Brake Pedal Position Sensor Replacement
Note. Brake system does not use a brake switch, stoplight switch or brakelight switch. System uses a Brake Pedal Position Sensor to control these functions.
Scheme 12
Scheme 12: Brake Pedal Position Sensor Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the instrument panel insulator panel left side. Refer to Instrument Panel Insulator Panel Replacement - Left Side (Equinox) , Instrument Panel Insulator Panel Replacement - Left Side (Terrain) . Remove the communication interface module. Refer to Communication Interface Module Replacement |
| 1 | Brake Pedal Position Sensor Bolt CAUTION: Refer to Fastener Caution . Tighten 9 N.m (80 lb in) |
| 2 | Brake Pedal Position Sensor Procedure Disconnect the electrical connector. Pull the sensor away from the bracket. Recalibrate the brake pedal position sensor. Refer to Brake Pedal Position Sensor Calibration . |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Brake Pedal Position Sensor Replacement
Scheme 13
Scheme 13: Dimmer Switch Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the instrument panel insulator, left side. Refer to Instrument Panel Insulator Panel Replacement - Left Side (Equinox) , Instrument Panel Insulator Panel Replacement - Left Side (Terrain) Remove the driver knee bolster panel. Refer to Driver Knee Bolster Panel Replacement (Terrain) , Driver Knee Bolster Panel Replacement (Equinox) Remove the driver knee bolster reinforcement. Refer to Driver Knee Bolster Reinforcement Replacement (Equinox) , Driver Knee Bolster Reinforcement Replacement (Terrain) |
| 1 | Instrument Panel Lamp Dimmer Switch Procedure Disconnect the electrical connector. From underneath, carefully insert a long appropriate tool into the switch bracket from the inner side of the instrument panel and release the tabs fastening the dimmer switch to the dimmer switch bracket. At the same time, push forward on the switch from a surface side to separate it from the tabs. Use care not to damage the bracket while releasing the fastening tabs. |
Dimmer Switch Replacement
Scheme 14
Scheme 14: Headlamp Automatic Control Ambient Light Sensor Replacement
| Callout | Component Name |
|---|
| 1 | Instrument Panel Accessory Trim Plate Refer to Instrument Panel Accessory Trim Plate Replacement (Equinox) , Instrument Panel Accessory Trim Plate Replacement (Terrain) . |
| 2 | Headlamp Automatic Control Ambient Light Sensor Procedure Depress tabs to remove sensor from trim plate. |
Headlamp Automatic Control Ambient Light Sensor Replacement
Scheme 15
Scheme 15: Reading Lamp Switch Pushbutton Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the roof console. Refer to Roof Console Replacement . |
| 1 | Reading Lamp Switch Pushbutton Procedure Press tabs together and remove switch. |
Reading Lamp Switch Pushbutton Replacement
Scheme 16
Scheme 16: Dome and Reading Lamp Switch Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the roof console. Refer to Roof Console Replacement . |
| 1 | Dome and Reading Lamp Switch Procedure Press tabs together and remove switch. |
Dome and Reading Lamp Switch Replacement
Scheme 17
Scheme 17: Dome and Reading Lamp Lens Replacement
| Callout | Component Name |
|---|
| 1 | Dome Lamp Lens Procedure Using a nylon flat bladed tool release the four integral tabs on the lens from the roof console. |
Dome and Reading Lamp Lens Replacement
Scheme 18
Scheme 18: Courtesy Lamp Replacement
| Callout | Component Name |
|---|
| 1 | Courtesy Lamp Lens and Bezel Procedure Using a nylon flat bladed tool release the lens and bezel. |
| 2 | Courtesy Lamp Procedure Release the retaining tabs and remove the courtesy lamp from the headliner. |
Courtesy Lamp Replacement
Scheme 19
Scheme 19: Courtesy Lamp Bulb Replacement
| Callout | Component Name |
|---|
| 1 | Courtesy Lamp Lens Procedure Using a nylon flat bladed tool release the lens to gain access to the bulb. |
| 2 | Courtesy Lamp Bulb |
Courtesy Lamp Bulb Replacement
Scheme 20
Scheme 20: Instrument Panel Courtesy Lamp Replacement - Left Side
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the instrument panel insulator panel left side. Refer to Instrument Panel Insulator Panel Replacement - Left Side (Equinox) , Instrument Panel Insulator Panel Replacement - Left Side (Terrain) . |
| 1 | Instrument Panel Courtesy Lamp Procedure Use a plastic flat-bladed trim tool in order to release the lamp assembly from the drivers side knee bolster. Disconnect the electrical connection. |
| 2 | Instrument Panel Courtesy Lamp Bulb |
Instrument Panel Courtesy Lamp Replacement - Left Side
Scheme 21
Scheme 21: Instrument Panel Courtesy Lamp Replacement - Right Side
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the instrument panel insulator panel right side. Refer to Instrument Panel Insulator Panel Replacement - Right Side (Terrain) , Instrument Panel Insulator Panel Replacement - Right Side (Equinox) . |
| 1 | Instrument Panel Courtesy Lamp Procedure Use a plastic flat-bladed trim tool in order to release the lamp assembly from the instrument panel compartment housing. Disconnect the electrical connection. |
| 2 | Instrument Panel Courtesy Lamp Bulb |
Instrument Panel Courtesy Lamp Replacement - Right Side
Scheme 22
Scheme 22: Front Floor Console Flood Lamp Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the roof console. Refer to Roof Console Replacement . |
| 1 | Front Floor Console Flood Lamp Procedure Disconnect electrical connector. |
Front Floor Console Flood Lamp Replacement
Scheme 23
Scheme 23: Front Floor Console Armrest Compartment Lamp Replacement
| Callout | Component Name |
|---|
| 1 | Front Floor Console Armrest Compartment Lamp Procedure Open arm rest and using the appropriate tool, release the bottom of the lamp. Pull lamp downward to remove. Guide switch button through hole in the console. Disconnect the electrical connector. |
| 2 | Front Floor Console Armrest Compartment Lamp Bulb |
Front Floor Console Armrest Compartment Lamp Replacement
Scheme 24
Scheme 24: Front Side Door Courtesy Lamp Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the front side door trim panel. Refer to Front Side Door Trim Panel Replacement |
| 1 | Front Side Door Courtesy Lamp Procedure Disconnect the electrical connector. |
Front Side Door Courtesy Lamp Replacement
Scheme 25
Scheme 25: Front Side Door Warning Lamp Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the front side door trim panel. Refer to Front Side Door Trim Panel Replacement |
| 1 | Front Side Door Warning Lamp Procedure Disconnect the electrical connector. |
Front Side Door Warning Lamp Replacement
Scheme 26
Scheme 26: Sunshade Illuminated Mirror Lamp Bulb Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the sunshade illuminated mirror lamp lens with bezel. Refer to Sunshade Illuminated Mirror Lamp Lens Replacement |
| 1 | Sunshade Illuminated Mirror Lamp Bulb |
Sunshade Illuminated Mirror Lamp Bulb Replacement
Scheme 27
Scheme 27: Sunshade Illuminated Mirror Lamp Lens Replacement
| Callout | Component Name |
|---|
| 1 | Sunshade Illuminated Mirror Lamp Lens Procedure Carefully use a flat bladed tool, and release the tabs retaining the lamp lens and bezel to the sunshade assembly. |
Sunshade Illuminated Mirror Lamp Lens Replacement
Scheme 28
Scheme 28: Dome Lamp Bulb Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the dome lamp lens. Refer to Dome and Reading Lamp Lens Replacement . |
| 1 | Dome Lamp Bulbs |
Dome Lamp Bulb Replacement
Scheme 29
Scheme 29: Headlamp Replacement (Equinox)
| Callout | Component Name |
|---|
| Preliminary Procedure Open the hood. Remove the front bumper fascia. Refer to Front Bumper Fascia Replacement (Terrain) , Front Bumper Fascia Replacement (Equinox) . |
| 1 | Headlamp Mounting Bolt / Screw (Qty: 4) CAUTION: Refer to Fastener Caution . TIP: One screw is located at the front lower edge of the front fender outer panel at the bottom edge of the headlamp. Tighten 4 (56 lb in) |
| 2 | Headlamp Ball Socket Locator Pin Procedure Pull from the bottom of the headlamp forward in order to release the headlamp locator pin from the front outer corner of the body rail. Disconnect the forward lamp harness electrical connector on the headlamp being serviced. |
| 3 | Headlamp Assembly Procedure Check and adjust the front headlamp aim after the headlamp have been reinstalled. Refer to Headlamp Aiming . |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Headlamp Replacement (Equinox)
Scheme 30
Scheme 30: Headlamp Replacement (Terrain)
| Callout | Component Name |
|---|
| Preliminary Procedure Open the hood. Remove the front bumper fascia. Refer to Front Bumper Fascia Replacement (Terrain) , Front Bumper Fascia Replacement (Equinox) . |
| 1 | Headlamp Assembly Bolt / Screw (Qty: 4) CAUTION: Refer to Fastener Caution . TIP: One screw is located inside the front bumper fascia side retainer assembly. Tighten 4 (56 lb in) |
| 2 | Headlamp Assembly Procedure Pull from the bottom of the headlamp forward in order to release the headlamp locator pin from the front outer corner of the body rail. Disconnect the forward lamp harness electrical connector on the headlamp being serviced. Check and adjust the front headlamp aim after the headlamps have been reinstalled. Refer to Headlamp Aiming . |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Headlamp Replacement (Terrain)
Scheme 31
Scheme 31: Headlamp Bulb Replacement (High Beam Equinox)
| Callout | Component Name |
|---|
| Preliminary Procedure Turn the tire and wheel assembly in order to access the wheelhouse panel hole cover and screw. Remove the screw and cover from the wheelhouse panel liner. |
| 1 | Wheelhouse Panel Hole Cover Screw CAUTION: Refer to Fastener Caution . Hand tighten the screw. |
| 2 | Wheelhouse Panel Hole Cover TIP: Rotate the cover counter-clockwise and remove. |
| 3 | Headlamp Bulb Accessory Cover TIP: Rotate the cover counter-clockwise and remove. |
| 4 | Headlamp Bulb Assembly (High Beam) WARNING: Refer to Halogen Bulb Warning . Procedure Disconnect the electrical connector from the bulb socket. Rotate the bulb socket counter-clockwise and remove from the headlamp assembly. |
| CAUTION |
|---|
| Refer to Fastener Caution . |
| WARNING |
|---|
| Refer to Halogen Bulb Warning . |
Headlamp Bulb Replacement (High Beam Equinox)
Scheme 32
Scheme 32: Headlamp Bulb Replacement (Low Beam Equinox)
| Callout | Component Name |
|---|
| Preliminary Procedure Turn the tire and wheel assembly in order to access the wheelhouse panel hole cover and screw. Remove the screw and cover from the wheelhouse panel liner. |
| 1 | Wheelhouse Panel Hole Cover Screw CAUTION: Refer to Fastener Caution . Hand tighten the screw. |
| 2 | Wheelhouse Panel Hole Cover TIP: Rotate the cover counter-clockwise and remove. |
| 3 | Headlamp Bulb Accessory Cover TIP: Rotate the cover counter-clockwise and remove. |
| 4 | Headlamp Bulb Assembly (Low Beam) WARNING: Refer to Halogen Bulb Warning . Procedure Disconnect the electrical connector from the bulb socket. Rotate the bulb socket counter-clockwise and remove from the headlamp assembly. |
| CAUTION |
|---|
| Refer to Fastener Caution . |
| WARNING |
|---|
| Refer to Halogen Bulb Warning . |
Headlamp Bulb Replacement (Low Beam Equinox)
Scheme 33
Scheme 33: Headlamp Bulb Replacement (High Beam Terrain)
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the front wheelhouse front panel hole cover. Refer to Front Wheelhouse Front Panel Hole Cover Replacement (Terrain) . |
| 1 | Headlamp Bulb Assembly-High Beam Procedure WARNING: Refer to Halogen Bulb Warning . Remove the headlamp bulb access cover assembly. Turn the cover a quarter turn counter-clockwise. Disconnect the high beam bulb socket electrical connector. Rotate the bulb socket a quarter turn counter-clockwise and remove from the headlamp assembly. |
| WARNING |
|---|
| Refer to Halogen Bulb Warning . |
Headlamp Bulb Replacement (High Beam Terrain)
Scheme 34
Scheme 34: Headlamp Bulb Replacement (Low Beam Terrain)
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the front wheelhouse front panel hole cover. Refer to Front Wheelhouse Front Panel Hole Cover Replacement (Terrain) . |
| 1 | Headlamp Bulb Assembly-Low Beam Procedure WARNING: Refer to Halogen Bulb Warning . Remove the headlamp bulb access cover assembly. Turn the cover a quarter turn counter-clockwise. Disconnect the low beam bulb socket electrical connector. Rotate the bulb socket a quarter turn counter-clockwise and remove from the headlamp assembly. |
| WARNING |
|---|
| Refer to Halogen Bulb Warning . |
Headlamp Bulb Replacement (Low Beam Terrain)
