Lighting System: Specifications GMC Terrain I

Exterior Lights 11 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Brake Pedal Position Sensor Bolt9 N.m80 lb in
Front Fog Lamp Screw2 N.m18 lb in
Headlamp Mounting Bolt-Equinox4 N.m35 lb in
Headlamp Mounting Bolt-Terrain4.4 N.m39 lb in
High Mount Stop Lamp Screw2.5 N.m22 lb in
Tail Lamp Nut-Equinox2.5 N.m22 lb in
Tail Lamp Nut-Terrain6.36 N.m56 lb in
Tail Lamp Screw2.5 N.m22 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Headlights And Daytime Running Lamps
Scheme 1: Headlights And Daytime Running Lamps

Scheme 2

Scheme 2: Front Fog Lamps
Scheme 2: Front Fog Lamps

Scheme 3

Scheme 3: Left Park And License Lamps
Scheme 3: Left Park And License Lamps

Scheme 4

Scheme 4: Right Park Lamps
Scheme 4: Right Park Lamps

Scheme 5

Scheme 5: Turn Signals And Stop Lamps
Scheme 5: Turn Signals And Stop Lamps

Scheme 6

Scheme 6: Backup Lamps
Scheme 6: Backup Lamps

Scheme 7

Scheme 7: Interior Light Controls, Air Bag Indication And Footwell Lighting
Scheme 7: Interior Light Controls, Air Bag Indication And Footwell Lighting

Scheme 8

Scheme 8: Headliner and Floor Console Lighting
Scheme 8: Headliner and Floor Console Lighting

Scheme 9

Scheme 9: Dimming Controls And Switch Illumination (1 Of 2)
Scheme 9: Dimming Controls And Switch Illumination (1 Of 2)

Scheme 10

Scheme 10: Shift Lever Position Indicator And Switch Illumination (2 Of 2)
Scheme 10: Shift Lever Position Indicator And Switch Illumination (2 Of 2)

Scheme 11

Scheme 11: Accent Lighting
Scheme 11: Accent Lighting
