Note. Proper riding height is necessary for correct wheel alignment. Before measuring riding height, ensure tire inflation pressure is correct, cargo compartment is empty, and fuel tank is full.
Bounce vehicle several times to normalize suspension. Measure riding height. (Scheme 4)or (Scheme 5). If riding height is not as specified, repair or replace suspension components as necessary. See the RIDING HEIGHT SPECIFICATIONS table. If riding height is okay, align wheels. See the WHEEL ALIGNMENT SPECIFICATIONS & PROCEDURES article.
Scheme 4
Scheme 5
MODEL IDENTIFICATION
In this article, vehicle models are designated by series letter, which is the fifth character of the Vehicle Identification Number (VIN). The VIN is stamped on a metal pad on top left end of instrument panel, near windshield. See MODEL IDENTIFICATION table.
| Series (1) | Model |
|---|---|
| "C" | 2WD |
| "K" | 4WD |
| (1) Fifth character of VIN. | |
| (1) | Fifth character of VIN. |
MODEL IDENTIFICATION
SPECIFICATIONS
| Application | In. (mm) | |
|---|---|---|
| 2WD | 3.7 +/- 0.2 (95 +/- 6.0) | |
| 4WD | ||
| K1500/K2500 | 6.2 +/- 0.2 (157 +/- 6.0) | |
| K3500 | 5.7 +/- 0.2 (145 +/- 6.0) | |
RIDING HEIGHT SPECIFICATIONS
