rocker arm assembly, do not remove the camshaft holder bolts. The bolts will keep the holders, springs and rocker arms on the shaft. Prior to reassembling, clean all the parts in solvent, dry them, and apply new engine oil to any contact points. Bundle the rocker arms with rubber bands to keep them together as a set.

Scheme 519

Scheme 520

Scheme 521

Scheme 522

1. Remove the rocker arm assembly (see «ROCKER ARM ASSEMBLY REMOVAL»(ref-173867-S26952556522005032300000) ).
2. Measure the diameter of the shaft at the first rocker location.
3. Zero the gauge (A) to the shaft diameter.
4. Measure the inside diameter of the rocker arm, and check it for an out-of-round condition. Rocker Arm-to-Shaft Clearance: Standard (New): Intake: 0.025-0.052 mm (0.0010-0.0020 in.) Exhaust: 0.018-0.056 mm (0.0007-0.0022 in.) Service Limit: 0.08 mm (0.003 in.)
5. Repeat for all rocker arms and both shafts. If the clearance is over the limit, replace the rocker shaft and all overtolerance rocker arms. If any VTEC rocker arm needs replacement, replace the rocker arms (primary and secondary) as a set.
6. Inspect the rocker arm pistons (A). Push each piston manually. If it does not move smoothly, replace the rocker arm set. NOTE: Apply new engine oil to the pistons when reassembling.
