Engine Cooling System (Gx): Removal & Installation Honda Civic VI

Replacement

1. Drain the engine coolant.
2. Remove the upper and lower radiator hoses, and ATF cooler hoses.
3. Disconnect the fan motor connector.
4. Remove the radiator upper bracket, then pull up the radiator.
5. Remove the fan shroud assemblies and other parts from the radiator.
6. Install the radiator in the reverse order of removal

Note. Set the upper and lower cushions securely. Fill the radiator with engine coolant and bleed the air.

Scheme 20

Note. Use a new O-ring when reassembling.

Scheme 21
