Automatic Transmission Overhaul & Testing - 4l60-e GMC Suburban I

APPLICATION

TRANSMISSION APPLICATIONS

IDENTIFICATION

The 4L60-E transmission can be identified by a letter code contained in identification number. Identification number is stamped on transmission case above oil pan rail on right rear side. (Scheme 1) Identification number contains information which must be used when ordering replacement parts.

Scheme 1

DESCRIPTION

The 4L60-E is a fully automatic transmission consisting of a 3-element hydraulic torque converter with a Torque Converter Clutch (TCC). Two planetary gear sets, 5 multiple-disc clutches, one sprag clutch, one roller clutch and a 2-4 band provide friction elements necessary to produce 4 forward speeds. (Scheme 2)

A hydraulic system, pressurized by a variable capacity vane type oil pump, provides pressure required to operate friction elements and automatic controls. The 4L60-E also contains electronic solenoids to control hydraulic operations. A Powertrain Control Module (PCM) receives signals from Vehicle Speed Sensor (VSS), Throttle Position (TP) Sensor, fluid pressure switch assembly, and temperature sensor. These signals help PCM determine when to switch 2 shift solenoids, 3-2 downshift solenoid, and/or TCC solenoid on or off. PCM can also control line pressure via pressure control solenoid (force motor).

Scheme 2

LUBRICATION

See appropriate TRANSMISSION SERVICING - A/T article in the TRANSMISSION SERVICING section.

ADJUSTMENTS

See appropriate TRANSMISSION SERVICING - A/T article in the TRANSMISSION SERVICING section.

Removal & Installation

Remove drive shaft. Pry oil seal from extension housing. Coat outside edge of NEW oil seal with non-hardening sealer. Using Seal Installer (J-21426 ), install oil seal. To complete installation, install drive shaft. Check fluid level.

VALVE BODY

Note. Beginning at start of production for all 1996 models, 4L60-E transmissions were built with a NEW design manual valve and a NEW design valve body casting. New design improves exhaust path for low-reverse clutch fluid when selector lever is in Drive. It also improves low-reverse clutch durability. Manual valves and valve bodies for 1995 and 1996 models ARE NOT interchangeable.

Removal

1. Remove transmission oil pan. Remove oil filter and "O" ring. Ensure "O" ring is removed from transmission case. Remove electrical connectors from switches and solenoids, and mark for reassembly reference. Remove pressure switch assembly. Remove accumulator cover. Remove valve body bolts. Note length and location of bolts for installation reference.
2. Note direction of manual valve link. Remove manual valve link from manual valve at valve body. (Scheme 3) Remove valve body. Note location of check balls. DO NOT lose balls. (Scheme 4)and (Scheme 5).

Scheme 3

Scheme 4

Scheme 5

Installation

1. Coat check balls with petroleum jelly. Install check balls in proper locations on separator plate. (Scheme 4)and (Scheme 5). Install manual valve link. Ensure manual valve link is properly seated in manual valve. (Scheme 3) Improper positioning may prevent vehicle operation in "D" range. NOTE: Improper positioning of throttle valve link will result in erratic shift points or high oil pressure.
2. Install valve body and retaining bolts. Tighten all bolts to specification. See «TORQUE SPECIFICATIONS»(/gmc/suburban/i-1992-1999/remont/automatic-trans/#automatic-transmission-overhaul-testing-4l60-e__torque-specifications). Lubricate oil filter "O" ring with ATF before installation. To complete installation, reverse removal procedure. Fill transmission with fluid.

Install Piston Compressor (J-29714) on oil pan. Compress servo cover, and remove retaining ring. (Scheme 6) Remove servo cover and "O" ring. Remove 2-4 servo assembly. To install, reverse removal procedure. For servo pin length check, see 2-4 SERVO ASSEMBLY under TRANSMISSION DISASSEMBLY.

Scheme 6

TROUBLE SHOOTING

Note. For electrical trouble shooting, see procedures in AUTO TRANS DIAGNOSIS - 4L60-E article. For additional trouble shooting, see TECHNICAL SERVICE BULLETINS. For elements in use at specified selector lever positions, see CLUTCH & BAND APPLICATION CHART under CLUTCH & BAND APPLICATION.

1st Gear Only, No Upshift

Check 1-2 shift valve sticking in valve body. Spacer plate or gaskets damaged or not positioned properly. Case-to-valve body face damaged or not flat. Governor screen restricted or damaged. 2-4 servo assembly restricted or blocked case passages. Nicks or burrs on servo pin or case pin bore. Missing or damaged piston or pin seals. 4th servo piston installed backward.2-4 band worn or damaged, or band anchor pin not engaged. Check shift solenoids.

1st Gear Start In 2nd Gear Start Mode (Camaro/Firebird Only)

Check second gear start switch.

Slips In 1st Gear

Defective forward clutch assembly. Clutch plates worn. Piston porous or damaged. Piston seals missing or damaged. Input housing-to-forward clutch housing "O" ring seal missing or damaged. Damaged housing. Housing retainer and ball assembly damaged or not seating. Input shaft and housing assembly turbine shaft seals missing or damaged. Accumulator valve stuck in valve body.

Valve body face not flat, damaged lands, or interconnected passages. Spacer plate or gaskets incorrect, damaged or not positioned properly. Check for defective 1-2 accumulator piston assembly. Porosity in piston or cover and pin assembly. Damaged piston ring grooves. Piston seal missing or damaged. Cover gasket missing or damaged. Broken accumulator spring.

Improper oil pressure. Torque converter stator roller clutch not holding or 4th servo piston in backward. Damage to low roller clutch lugs or inner ramps. Rollers not free moving, inadequate spring tension or damage to inner splines. Oil passage plugged. Forward clutch accumulator piston seal missing or damaged. Piston out of its bore.

Slipping Or Rough 1-2 Shift

Check for defective valve body assembly. 1-2 shift valve train or accumulator valve stuck. Gaskets or spacer plate incorrect, damaged or not installed properly. Valve body face not flat.

Defective 2-4 servo assembly. Apply pin incorrect length. Servo seals or "O" ring seals missing or damaged. Restricted or missing oil passages. Case servo bore damaged. Defective 2nd accumulator. Porosity in 1-2 accumulator housing or piston. Piston seal or groove damaged. Nicks or burrs in 1-2 accumulator housing. Missing or restricted oil passages or 2-4 band worn or not positioned properly. Oil pump assembly or case faces not flat.

Slipping, Rough Or No 2-3 Shift

Internal converter damage. Oil pump stator shaft sleeve scored or not located properly. Valve body 2-3 valve train or accumulator valve stuck. Spacer plate or gaskets incorrect, damaged or not positioned properly. Input housing assembly forward or 3-4 clutch plates worn. Excessive clutch plate travel.

Forward or 3-4 piston seals damaged. Porosity in 3-4 clutch housing or piston, or 3-4 piston check ball stuck, damaged or not sealing. Restricted apply passages. Forward clutch piston or 3rd accumulator retainer and ball assembly not seating. Sealing balls loose or missing. 2-4 servo assembly or 2nd apply piston seals missing or damaged.

1st & 4th Or 2nd & 3rd Gear Only

Check shift solenoids for dirt, damaged seals or electrical connections.

3rd Gear Only

Check 2-3 shift solenoid and 3-2 control solenoid circuits, damaged seals or electrical connections.

3-2 Flare Or Tie Up

Check 3-2 control solenoid for dirt, damaged seals or electrical connections.

Slipping, Rough Or No 3-4 Shift

Check oil pump assembly faces not flat or pump cover retainer and ball assembly omitted or damaged. Valve body assembly 2-3 shift train, accumulator valve, 1-2 shift valve or 3-2 control valve stuck. Manual valve link bent or damaged. Spacer plate or gaskets incorrect, damaged or not positioned properly. Defective 2-4 servo assembly.

Incorrect band apply pin. Servo seals missing or damaged. Porosity in pistons, cover or case. Plugged or missing orifice cup plug. Case 3rd accumulator retainer and ball assembly leaking. Porosity in 3-4 accumulator piston or bore. 3-4 accumulator piston seal or seal grooves damaged. Restricted oil passage. Defective input housing assembly. Forward or 3-4 clutch plates worn, or excessive plate travel.

Forward or 3-4 piston seals damaged. Porosity in 3-4 clutch housing or piston. 3-4 piston check ball stuck, damaged or not sealing. Restricted apply passages. Forward clutch piston retainer and ball assembly not seating. 2-4 band worn or not positioned properly. Sealing balls loose or missing.

No Reverse Or Slips In Reverse

Defective input housing assembly. 3-4 apply ring stuck in applied position. Forward clutch not releasing. Turbine shaft seals missing or damaged. Manual valve link disconnected. Defective oil pump assembly. Retainer and ball assembly missing or damaged. Stator shaft seal rings or ring grooves damaged. Stator shaft sleeve scored or damaged. Reverse boost valve stuck, damaged or not assembled properly. Cup plug missing.

Restricted oil passage. Oil pump faces not flat. Converter clutch valve stuck. Defective valve body assembly. 2-3 shift valve stuck. Manual linkage out of adjustment. Spacer plate and gaskets incorrect, damaged or not positioned properly. Defective reverse input clutch assembly. Clutch plate worn. Housing and drum assembly cracked at weld. Clutch plate or return spring assembly retaining ring out of groove. Piston deformed or dished.

Seals damaged or missing. Retainer and ball assembly not sealing. Restricted apply passage. Defective low-reverse clutch. Clutch plates worn or retaining ring not positioned properly. Porosity in piston. Seals damaged. Return spring assembly retaining ring not positioned properly. Case porosity. Case cover plate not tightened properly or gasket missing or damaged.

No Part-Throttle Or Delayed Downshifts

Check for defective 2-4 servo assembly. Servo cover retaining ring missing or not assembled properly. 4th apply piston damaged or not assembled properly. Inner housing damaged or not assembled properly. Defective valve body assembly. 3-2 control valve stuck. 4-3 sequence valve body channel blocked. No. 5 check ball missing.

Harsh Garage Shifts

Check valve body for missing check ball, or orifice cup plug.

No Overrun Braking In Manual 3-2-1

Defective valve body assembly. 4-3 sequence valve or throttle valve stuck. No. 3 check ball not positioned properly. Spacer plate and gaskets incorrect, damaged or not positioned properly. Defective input clutch assembly. Turbine shaft oil passages plugged or not drilled. Turbine shaft seal rings damaged. Turbine shaft sealing balls loose or missing. Porosity in forward or overrun clutch piston. Overrun piston seals damaged or cut. Overrun piston check ball not sealing.

Drives (Creeps) In Neutral

Forward clutch not releasing. Manual valve link disconnected. Converter clutch apply valve stuck in oil pump. Face of transmission case not flat or internal leakage in case.

Starts In 2nd In "D"

Forward sprag clutch assembly installed backward.

No Park

Parking linkage binding, loose, missing or not positioned properly.

Oil Pressure High Or Low

Oil pressure regulator valve stuck or valve spring damaged. Rotor guide omitted or not assembled properly. Rotor cracked or reverse boost valve or sleeve stuck, damaged or not assembled properly. Orifice hole in pressure regulator valve plugged. Sticking slide or excessive rotor clearance. Pressure relief ball not seated or damaged. Pump cover or body has porosity. Incorrect pump cover or pump face not flat. Excessive rotor clearance.

Intake pipe restricted by casting flash. Cracks in filter body or intake pipe. "O" ring seal missing, cut or damaged. Incorrect lubricant used during rebuild procedure.

Manual valve scored or damaged. Spacer plate or gaskets incorrect, damaged or not assembled properly. Check for stuck 2-3 shift valve, damaged pressure control solenoid or damaged pressure switch assembly. Check for missing check balls or wrong assembly. Case-to-valve body face not flat. Harsh Shifts

Check PCM input signals from TP sensor, pressure switch assembly, fluid temperature sensor, VSS and engine coolant temperature sensor. Inspect pressure control solenoid for damaged pins or seals, or dirt in oil circuits.

High Or Low Shift Points

Check for stuck pressure regulator valve or pump slide sticking. Spacer plate or gaskets damaged, incorrect or not assembled properly.

Valve body pad porous or damaged. 2-4 accumulator has porosity. Servo piston seals damaged. Apply pin damaged or has improper length. 2-4 band burned or anchor pin not engaged. Throttle Position (TP) sensor, VSS and/or 4WD low switch (if equipped) disconnected or damaged.

No Converter Clutch Apply

Transmission not supplied 12 volts. Outside electrical connector damaged. Inside electrical connector wiring harness or solenoid damaged. Solenoid wire pinched. Solenoid not grounded. Pressure switches incorrect or damaged. Temperature sensor damaged. Engine speed sensor or pressure switch assembly. Converter internal damage.

Converter clutch valve stuck or assembled backward, or retaining ring not positioned properly. Pump-to-case gasket not positioned properly. Orifice cup plug restricted or damaged. Solenoid "O" ring seal cut or damaged. Pump-to-body cover high or uneven bolt torque.Turbine shaft "O" ring seal cut or damaged. Turbine shaft retainer and ball assembly restricted or damaged. TCC shift valve or apply valve stuck. Solenoid "O" ring leaking. Solenoid screen is blocked.

Converter Shudder

Torque converter has internal damage. Converter clutch valve stuck. Restricted oil passages. Crack in filter body. Restriction in filter neck. "O" ring seal cut or damaged. Turbine shaft "O" ring cut or damaged. Turbine shaft retainer and ball assembly restricted or damaged. Low oil pressure. Engine not tuned properly.

No Converter Clutch Release

Solenoid external ground. Converter internal damage. Converter clutch valve stuck. Converter clutch apply valve stuck in apply position. PCM external ground faulty.

Converter Clutch Applies When Cold

Check engine coolant temperature sensor and trouble codes.

Ratcheting Noise

Parking pawl return spring weak, damaged or not assembled properly.

Oil Leaking Out Vent

Chamfer in pump body rotor pocket too large. Fluid level overfilled. Cross leak out of pump body and cover.

Vibration In Reverse & Whining Noise In Park

Broken oil pump vane rings.

Front Oil Leak

Torque converter welded seam leaking. Damaged torque converter hub. Damaged front seal.

Pump Bushing Spins Out, "Walks" Into Seal, Or Seizes To Converter Hub

Transmission and engine center lines do not match. Excessive crankshaft runout. Bent flexplate (drive plate). Excessive converter hub runout. Pump bushing I.D. not centered in pump. Bushing too loose in pump. Not enough hub-to-bushing clearance.

Falls Out Of 4th Gear During Coasting

Low line pressure at idle (weak pressure regulator spring).

Binds Up On 3-4 Shift (Feels Like Brake Drag)

Forward pressure plate installed incorrectly. Too many plates in overrun clutch. Incorrect top steel plate installed in overrun clutch.

No Forward Or Reverse Gears (Line Pressure Reading Okay)

Mismatched converter input shaft or broken turbine hub.

Binds Up In Reverse

Stator sleeve rotated out of position. Stuck2-3 shift valve. Servo pin jammed in case. Stuck 3-4 relay or 4-3 sequence valve.

No Reverse

Reverse input drum cracked at weld or seals damaged.

No Drive In "D" Range

Torque converter stator roller clutch not holding.

No Drive In "OD" Range

Faulty output sprag. Teeth "hammered" out of forward friction plates.

CLUTCH & BAND APPLICATION

CLUTCH & BAND APPLICATION CHART (4L60-E)

TORQUE CONVERTER

Note. Torque converter is a sealed unit and must be serviced as a complete assembly.

STALL SPEED TEST

1. Torque converter whine is usually noticed when vehicle is stopped and transmission is in Reverse or Drive. Whine will increase when engine RPM is increased and will stop when vehicle is moving or when torque converter clutch is applied. Stall test is to ensure whine is coming from torque converter.
2. Start engine, and allow it to reach normal operating temperature. Apply parking and service brakes. Put transmission in Drive. Depress accelerator to approximately 1200 RPM for less than 6 seconds. DO NOT depress accelerator for more than 6 seconds or transmission damage may occur. Torque converter noise will increase under this load.

Note. Torque converter whine should not be confused with pump whine, which is usually noticeable in Park, Neutral and all other gear ranges. Pump whine will vary with pressure.

STATOR CHECK

1. Torque converter stator roller clutch can either remain locked up at all times or freewheel in both directions. If stator is freewheeling at all times, vehicle tends to have poor acceleration from a stop. Vehicle may act normal at speeds above 30-35 MPH.
2. If poor acceleration is noted, ensure exhaust system is not blocked, engine timing is correct and transmission is in 1st gear when starting from a stop. If stator is locked up at all times, performance from a stop appears normal. Engine RPM and acceleration is limited at high speeds. Engine may overheat from this condition.
3. A visual inspection of torque converter may reveal converter is Blues from overheating. If torque converter has been removed from vehicle, stator roller clutch can be checked by inserting a finger into splined inner race of roller clutch and trying to turn race in both directions. Inner race should turn freely clockwise but should not turn or should be difficult to turn counterclockwise.

END PLAY CHECK

1. Inspect torque converter for hub scoring, cracks or weld area cracks before checking end play. Install End Play Checking Tool (J-35138 ) on torque converter. (Scheme 7)
2. Note end play of torque converter. End play must be within specification. See «TORQUE CONVERTER END PLAY SPECIFICATIONS»(/gmc/suburban/i-1992-1999/remont/automatic-trans/#automatic-transmission-overhaul-testing-4l60-e). Replace torque converter if end play is not within specification or damage to hub area exists.

TORQUE CONVERTER END PLAY SPECIFICATIONS

Scheme 7

CONVERTER FLUSHING

Torque converter flushing is not recommended. Replace torque converter if contamination is found during oil cooler flushing procedure.

Note. For additional information on Torque Converter Clutch (TCC), see AUTO TRANS DIAGNOSIS - 4L60-E article in the AUTOMATIC TRANSMISSIONS section.

ELECTRONIC SELF-DIAGNOSTICS

Note. See AUTO TRANS DIAGNOSIS - 4L60-E article in the AUTOMATIC TRANSMISSIONS section.

ROAD TEST

Note. Shift speed charts reference throttle position angle instead of minimum or wide open throttle position. This measurement is more accurate. A scan tool should be used to monitor throttle position angle. For transmission model code, refer to metal identification tag attached to transmission. Shift speed information for 3.8L is not available.

Gear Selector Position "D" (Overdrive)

1. With gear selector in "D" (overdrive) position, choose throttle position angle of 10 or 25 percent. (Scheme 8)and (Scheme 9). Set scan tool to monitor throttle position angle and vehicle speed. Accelerate vehicle to chosen throttle position angle and hold throttle steady.
2. Note shift speed engagement points in 2nd gear, 3rd gear and overdrive gear. Use charts as a reference for proper shift speeds. (Scheme 8)and (Scheme 9). Also note Torque Converter Clutch (TCC) engagement point while in overdrive. Repeat procedure using different throttle position angle. NOTE: Shift speeds may vary due to slight hydraulic delays responding to electronic controls. A change from original equipment tire size also affects shift speeds. Ensure TCC engages in 3rd or overdrive. TCC should not apply unless transmission has reached a minimum operating temperature of 64°F (18°C) and engine coolant temperature is 140°F (60°C).
3. At vehicle speeds of 40-50 MPH in overdrive, quickly increase throttle position angle to more than 50 percent. Verify TCC releases, transmission immediately downshifts to 3rd gear and 1-2 shift solenoid turns off.
4. At vehicle speeds of 40-50 MPH in overdrive, quickly depress accelerator to wide open position (full throttle detent downshift). Verify TCC releases, transmission immediately downshifts to 2nd gear, 1-2 solenoid is off and 2-3 solenoid is on.
5. At vehicle speeds of 40-55 MPH in overdrive, release accelerator pedal while moving gear selector to "3" (third gear) position. Verify TCC releases, transmission immediately downshifts into 3rd gear, and engine braking slows vehicle.
6. Move gear selector to "D" (overdrive) position, and accelerate to 40-45 MPH. Release accelerator pedal while moving gear selector to "2" (2nd gear) position. Verify TCC releases, transmission immediately downshifts to 2nd gear, and engine braking slows vehicle.
7. Move gear selector to "D" (overdrive) position, and accelerate to 30 MPH. Release accelerator pedal while moving gear selector to "1" (1st gear) position. Verify TCC releases, transmission immediately downshifts to 1st gear and engine braking slows vehicle. At speeds below 30 MPH, transmission immediately downshifts to 1st gear.
8. With gear selector in the "D" (overdrive) position, accelerate vehicle to overdrive gear with TCC applied. Release accelerator pedal, and lightly apply brakes. Verify TCC releases and downshifts occur at speeds shown in shift speed charts. (Scheme 8)and (Scheme 9).

Scheme 8

Scheme 9

Note. Upshifts in manual gear ranges are controlled by shift solenoids. Perform following steps by accelerating vehicle at throttle position angle of 10-15 percent.

Gear Selector Position "3" (3rd Gear)

With vehicle stopped, move gear selector to "3" (3rd gear) position and steadily increase throttle pressure to accelerate vehicle. Note speeds at which vehicle shifts into 2nd and 3rd gears. (Scheme 8)and (Scheme 9).

Gear Selector Position "2" (2nd Gear)

With vehicle stopped, move gear selector to "2" (2nd gear) position. Accelerate vehicle and note speed at which vehicle shifts from 1st gear to 2nd gear. Accelerate vehicle to 35 MPH. Verify transmission does not shift into 3rd gear, and TCC does not apply.

Gear Selector Position "1" (1st Gear)

With vehicle stopped, move gear selector to "1" (1st gear) position. Accelerate vehicle to 20 MPH. Verify transmission does not upshift, and TCC does not apply.

Gear Selector Position "R" (Reverse)

With vehicle stopped, move gear selector to "R" (Reverse) position. Verify 1-2 and 2-3 shift solenoids are on.

HYDRAULIC PRESSURE TEST

1. Before performing hydraulic pressure test, check fluid level and condition. Check manual control linkages for correct adjustment, and ensure engine is properly tuned.
2. Connect scan tool to Data Link Connector (DLC). Apply parking brake and start engine. Check for stored trouble codes. If trouble codes are present, diagnose as necessary. See «AUTO TRANS DIAGNOSIS - 4L60-E»(ref-55998) article. Turn engine off. Connect oil pressure gauge to line pressure test port. (Scheme 10)
3. Start engine and warm to normal operating temperature. With vehicle in Reverse, line pressure should be 64-324 psi (441-2234 kPa). With vehicle in Park, Neutral or Drive, line pressure should be 55-189 psi (379-1303 kPa).
4. Shift transaxle into Park. Access Pressure Control Solenoid (PCS) test on scan tool. Increase DESIRED PCS in 0.1 amp increments and read corresponding line pressure on oil pressure gauge. Allow pressure to stabilize for 5 seconds after each current change. Compare readings to «LINE PRESSURE SPECIFICATIONS»(/gmc/suburban/i-1992-1999/remont/automatic-trans/#automatic-transmission-overhaul-testing-4l60-e). If pressure readings are not as specified, and no trouble codes are present, internal malfunction exists. See «TROUBLE SHOOTING»(/gmc/suburban/i-1992-1999/remont/automatic-trans/#automatic-transmission-overhaul-testing-4l60-e__trouble-shooting).

Note. Scan tool is only able to control pressure control solenoid in Park and Neutral with vehicle stopped. This protects clutches from extremely high or low pressures in Reverse and Drive.

LINE PRESSURE SPECIFICATIONS

Scheme 10

See appropriate TRANSMISSION REMOVAL & INSTALLATION - A/T article in the TRANSMISSION SERVICING section.

TRANSMISSION DISASSEMBLY

Note. Beginning at start of production for all 1996 models, some 4L60-E transmissions were built with a bolt-on bellhousing. This design is used on models with a 4.3L engine. Design change will make 4L60-E transmission more versatile for a wide variety of engine sizes. Bolts securing bellhousing require a Torx-Plus 50-IP bit for removal. Bolt heads will strip if incorrect tool is used during removal. Transmission case has a totally different casting design for bolt-on bellhousing. Oil pump body has a machined ring added to front of pump body to center bellhousing on installation. Pump body with added machined ring may be found on and can be used in 1995 models, but cannot be used in 1993-94 models.

2-4 SERVO ASSEMBLY

1. Mount transmission on bench using Holding Fixture (J-8763-02 ). Remove torque converter. Install Servo Cover Compressor (J-29714 ) on oil pan. (Scheme 6) Compress servo cover. Remove servo cover and "O" ring.
2. Remove 2-4 servo assembly. Servo pin length should be checked before disassembling assembly to determine 2-4 band and reverse input drum wear or damage.

CHECKING SERVO PIN LENGTH

1. Remove 4th apply piston and return spring. (Scheme 11) Remove retainer ring, washer, apply pin spring and 2nd apply piston pin. Install Piston Compressor (J-22269-01 ) on 2nd apply piston. (Scheme 12)
2. Remove retainer ring, cushion spring and spring retainer. Install Band Apply Pin Tool (J-33037 ) and apply pin. (Scheme 13) Apply 100 INCH lbs. (11 N.m) torque.
3. White line on band apply tool should be within gauge slot if pin length is correct. If White line is not within gauge slot, inspect 2-4 band and reverse input drum for wear and damage during disassembly.
4. Servo pin length must be checked during reassembly. Servo pin is preset and must not be readjusted. See «SERVO PIN SPECIFICATIONS»(/gmc/suburban/i-1992-1999/remont/automatic-trans/#automatic-transmission-overhaul-testing-4l60-e) under 2-4 BAND & SERVO ASSEMBLY under TRANSMISSION REASSEMBLY.

Scheme 11

Scheme 12

Scheme 13

EXTENSION HOUSING

Remove speed sensor retaining bolt. Using Puller (J-38417 ), remove speed sensor assembly and "O" ring. (Scheme 15) Remove extension housing and seal. Remove output shaft sleeve and "O" ring (if equipped). Remove speed sensor rotor from output shaft (if necessary). Install Gear Puller (J-21427-01 ) and Adapter (J-8433 ) on rotor. Pull rotor from output shaft.

1-2 ACCUMULATOR & SPACER PLATES

1. Remove solenoid retaining bolts. Remove solenoid and "O" ring. Remove wiring harness, and note location for reassembly reference. Carefully remove accumulator cover retaining bolts, 1-2 accumulator cover and pin assembly. (Scheme 15)
2. Remove 1-2 accumulator piston, seal and spring. Remove spacer plate, and note check ball and filter locations. Remove spring, 3-4 accumulator piston and pin. Note spacer plate and gasket locations. (Scheme 5)for check ball and filter locations.

TRANSMISSION END PLAY CHECK

Note. Check transmission end play before disassembly. If end play is not within specification, check for damaged parts.

Install Pump Remover/End Play Fixture (J-24773-A ) and End Play Adapter (J-25022-A ) on end of turbine shaft. (Scheme 14) Clamp dial indicator on long bolt with indicator tip on end play fixture. Zero dial indicator. Pull up on end play fixture. Measure transmission end play. Transmission end play should be.005-.036" (.13-.91 mm).

Scheme 14

OIL PUMP, INPUT CLUTCH & REVERSE CLUTCH

1. Ensure TCC solenoid assembly and oil filter are removed before oil pump removal. Remove oil pump retaining bolts. Using Oil Pump Remover (J-37789-A ) and Adapter (J-39119 ), pull oil pump assembly free from case. (Scheme 15)
2. Remove oil pump seal and gasket. Remove reverse input clutch-to-pump thrust washer from pump. Lift out turbine shaft with reverse input clutch assembly.

2-4 BAND & INPUT GEAR SET

1. Remove band anchor pin from case. (Scheme 15) Remove 2-4 band assembly from case. Remove input sun gear. (Scheme 16) CAUTION: Output shaft must be held in place when removing input carrier retainer ring.
2. Install Output Shaft Support (J-29837 ) on output shaft. (Scheme 17) Remove input carrier to output shaft retainer ring. Remove input carrier. Remove output shaft. Remove input carrier thrust bearing from reaction carrier shaft.

Scheme 15

Scheme 16

Scheme 17

REACTION GEAR SET

1. Remove input internal gear and reaction carrier shaft Remove reaction sun shell and thrust washer. Remove sun shell-to-clutch race thrust washer. Remove support-to-case retaining ring.
2. Remove spring retainer from low-reverse support. Remove reaction sun gear, low-reverse roller clutch race, roller clutch, support assembly and reaction carrier assembly. (Scheme 16)
3. Remove low-reverse clutch assembly. Note locations of parts. Remove internal reaction gear and bearing assembly. Remove internal reaction support-to-case bearing assembly.

LOW-REVERSE CLUTCH

Note. Parking pawl may require removal to access low-reverse clutch.

1. Remove parking lock bracket retaining bolts. Remove lock bracket. Using screw extractor, remove shaft plug. Remove parking pawl shaft, parking pawl and return spring if necessary. (Scheme 15)
2. Using Clutch Spring Compressor (J-23327 ), compress low reverse clutch spring retainer. Remove spring retaining ring and low-reverse spring assembly. Remove low-reverse clutch piston by applying air pressure in case apply passage. (Scheme 18)

Scheme 18

INNER MANUAL SHAFT LINKAGE

Remove manual shaft nut. Remove manual shaft and retainer. Remove parking lock actuator assembly and inner detent lever. Remove manual shaft seal from transmission case.

3RD ACCUMULATOR CHECK VALVE

1. Check 3rd accumulator check valve before removing it. DO NOT remove check valve unless it is leaking. Install servo assembly in bore. Install servo cover and retaining ring. (Scheme 6) Pour clean solvent in bore. Inspect for leaks in transmission case. Replace check valve assembly if it leaks. (Scheme 19) Remove servo assembly.
2. For check valve removal, install No. 4 screw extractor in check valve assembly. Remove check valve. Ensure bore is free of burrs. Installation tool must be made to ensure proper installation depth is obtained. Using a 3/8" O.D. rod, scribe indicator mark at 1.653" (41.98 mm) from end of rod. Install check valve until scribe mark on rod is flush with case. (Scheme 19)

Scheme 19

Cleaning & Inspection

Clean transmission case and dry with compressed air. Inspect case assembly for damage, cracks and damaged bolt hole threads. Inspect valve body surface for flatness and land damage. Check case oil passages for restrictions and blockage. Inspect case internal clutch plate lugs for damage and wear. Inspect servo and accumulator bores for damage. Inspect all snap ring grooves for damage.

Clean all parts and dry with compressed air. Inspect 1-2 and 3-4 accumulator parts for damage to pistons or housing. Inspect for flatness and condition of accumulator, oil passage plate and gasket. Inspect wiring harness leads and connectors for damage. Inspect speed sensor rotor teeth for damage and distortion.

1. Clean all parts and dry with compressed air. Inspect reaction and input carriers for pinion gear damage, excessive wear and improper staking of pinion pins. Inspect carrier bearings for heat damage, flatness and roller condition. Place output shaft sleeve inside reaction carrier and input carrier.
2. Rotate sleeve and note smoothness of bearing operation. Replace carrier assembly if roughness is felt. Check pinion gear end play on reaction and input carriers.
3. Pinion gear end play should be .008-.024" (.20-.61 mm). Inspect internal reaction gear and support for cracks and damaged splines. Inspect low-reverse clutch plates for wear and signs of excessive heat.
4. Inspect low-reverse clutch piston for roughness or damage in seal ring area. Inspect retainer ring and spring assembly for damage. Inspect sun and internal gears and supports for spline and bushing wear and damage. Replace damaged parts as necessary.

Disassembly

1. Remove snap ring from reverse input clutch housing. Remove selective backing plate, steel plates, composition plates and Belleville plate. (Scheme 16) Note number of clutch plates for reassembly reference. Compress reverse input clutch spring assembly.
2. Remove retainer ring and spring assembly. Remove piston and seals. Thickness of composition plates should be.068-.074" (1.73-1.88 mm). Thickness of steel plates should be.075-.081" (1.90-2.05 mm). Thickness of Belleville plate should be.087-.091" (2.21-2.31 mm).

Inspection

Inspect all plates for damage, distortion, flatness and burred edges. Inspect spring retainer for distortion. Check piston for deformation or damage. Inspect clutch housing bushings for wear. Inspect clutch housing for dishing. Replace worn or damaged parts as necessary.

Note. Soak clutch plates in ATF before installation.

Reassembly

1. Apply ATF to piston seals. Install seals on piston with seal lips facing away from plates. Install piston in clutch housing. Install spring assembly with large opening toward piston. Compress spring assembly. Install retainer ring. CAUTION: Ensure correct retainer ring is used. Ensure reverse input clutch retainer ring is not interchanged with low-reverse retainer ring.
2. Install Belleville plate. Install clutch plates starting with steel plate and alternating with composition plate. Install backing plate with chamfered side upward. Install snap ring. Apply even pressure to backing plate using fingers.
3. DO NOT apply too much pressure or Belleville plate will be distorted. Using feeler gauge, measure clearance between snap ring and backing plate. Clearance should be .040-.076" (1.02-1.94 mm). Select backing plate. See «REVERSE INPUT CLUTCH BACKING PLATE SPECIFICATIONS»(/gmc/suburban/i-1992-1999/remont/automatic-trans/#automatic-transmission-overhaul-testing-4l60-e) .

REVERSE INPUT CLUTCH BACKING PLATE SPECIFICATIONS

LOW-REVERSE SUPPORT ASSEMBLY

Disassembly & Inspection

Remove inner race and snap ring. Remove roller clutch assembly. Check inner race for damage and surface finish. (Scheme 20) Inspect roller and springs for damage and distortion. Inspect support for loose cam, cracks and damaged surface finish. Replace damaged parts as necessary.

1. Install roller clutch assembly in low-reverse support. (Scheme 20) Place support in case with hub facing downward. Install inner race. Rotate inner race while pushing downward. Use care not to damage roller and springs during installation.
2. Ensure inner race is fully seated. Bottom tangs will be flush with carrier hub when fully seated. Inner race should rotate clockwise and lock counterclockwise with clutch hub downward. Insert support retainer spring into case between case lug and open notch in support.

Scheme 20

1. Remove snap ring and backing plate. Remove 3-4 clutch plates. Note number and location of parts for reassembly reference. Remove 3-4 apply plate and clutch ring retainer. (Scheme 16)
2. Remove forward clutch snap ring, and remove backing plate. Remove forward clutch sprag assembly and bearing. Remove input housing seal. Remove forward clutch plates. Note number and location of parts for reassembly reference. Remove waved and apply plates. Remove overrun clutch plates (2 steel and 2 composition). Compress overrun clutch spring retainer.
3. Remove snap ring and spring assembly. Remove overrun piston and forward clutch piston. Remove seals from pistons. Note direction of seals. Remove forward clutch housing. Remove 3-4 clutch spring, 3-4 clutch apply ring and piston. Remove "O" ring from input housing. Remove turbine shaft oil seal rings.
4. Remove forward clutch race. Remove snap ring and overrun clutch hub. Remove sprag retainer and race. Note direction race is installed. Use care not to lose rollers from roller cage.

1. Inspect sprag assembly for weak or damaged springs and retainers and worn rollers. Inspect overrun clutch hub for spline damage, excessive wear and open oil passages. Inspect retainer and race for spline damage, surface wear and damaged ring grooves.
2. Replace sprag assembly if damaged. Inspect forward clutch race for spline damage, excessive wear and open oil passages. Inspect input shaft and housing for spline damage, wear and open feed passages.
3. Inspect 3 sealing balls located in rear of turbine shaft for tightness. Turbine shaft contains one open lubrication hole. Ensure orifice plug is installed. Inspect turbine shaft seal areas for roughness and burrs.
4. Inspect check ball located in input housing for free operation. Inspect pistons for wear, damage and porosity. Inspect spring assemblies for damage and distortion.
5. Inspect steel and composition plates for damage. Inspect snap rings for distortion and damage. Check backing plates for flatness and distortion. Inspect clutch apply rings for distortion and damaged tangs.
6. Inspect forward clutch housing check ball for proper operation (if equipped). Inspect housing for cracks and damage in seal areas. Inspect bearings for excessive wear, flatness, damage and flat rollers.

Scheme 21

1. For input housing check ball replacement, drive retainer and ball assembly from housing using 1/4" diameter drift. Install NEW check ball assembly using 1/4" drift. Check ball assembly should seat on housing shoulder. Assemble forward clutch sprag assembly.
2. Install sprag assembly in forward clutch race. Notches located in sprag must face upward. (Scheme 21) Install snap ring on sprag retainer and race. Snap ring flange must face away from retainer and race.
3. Hold forward clutch race in left hand. Support sprag assembly. Install sprag retainer and race assembly in sprag assembly. (Scheme 16) Rotate sprag retainer and race assembly counterclockwise. Install remaining retainer ring. Install overrun clutch hub. Install snap ring.
4. Check sprag operation. Holding forward clutch race, rotate overrun clutch hub. Overrun clutch hub should turn freely clockwise and lock counterclockwise. (Scheme 21) NOTE: If replacing forward sprag or overrun clutch hub, see OE parts department for updated and redesigned parts availability.
5. Place input clutch housing with turbine shaft downward. Install 3-4 piston seals with lips facing away from hub. Install 3-4 piston in input housing.
6. Install 3-4 clutch apply ring. Install "O" ring seal in input clutch housing. Install forward clutch housing. Install seals on forward clutch piston with lips facing away from tangs.
7. Install forward clutch piston in forward clutch housing. Install 3-4 spring on 3-4 clutch apply ring. Install forward clutch assembly on 3-4 spring assembly. Align forward clutch piston legs with tangs of 3-4 apply ring. Install Seal Protector (J-29883 ) on input housing.
8. Install 3-4 apply ring and forward clutch assembly in input clutch housing. Hold apply ring tangs while installing. DO NOT allow forward clutch piston to separate from assembly. Ensure assembly is firmly seated.
9. Install Seal Protector (J-29883 ) on input housing. Install overrun clutch piston with hub facing upward. If fully seated, overrun piston should be 3/16" below top of snap ring groove in input housing hub. Install spring assembly on overrun piston. Compress springs, and install snap ring. Install input housing seal. NOTE: Soak clutch plates in ATF before installation. Coat all seals and "O" rings with ATF. Coat thrust washers and bearings with petroleum jelly.
10. Install 4 overrun clutch plates, starting with steel plate. Align wide notches with case lugs. Install remaining clutch plates, alternating steel and composition plates.
11. Install bearing assembly on input clutch hub. Bearing inner race must face input housing hub. Ensure bearing is centered. Align clutch plate tabs. Install forward clutch sprag assembly in input housing. Align overrun clutch hub with clutch plates.
12. Install forward clutch apply plate in input housing. Install waved forward clutch plate. Ensure all plates are aligned with input housing tangs. Starting with steel plate, install clutch plates, alternating steel and composition plates. Install backing plate and snap ring. See «FORWARD CLUTCH PLATE SPECIFICATIONS»(/gmc/suburban/i-1992-1999/remont/automatic-trans/#automatic-transmission-overhaul-testing-4l60-e).
13. Using 2 feeler gauges, measure clearance between backing plate and snap ring. Clearance should be.030-.063" (.75-1.60 mm). Install proper size backing plate with chamfered side upward. See «FORWARD CLUTCH BACKING PLATE SPECIFICATIONS»(/gmc/suburban/i-1992-1999/remont/automatic-trans/#automatic-transmission-overhaul-testing-4l60-e). Install snap ring. FORWARD CLUTCH PLATE SPECIFICATIONS Plate Type Quantity Thickness In. (mm) Apply 1.169 (4.29) Backing 1 Selective Composition 5.070 (1.78) Flat Steel 5.090 (2.29) Waved Steel 1.070 (1.78) FORWARD CLUTCH BACKING PLATE SPECIFICATIONS ID Letter Thickness In. (mm) A.274-.278 (6.96-7.06) B.251-.255 (6.38-6.48) C.228-.232 (5.79-5.89) D.205-.208 (5.20-5.28) E.180-.185 (4.57-4.70)
14. Install 3-4 clutch plates and backing plate. Install clutch plates and backing plate with chamfered side upward. Install retainer ring. Using feeler gauge, measure clearance between backing plate and first composition plate. Clearance should be.035-.083" (.90-2.10 mm).
15. Select proper backing plate to obtain correct clearance. See «3-4 BACKING PLATE SPECIFICATIONS»(/gmc/suburban/i-1992-1999/remont/automatic-trans/#automatic-transmission-overhaul-testing-4l60-e). Air check all clutches at feed holes in turbine shaft.
16. During overrun clutch test, air pressure will blow past forward clutch piston seals and exit out forward clutch feed hole in turbine shaft. Turbine shaft seals require sizing and should be installed just before oil pump installation.

3-4 CLUTCH PLATE SPECIFICATIONS

3-4 BACKING PLATE SPECIFICATIONS

1. Remove reverse input clutch drum-to-oil pump thrust washer, pump-to-case gasket and pump-to-case oil seal ring from pump assembly. Remove pump cover retaining bolts. Separate pump cover from pump body. CAUTION: Pump slide spring and pressure relief spring rivet are under high pressure. To prevent possible injury, cover springs during removal.
2. Using needle-nose pliers, compress pump slide spring. Remove from pump by pulling straight out. Remove pump vane rings, pump vanes, pump rotor and rotor guide from pump pocket. CAUTION: Keep pump vanes in installed position. If pump vanes are installed upside-down or backwards, they will quickly wear out.
3. Remove slide from pump pocket. Remove slide seal and seal support from pump slide. (Scheme 22) Remove pivot pin and pivot pin spring. Remove seal ring and "O" ring from pump slide. Remove seal retainer and seal from pump body.
4. Check condition of pump bushing. If bushing is in good condition, DO NOT remove it. Push inward on converter clutch valve stop to compress spring. Remove snap ring. Remove valve stop, converter clutch apply valve and springs.
5. Using a small punch, remove pressure relief spring retaining rivet. Remove relief spring and ball. Remove oil screen and "O" ring from pump cover. Remove reverse boost valve sleeve. Remove reverse boost valve, pressure regulator valve spring and pressure regulator valve.

Scheme 22

1. Inspect all valves, springs, sleeves and bushings for chips, burrs, distortion and free movement in bores. Check pressure relief ball and spring for damage and distortion. Low line pressure will exist if ball and spring are damaged.
2. Inspect pump cover screen and "O" ring for wear and damage. Clean pump body and cover. Check all bores for obstructions. Inspect mating sides of cover and body for scoring, flatness and damage between channels. Check channels for dirt and damaged passages. Inspect stator shaft and pump body bushings for damage.
3. Inspect rotor and slide for scoring, cracks and damage. Check rotor guide and pump vane rings for excessive wear and damage. Inspect all seals for damage. Measure pump rotor and slide thickness in undamaged area if replacement is required. Replacement parts must be same size as those removed to provide proper end clearance.

1. Install "O" ring and seal ring in groove on back side of pump slide. Retain seal ring using petroleum jelly. Install pivot pin and spring in pump body. Install pump slide. Notch in pump slide must align with pivot pin hole and with flat oil seal ring facing downward in pump pocket. Install slide seal and support. CAUTION: Keep pump vanes in installed position. If pump vanes are installed upside-down or backwards, they will quickly wear out.
2. Install pump vane ring into pump pocket. Coat rotor guide with petroleum jelly. Install rotor guide on rotor. Install rotor and guide into pump pocket with guide toward pump pocket. Install vanes in rotor. Install vane guide ring. Compress pump slide spring and install into pump pocket. All parts must be even with pump body surface. Install "O" ring on pump screen, and install screen in pump cover with "O" ring end out.
3. Install oil seal in pump body. Install seal retainer. Install pressure relief check ball and spring in pump cover. Install retaining rivet. Install converter clutch valve springs and converter clutch valve. Install valve stop and snap ring. Install pressure regulator valve and spring in pump cover. (Scheme 22)
4. Coat reverse boost valve with petroleum jelly. Install reverse boost valve in boost valve sleeve with small end first. Install reverse boost valve sleeve in pump cover.
5. Install pump cover on pump body. Install retaining bolts finger tight. Align pump body and cover using Alignment Strap (J-21368). Place bolt through pump-to-case bolt hole. Tighten retaining bolts to specification. See «TORQUE SPECIFICATIONS»(/gmc/suburban/i-1992-1999/remont/automatic-trans/#automatic-transmission-overhaul-testing-4l60-e__torque-specifications). Remove alignment strap.
6. Position pump-to-case gasket on pump, and retain it using petroleum jelly. Install oil seal rings on stator hub. Retain oil seal rings using petroleum jelly. Install pump-to-case oil seal on cover. Ensure seal is not twisted. Coat seal with ATF. Install pump-to-drum thrust washer. Ensure tangs on washer engage with holes in hub.

1. Remove 4th apply piston and housing from 2nd apply piston assembly. Remove return spring from apply pin. Install Piston Compressor (J-22269-01 ) on second apply piston. (Scheme 12)
2. Compress 2nd servo apply piston assembly. Remove retainer ring. Separate 2nd apply piston, spring and retainer. Remove retainer ring, washer and spring from apply pin, and remove pin. Remove all oil seal rings. (Scheme 11)

Inspect all pistons for porosity and damage. Check for ring groove damage and servo bore in case for any wear which may cut servo seals. Check all springs and oil seal rings for distortion and damage.

Different servo piston housings and 2nd apply pistons are used for different applications. If servo piston housing or 2nd apply piston is replaced, inside dimension of parts must be checked. Measure inside diameter of piston housing and 2nd apply piston. Dimension must be same as original. To reassemble, reverse disassembly procedure. Coat seals with petroleum jelly before assembly.

Note. Valves are held in valve body by pins or retainers. Valves may be under spring pressure. Note location of all parts during disassembly for reassembly reference.

Remove valve train, and note direction of valve installation. (Scheme 23) Remove all valve pins, retainers and bore plugs. Remove shift solenoids. Note locations of all parts.

Inspect valves and sleeves for scoring and cracks. Ensure valves move freely in bores. Inspect valve body for cracks and scored bores. Inspect machined surfaces for damage. Inspect springs for damaged coils. Replace damaged parts as necessary.

For reassembly, reverse disassembly procedure. Ensure all parts are installed in correct location. (Scheme 23) Ensure pins, retainers and bore plugs are fully installed and do not extend into machined areas.

Scheme 23

TRANSMISSION REASSEMBLY

Note. To identify seal, thrust bearing and thrust washer locations and direction, see SEALS, BEARINGS & THRUST WASHERS under TRANSMISSION REASSEMBLY. (Scheme 24)and (Scheme 25).

1. Place transmission in a vertical position. Install seals on low-reverse clutch piston. Apply petroleum jelly to seals. Align and install piston with notch in bottom of transmission case. Ensure piston is fully seated and parking pawl aligns with opening in piston wall. Install spring assembly with flat side of retainer upward. Compress springs and install retainer ring.
2. Coat bearing assembly with petroleum jelly. Install bearing assembly on case hub with outside bearing race toward case hub. Install internal reaction gear and support. Install bearing assembly onto support with outside bearing race toward support. Install oil deflector (if equipped) and reaction carrier assembly in case. (Scheme 16) Ensure clutch plates are proper thickness.
3. Install clutch plates. See «LOW-REVERSE CLUTCH PLATE USAGE»(/gmc/suburban/i-1992-1999/remont/automatic-trans/#automatic-transmission-overhaul-testing-4l60-e). Ensure clutch plates align with splines of reaction carrier and case and that steel plates are aligned. Place waved plate on work bench. Install 5 composition plates and 4 steel plates alternately, starting with composition plate. LOW-REVERSE CLUTCH PLATE USAGE Type No. Used Thickness In. (mm) Composition 5.088 (2.24) Flat Steel 5.069 (1.75)
4. Install low-reverse support. Apply light pressure to low-reverse support. DO NOT flatten waved plate. Measure height of clutch pack from work bench to top of low-reverse support. Using height dimension, determine proper selective spacer plate to be used. See «SPACER PLATE SELECTION»(/gmc/suburban/i-1992-1999/remont/automatic-trans/#automatic-transmission-overhaul-testing-4l60-e) table. SPACER PLATE SELECTION Measured Clutch Pack Height In. (mm) (1) Plate Thickness (2) In. (mm) 1.081-1.102 (27.55-28.06).066-.073 (1.67-1.85) 1.102-1.122 (28.06-28.59).046-.052 (1.17-1.31) 1.061-1.081 (27.03-27.54).087-.092 (2.19-2.34) (1) Clutch pack height is measured without spacer plate in position. (2) Spacer plates are available in select sizes. Plate 066-.073" (1.67-1.85 mm) thick has no identifying marks. Other plates are marked "0" or "1".
5. Place spacer plate between waved plate and first composition plate with identification facing upward. Measure overall height of clutch pack. Overall height should be 1.15-1.18" (29.2-29.9 mm). Install clutch pack assembly in transmission case.
6. Install low-reverse support in case with hub downward. Install inner race by pushing downward while rotating until it is fully engaged. Bottom tangs will be flush with hub when fully installed. Install spring retainer in case between case lug and open notch in support. Install low-reverse snap ring.

REACTION & INPUT GEAR SETS

1. Install retainer ring on reaction sun gear (if removed). Install sun gear into reaction carrier. Install thrust washer on low-reverse clutch race. Install reaction sun gear shell on reaction sun gear.
2. Install thrust washer on reaction sun gear shell. Ensure thrust washer tangs engage on gear shell. Install input internal gear and reaction carrier shaft in sun gear shell. Carrier shaft splines must engage with reaction carrier. (Scheme 16)
3. Install thrust washer on reaction carrier shaft. Outer race must face toward reaction carrier shaft. Install output shaft in transmission. Ensure output shaft engages with all parts.
4. Install Output Shaft Support (J-29837 ). Adjust support so output shaft is positioned upward as far as possible. Install input carrier assembly with hub end down on output shaft. Install NEW retainer ring on output shaft. Remove output shaft support. Install input sun gear, indexing gear end with input carrier pinions.

REVERSE INPUT ASSEMBLY & INPUT CLUTCH

Install selective thrust washer on input housing. Install bearing assembly on selective thrust washer. Inner race (Black) must go toward oil pump. Position reverse input assembly on input clutch assembly. Reverse input clutch plates must align with input clutch hub. Ensure all clutch plates are fully engaged.

REVERSE & INPUT CLUTCHES

Install reverse and input clutch assemblies in transmission case as an assembly. Align 3-4 clutch plates of input assembly with input internal gear. Assembly is fully seated when reverse input clutch housing is just below oil pump face of case.

2-4 BAND & SERVO ASSEMBLY

1. Install 2-4 band in case. Align band anchor pin end with case pin hole. Install band anchor pin in case. Ensure band anchor pin aligns with end of 2-4 band.
2. Install 2-4 servo assembly into case, and index apply pin on band end. Check for proper engagement of apply pin on band end. Recheck 2-4 servo apply pin selection to ensure correct pin is installed. See «CHECKING SERVO PIN LENGTH»(/gmc/suburban/i-1992-1999/remont/automatic-trans/#automatic-transmission-overhaul-testing-4l60-e__checking-servo-pin-length) under TRANSMISSION DISASSEMBLY.
3. Different length servo pins are available. See «SERVO PIN SPECIFICATIONS»(/gmc/suburban/i-1992-1999/remont/automatic-trans/#automatic-transmission-overhaul-testing-4l60-e) . Select proper length servo pin. Install servo cover and "O" ring. Compress cover and install cover retaining ring. Index ring ends with slot in case.

SERVO PIN SPECIFICATIONS

SEALS, BEARINGS & THRUST WASHERS

Note. To identify seal, thrust bearing and thrust washer locations and direction (Scheme 24)and (Scheme 25).

Scheme 24

Scheme 25

Scheme 26

1. Turbine shaft seals should be installed prior to oil pump installation. Position Seal Installer (J-36418-1 ) on input shaft. (Scheme 26) Adjustment screw in seal installer must be adjusted to obtain correct height for each seal installation. Install 4 turbine shaft seals.
2. Turbine shaft seals must be sized using Seal Sizer (J-36418-2A ) after installation. Install aligning pins in 2 opposing pump bolt holes in case. Ensure thrust washer is installed on rear of oil pump. Thrust washer can be retained using petroleum jelly.
3. Install oil pump into case, aligning filter and pressure regulator holes with holes in case. Install retaining bolts. Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(/gmc/suburban/i-1992-1999/remont/automatic-trans/#automatic-transmission-overhaul-testing-4l60-e__torque-specifications). Place transmission in a horizontal position.
4. Turbine shaft should rotate by hand. If turbine shaft will not rotate, loosen pump retaining bolts and attempt to rotate shaft again. If shaft now turns, reverse and input assemblies have not been indexed properly or some other assembly problem has occurred, such as thrust washer not positioned properly.
5. Check transmission end play. See «TRANSMISSION END PLAY CHECK»(/gmc/suburban/i-1992-1999/remont/automatic-trans/#automatic-transmission-overhaul-testing-4l60-e__transmission-end-play-check) under TRANSMISSION DISASSEMBLY. Transmission end play should be.005-.036" (.13-.91 mm). If transmission end play is not within specification, thrust washer must be changed between oil pump and input housing.
6. See «OIL PUMP THRUST WASHER SPECIFICATIONS»(/gmc/suburban/i-1992-1999/remont/automatic-trans/#automatic-transmission-overhaul-testing-4l60-e). Install thrust washer, and recheck end play. Install torque converter. Ensure converter hub is aligned with oil pump. Install torque converter retaining strap to hold converter.

OIL PUMP THRUST WASHER SPECIFICATIONS

1. Install 3-4 accumulator piston pin in case. Install 3-4 piston seal on piston. Install 3-4 accumulator piston on pin. Legs of piston must face valve body.
2. Install 3-4 accumulator spring. Install check balls and oil screens in proper locations. Install special retainer and ball assembly. (Scheme 5)for check ball and filter installation locations. Install spacer plate gasket and spacer plate.
3. Install 1-2 accumulator spring, oil seal ring and 1-2 accumulator piston. Install accumulator cover and bolts. Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(/gmc/suburban/i-1992-1999/remont/automatic-trans/#automatic-transmission-overhaul-testing-4l60-e__torque-specifications).

Install valve body. See VALVE BODY under ON-VEHICLE SERVICE.

1. Install speed sensor rotor retaining clip on output shaft. Install "O" ring in output shaft sleeve. Install output shaft sleeve on output shaft. DO NOT position output sleeve past machined surface of output shaft. Install seal ring on extension housing.
2. Position extension housing on transmission case. Install retaining bolts. Install oil seal in extension housing. Install speed sensor assembly. Install retainer and bolt. Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(/gmc/suburban/i-1992-1999/remont/automatic-trans/#automatic-transmission-overhaul-testing-4l60-e__torque-specifications) . Install outside electrical connector and manual shift lever.

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

See also:
• TORQUE SPECIFICATIONS
• 2-4 SERVO ASSEMBLY
• TROUBLE SHOOTING
• SEALS, BEARINGS & THRUST WASHERS
• CHECKING SERVO PIN LENGTH
• TRANSMISSION END PLAY CHECK
• VALVE BODY
