Reference Information
Schematic Reference
Outside Rearview Mirror Schematics
Connector End View Reference
COMPONENT CONNECTOR END VIEWS - INDEX
Description and Operation
Outside Mirror Description and Operation (with LTZ or SLT) , Outside Mirror Description and Operation (without LTZ or SLT)
Electrical Information Reference
- «Circuit Testing»(ref-491170-S01761107082012073000000)
- «Connector Repairs»(ref-491170-S29468502572012073000000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-491170-S23088445062012073000000)
- «Wiring Repairs»(ref-491170-S24000289392012073000000)
Scan Tool Reference
Control Module References for scan tool information
Circuit/System Verification
If the DTC is set, replace the appropriate K96L left mirror control module or the S79P passenger window switch.
Repair Instructions
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
Control Module References for left mirror control module or passenger window switch replacement, setup, and programming
Symptoms - Mirrors
Note. The following steps must be completed before using the symptom tables.
- Perform the «Diagnostic System Check - Vehicle»(ref-491140-S24065023222012073000000) before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link.
- Review the system operation in order to familiarize yourself with the system functions. Refer to the following system descriptions: «Outside Mirror Description and Operation (with LTZ or SLT)»(ref-491188-S04044415272012073000000) , «Outside Mirror Description and Operation (without LTZ or SLT)»(ref-491188-S04710081012012073000000) «Automatic Day-Night Mirror Description and Operation»(ref-491188-S21848517902012073000000) «OnStar Description and Operation»(ref-491155-S15519114412012073000000)
Intermittent
Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .
Schematic Reference
Outside Rearview Mirror Schematics
Connector End View Reference
COMPONENT CONNECTOR END VIEWS - INDEX
Description and Operation
Outside Mirror Description and Operation (with LTZ or SLT) , Outside Mirror Description and Operation (without LTZ or SLT)
Electrical Information Reference
- «Circuit Testing»(ref-491170-S01761107082012073000000)
- «Connector Repairs»(ref-491170-S29468502572012073000000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-491170-S23088445062012073000000)
- «Wiring Repairs»(ref-491170-S24000289392012073000000)
Scan Tool Reference
Control Module References for scan tool information
- Engine running, press the rear window defogger switch.
- Verify the rear window defogger turns ON and the rear window becomes warm. If the rear window defogger does not turn on Refer to «Rear Window Defogger Malfunction»(ref-491176-S24899476212012073000000) . If the rear window defogger does turn on
- Verify both the left and right outside mirror glass become warm. If both the left and right outside mirror glass do not become warm Refer to Circuit/System Testing below. If both the left and right outside mirror glass become warm
- All OK.
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
Outside Rearview Mirror Glass Replacement
Schematic Reference
Inside Rearview Mirror Schematics
Connector End View Reference
COMPONENT CONNECTOR END VIEWS - INDEX
Description and Operation
Automatic Day-Night Mirror Description and Operation
Electrical Information Reference
- «Circuit Testing»(ref-491170-S01761107082012073000000)
- «Connector Repairs»(ref-491170-S29468502572012073000000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-491170-S23088445062012073000000)
- «Wiring Repairs»(ref-491170-S24000289392012073000000)
Scan Tool Reference
Control Module References for scan tool information
- Ignition ON, headlamps ON, transmission not in R, cover the front light sensor with a towel or other suitable item.
- Shine a flashlight at the rear light sensor while observing the inside rearview mirror face.
- Verify the inside rearview mirror face dims. If the inside rearview mirror does not dim Refer to Circuit/System Testing below. If the inside rearview mirror dims
- Engine running, park brake applied, place the transmission in R.
- Verify the inside rearview mirror face transitions from dim to bright. If the mirror does not transition between bright and dim states Refer to Circuit/System Testing below. If the mirror transitions between bright and dim states
- All OK.
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
Inside Rearview Mirror Replacement
Schematic Reference
Outside Rearview Mirror Schematics
Connector End View Reference
COMPONENT CONNECTOR END VIEWS - INDEX
Description and Operation
Outside Mirror Description and Operation (with LTZ or SLT) , Outside Mirror Description and Operation (without LTZ or SLT)
Electrical Information Reference
- «Circuit Testing»(ref-491170-S01761107082012073000000)
- «Connector Repairs»(ref-491170-S29468502572012073000000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-491170-S23088445062012073000000)
- «Wiring Repairs»(ref-491170-S24000289392012073000000)
Scan Tool Reference
Control Module References for scan tool information
- Ignition ON.
- Verify the scan tool Select Switch parameter changes between Left, Right, and None when cycling the S52 Outside Rearview Mirror Switch between the left, right, and none positions. If the parameter does not cycle between the specified values Refer to Circuit/System Testing - Mirror Switch Circuit Test below. If the parameter does cycle between the specified values
- Verify the scan tool Mirror Direction Command parameter changes between Up/Down and Right/Left while cycling the S52 Outside Rearview Mirror Switch Up/Down and Right/Left. If the parameter does not cycle between the specified values Refer to Circuit/System Testing - Mirror Switch Circuit Test below. If the parameter does cycle between the specified values
- Verify the scan tool Mirror Vertical and Horizontal Position parameters are between 0.2-4.8 V. If the parameters are not between 0.2-4.8 V Refer to Circuit/System Testing - Mirror Position Sensor Circuit Test below. If the parameters are between 0.2-4.8 V
- Verify the mirrors move in the commanded direction when commanding the UP/DOWN and RIGHT/LEFT states with a scan tool. If a mirror does not move in all the commanded directions Refer to Circuit/System Testing - Mirror Motor Circuit Test below. If both mirrors move in all commanded directions
- Verify the outside rearview mirrors adjust to the stored memory positions when operating the memory 1 and 2 recall switches. If a mirror does not adjust to the stored memory position Refer to «Memory Seat Feature Malfunction»(ref-491196-S36844697482012073000000) If both mirrors adjust to the stored memory positions
- All OK.
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
- «Outside Rearview Mirror Folding Control Module Replacement»(ref-491188-S24636452742012073000000)
- «Outside Rearview Mirror Inner Actuator Replacement»(ref-491188-S38202906032012073000000)
- «Outside Remote Control Rearview Mirror Switch Replacement»(ref-491188-S12583196312012073000000)
- «Control Module References»(ref-491163-S28884786072012073000000) for module replacement, programming and setup.
Schematic Reference
Outside Rearview Mirror Schematics
Connector End View Reference
COMPONENT CONNECTOR END VIEWS - INDEX
Description and Operation
Outside Mirror Description and Operation (with LTZ or SLT) , Outside Mirror Description and Operation (without LTZ or SLT)
Electrical Information Reference
- «Circuit Testing»(ref-491170-S01761107082012073000000)
- «Connector Repairs»(ref-491170-S29468502572012073000000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-491170-S23088445062012073000000)
- «Wiring Repairs»(ref-491170-S24000289392012073000000)
Scan Tool Reference
Control Module References for scan tool information
- Verify that both outside rearview mirrors operate while commanding the outside rearview mirrors UP/DOWN and LEFT/RIGHT with the outside mirror directional switch. If the outside rearview mirrors do not move up/down or left/right Refer to Circuit/System Testing below. If the outside rearview mirrors move up/down and left/right
- All OK.
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
- «Outside Rearview Mirror Inner Actuator Replacement»(ref-491188-S38202906032012073000000)
- «Outside Remote Control Rearview Mirror Switch Replacement»(ref-491188-S12583196312012073000000)
Schematic Reference
Outside Rearview Mirror Schematics
Connector End View Reference
COMPONENT CONNECTOR END VIEWS - INDEX
Description and Operation
Outside Mirror Description and Operation (with LTZ or SLT) , Outside Mirror Description and Operation (without LTZ or SLT)
Electrical Information Reference
- «Circuit Testing»(ref-491170-S01761107082012073000000)
- «Connector Repairs»(ref-491170-S29468502572012073000000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-491170-S23088445062012073000000)
- «Wiring Repairs»(ref-491170-S24000289392012073000000)
Scan Tool Reference
Control Module References for scan tool information
- Ignition ON.
- Verify the park assist option is activated in the driver information center (DIC).
- Select the driver outside mirror on S52 Outside Rearview Mirror Switch.
- Verify mirror functions properly when operating the S52 Outside Rearview Mirror Switch in UP/DOWN and LEFT/RIGHT positions. If the mirror does not function properly Refer to «Power Mirror Malfunction (with LTZ or SLT)»(ref-491188-S29477750572012073000000) , «Power Mirror Malfunction (without LTZ or SLT)»(ref-491188-S19062069862012073000000) . If the mirror functions properly
- Select the passenger outside mirror on S52 Outside Rearview Mirror Switch.
- Verify mirror functions properly when operating the S52 Outside Rearview Mirror Switch in UP/DOWN and LEFT/RIGHT positions. If the mirror does not function properly Refer to «Power Mirror Malfunction (with LTZ or SLT)»(ref-491188-S29477750572012073000000) , «Power Mirror Malfunction (without LTZ or SLT)»(ref-491188-S19062069862012073000000) . If the mirror functions properly
- Operate the memory 1 and 2 recall switches on S47D Seat Memory Switch - Driver.
- Verify the outside rearview mirrors adjust to the stored memory positions. If the mirrors do not adjust to the stored positions Refer to «Power Mirror Malfunction (with LTZ or SLT)»(ref-491188-S29477750572012073000000) , «Power Mirror Malfunction (without LTZ or SLT)»(ref-491188-S19062069862012073000000) . If the mirrors adjust to the stored positions
- Park brake on, vehicle running, shift the vehicle in REVERSE.
- Verify that the outside rearview mirrors tilt. If the driver outside mirror does not tilt Ignition OFF. Replace the S52 Outside Rearview Mirror Switch. Park brake on, vehicle running, shift the vehicle in REVERSE. Verify the driver mirror tilts. If the mirror does not tilt, replace the K40 Memory Seat Module. If the mirror tilts All OK. If the passenger outside mirror does not tilt Ignition OFF. Replace the S79P Passenger Window Switch. Park brake on, vehicle running, shift the vehicle in REVERSE. Verify the driver mirror tilts. If the mirror does not tilt, replace the K40 Memory Seat Control Module. If the mirror tilts All OK. If the mirrors tilt
- All OK.
Perform the Diagnostic Repair Verification after completing the repair.
Control Module References for door lock/window switches and memory seat control module replacement, programming and setup
Scheme 5
| Callout | Component Name |
|---|---|
| Preliminary Procedures Place the window in the fully down position. Remove front door trim panel. Refer to Front Side Door Trim Panel Replacement . Remove the front side door garnish molding. Refer to Front Side Door Garnish Molding Replacement . | |
| 1 | Outside Rearview Mirror Bolt (Qty: 3) CAUTION: Refer to Fastener Caution . Procedure Disconnect the electrical connector. Tighten 10 N.m (89 lb in). |
| 2 | Outside Rearview Mirror Procedure Inspect the mirror for proper operation before installing the side door garnish molding and door trim panel. |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Outside Rearview Mirror Replacement (Equinox)
Scheme 6
| Callout | Component Name |
|---|---|
| Preliminary Procedures Place the window in the full down position. Remove the front side door garnish molding. Refer to Front Side Door Garnish Molding Replacement . | |
| 1 | Outside Rearview Mirror Bolt (Qty: 3) WARNING: Refer to Glass and Sheet Metal Handling Warning . CAUTION: Refer to Fastener Caution . Procedure Disconnect the electrical connector. Tighten 10 N.m (89 lb in). |
| 2 | Outside Rearview Mirror Procedure Inspect the mirror for proper operation before installing the door trim panel. |
| WARNING |
|---|
| Refer to Glass and Sheet Metal Handling Warning . |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Outside Rearview Mirror Replacement (Terrain)
Scheme 7
| Callout | Component Name |
|---|---|
| Preliminary Procedure Remove the front side door accessory switch mount plate. Refer to Front Side Door Accessory Switch Mount Plate Replacement . | |
| 1 | Outside Remote Control Rearview Mirror Switch Assembly Procedure Disconnect the electrical connector. Refer to Control Module References for programming and setup information. |
Outside Remote Control Rearview Mirror Switch Replacement
Scheme 8
| Callout | Component Name |
|---|---|
| Preliminary Procedure Remove the front side door trim panel. Refer to Front Side Door Trim Panel Replacement . | |
| 1 | Outside Rearview Mirror Folding Control Module Bolts (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb ft) |
| 2 | Outside Rearview Mirror Folding Control Module Procedure Disconnect electrical connector. |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Outside Rearview Mirror Folding Control Module Replacement
Scheme 9
| Callout | Component Name |
|---|---|
| Preliminary Procedure Remove the outside rearview mirror glass. Refer to Outside Rearview Mirror Glass Replacement . | |
| 1 | Outside Rearview Mirror Inner Actuator Screws (Qty: 3) WARNING: Refer to Glass and Sheet Metal Handling Warning . CAUTION: Refer to Fastener Caution . Procedure Disconnect the electrical connector. Tighten 5 N.m (44 lb in) |
| 2 | Outside Rearview Mirror Inner Actuator Procedures When installing, align the retainers on the mirror glass with the motor retainers. With the palm of your hand push inward until the glass lock in place. Inspect the mirror actuator for proper operation before installing the outside rearview mirror glass. |
| WARNING |
|---|
| Refer to Glass and Sheet Metal Handling Warning . |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Outside Rearview Mirror Inner Actuator Replacement
Scheme 10
| Callout | Component Name |
|---|---|
| 1 | Outside Rearview Mirror Glass WARNING: Refer to Glass and Sheet Metal Handling Warning . Procedures Push the top center of the mirror inward, grasp the bottom center of mirror pulling rearward until the mirror releases from the motor. Disconnect the electrical connectors from the back of the mirror, if equipped. When installing, align the retainers on the mirror glass with the motor retainers. With the palm of your hand push inward until the glass lock in place. Inspect the mirror for proper operation before installing the door trim panel. |
| WARNING |
|---|
| Refer to Glass and Sheet Metal Handling Warning . |
Outside Rearview Mirror Glass Replacement
Scheme 11
| Callout | Component Name |
|---|---|
| 1 | Inside Rearview Mirror CAUTION: Refer to Fastener Caution . Procedure Remove the inside rearview mirror cover, if equipped. Disconnect the electrical connector, if equipped. Adjust the mirror to the full upward position. Loosen the set screw located at the base of the mirror. Slide the mirror upward off of the rearview mirror button. Refer to Control Module References for programming and setup information. Tighten 1.8 N.m (16 lb in) |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Inside Rearview Mirror Replacement
Scheme 12
- Determine the location of the mirror mounting base by marking the outside of the windshield with a marking pencil where the base was previously located. If it is not clear where the base was mounted, use the following steps to determine where the base should be installed: Using a measuring tape, measure the distance between the windshield pillars from the base of the shade line. Using a marking pencil, halfway between the windshield pillars, draw a centerline (1) on the windshield from the roof panel to the windshield base. Draw a perpendicular line intersecting the centerline (2) at that location. The top center of the mirror mounting base will be at the intersection of these lines.
- Scrape the inside windshield glass thoroughly with a safety razor or utility knife in order to remove all old adhesive.
- If reinstalling the original mounting base, place the mirror mounting base in a suitable holding device, such as a vice.
- Scrape the mirror mounting base thoroughly with a safety razor or utility knife in order to remove all old adhesive.
- Clean the inside windshield glass and the mounting surface of the mirror mounting base thoroughly with a clean cloth saturated with naphtha or a 50/50 mixture (by volume) of clean water and isopropyl alcohol.
- Using the Inside Mirror Adhesive Kit, or equivalent to apply a small amount of activator to the mounting surface of the mirror mounting base.
- Apply a small amount of activator to the windshield where the mounting base is to be installed.
- Allow the activator to dry 5 minutes.
- Apply 1 drop of adhesive to the center of the mirror mounting base.
- Immediately apply the mounting base to the windshield, ensuring that the mounting base aligns correctly to the marks made on the outside of the windshield.
- Hold the mounting base firmly in place for 1 minute.
- Allow the adhesive to set for 15 minutes.
- Install the mirror to the mirror mounting base and fasten, if necessary.
- Connect the electrical connector and install the wire cover, if equipped.
Heated Mirrors
The heated mirrors are controlled through the rear defog relay. Whenever the vehicle is running and the rear window defogger is turned on battery voltage is supplied to the mirror heater elements through the left and right mirror heater element control circuits.
