Maintenance Information: Overview Honda Civic VI

Fuse & Circuit Breaker Identification

1. 1 - Not Used
2. 2 - Not Used
3. 3 - Not Used
4. 4 - 10 Amp Right Headlight High Beam
5. 5 - 10 Amp Left Headlight High Beam
6. 6 - Not Used
7. 7 - 20 Amp (Sedan) Rear Left Power Window
8. Not Used (Coupe)
9. 8 - 20 Amp (Sedan) Rear Right Power Window
10. Not Used (Coupe)
11. 9 - 15 Amp Ignition Coil
12. 10 - 20 Amp Front Right Power Window
13. 11 - 20 Amp Front Left Power Window
14. 12 - 7.5 Amp Turn Signal Lights
15. 13 - 15 Amp Fuel Pump (SRS Unit)
16. 14 - 7.5 Amp Cruise Control, Keyless
17. 15 - 7.5 Amp Alternator, SP Sensor
18. 16 - 7.5 Amp Rear Defroster Relay
19. 17 - 7.5 Amp Heater, Air Conditioning Relay
20. 18 - 7.5 Amp Daytime Running Light Relay (Canada)
21. 19 - 7.5 Amp Back-Up Lights
22. 20 - 10 Amp Daytime Running Lights
23. 21 - 10 Amp Right Headlight Low Beam
24. 22 - 10 Amp Left Headlight Low Beam
25. 23 - 10 Amp SRS
26. 24 - 7.5 Amp Power Window Relay, Moonroof Relay
27. 25 - 7.5 Amp Meter
28. 26 - 20 Amp Front Wiper, Front Washer
29. 27 - 10 Amp Accessory Socket
30. 28 - 10 Amp Radio, Clock
31. 29 - Not Used
32. 30 - 7.5 Amp Instrument Lights
33. 31 - 7.5 Amp Starter Signal
34. 32 - 7.5 Amp License Plate Lights, Taillights
35. 33 - 7.5 Amp Inter Lock Unit
36. 34 - 20 Amp Spare Fuse
37. 35 - 7.5 Amp Spare Fuse
38. 36 - Not Used
39. 37 - 10 Amp Spare Fuse
40. 38 - 15 Amp Spare Fuse

Scheme 1

1. 1 - 80 Amp Battery
2. 2 - 40 Amp Ignition 1
3. 3 - Not Used
4. 4 - 40 Amp Power Window
5. 5 - 30 Amp Headlight, Small Light
6. 6 - Not Used
7. 7 - 30 Amp Rear Defroster
8. 8 - 40 Amp Option
9. 9 - 40 Amp Heater Motor
10. 10 - 7.5 Amp Interior Light
11. 11 - 15 Amp FI E/M (ECM/PCM)
12. 12 - 7.5 Amp Back Up, Radio
13. 13 - 20 Amp Door Lock Unit, Moonroof
14. 14 - 20 Amp Magnetic Clutch (A/C), Condenser Fan (A/C)
15. 15 - 20 Amp Cooling Fan
16. 16 - 15 Amp Horn, Stop Light
17. 17 - 10 Amp Hazard

Scheme 2

Fuse & Relay Identification

1. 1 - 40 Amp ABS Pump Motor
2. 2 - 20 Amp ABS +B
3. 3 - 7.5 Amp Motor Check

1. 1 - 10 Amp S.R.S
2. 2 - 15 Amp ACG (S)
3. 3 - 20 Amp Spare Fuse
4. 4 - 15 Amp Spare Fuse
5. 5 - 15 Amp Radio, Cigarette Lighter
6. 6 - Not Used
7. 7 - 10 Amp Left Headlight Low Beam
8. 8 - 10 Amp Left Headlight High Beam
9. 9 - 10 Amp Right Headlight Low Beam
10. 10 - 10 Amp Right Headlight High Beam
11. 11 - 10 Amp Taillight, Instrument Panel Light, License Plate Light
12. 12 - 20 Amp Left Power Window
13. 13 - 7.5 Amp Starter Signal
14. 14 - 20 Amp Rear Power Window
15. 15 - 10 Amp Daytime Running Light (Canada)
16. 16 - 20 Amp Power Door Lock
17. 17 - 7.5 Amp Daytime Running Light Relay (Canada)
18. 18 - 20 Amp Right Power Window
19. 19 - 10 Amp Back-Up Light
20. 20 - 20 Amp Wiper, Washer, Power Window Relay
21. 21 - 7.5 Amp Interior Light
22. 22 - 7.5 Amp Rear Defroster Relay
23. 23 - 15 Amp AGG (S)
24. 24 - 10 Amp Spare Fuse
25. 25 - 7.5 Amp Spare Fuse

1. 1 - 80 Amp Main Fuse Battery
2. 2 - 15 Amp Stop, Horn
3. 3 - 10 Amp Hazard
4. 4 - 40 Amp Main Fuse Light
5. 5 - 50 Amp Main Fuse Ignition
6. 6 - 30 Amp Main Fuse Heater Motor
7. 7 - 50 Amp Main Fuse Option
8. 8 - 20 Amp Condenser Fan
9. 9 - 15 Amp ECU (ECM)
10. 10 - 7.5 Amp Back Up
11. 11 - 15 Amp Cooling Fan
12. 12 - 15 Amp Main Fuse Rear Defroster

1. 1 - 7.5 Amp Motor Check
2. 2 - 15 Amp ABS +B2
3. 3 - 20 Amp ABS +B1
4. 4 - 50 Amp ABS Pump Motor
