Power Window System: Removal & Installation Honda Accord VI

Windows 85 illustrations ~4069 words

Windshield Replacement

Note. Put on gloves to protect your hands. Wear eye protection when removing the glass with piano wire. Use seat covers to avoid damaging any surfaces.

Scheme 8

Scheme 8: Windshield Replacement

Scheme 9

Scheme 9

Scheme 10

Scheme 10

Scheme 11

Scheme 11

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Scheme 14

Scheme 14

Scheme 15

Scheme 15

Scheme 16

Scheme 16

Scheme 17

Scheme 17

Scheme 18

Scheme 18

Scheme 19

Scheme 19

Scheme 20

Scheme 20

Scheme 21

Scheme 21

Scheme 22

Scheme 22

Scheme 23

Scheme 23

Scheme 24

Scheme 24

Scheme 25

Scheme 25

Scheme 26

Scheme 26

Scheme 27

Scheme 27

Scheme 28

Scheme 28

Scheme 29

Scheme 29
  1. Remove these items: Rearview mirror (see «REARVIEW MIRROR REPLACEMENT»(ref-153435-S24916429972005060100000) ) Sunvisors and holders, both sides, Roof console, Grab handles, both sides (see «HEADLINER REMOVAL/INSTALLATION»(ref-177458-S17683301142005053100000) ) Front door opening trim, both sides as necessary Coupe (see «TRIM REMOVAL/INSTALLATION - DOOR AREA - COUPE»(ref-177458-S40693052432005053100000) ) Sedan (see «TRIM REMOVAL/INSTALLATION - DOOR AREA - SEDAN»(ref-177458-S33721647172005053100000) ) Front pillar trim, both sides Coupe (see «TRIM REMOVAL/INSTALLATION - DOOR AREA - COUPE»(ref-177458-S40693052432005053100000) ) Sedan (see «TRIM REMOVAL/INSTALLATION - DOOR AREA - SEDAN»(ref-177458-S33721647172005053100000) ) Windshield wiper arms and cowl cover (see WIPER MOTOR )
  2. Remove the molding (A) from the edge of the windshield (B). If necessary, cut the molding with a utility knife.
  3. Pull down the front portion of the headliner (see «HEADLINER REMOVAL/INSTALLATION»(ref-177458-S17683301142005053100000) ). Take care not to bend the headliner excessively, or you may crease or break it.
  4. Apply protective tape (A) along the edge of the dashboard (B) and body as shown. Using an awl, make a hole through the rubber dam (C), adhesive (D), and dashboard seal (E) from inside the vehicle. Push a piece of piano wire (F) through the hole, and wrap each end around a piece of wood.
  5. With a helper on the outside, pull the piano wire (A) back and forth in a sawing motion. Hold the piano wire as close to the windshield as possible to prevent damage to the body and dashboard. Carefully cut through the rubber dam and adhesive around the entire windshield.
  6. Carefully remove the windshield.
  7. With a knife, scrape the old adhesive smooth to a thickness of about 2 mm (0.08 in) on the bonding surface around the entire windshield opening flange: Do not scrape down to the painted surface of the body; damaged paint will interfere with proper bonding. Remove the rubber dam and fasteners from the body. Mask off surrounding surfaces before painting.
  8. Clean the body bonding surface with a sponge dampened in alcohol. After cleaning, keep oil, grease, and water from getting on the clean surface.
  9. If the old windshield is to be reinstalled, use a putty knife to scrape off all of the old adhesive, the fastener, the rubber dam, and the dashboard seal from the windshield. Clean the shaded portion of the windshield with alcohol where new adhesive is to be applied. Make sure the bonding surface is kept free of water, oil, and grease.
  10. Glue the rubber dam (A), fasteners (B) and dashboard seal (C) to the inside face of the windshield (D) as shown: Be sure the rubber dam, fasteners, and dashboard seal line up with the alignment marks (E). Be careful not to touch the windshield where adhesive will be applied.
  11. Apply primer (3M N-200, or equivalent) to the areas between the alignment marks (A), and glue the adhesive tape (B) (NITTO 501, or equivalent) to the edge of the windshield. Be careful not to touch the windshield where adhesive will be applied.
  12. Glue the molding (A) with adhesive tape (B) to the edge of the windshield (C): Be sure the alignment mark (D) of the molding lines up with the alignment mark (E) of the windshield. Be careful not to touch the windshield where adhesive will be applied.
  13. Glue the molding middle upper seal (coupe) (A), molding upper seal (coupe) (B), molding Corner Seal (Sedan) (C) and molding side seal (coupe) (D) to the molding (E). Be careful not to touch the windshield where adhesive will be applied.
  14. Install the fasteners to the body.
  15. Set the windshield in the opening, and center it. Make alignment marks (A) across the windshield and body with a grease pencil at the four points shown. Be careful not to touch the windshield where adhesive will be applied.
  16. Remove the windshield.
  17. With a sponge, apply a light coat of glass primer around the edge of the windshield (A) between the dam (B) and molding (C) as shown, then lightly wipe it off with gauze or cheesecloth: Apply glass primer to the molding. Do not apply body primer to the windshield, and do not get the body and glass primer sponges mixed up. Never touch the primed surfaces with your hands. If you do, the adhesive may not bond to the windshield properly, causing a leak after the windshield is installed. Keep water, dust, and abrasive materials away from the primed surface.
  18. With a sponge, apply a light coat of body primer to the original adhesive remaining around the windshield opening flange. Let the body primer dry for at least 10 minutes: Do not apply glass primer to the body, and be careful not to mix up the glass and body primer sponges. Never touch the primed surfaces with your hands. Mask off the dashboard before painting the flange.
  19. Before filling a cartridge, cut a "V" in the end of the nozzle (A) as shown.
  20. Pack adhesive into the cartridge without air pockets to ensure continuous delivery. Put the cartridge in a caulking gun, and run a bead of adhesive (A) around the edge of the windshield (B) between the dam (C) and molding (D) as shown. Apply the adhesive within 30 minutes after applying the glass primer. Make a slightly thicker bead at each corner.
  21. Use suction cups (A) to hold the windshield over the opening, align it with the alignment marks (B) made in step 15 , and set it down on the adhesive. Lightly push on the windshield until its edges are fully seated on the adhesive all the way around. Do not open or close the doors until the adhesive is dry.
  22. Scrape or wipe the excess adhesive off with a putty knife or towel. To remove adhesive from a painted surface or the windshield, wipe with a soft shop towel dampened with alcohol.
  23. Let the adhesive dry for at least 1 hour, then spray water over the windshield and check for leaks. Mark leaking areas, and let the windshield dry, then seal with sealant: Let the vehicle stand for at least 4 hours after windshield installation. If the vehicle has to be used within the first 4 hours, it must be driven slowly. Keep the windshield dry for the first hour after installation.
  24. Reinstall all remaining removed parts. Install the rearview mirror after the adhesive has dried thoroughly. Advise the customer not to do the following things for 2 to 3 days: Slam the doors with all the windows rolled up. Twist the body excessively (such as when going in and out of driveways at an angle or driving over rough, uneven roads).

Rear Window Replacement

Note. Put on gloves to protect your hands. Wear eye protection when removing the glass with piano wire. Use seat covers to avoid damaging any surfaces. Do not damage the rear window defogger grid lines, window antenna grid lines, and terminals.

Scheme 30

Scheme 30: Rear Window Replacement

Scheme 31

Scheme 31

Scheme 32

Scheme 32

Scheme 33

Scheme 33

Scheme 34

Scheme 34

Scheme 35

Scheme 35

Scheme 36

Scheme 36

Scheme 37

Scheme 37

Scheme 38

Scheme 38

Scheme 39

Scheme 39

Scheme 40

Scheme 40

Scheme 41

Scheme 41

Scheme 42

Scheme 42

Scheme 43

Scheme 43

Scheme 44

Scheme 44

Scheme 45

Scheme 45

Scheme 46

Scheme 46

Scheme 47

Scheme 47

Scheme 48

Scheme 48
  1. Remove the trunk lid (see «TRUNK LID»(ref-178623-S34479294762005061700000) ).
  2. Remove these items: Sedan (see «REAR SEAT REMOVAL/INSTALLATION - SEDAN»(ref-153508-S05246943652005060100000) ) Rear seat cushion Rear seat side bolster (both sides) Coupe (see «REAR SEAT REMOVAL/INSTALLATION - COUPE»(ref-153508-S01026885772005060100000) ) Rear seat-back Rear seat-cushion
  3. Remove these items: Sedan (see «TRIM REMOVAL/INSTALLATION - REAR SHELF AREA»(ref-177458-S13172957532005053100000) ) Rear door opening trim (both sides as necessary) Rear pillar trim (both sides) Rear bulkhead cover Center anchor bolt of the center belt Center belt cover High mount brake light Lock cylinder trim Rear shelf Coupe (see «TRIM REMOVAL/INSTALLATION - REAR SHELF AREA»(ref-177458-S35534143862005053100000) ) Rear bulkhead cover Rear shelf Coupe (see «TRIM REMOVAL/INSTALLATION - DOOR AREA - COUPE»(ref-177458-S40693052432005053100000) ) Door sill trim Rear side trim panel Upper anchor bolts of the front and rear seat belts Coat hanger Quarter trim panel
  4. Remove the window antenna terminal cover (A) from the window antenna terminal base (B), and disconnect the window antenna connector (C).
  5. Disconnect the rear window defogger connectors (A).
  6. Remove the molding (A) from the edge of the rear window (B). If necessary, cut the molding with a utility knife.
  7. Pull down the rear portion of the headliner (see «HEADLINER REMOVAL/INSTALLATION»(ref-177458-S17683301142005053100000) ). Take care not to bend the headliner excessively, or you may crease or break it.
  8. Apply protective tape (A) along the inside and outside edges of the body as shown. Using an awl, make a hole through the adhesive (B) from inside the vehicle. Push a piece of piano wire (C) through the hole, and wrap each end around a piece of wood.
  9. With a helper on the outside, pull the piano wire (A) back and forth in a sawing motion. Hold the piano wire as close to the rear window as possible to prevent damage to the body, and carefully cut through the adhesive around the entire rear window.
  10. Carefully remove the rear window.
  11. With a putty knife, scrape the old adhesive smooth to a thickness of about 2 mm (0.08 in) on the bonding surface around the entire rear window opening flange: Do not scrape down to the painted surface of the body; damaged paint will interfere with proper bonding Mask off surrounding surfaces before painting. Remove the fasteners from the body.
  12. Clean the body bonding surface with a sponge dampened in alcohol. After cleaning, keep oil, grease, and water from getting on the surface.
  13. If the old rear window is to be reinstalled, use a putty knife to scrape off all of the old adhesive, then clean the shaded portion of the rear window with alcohol where new adhesive is to be applied. Make sure the bonding surface is kept free of water, oil, and grease.
  14. Glue the fasteners (A, B) and spacers (U.S.-Produced); (C) to the inside face of the rear window as shown. If necessary, apply primer (3M N-200, or equivalent) to the areas where the window antenna terminal base (D) will be glued, then glue the base on: Be sure the fasteners, spacers (and window antenna terminal base cover) line up with the alignment marks (E). Be careful not to touch the rear window where adhesive will be applied.
  15. Apply the adhesive tape (A) (3M 4216, or equivalent) to the edge of the rear window (B): Be sure the adhesive tape lines up with the alignment marks (C). Be careful not to touch the rear window where adhesive will be applied.
  16. Glue the molding (A) around the edge of the rear window (B): Be sure the joint (C) lines up with the alignment mark (D). Be careful not to touch the rear window where adhesive will be applied.
  17. Sedan only, glue the molding corner seal (A) to the molding (B). Be careful not to touch the rear window where adhesive will be applied.
  18. Install the upper fasteners (A) (Japan-Produced models). Glue the lower fasteners (B) to the body as shown. Align the lower fasteners with 1.0 mm (0.04 in.) offset surface of the rear parcel shelf (C).
  19. Set the rear window in the opening, and center it. Make alignment marks (A) across the rear window and body with a grease pencil at the four points shown. Be careful not to touch the rear window where adhesive will be applied.
  20. Remove the rear window.
  21. With a sponge, apply a light coat of glass primer along the edge of the rear window (A) and molding (B) as shown, then lightly wipe it off with gauze or cheesecloth: Do not apply body primer to the rear window, and do not get the body and glass primer sponges mixed up. Never touch the primed surfaces with your hands. If you do, the adhesive may not bond to the rear window properly, causing a leak after the rear window is installed. Keep water, dust, and abrasive materials away from the primed surface.
  22. With a sponge, apply a light coat of body primer to the original adhesive remaining around the rear window opening flange. Let the body primer dry for at least 10 minutes: Do not apply glass primer to the body, and be careful not to mix up the glass and body primer sponges. Never touch the primed surfaces with your hands.
  23. Before filling a cartridge, cut a "V" in the end of the nozzle (A) as shown.
  24. Pack adhesive into the cartridge without air pockets to ensure continuous delivery. Put the cartridge in a caulking gun, and run a bead of adhesive (A) around the edge of the rear window (B) as shown. Apply the adhesive within 30 minutes after applying the glass primer. Make a slightly thicker bead at each corner.
  25. Use suction cups (A) to hold the rear window over the opening, align it with the alignment marks (B) you made in step 19 , and set it down on the adhesive. Lightly push on the rear window until its edges are fully seated on the adhesive all the way around. Do not open or close the doors until the adhesive is dry.
  26. Scrape or wipe the excess adhesive off with a putty knife or towel. To remove adhesive from a painted surface or the rear window, use a soft shop towel dampened with alcohol.
  27. Let the adhesive dry for at least 1 hour, then spray water over the rear window and check for leaks. Mark the leaking areas, let the rear window dry, then seal with sealant. Let the vehicle stand for at least 4 hours after rear window installation. If the vehicle has to be used within the first 4 hours, it must be driven slowly.
  28. Reinstall all remaining removed parts. Advise the customer not to do the following things for 2 to 3 days: Slam the doors with all the windows rolled up. Twist the body excessively (such as when going in and out of driveways at an angle or driving over rough, uneven roads).

Quarter Glass Replacement - Coupe

Note. Put on gloves to protect your hands. Use seat covers to avoid damaging any surface.

Scheme 49

Scheme 49: Quarter Glass Replacement - Coupe

Scheme 50

Scheme 50

Scheme 51

Scheme 51

Scheme 52

Scheme 52

Scheme 53

Scheme 53

Scheme 54

Scheme 54

Scheme 55

Scheme 55

Scheme 56

Scheme 56

Scheme 57

Scheme 57

Scheme 58

Scheme 58

Scheme 59

Scheme 59

Scheme 60

Scheme 60

Scheme 61

Scheme 61

Scheme 62

Scheme 62
  1. Remove these items (see «REAR SEAT REMOVAL/INSTALLATION - COUPE»(ref-153508-S01026885772005060100000) ): Rear seat-back Rear seat cushion
  2. Remove these items (see «TRIM REMOVAL/INSTALLATION - REAR SHELF AREA»(ref-177458-S35534143862005053100000) ): Rear bulkhead cover Center anchor bolt of the center belt Center belt lid High mount brake light Lock cylinder trim Rear shelf
  3. Remove these items (see «TRIM REMOVAL/INSTALLATION - DOOR AREA - COUPE»(ref-177458-S40693052432005053100000) ): Door sill trim Rear side trim panel Upper anchor bolts of the front and rear seat belts Coat hanger Quarter trim panel
  4. From inside the vehicle, use a knife (A) to cut through the quarter glass adhesive (B) all the way around: If the quarter glass (C) is to be reinstalled, take care not to damage the molding (D). If the molding is damaged, replace the quarter glass, molding and clips (E) as an assembly. If any of the clips are broken, the quarter glass can be reinstalled using butyl tape (refer to step 9 ). Apply protective tape (F) along the edge of the entire quarter glass opening flange.
  5. Carefully remove the quarter glass, and check the molding for damage, and replace the quarter glass if necessary.
  6. With a knife, scrape the old adhesive smooth to a thickness of about 2 mm (0.08 in.) on the bonding surface around the entire quarter glass opening flange: Do not scrape down to the painted surface of the body; damaged paint will interfere with proper bonding. If any of the clips are broken, remove them from the body. Mask off surrounding surfaces before applying primer.
  7. Clean the body bonding surface with a sponge dampened in alcohol. After cleaning, keep oil, grease, and water from getting on the glass surface.
  8. If the old quarter glass is to be reinstalled, use a putty knife to scrape off all traces of old adhesive from the quarter glass. Scrape the old adhesive from the molding with a knife, then clean the quarter glass and molding shaded portion of the quarter glass with alcohol where adhesive is to be applied. Make sure the bonding surface is kept free of water, oil, and grease.
  9. If the old quarter glass is to be reinstalled (and either clip is broken off the molding), apply a light coat of primer (C-100, or equivalent), then apply butyl tape (A) and (B) to the molding (C) as shown: Be careful not to touch the quarter glass where adhesive will be applied. Do not peel the separator off the butyl tape.
  10. If the old quarter glass is to be reinstalled (and either clip is broken off the molding), seal the body holes with pieces of urethane tape (A). Then set the quarter glass upright in the opening, and make alignment marks (B) across the quarter glass and body with a grease pencil at the three points shown. Be careful not to touch the quarter glass where adhesive will be applied.
  11. Remove the quarter glass.
  12. With a sponge, apply a light coat of glass primer to the inside face of the quarter glass (A) as shown, then lightly wipe it off with gauze or cheesecloth: Do not apply body primer to the quarter glass, and do not get the body and glass primer sponges mixed up. Never touch the primed surfaces with your hands. If you do the adhesive may not bond to the quarter glass properly, causing a leak after the quarter glass is installed. Keep water, dust, and abrasive materials away from the primed surface.
  13. With a sponge, apply a light coat of body primer to the original adhesive remaining around the quarter glass opening flange. Let the body primer dry for at least 10 minutes: Do not apply glass primer to the body, and be careful not to mix up the glass and body primer sponges. Never touch the primed surfaces with your hands. Mask off the dashboard before painting the flange.
  14. Before filling a cartridge, cut a "V" in the end of the nozzle (A) as shown.
  15. Pack adhesive into the cartridge without air pockets to ensure continuous delivery. Put the cartridge in a caulking gun, and run a bead of adhesive (A) around the edge of the quarter glass (B) as shown: After applying the adhesive, peel the separator off the butyl tape. Apply the adhesive within 30 minutes after applying the glass primer. Make slightly thicker bead at each corner.
  16. Use suction cups (A) to hold the quarter glass (B) over the opening, align the clips or the alignment marks (C) made in step 10 , and set it down on the adhesive. Lightly push on the quarter glass until its edges are fully seated on the adhesive all the way around. Do not open or close the doors until the adhesive is dry.
  17. Scrape or wipe the excess adhesive off with a putty knife or towel. To remove adhesive from a painted surface or the quarter glass, wipe with a soft shop towel dampened with alcohol.
  18. Let the adhesive dry for at least 1 hour, then spray water over the quarter glass and check for leaks. Mark the leaking areas and let the quarter glass dry, then seal with sealant. Let the vehicle stand for at least 4 hours after quarter glass installation. If the vehicle has to be used within the first 4 hours, it must be driven slowly.
  19. Reinstall all remaining removed parts. Advise the customer not to do the following things for 2 to 3 days: Slam the doors with all the windows rolled up. Twist the body excessively (such as when going in and out of driveways at an angle or driving over rough, uneven roads).

Scheme 63

Scheme 63: Sticker Replacement
  1. Clean the quarter glass surface with a sponge dampened in alcohol. After cleaning, keep oil, grease and water from getting on the surface.
  2. Apply the sticker where shown.

Scheme 64

Scheme 64: Component Location Index

Scheme 65

Scheme 65: Circuit Diagram - Sedan

Scheme 66

Scheme 66

Scheme 67

Scheme 67

Scheme 68

Scheme 68

Scheme 69

Scheme 69

Scheme 70

Scheme 70

Scheme 71

Scheme 71

Scheme 72

Scheme 72

Scheme 73

Scheme 73: Circuit Diagram - Coupe

Scheme 74

Scheme 74

Scheme 75

Scheme 75

Scheme 76

Scheme 76

Scheme 77

Scheme 77: Control Unit Input Test

Scheme 78

Scheme 78

Scheme 79

Scheme 79

Scheme 80

Scheme 80

Scheme 81

Scheme 81

Scheme 82

Scheme 82

Scheme 83

Scheme 83

Scheme 84

Scheme 84

Scheme 85

Scheme 85

Scheme 86

Scheme 86

Scheme 87

Scheme 87

Scheme 88

Scheme 88
  1. Before testing the power window control functions, troubleshoot the multiplex control system (see «TROUBLESHOOTING»(ref-178653-S13041513642005061800000) ). Driver's Multiplex Control Unit
  2. Remove the driver's multiplex control unit from the driver's under-dash fuse/relay box, and disconnect its connector.
  3. Inspect all connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 4.
  4. With the driver's multiplex control unit still disconnected, make these input tests at the driver's under-dash fuse/relay box socket. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 5.
  5. Reconnect the driver's multiplex control unit to the driver's under-dash fuse/relay box, and perform the following input tests at Connector A on the back of the driver's under-dash fuse/relay box. For driver's under-dash fuse/relay box connector socket location (see COMPONENT LOCATIONS ). If any test indicates a problem, find and correct the cause then recheck the system. If all the input tests prove OK, go to step 6. Multiplex Control Unit, Passenger's
  6. Remove the passenger's multiplex control unit from the passenger's under-dash fuse/relay box, and disconnect its connector.
  7. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 8.
  8. With the passenger's multiplex control unit still disconnected, make these input tests at the passenger's under-dash fuse/relay box socket. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 9.
  9. Reconnect the passenger's multiplex control unit to the passenger's under-dash fuse/relay box, and perform the following input tests at the appropriate connectors on the passenger's under-dash fuse/relay box. For passenger's under-dash fuse/relay box connector socket location (see COMPONENT LOCATIONS ). If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 10. Multiplex Control Unit, Door
  10. Remove the door multiplex control unit from the driver's door, and disconnect its connectors.
  11. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 12.
  12. With the door multiplex control unit still disconnected, make these input tests at the connectors. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input test prove OK, go to step 13.
  13. Reconnect the door multiplex control unit and perform the following input test. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 14.
  14. If all the input tests prove OK, one of the control units must be faulty. Substitute a known-good control unit for the one that is most likely at fault, then check the system. If the system works properly, the original control unit is faulty; replace it. If there is still a malfunction, substitute a known-good control unit for the next most likely unit to be at fault, and recheck. If the system works properly, the original unit is faulty; replace it.

Scheme 89

Scheme 89: Master Switch Replacement

Scheme 90

Scheme 90
  1. Remove the screw and master switch assembly from the door panel.
  2. Remove the four mounting screws, then remove the master switch from the panel.

Scheme 91

Scheme 91: Passenger's Switch Replacement

Scheme 92

Scheme 92
  1. Remove the screw and passenger's switch assembly from the door panel.
  2. Remove the three mounting screws, then remove the passenger's switch from the panel.
