Audio System Troubleshooting & Testing: Removal & Installation Honda Civic IX

Removal

SRS components are located in this area. Review the SRS component locations See SRS COMPONENT LOCATION INDEX ('12: EXCEPT NATURAL GAS MODELS) or SRS COMPONENT LOCATION INDEX ('12: NATURAL GAS MODELS) and the PRECAUTIONS AND PROCEDURES before doing repairs or service.

Scheme 874

Scheme 875

Scheme 876

Scheme 877

Scheme 878

Scheme 879

Scheme 880

Scheme 881

1. Battery Terminal (SRS) - Disconnection Make sure the ignition switch is in LOCK (0). Disconnect and isolate the negative cable and battery sensor (A) from the battery (B). NOTE: Always disconnect the negative side first. Disconnect the positive cable (C) from the battery. Wait at least 3 minutes before starting work.
2. Driver's Airbag Remove the access panel (A). Disconnect the driver's airbag inflator connector (B) on the cable reel harness. Disconnect the horn switch connector (C). Remove the TORX bolts using a TORX T30 bit. Remove the driver's airbag (A).
3. Steering Wheel Assembly Set the front wheels in the straight ahead position. Disconnect the connector (A). Loosen the steering wheel bolt (B) three turns. Install a commercially available steering wheel puller (A) on the steering wheel (B). Free the steering wheel from the steering column shaft by turning the pressure bolt (C) of the puller. Note these items when removing the steering wheel: Do not tap on the steering wheel or the steering column shaft when removing the steering wheel. If you thread the puller bolts (D) into the wheel hub more than five threads, the bolts will hit the cable reel and damage it. To prevent this, install a pair of jam nuts five threads up on each puller bolt. Remove the steering wheel puller. Remove the steering wheel (A) from the steering column.
4. Steering Wheel Rear Cover Remove the steering wheel rear cover (A).
5. Audio Remote/Multi-Information Display Switch Remove the audio remote/multi-information display switch (A).

Scheme 882

1. Audio Remote/Multi-Information Display Switch - Test Measure the resistance between terminals No. 2 and No. 5 in each switch position according to the table. Position Resistance No button pressed About 10 kohms SOURCE About 3.7 kohms Right (CH +) About 1.7 kohms Left (CH -) About 775 ohms + (VOL.UP) About 357 ohms - (VOL.DOWN) About 99 ohms Measure the resistance between terminals No. 3 and No. 5 in each switch position according to the table. Position Resistance MENU About 33 kohms INFO About 363 kohms If the resistance is not as specified, replace the audio remote/multi-information display switch (A).

Installation

SRS components are located in this area. Review the SRS component locations See SRS COMPONENT LOCATION INDEX ('12: EXCEPT NATURAL GAS MODELS) or SRS COMPONENT LOCATION INDEX ('12: NATURAL GAS MODELS) and the PRECAUTIONS AND PROCEDURES before doing repairs or service.

Scheme 883

Scheme 884

Scheme 885

Scheme 886

Scheme 887

Scheme 888

Scheme 889

Scheme 890

Scheme 891

Scheme 892

1. Audio Remote/Multi-Information Display Switch Install the audio remote/multi-information display switch (A).
2. Steering Wheel Rear Cover Install the steering wheel rear cover (A).
3. Steering Wheel Assembly Make sure the front wheels are pointing straight ahead. Center the cable reel (A). Do this by first rotating the cable reel clockwise until it stops. Rotate the cable reel counterclockwise about three full turns. The arrow mark (B) on the cable reel label should point straight up. Position the steering wheel hub (A) so that it engages the pin (B) of the cable reel. Install the steering wheel (C) on to the steering column shaft. NOTE: Do not tap on the steering wheel or the steering column shaft when installing the steering wheel. Install the steering wheel bolt (A), and tighten it to the specified torque. Connect the connector (B). Make sure the wire harness is routed and fastened properly.
4. Driver's Airbag NOTE: If you are replacing a deployed driver's airbag, inspect the cable reel for heat damage. If there is any damage, replace the cable reel. Place the driver's airbag (A) in the steering wheel. Tighten the new TORX bolts using a TORX T30 bit. NOTE: Make sure the clearance (B) between the steering wheel and horn pad is the specified value. Connect the driver's airbag inflator connector (A) on the cable reel harness. Connect the horn switch connector (B). NOTE: After reconnecting the negative cable to the battery, make sure the horn works properly. Install the access panel (C).
5. Battery Terminal (SRS) - Reconnection NOTE: If the battery performs abnormally, test the battery. Clean the battery terminals. Connect the positive cable (A) to the battery (B). NOTE: Always connect the positive side first. Connect the negative cable and battery sensor (C) to the battery. Apply multipurpose grease to the terminals to prevent corrosion.
6. HDS DLC - Connection Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard. Turn the ignition switch to ON (II). Make sure the HDS communicates with the vehicle. If it does not communicate, go to the DLC circuit troubleshooting.
7. VSA Sensor Neutral Position - Memorization Park the vehicle on a flat and level surface, with the steering wheel in the straight ahead position. Select VSA ADJUSTMENT, then select ALL SENSORS with the HDS, and follow the screen prompts. NOTE: See the HDS Help menu for specific instructions.
8. Steering Angle Sensor Neutral Position - Clear Select EPS ADJUSTMENT, then select EPS STEERING ANGLE SENSOR VALUE CLEAR and follow the screen prompts on the HDS. NOTE: See the HDS Help menu for specific instructions.

Note. SRS components are located in this area. Review the SRS component locations See SRS COMPONENT LOCATION INDEX ('12: EXCEPT NATURAL GAS MODELS) or SRS COMPONENT LOCATION INDEX ('12: NATURAL GAS MODELS) and the PRECAUTIONS AND PROCEDURES before doing repairs or service.

Scheme 893

Scheme 894

Scheme 895

Scheme 896

Scheme 897

1. Front Door Opening Seal as Needed Remove the front door opening seal (A) as needed.
2. A-Pillar Trim Pull out the A-pillar trim (A) to release the clips. Put a shop towel (A) in the opening between the A-pillar trim (B) and the dashboard to prevent dropping the A-pillar clips. Remove the A-pillar trim (A). NOTE: The upper clip (B) will stay in the body. Remove the upper clip (A) from the body.

Scheme 898

1. Tweeter - Test Measure the resistance between terminal No. 2 and the outside terminal of the capacitor (A). There should be about 4 ohms. Also check the capacitor condition. If any problem is found, replace the tweeter (B).

Note. SRS components are located in this area. Review the SRS component locations See SRS COMPONENT LOCATION INDEX ('12: EXCEPT NATURAL GAS MODELS) or SRS COMPONENT LOCATION INDEX ('12: NATURAL GAS MODELS) and the PRECAUTIONS AND PROCEDURES before doing repairs or service.

Scheme 899

Scheme 900

Scheme 901

1. A-Pillar Trim Carefully install the new upper clip (A) to the A-pillar trim (B). Install the A-pillar trim (A). NOTE: Make sure the side curtain airbag is not tucked under the clips or the trim ribs. Do not push too hard on the A-pillar trim. If you push too hard, the clip will be damaged, and it will not hold the trim properly. Gently tug on the A-pillar trim to verify that all clips are securely fastened.
2. Front Door Opening Seal as Needed Install the front door opening seal (A).
