GENERATOR SPECIFICATIONS
| Application | Minimum Output - Amps |
|---|
| Civic | 50 |
| CR-V | 65 |
| Except Civic & CR-V | 75 |
GENERATOR TEST OUTPUT SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Mounting Bolt/Nut |
| Lower |
| Civic & CR-V | 33 (44) |
| Prelude | 16 (22) |
| Upper |
| Civic & Prelude | 33 (44) |
| CR-V | 17 (24) |
| Pulley Lock Nut | 82 (111) |
| (1) Tighten to 106 INCH lbs. (12 N.m). (2) Pulley bolt has left-hand threads. |
| (1) | Tighten to 106 INCH lbs. (12 N.m). |
| (2) | Pulley bolt has left-hand threads. |
Charging System Wiring Diagram (Civic). Scheme 1
Scheme 1: Charging System Wiring Diagram (Civic)
Charging System Wiring Diagram (CR-V). Scheme 2
Scheme 2: Charging System Wiring Diagram (CR-V)
Charging System Wiring Diagram (Prelude). Scheme 3
Scheme 3: Charging System Wiring Diagram (Prelude)
