Design Specifications
| Item | Measurement | Qualification | Specification |
|---|---|---|---|
| DIMENSIONS (4-door) | Overall length | 4, 930 mm (194.1 in) | |
| Overall width | 1, 847 mm (72.7 in) | ||
| Overall height | 1, 475 mm (58.1 in) | ||
| Wheel base | 2, 800 mm (110.2 in) | ||
| Track | Front | 1, 580 mm (62.2 in) | |
| Rear | 1, 580 mm (62.2 in) | ||
| Seating capacity | Five (5) | ||
| DIMENSIONS (2-door) | Overall length | 4, 849 mm (190.9 in) | |
| Overall width | 1, 848 mm (72.7 in) | ||
| Overall height | 1, 432 mm (56.3 in) | ||
| Wheelbase | 2, 740 mm (107.9 in) | ||
| Track | Front | 1, 580 mm (62.2 in) | |
| Rear | 1, 580 mm (62.2 in) | ||
| Seating capacity | Five (5) | ||
| WEIGHT (4-door) | Gross Vehicle Weight Rating (GVWR) USA models | 2, 075 kg (4, 575 lbs) | |
| Gross Vehicle Weight Rating (GVWR) Canada models | 2, 090 kg (4, 608 lbs) | ||
| WEIGHT (2-door) | Gross Vehicle Weight Rating (GVWR) USA models | AT | 2, 060 kg (4, 541 lbs) |
| M/T | 2, 030 kg (4, 475 lbs) | ||
| Gross Vehicle Weight Rating (GVWR) Canada models | A/T | 2, 075 kg (4, 575 lbs) | |
| M/T | 2, 040 kg (4, 497 lbs) | ||
| ENGINE | Type | J35Z2 | Water-cooled, 4-stroke SOHC i-VTEC Variable Cylinder Management gasoline engine |
| J35Z3 | Water-cooled, 4-stroke SOHC VTEC gasoline engine | ||
| Cylinder arrangement | 60° V6-cylinder, transverse | ||
| Bore and stroke | 89.0 x 93.0 mm (3.504 x 3.661 in) | ||
| Displacement | 3, 471 cm 3 (211.8 cu in) | ||
| Compression ratio | J35Z2 | 10.5 | |
| J35Z3 | 10.0 | ||
| Valve train | Belt driven, SOHC VTEC 4 valves per cylinder | ||
| Lubrication system | Forced, wet sump, with trochoid pump | ||
| Fuel required | Regular UNLEADED gasoline with 87 Pump Octane Number or higher | ||
| STARTER | Type | Gear reduction | |
| Nominal output | J35Z2 | 1.8 kW | |
| J35Z3 | 1.6 kW | ||
| Nominal voltage | 12V | ||
| Hour rating | 30 seconds | ||
| Direction of rotation | Counterclockwise as viewed from drive end | ||
| CLUTCH | Type | Single plate dry, diaphragm spring | |
| MANUAL TRANSMISSION | Type | Synchronized, six-speed forward, one reverse | |
| Primary reduction | Direct 1:1 | ||
| Gear ratio | 1st | 3.933 | |
| 2nd | 2.478 | ||
| 3rd | 1.700 | ||
| 4th | 1.250 | ||
| 5th | 0.976 | ||
| 6th | 0.771 | ||
| Reverse | 4.008 | ||
| Final reduction | Type | Single helical gear | |
| Gear ratio | 3.550 | ||
| AUTOMATIC TRANSMISSION | Type | Electronically-controlled automatic, five-speed forward, one reverse, three-element torque converter with lock-up clutch | |
| Primary reduction | Direct 1:1 | ||
| Gear ratio | 1st | 2.697 | |
| 2nd | 1.606 | ||
| 3rd | 1.071 | ||
| 4th | 0.765 | ||
| 5th ('08-10 models) | 0.612 | ||
| 5th ('11-12 models) | 0.538 | ||
| Reverse | 1.888 | ||
| Final reduction | Type | Single helical gear | |
| Gear ratio | 4.312 | ||
| STEERING | Type | Hydraulic power-assisted rack and pinion | |
| Overall ratio | 13.1 | ||
| Turns, lock-to-lock | 2.56 | ||
| Steering wheel diameter | 370 mm (14.57 in) | ||
| SUSPENSION | Type | Front | Independent double wishbone with stabilizer, coil spring |
| Rear | Independent multilink with stabilizer, coil spring | ||
| Shock absorber | Front | Telescopic, hydraulic, nitrogen gas-filled | |
| Rear | Telescopic, hydraulic, nitrogen gas-filled | ||
| TIRES | Size (4-door) | Front and rear | P225/50R17 93V |
| Spare | T135/80D16101M | ||
| Size (2-door) | Front and rear | P235/45R18 94V | |
| Spare | T135/80D16101M | ||
| WHEEL ALIGNMENT | Camber (17 inch wheels) | Front | 0°00' |
| Rear | 1°00' | ||
| Camber (18 inch wheels) | Front | 0°05' | |
| Rear | 1°19' | ||
| Caster | Front (4-door) | 3°48' | |
| Front (2-door) | 3° 47' | ||
| Total toe-in | Front | 0 mm (0 in) | |
| Rear | 2 mm (0.08 in) | ||
| Front wheel turning angle (17 inch wheels) | Inward | 39° 00' | |
| Outward (reference) | 3°50' | ||
| Front wheel turning angle (18 inch wheels) | Inward | 37° 00' | |
| Outward (reference) | 30° 20' | ||
| BRAKES | Type of service brake | Front | Power-assisted self-adjusting ventilated disc |
| Rear | Power-assisted self-adjusting solid disc | ||
| Type of parking brake | Mechanical actuating, rear wheels | ||
| Pad friction surface area (swept area) | Front (NISSIN without pad return spring) | 50.6 cm 2 (7.84 sq in) X2 | |
| Front (NISSIN with pad return spring: 4-door) | 46.2cm 2 (7.16 sq in)X2 | ||
| Front (NISSIN with pad return spring: 2-door) | 45.3cm 2 (7.02 sq-in)X2 | ||
| Rear | 27.3 cm 2 (4.23 sq in) x 2 | ||
| AIR CONDITIONING | Compressor | Type | Swash plate/DENSO |
| Capacity | 154.4 mL (9.42 cu in)/rev | ||
| Maximum speed | 7, 600 RPM | ||
| Lubricant capacity | 70 mL (2 3/8 fl-oz) | ||
| Lubricant type | DENSOND-OIL8 | ||
| Condenser | Type | Corrugated fin | |
| Evaporator | Type | Corrugated fin | |
| Blower | Type | Stabilized swirling flow | |
| Motor type | 216W/12V | ||
| Speed control | Infinitely variable | ||
| Maximum capacity | 505 m 3 (17, 834 cu ft)/h | ||
| Temperature control | Air-mix type | ||
| Compressor clutch | Type | Dry, single plate, poly V-belt drive | |
| Electrical power consumption at 68°F (20°C) | 35 W maximum at 12 V | ||
| Refrigerant | Type | HFC-134a (R-134a) | |
| Capacity | 400-450 g (14.1-15.9 oz) | ||
| ELECTRICAL RATINGS | Battery | 12 V-72 Ah/20 HR (12 V-60 Ah/5 HR) | |
| Fuse | Under-hood fuse/relay box | 120 A, 60 A, 50 A, 40 A, 30 A, 20 A, 15 A, 10 A, 7.5 A | |
| Driver's under-dash fuse/relay box | 20 A, 15 A, 10A, 7.5A | ||
| Passenger's under-dash fuse/relay box | 20 A, 15A, 10A, 7.5A | ||
| Light bulbs | Headlight high beam | 12V-60W | |
| Headlight low beam (4-door) | 12V-51 W | ||
| Headlight low beam (2-door) | 12V-55W | ||
| Fog lights | 12V-55W | ||
| Front turn signal/parking lights (4-door) | 12V-21/5W | ||
| Front turn signal/parking lights (2-door) | 12V-24/2.2CP | ||
| Front side marker lights (4-door) | 12V-3CP | ||
| Front side marker lights (2-door) | 12V-5W | ||
| Rear turn signal lights | 12V-21 W | ||
| Brake lights/taillights | 12V-21/5W | ||
| High mount brake light | 12V-21 W | ||
| Back-up lights (4-door) | 12V-21 W | ||
| Back-up lights (2-door) | 12V-16W | ||
| License plate light (s) | 12V-5W | ||
| Ceiling light | 12V-8W | ||
| Trunk light | 12V-5W | ||
| Individual map light | 12V-8W | ||
| Ambient light | LED | ||
| Vanity mirror lights | 12V-1.1 W | ||
| Glove box light ('08-09 models) | 12V-2CP | ||
| Door courtesy light | 12V-2CP | ||
| Gauge lights | LED | ||
| Indicator lights | LED |
DESIGN SPECIFICATIONS CHART
Body Specifications
4-door Model
Scheme 1
2-door Model
