HVAC System - Automatic: Other GMC Terrain I

Reference Information

Schematic Reference

HVAC Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Automatic HVAC Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-491170-S01761107082012073000000)
2. «Connector Repairs»(ref-491170-S29468502572012073000000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-491170-S23088445062012073000000)
4. «Wiring Repairs»(ref-491170-S24000289392012073000000)

Scan Tool Reference

Control Module References

Repair Instructions

Perform the Diagnostic Repair Verification after completing the repair.

1. «HVAC Component Replacement Reference»(ref-491160-S12156961572012073000000)
2. «Control Module References»(ref-491163-S28884786072012073000000) for HVAC control module replacement, programming and setup

Schematic Reference

HVAC Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Automatic HVAC Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-491170-S01761107082012073000000)
2. «Connector Repairs»(ref-491170-S29468502572012073000000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-491170-S23088445062012073000000)
4. «Wiring Repairs»(ref-491170-S24000289392012073000000)

Scan Tool Reference

Control Module References

Perform the Diagnostic Repair Verification after completing the repair.

1. «HVAC Component Replacement Reference»(ref-491160-S12156961572012073000000)
2. «Control Module References»(ref-491163-S28884786072012073000000) for HVAC control module replacement, programming and setup

Schematic Reference

HVAC Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Automatic HVAC Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-491170-S01761107082012073000000)
2. «Connector Repairs»(ref-491170-S29468502572012073000000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-491170-S23088445062012073000000)
4. «Wiring Repairs»(ref-491170-S24000289392012073000000)

Scan Tool Reference

Control Module References for scan tool information

Perform the Diagnostic Repair Verification after completing the repair.

1. «HVAC Component Replacement Reference»(ref-491160-S12156961572012073000000)
2. «Control Module References»(ref-491163-S28884786072012073000000) for HVAC control module replacement, programming and setup

Schematic Reference

HVAC Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Automatic HVAC Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-491170-S01761107082012073000000)
2. «Connector Repairs»(ref-491170-S29468502572012073000000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-491170-S23088445062012073000000)
4. «Wiring Repairs»(ref-491170-S24000289392012073000000)

Scan Tool Reference

Control Module References for scan tool information

Perform the Diagnostic Repair Verification after completing the repair.

1. «HVAC Component Replacement Reference»(ref-491160-S12156961572012073000000)
2. «Control Module References»(ref-491163-S28884786072012073000000) for HVAC control module programming and setup

Schematic Reference

HVAC Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Automatic HVAC Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-491170-S01761107082012073000000)
2. «Connector Repairs»(ref-491170-S29468502572012073000000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-491170-S23088445062012073000000)
4. «Wiring Repairs»(ref-491170-S24000289392012073000000)

Scan Tool Reference

Control Module References for scan tool information

Perform the Diagnostic Repair Verification after completing the repair.

1. «HVAC Component Replacement Reference»(ref-491160-S12156961572012073000000)
2. «Control Module References»(ref-491163-S28884786072012073000000) for HVAC control module replacement, programming, and setup

Schematic Reference

HVAC Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Automatic HVAC Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-491170-S01761107082012073000000)
2. «Connector Repairs»(ref-491170-S29468502572012073000000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-491170-S23088445062012073000000)
4. «Wiring Repairs»(ref-491170-S24000289392012073000000)

Scan Tool Reference

Control Module References for scan tool information

Circuit/System Verification

Ignition ON, command the appropriate actuator in both directions with a scan tool. The scan tool Door Position parameter reading should be between 5-250 counts.

Perform the Diagnostic Repair Verification after completing the repair.

1. «HVAC Component Replacement Reference»(ref-491160-S12156961572012073000000)
2. «Control Module References»(ref-491163-S28884786072012073000000) for HVAC control module replacement, programming and setup

Schematic Reference

HVAC Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Automatic HVAC Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-491170-S01761107082012073000000)
2. «Connector Repairs»(ref-491170-S29468502572012073000000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-491170-S23088445062012073000000)
4. «Wiring Repairs»(ref-491170-S24000289392012073000000)

Scan Tool Reference

Control Module References for scan tool information

Perform the Diagnostic Repair Verification after completing the repair.

1. «HVAC Component Replacement Reference»(ref-491160-S12156961572012073000000)
2. «Control Module References»(ref-491163-S28884786072012073000000) for HVAC control module replacement, programming, and setup

Schematic Reference

HVAC Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Automatic HVAC Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-491170-S01761107082012073000000)
2. «Connector Repairs»(ref-491170-S29468502572012073000000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-491170-S23088445062012073000000)
4. «Wiring Repairs»(ref-491170-S24000289392012073000000)

Scan Tool Reference

Control Module References for scan tool information

Perform the Diagnostic Repair Verification after completing the repair.

1. «HVAC Component Replacement Reference»(ref-491160-S12156961572012073000000)
2. «Control Module References»(ref-491163-S28884786072012073000000) for engine control module (ECM) replacement, programming, and setup

Schematic Reference

HVAC Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Automatic HVAC Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-491170-S01761107082012073000000)
2. «Connector Repairs»(ref-491170-S29468502572012073000000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-491170-S23088445062012073000000)
4. «Wiring Repairs»(ref-491170-S24000289392012073000000)

Scan Tool Reference

Control Module References for scan tool information

Perform the Diagnostic Repair Verification after completing the repair.

1. «HVAC Component Replacement Reference»(ref-491160-S12156961572012073000000)
2. «Control Module References»(ref-491163-S28884786072012073000000) for HVAC control module replacement, programming and setup

Symptoms - HVAC Systems - Automatic

Note. The following steps must be completed before using the symptom tables

1. Perform the «Diagnostic System Check - Vehicle»(ref-491140-S24065023222012073000000) before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link.
2. Review the system operation in order to familiarize yourself with the system functions. Refer to «Automatic HVAC Description and Operation»(ref-491160-S17874792192012073000000) .

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Schematic Reference

HVAC Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Automatic HVAC Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-491170-S01761107082012073000000)
2. «Connector Repairs»(ref-491170-S29468502572012073000000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-491170-S23088445062012073000000)
4. «Wiring Repairs»(ref-491170-S24000289392012073000000)

Scan Tool Reference

Control Module References

Perform the Diagnostic Repair Verification after completing the repair.

1. «HVAC Component Replacement Reference»(ref-491160-S12156961572012073000000)
2. «Control Module References»(ref-491163-S28884786072012073000000) for HVAC control module replacement, programming and setup

Schematic Reference

HVAC Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Automatic HVAC Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-491170-S01761107082012073000000)
2. «Connector Repairs»(ref-491170-S29468502572012073000000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-491170-S23088445062012073000000)
4. «Wiring Repairs»(ref-491170-S24000289392012073000000)

Scan Tool Reference

Control Module References

Perform the Diagnostic Repair Verification after completing the repair.

1. «HVAC Component Replacement Reference»(ref-491160-S12156961572012073000000)
2. «Control Module References»(ref-491163-S28884786072012073000000) for HVAC control module replacement, programming and setup

Schematic Reference

HVAC Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Automatic HVAC Description and Operation

Electrical Information Reference

1. «Circuit Testing»(ref-491170-S01761107082012073000000)
2. «Connector Repairs»(ref-491170-S29468502572012073000000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-491170-S23088445062012073000000)
4. «Wiring Repairs»(ref-491170-S24000289392012073000000)

Scan Tool Reference

Control Module References

Perform the Diagnostic Repair Verification after completing the repair.

1. «HVAC Component Replacement Reference»(ref-491160-S12156961572012073000000)
2. «Control Module References»(ref-491163-S28884786072012073000000) for HVAC control module replacement, programming and setup

Actuator Recalibration

Note. Do not adjust any controls on the HVAC control module while the HVAC control module is self-calibrating. If interrupted, improper HVAC performance will result.

When replacing the HVAC control module it will be necessary to allow the HVAC control module to perform a calibration process. When installing the HVAC control module be sure to perform the following

1. Place the ignition switch to the OFF position.
2. Disconnect the scan tool.
3. Install the HVAC control module.
4. Connect all previously disconnected components.
5. Ignition ON.
6. Wait 40 s for the HVAC control module to self-calibrate.
7. Verify that no DTCs have set as current DTCs.

When replacing the HVAC actuator it will be necessary to allow the HVAC control module to perform a calibration process. When installing the HVAC actuator be sure to perform one of the following

Preferred Method (with Scan Tool)

1. Clear all DTCs.
2. Place the ignition switch in the OFF position.
3. Install the HVAC actuator.
4. Connect all previously disconnected components.
5. Start the vehicle.
6. With the scan tool, initiate the HVAC Actuators re-calibration feature of the Remote Heater and Air Conditioning Control Module Special Functions menu.
7. Verify that no DTCs have set as current DTCs.

Alternate Method (without Scan Tool)

1. Clear all DTCs.
2. Place the ignition switch to the OFF position.
3. Install the HVAC actuator.
4. Connect all previously disconnected components.
5. Remove the HVAC control module fuse for a minimum of 10 s.
6. Install the HVAC control module fuse.
7. Ignition ON.
8. Wait 40 s for the HVAC control module to self-calibrate.
9. Verify that no DTCs have set as current DTCs.

Scheme 51

Heater and Air Conditioning Control Replacement (Equinox)

Scheme 52

Heater and Air Conditioning Control Replacement (Terrain)

Scheme 53

Air Inlet Valve Actuator Replacement

Scheme 54

Mode Valve Actuator Replacement

Scheme 55

Mode Control Cam Replacement

Scheme 56

Temperature Valve Actuator Replacement

Scheme 57

Duct Air Temperature Sensor Replacement - Upper

Scheme 58

Duct Air Temperature Sensor Replacement - Lower

Scheme 59

Ambient Air Temperature Sensor Replacement

Scheme 60

Sun Load Temperature Sensor Replacement

Scheme 61

Blower Motor Control Module Replacement

HVAC Control Components

Radio/HVAC Control

The Radio/HVAC control contains all switches, which are required to control the functions of HVAC and serve as interface between the operator and the HVAC control module. The selected values are passed to the HVAC control module via LIN-Bus.

HVAC Control Module

The HVAC control module is a GMLAN device that interfaces between the operator and the HVAC system to maintain and control desired air temperature and air distribution settings. The battery positive voltage circuit provides power that the HVAC control module uses for keep alive memory. If the battery positive voltage circuit loses power, all HVAC DTCs and settings will be erased from keep alive memory. The body control module (BCM), which is the vehicle mode master, provides a device ON-Signal. The HVAC control module provides blower, air delivery mode and air temperature settings.

The HVAC control module supports the following features

Mode Actuator

The actuator is a 5-wire bi-directional electric motor that incorporates a feedback potentiometer. Low reference, 5V reference, position signal, and 2 control circuits enable the actuator to operate. The control circuits use either a 0 or 12 V value to coordinate the actuator movement. When the actuator is at rest, both control circuits have a value of 0 V. In order to move the actuator, the HVAC control module grounds one of the control circuits while providing the other with 12 V. The HVAC control module reverses the polarity of the control circuits to move the actuator in the opposite direction. When the actuator shaft rotates, the potentiometers adjustable contact changes the door position signal between 0-5 V. The HVAC control module uses a range of 0-255 counts to index the actuator position. The door position signal voltage is converted to a 0-255 count range. When the module sets a commanded, or targeted, value, one of the control circuits is grounded. As the actuator shaft rotates the changing position signal is sent to the module. Once the position signal and the commanded value are the same, the module removes power and ground from the control circuits.

Air Temperature Actuator

The actuator is a 5-wire bi-directional electric motor that incorporates a feedback potentiometer. Low reference, 5V reference, position signal, and 2 control circuits enable the actuator to operate. The control circuits use either a 0 or 12 V value to coordinate the actuator movement. When the actuator is at rest, both control circuits have a value of 0 V. In order to move the actuator, the HVAC control module grounds one of the control circuits while providing the other with 12 V. The HVAC control module reverses the polarity of the control circuits to move the actuator in the opposite direction. When the actuator shaft rotates, the potentiometers adjustable contact changes the door position signal between 0-5 V. The HVAC control module uses a range of 0-255 counts to index the actuator position. The door position signal voltage is converted to a 0-255 count range. When the module sets a commanded, or targeted, value, one of the control circuits is grounded. As the actuator shaft rotates the changing position signal is sent to the module. Once the position signal and the commanded value are the same, the module removes power and ground from the control circuits.

Recirculation Actuator

The actuator is a 5-wire bi-directional electric motor that incorporates a feedback potentiometer. Low reference, 5V reference, position signal, and 2 control circuits enable the actuator to operate. The control circuits use either a 0 or 12 V value to coordinate the actuator movement. When the actuator is at rest, both control circuits have a value of 0 V. In order to move the actuator, the HVAC control module grounds one of the control circuits while providing the other with 12 V. The HVAC control module reverses the polarity of the control circuits to move the actuator in the opposite direction. When the actuator shaft rotates, the potentiometers adjustable contact changes the door position signal between 0-5 V. The HVAC control module uses a range of 0-255 counts to index the actuator position. The door position signal voltage is converted to a 0-255 count range. When the module sets a commanded, or targeted, value, one of the control circuits is grounded. As the actuator shaft rotates the changing position signal is sent to the module. Once the position signal and the commanded value are the same, the module removes power and ground from the control circuits.

Blower Motor Control Processor

The blower motor control processor controls the speed of the blower motor by increasing or decreasing the voltage drop on the ground side of the blower motor. The HVAC control module provides a low side pulse width modulation (PWM) signal to the blower motor control processor via the blower motor speed control circuit. As the requested blower speed increases, the HVAC control module increases the amount of time that the speed signal is modulated to ground. As the requested blower speed decreases, the HVAC control module decreases the amount of time that the signal is modulated to ground.

Duct Temperature Sensors

The air temperature sensors are 2-wire negative temperature co-efficient thermistors. The sensors operate within a temperature range of -40 to +85°C (-40 to +185°F). The sensors are installed in the air distribution ducts and measure the temperature of the air that streams from the ducts. The HVAC control module uses these values to calculate the mixed air flap position.

Evaporator Temperature Sensor

The evaporator temperature sensor is a 2-wire negative temperature co-efficient thermistor. The sensor operates within a temperature range of -40 to +85°C (-40 to +185°F). The sensor is installed at the evaporator and measures its temperature. If the temperature drops under 3°C (38°F), the compressor will be switched off in order to prevent a frozen evaporator.

A/C Refrigerant Pressure Sensor

The A/C refrigerant pressure sensor is a 3-wire piezoelectric pressure transducer. A 5 V reference voltage, low reference, and signal circuits enable the sensor to operate. The A/C pressure signal can be between 0.2-4.8 V. When the A/C refrigerant pressure is low, the signal value is near 0 V. When the A/C refrigerant pressure is high, the signal value is near 5 V. The engine control module (ECM) converts the voltage signal to a pressure value. When pressure is too high or too low, the ECM will not allow the A/C compressor clutch to engage.

A/C Compressor

The A/C compressor is belt driven and operates when the magnetic clutch is engaged. When the A/C switch is pressed, the HVAC control module sends an A/C request message to the ECM via CAN-Bus. Therefore the ECM grounds the A/C compressor clutch relay control circuit, which will switch the A/C compressor clutch relay. With the relay contacts closed, battery voltage is supplied to the A/C compressor clutch. The A/C compressor clutch will be activated.

Ambient Light/Sunload Sensor

The ambient light/sunload sensor includes the sunload sensor and passenger compartment temperature sensor.

This sensor assembly provides information about

1. Sun heat intensity
2. Passenger compartment temperature

The solar sensor is connected to ground and to a 5 V stabilized voltage supply through the HVAC control module. As the sunload increases, the sensor signal voltage also increases and vice versa. The signal varies between 1.4-4.5 V and is provided to the HVAC control module.

The passenger compartment temperature sensor is a negative temperature co-efficient thermistor. A signal and low reference circuit enables the sensor to operate. As the air temperature increases, the sensor resistance decreases. The sensor signal varies between 0-5 V.

Bright or high intensity light causes the vehicles interior temperature to increase. The HVAC system compensates for the increased temperature by diverting additional cool air into the vehicle.

Air Speed

The blower control switch is part of the Radio/HVAC control. The selected value of the blower switch position is sent to the HVAC control module via LIN-Bus.

The blower motor control module is an interface between HVAC control module and blower motor. The blower motor control module regulates supply voltage and ground circuits to blower motor. The HVAC control module provides a PWM signal to the blower motor control module in order to command the desired blower motor speed. The blower motor control module supplies battery voltage to the blower motor and uses the blower motor ground as a low side control to adjust the blower motor speed. The voltage amounts between 2-13 V and changes linear to the height of the PWM signal.

Air Delivery

The HVAC control module controls the distribution of air by the use of recirculation and mode actuator. The modes that may be selected are

1. Defrost
2. Defog
3. Panel
4. Floor

The desired air distribution mode can be selected with the air distribution switches at the Radio/HVAC control. The Radio/HVAC control delivers the values to the HVAC control module via LIN-Bus. The HVAC control module controls the air distribution actuator so that it drives the flap to the calculated position. Depending on the position of the flap, air is distributed through various ducts leading to the outlets in the dash. Turning the mode flap to the defrost position, the HVAC control module will move the recirculation actuator to outside air, reducing window fogging. When defrost is selected, the blower motor will be activated, regardless of the coolant temperature. The HVAC control module enables a high volume of air delivered to the front defrost vents. A/C is available in all modes.

The rear window defogger does not affect the HVAC system.

Engine Coolant

Engine coolant is the essential element of the heating system. The thermostat controls the normal engine operating coolant temperature. The thermostat also creates a restriction for the cooling system that promotes a positive coolant flow and helps prevent cavitation.

Coolant enters the heater core through the inlet heater hose, in a pressurized state. The heater core is located inside the HVAC control module. The ambient air drawn through the HVAC control module absorbs the heat of the coolant flowing through the heater core. Heated air is distributed to the passenger compartment, through the HVAC control module, for passenger comfort. Opening or closing the air temperature flap controls the amount of heat delivered to the passenger compartment. The coolant exits the heater core through the return heater hose and recirculates back to the engine cooling system.

A/C Cycle

Refrigerant is the key element in an air conditioning system. R-134a is presently the only Environmental Protection Agency approved refrigerant for automotive use. R-134a is a very low temperature gas that can transfer the undesirable heat and moisture from the passenger compartment to the outside air.

The compressor builds pressure on the vapor refrigerant. Compressing the refrigerant also adds heat to the refrigerant. The refrigerant is discharged from the compressor, through the discharge hose, and forced to flow to the condenser and then through the balance of the A/C system. The A/C system is mechanically protected with the use of a high pressure relief valve. If the A/C refrigerant pressure sensor fails or if the refrigerant system becomes restricted and refrigerant pressure continued to rise, the high pressure relief will pop open and release refrigerant from the system.

Compressed refrigerant enters the condenser in a high temperature, high pressure vapor state. As the refrigerant flows through the condenser, the heat of the refrigerant is transferred to the ambient air passing through the condenser. Cooling the refrigerant causes the refrigerant to condense and change from a vapor to a liquid state.

The condenser is located in front of the radiator for maximum heat transfer. The condenser is made of aluminum tubing and aluminum cooling fins, which allows rapid heat transfer for the refrigerant. The semi-cooled liquid refrigerant exits the condenser and flows to the Receiver/Dehydrator (R/D).

The R/D contains desiccant that absorbs moisture that may be in the refrigerant system. The R/D also acts as a storage vessel to ensure that a steady flow of liquid reaches the thermal expansion valve. The refrigerant exits the R/D and flows through the liquid line to the thermal expansion valve.

The thermal expansion valve is located at the front of dash and attaches to the evaporator inlet and outlet pipes. The thermal expansion valve is the dividing point for the high and the low pressure sides of the A/C system. As the refrigerant passes through the thermal expansion valve, the pressure on the refrigerant is lowered. The thermal expansion valve also meters the amount of liquid refrigerant that can flow into the evaporator.

Refrigerant exiting the thermal expansion valve flows into the evaporator core in a low pressure, liquid state. Ambient air is drawn through the HVAC control module and passes through the evaporator core. Warm and moist air will cause the liquid refrigerant boil inside of the evaporator core. The boiling refrigerant absorbs heat from the ambient air and draws moisture onto the evaporator. The refrigerant exits the evaporator through the suction line and back to the A/C compressor, in a vapor state, and completing the A/C cycle of heat removal. At the A/C compressor, the refrigerant is compressed again and the cycle of heat removal is repeated.

The conditioned air is distributed through the HVAC control module for passenger comfort. The heat and moisture removed from the passenger compartment will also change form, or condense, and is discharged from the HVAC control module as water.
