Engine Control Module Replacement

CAUTIONTurn the ignition OFF when installing or removing the control module connectors and disconnecting or reconnecting the power to the control module (battery cable, powertrain control module (PCM)/engine control module (ECM)/transaxle control module (TCM) pigtail, control module fuse, jumper cables, etc.) in order to prevent internal control module damage. Control module damage may result when the metal case contacts battery voltage. DO NOT contact the control module metal case with battery voltage when servicing a control module, using battery booster cables, or when charging the vehicle battery. In order to prevent any possible electrostatic discharge damage to the control module, do no touch the connector pins or the soldered components on the circuit board. Remove any debris from around the control module connector surfaces before servicing the control module. Inspect the control module connector gaskets when diagnosing or replacing the control module. Ensure that the gaskets are installed correctly. The gaskets prevent contaminant intrusion into the control module. The replacement control module must be programmed.

Note. Before removing the engine control module (ECM), use the scan tool to capture the ECM data. This captured data will then need to be restored into the NEW ECM. Refer to Control Module References .

Removal Procedure

  1. Record the current Engine Oil Life percentage, and use a scan tool to update the NEW ECM, if replacing.
  2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection (TP2)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) , «Battery Negative Cable Disconnection and Connection (Single Battery)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  3. Disengage the engine wiring harness upper electrical connector retainer (2) and remove the connector (1) from the ECM.
  4. Disengage the engine wiring harness lower electrical connector retainer (3) and remove the connector (4) from the ECM.
  5. Disengage the retainer tabs securing the ECM to the bracket.
  6. Remove the ECM.

Installation Procedure

  1. Install the bottom ECM tabs into the bracket.
  2. Push the ECM in securing the ECM to the bracket.
  3. Position the engine wiring harness lower electrical connector and engage the retainer (3) securing the lower connector (4) to the ECM.
  4. Position the engine wiring harness upper electrical connector and engage the retainer (2) securing the upper connector (1) to the ECM.
  5. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection (TP2)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) , «Battery Negative Cable Disconnection and Connection (Single Battery)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  6. If a NEW ECM was installed, program the ECM. Refer to «Control Module References»(/gmc/sierra-2500/2012-2012/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) .

Crankshaft Position System Variation Learn

Note. The Crankshaft Position System Variation Learn procedure is required when the following service procedures have been performed, regardless of whether DTC P0315 is set: A crankshaft position sensor replacement An engine control module (ECM) replacement An engine replacement A crankshaft balancer replacement A crankshaft replacement Any engine repairs which disturb the crankshaft to crankshaft position sensor relationship.

Note. The ECM monitors certain component signals to determine if all the conditions are met to continue with the Crankshaft Position System Variation Learn Procedure.

  1. Ignition ON, observe the DTC information with a scan tool. Verify no other DTCs are set, except DTCs P0300-P0308, or P0315. If DTCs are set, except DTCs P0300-P0308, or P0315, refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(/gmc/sierra-2500/2012-2012/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-trouble-code-dtc-list) for further diagnosis.
  2. Select the Crankshaft Pos. Variation Learn procedure with a scan tool.
  3. The scan tool instructs you to perform the following: Block drive wheels. Set parking brake. Cycle the ignition. Apply and hold brake pedal. NOTE: The vehicle must remain in PARK/NEUTRAL. Start and idle the engine.
  4. Enable the CKP System Variation Learn Procedure with a scan tool.
  5. Accelerate to wide open throttle (WOT) and release the throttle when fuel cut-off occurs.
  6. Test in progress.
  7. The scan tool displays Learn Status: Learned this ignition.
  8. Once the Learn Procedure has successfully completed, and in order to store the crankshaft position system variation values in the ECM, turn OFF the ignition and verify all vehicle systems are OFF. This may take up to 2 minutes.

Description

The engine control module (ECM) learns the airflow through the throttle body to ensure the correct idle. The learned airflow values are stored within the ECM. These values are learned to adjust for production variation and will continuously learn during the life of the vehicle to compensate for reduced airflow due to throttle body coking. Anytime the throttle body airflow rate changes, for example due to cleaning or replacing, the values must be relearned.

An engine that had a heavily coked throttle body that has been cleaned or replaced may take several drive cycles to learn out the coking. To accelerate the process, the scan tool has the ability to reset all learned values back to zero. A new ECM will also have values set to zero.

The idle may be unstable or a DTC may set if the learned values do not match the actual airflow.

Conditions for Running the Throttle Learn Procedure

Reset Procedure

  1. DTCs P0068, P0101, P0102, P0103, P0106, P0107, P0108, P0116, P0117, P0118, P0120, P0122, P0123, P0128, P0171, P0172, P0174, P0175, P0201, P0202, P0203, P0204, P0205, P0206, P0220, P0222, P0223, P0300, P0351, P0352, P0353, P0496, P0601, P0604, P0606, P060D, P0641, P0651, P1516, P2101, P2119, P2120, P2122, P2123, P2125, P2127, P2128, P2135, P2138, or P2176 are not set.
  2. Ignition ON, engine OFF.
  3. The vehicle speed sensor (VSS) is 0 km/h (0 mph).

Learn Procedure

  1. DTCs P0068, P0101, P0102, P0103, P0106, P0107, P0108, P0116, P0117, P0118, P0120, P0122, P0123, P0128, P0171, P0172, P0174, P0175, P0201, P0202, P0203, P0204, P0205, P0206, P0220, P0222, P0223, P0300, P0351, P0352, P0353, P0496, P0601, P0604, P0606, P060D, P0641, P0651, P1516, P2101, P2119, P2120, P2122, P2123, P2125, P2127, P2128, P2135, P2138, or P2176 are not set.
  2. The engine speed is between 450-4, 000 RPM.
  3. The manifold absolute pressure (MAP) is greater than 5 kPa.
  4. The mass air flow (MAF) is greater than 2 g/s.
  5. The ignition voltage is greater than 10 volts.

Throttle Learn

Reset Procedure (Performed after the throttle body is cleaned or replaced)

  1. Ignition ON, engine OFF, perform the Idle Learn Reset in Module Setup with a scan tool.
  2. Start the engine and monitor the TB Idle Airflow Compensation parameter. The TB Idle Airflow Compensation value should equal 0 percent and the engine should be idling at a normal idle speed.
  3. Clear the DTCs and return to the diagnostic that referred you here.

Learn Procedure (Performed after the ECM is flashed or replaced)

  1. Start and idle the engine for 3 minutes.
  2. With a scan tool, monitor the Desired Idle Speed and the actual Engine Speed.
  3. The ECM will start to learn the new idle cells and Desired Idle Speed should start to decrease.
  4. Ignition OFF for 60 seconds.
  5. Start and idle the engine for 3 minutes.
  6. After the 3 minute run time the engine should be idling normal. NOTE: During the drive cycle the check engine light may come on with idle speed DTCs. If idle speed codes are set, clear codes so the ECM can continue to learn. If the engine idle speed has not been learned the vehicle will need to be driven at speeds above 70 km/h (44 mph) with several decelerations and extended idles.
  7. After the drive cycle, the engine should be idling normally. If the engine idle speed has not been learned, turn OFF the ignition for 60 seconds and repeat step 6.
  8. Once the engine speed has returned to normal, clear DTCs and return to the diagnostic that referred you here.
CAUTIONUse care when handling the coolant sensor. Damage to the coolant sensor will affect the operation of the fuel control system.
  1. Drain the cooling system to a level below the engine cooling temperature (ECT) sensor. Refer to «Cooling System Draining and Filling (Vac-N-Fill Gasoline)»(/gmc/sierra-2500/2012-2012/remont/cooling-system-mechanical/#engine-cooling-system__cooling-system-draining-and-filling-vac-n-fill) , «Cooling System Draining and Filling (Static Fill)»(/gmc/sierra-2500/2012-2012/remont/cooling-system-mechanical/#engine-cooling-system__cooling-system-draining-and-filling-static) , «Cooling System Draining and Filling (Vac-N-Fill Diesel)»(/gmc/sierra-2500/2012-2012/remont/cooling-system-mechanical/#engine-cooling-system__cooling-system-draining-and-filling-vac-n-fill) .
  2. Disconnect the engine wiring harness electrical connector (2) from the ECT sensor.
  3. Remove the ECT sensor.
CAUTIONDo not insert any tools into the throttle body bore in order to avoid damage to the throttle valve plate.
CAUTIONUse care when handling the coolant sensor. Damage to the coolant sensor will affect the operation of the fuel control system.
  1. If installing the old sensor, coat the threads with sealant GM P/N 12346004 (Canadian P/N 10953480) or equivalent.
  2. Install the ECT sensor and tighten to 20 N.m (15 lb ft).
  3. Connect the engine wiring harness electrical connector (2) to the ECT sensor.
  4. Refill the cooling. Refer to «Cooling System Draining and Filling (Vac-N-Fill Gasoline)»(/gmc/sierra-2500/2012-2012/remont/cooling-system-mechanical/#engine-cooling-system__cooling-system-draining-and-filling-vac-n-fill) , «Cooling System Draining and Filling (Static Fill)»(/gmc/sierra-2500/2012-2012/remont/cooling-system-mechanical/#engine-cooling-system__cooling-system-draining-and-filling-static) , «Cooling System Draining and Filling (Vac-N-Fill Diesel)»(/gmc/sierra-2500/2012-2012/remont/cooling-system-mechanical/#engine-cooling-system__cooling-system-draining-and-filling-vac-n-fill) .

Scheme 51

Scheme 51: Mass Airflow Sensor with Intake Air Temperature Sensor Replacement
Scheme 51: Mass Airflow Sensor with Intake Air Temperature Sensor Replacement
CalloutComponent Name
1Mass Airflow Sensor Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 1.5 (13 lb in)
2Mass Airflow Sensor/Intake Air Temperature Sensor Procedure Disconnect the electrical connector.
CAUTION
Refer to Fastener Caution .

Mass Airflow Sensor with Intake Air Temperature Sensor Replacement

  1. Remove the intake manifold sight shield. Refer to «Upper Intake Manifold Sight Shield Replacement»(/gmc/sierra-2500/2012-2012/remont/mechanical/#engine-mechanical-48l-53l-60l-62l-repair-instructions-on-vehicle) .
  2. Disconnect the engine wiring harness electrical connector (4) from the manifold absolute pressure (MAP) sensor.
  3. Remove the MAP sensor retainer.
  4. Remove the MAP sensor.
IMPORTANTLightly coat the MAP sensor seal with clean engine oil before installing the sensor.
  1. Install the MAP sensor.
  2. Install the MAP sensor retainer.
  3. Connect the engine harness wiring electrical connector (4) to the MAP sensor.
  4. Install the intake manifold sight shield. Refer to «Upper Intake Manifold Sight Shield Replacement»(/gmc/sierra-2500/2012-2012/remont/mechanical/#engine-mechanical-48l-53l-60l-62l-repair-instructions-on-vehicle) .

Scheme 52

Scheme 52: Throttle Inlet Absolute Pressure Sensor Replacement
Scheme 52: Throttle Inlet Absolute Pressure Sensor Replacement
CalloutComponent Name
1Throttle Inlet Absolute Pressure Sensor Fastener CAUTION: Refer to Fastener Caution . Tighten 5 N.m (44 lb in)
2Throttle Inlet Absolute Pressure Sensor Procedure Disconnect the electrical connector.
CAUTION
Refer to Fastener Caution .

Throttle Inlet Absolute Pressure Sensor Replacement

  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Unbolt the front propeller shaft from the front differential, if equipped with four wheel drive (4WD). Refer to «Front Propeller Shaft Replacement»(/gmc/sierra-2500/2012-2012/remont/driveshaft-universal-joints/#propeller-shaft-and-universal-joints__front-propeller-shaft-replacement) .
  3. Remove the connector position assurance (CPA) retainer (3).
  4. Disconnect the HO2S (1) electrical connector from the engine wiring harness electrical connector (2).
  5. Remove the HO2S (1).
  1. If reinstalling the old sensor, coat the threads with anti-seize compound GM P/N 12377953, or equivalent.
  2. Install the HO2S (1). Tighten Tighten the sensor to 42 N.m (31 lb ft).
  3. Connect the HO2S (1) electrical connector to the engine wiring harness electrical connector (2).
  4. Install the CPA retainer (3).
  5. Install the front propeller shaft to the front differential, if equipped with 4WD. Refer to «Front Propeller Shaft Replacement»(/gmc/sierra-2500/2012-2012/remont/driveshaft-universal-joints/#propeller-shaft-and-universal-joints__front-propeller-shaft-replacement) .
  6. Lower the vehicle.
  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Unbolt the front propeller shaft from the front differential, if equipped with four wheel drive (4WD). Refer to «Front Propeller Shaft Replacement»(/gmc/sierra-2500/2012-2012/remont/driveshaft-universal-joints/#propeller-shaft-and-universal-joints__front-propeller-shaft-replacement) .
  3. For vehicles equipped with a 4L60-E/4L70-E automatic transmission perform the following steps. For vehicles equipped with a 6L80-E automatic transmission proceed to step 7.
  4. Remove the connector position assurance (CPA) retainer.
  5. Disconnect the engine wiring harness electrical connector (2) from the HO2S.
  6. Remove the HO2S electrical connector clip (1) from the fuel line clip.
  7. Remove the CPA retainer (2).
  8. Remove the engine wiring harness electrical connector clip (1) from the fuel line clip.
  9. Disconnect the engine wiring harness electrical connector (3) from the HO2S.
  10. Remove the HO2S (1).
  1. If reinstalling the old sensor, coat the threads with anti-seize compound GM P/N 12377953, or equivalent.
  2. Install the HO2S (1). Tighten Tighten the sensor to 42 N.m (31 lb ft).
  3. For vehicles equipped with a 4L60-E/4L70-E automatic transmission perform the following steps, for vehicles equipped with a 6L80-E automatic transmission proceed to step 7.
  4. Install the HO2S electrical connector clip (1) to the fuel line clip.
  5. Connect the engine wiring harness electrical connector (2) to the HO2S.
  6. Install the CPA retainer.
  7. Connect the engine wiring harness electrical connector (3) to the HO2S.
  8. Install the engine wiring harness electrical connector clip (1) to the fuel line clip.
  9. Install the CPA retainer (2).
  10. Install the front propeller shaft to the front differential, if equipped with 4WD. Refer to «Front Propeller Shaft Replacement»(/gmc/sierra-2500/2012-2012/remont/driveshaft-universal-joints/#propeller-shaft-and-universal-joints__front-propeller-shaft-replacement) .
  11. Lower the vehicle.
  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Unbolt the front propeller shaft from the front differential, if equipped with four wheel drive (4WD). Refer to «Front Propeller Shaft Replacement»(/gmc/sierra-2500/2012-2012/remont/driveshaft-universal-joints/#propeller-shaft-and-universal-joints__front-propeller-shaft-replacement) .
  3. For vehicles equipped with a 4L60-E/4L70-E automatic transmission perform the following steps, for vehicles equipped with a 6L80-E automatic transmission proceed to step 7.
  4. Remove the connector position assurance (CPA) retainer.
  5. Disconnect the engine wiring harness electrical connector (2) from the HO2S.
  6. Remove the HO2S electrical connector clip (1) from the fuel line clip.
  7. Remove the CPA retainer (2).
  8. Remove the engine wiring harness electrical connector clip (1) from the fuel line clip.
  9. Disconnect the engine wiring harness electrical connector (3) from the HO2S.
  10. Remove the HO2S (1 or 2).
  1. If reinstalling the old sensor, coat the threads with anti-seize compound GM P/N 12377953, or equivalent.
  2. Install the HO2S (1 or 2). Tighten Tighten the sensor to 42 N.m (31 lb ft).
  3. For vehicles equipped with a 4L60-E/4L70-E automatic transmission perform the following steps, for vehicles equipped with a 6L80-E automatic transmission proceed to step 7.
  4. Install the HO2S electrical connector clip (1) to the fuel line clip.
  5. Connect the engine wiring harness electrical connector (2) to the HO2S.
  6. Install the CPA retainer.
  7. Connect the engine wiring harness electrical connector (3) to the HO2S.
  8. Install the engine wiring harness electrical connector clip (1) to the fuel line clip.
  9. Install the CPA retainer (2).
  10. Install the front propeller shaft to the front differential, if equipped with 4WD. Refer to «Front Propeller Shaft Replacement»(/gmc/sierra-2500/2012-2012/remont/driveshaft-universal-joints/#propeller-shaft-and-universal-joints__front-propeller-shaft-replacement) .
  11. Lower the vehicle.
  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Remove the HO2S electrical connector rosebud clip from the engine wiring harness clip.
  3. Remove the connector position assurance (CPA) retainer (8).
  4. Disconnect the HO2S electrical connector (3) from the engine wiring harness electrical connector (4).
  5. Remove the HO2S (4).
  1. If reinstalling the old sensor, coat the threads with anti-seize compound GM P/N 12377953, or equivalent.
  2. Install the HO2S (4). Tighten Tighten the sensor to 42 N.m (31 lb ft).
  3. Connect the HO2S electrical connector (3) to the engine wiring harness electrical connector (4).
  4. Install the CPA retainer (8).
  5. Install the HO2S electrical connector rosebud clip to the engine wiring harness clip.
  6. Lower the vehicle.
  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Remove the connector position assurance (CPA) retainer (1).
  3. Disconnect the HO2S electrical connector from the engine wiring harness electrical connector (3).
  4. Remove the HO2S (4).
  1. If reinstalling the old sensor, coat the threads with anti-seize compound GM P/N 12377953, or equivalent.
  2. Install the HO2S (4). Tighten Tighten the sensor to 42 N.m (31 lb ft).
  3. Connect the HO2S electrical connector to the engine wiring harness electrical connector (3).
  4. Install the CPA retainer (1).
  5. Lower the vehicle.
  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Remove the connector position assurance (CPA) retainer (1).
  3. Disconnect the HO2S electrical connector from the engine wiring harness electrical connector (3).
  4. Remove the HO2S (5).
  1. If reinstalling the old sensor, coat the threads with anti-seize compound GM P/N 12377953, or equivalent.
  2. Install the HO2S (5). Tighten Tighten the sensor to 42 N.m (31 lb ft).
  3. Connect the HO2S electrical connector to the engine wiring harness electrical connector (3).
  4. Install the CPA retainer (1).
  5. Lower the vehicle.
  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Remove the connector position assurance (CPA) retainer (9).
  3. Disconnect the HO2S electrical connector (1) from the engine wiring harness electrical connector (2).
  4. Remove the HO2S (2).
  1. If reinstalling the old sensor, coat the threads with anti-seize compound GM P/N 12377953, or equivalent.
  2. Install the HO2S (2). Tighten Tighten the sensor to 42 N.m (31 lb ft).
  3. Connect the HO2S electrical connector (1) to the engine wiring harness electrical connector (2).
  4. Install the CPA retainer (9).
  5. Lower the vehicle.
  1. Remove the right wheelhouse liner. Refer to «Front Wheelhouse Liner Replacement - Right Side (GMC)»(/gmc/sierra-2500/2012-2012/remont/frames-subframes-crossmembers/#frame-and-underbody) , «Front Wheelhouse Liner Replacement - Right Side (Chevrolet)»(/gmc/sierra-2500/2012-2012/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  2. Remove the connector position assurance (CPA) retainer (2).
  3. Disconnect the HO2S electrical connector (7) from the engine wiring harness electrical connector (1).
  4. Remove the HO2S clip (8) from the engine wiring harness.
  5. Remove the HO2S (2).
  1. If reinstalling the old sensor, coat the threads with anti-seize compound GM P/N 12377953, or equivalent.
  2. Install the HO2S (2). Tighten Tighten the sensor to 42 N.m (31 lb ft).
  3. Connect the HO2S electrical connector (7) to the engine wiring harness electrical connector (1).
  4. Install the CPA retainer (2).
  5. Install the HO2S clip (8) to the engine wiring harness.
  6. Install the right wheelhouse liner. Refer to «Front Wheelhouse Liner Replacement - Right Side (GMC)»(/gmc/sierra-2500/2012-2012/remont/frames-subframes-crossmembers/#frame-and-underbody) , «Front Wheelhouse Liner Replacement - Right Side (Chevrolet)»(/gmc/sierra-2500/2012-2012/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  1. Remove the right wheelhouse liner. Refer to «Front Wheelhouse Liner Replacement - Right Side (GMC)»(/gmc/sierra-2500/2012-2012/remont/frames-subframes-crossmembers/#frame-and-underbody) , «Front Wheelhouse Liner Replacement - Right Side (Chevrolet)»(/gmc/sierra-2500/2012-2012/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  2. Remove the connector position assurance (CPA) retainer (2).
  3. Disconnect the HO2S electrical connector (7) from the engine wiring harness electrical connector (1).
  4. Remove the HO2S clip (8) from the engine wiring harness.
  5. Remove the HO2S (3).
  1. If reinstalling the old sensor, coat the threads with anti-seize compound GM P/N 12377953, or equivalent.
  2. Install the HO2S (3). Tighten Tighten the sensor to 42 N.m (31 lb ft).
  3. Connect the HO2S electrical connector (7) to the engine wiring harness electrical connector (1).
  4. Install the CPA retainer (2).
  5. Install the HO2S clip (8) to the engine wiring harness.
  6. Install the right wheelhouse liner. Refer to «Front Wheelhouse Liner Replacement - Right Side (GMC)»(/gmc/sierra-2500/2012-2012/remont/frames-subframes-crossmembers/#frame-and-underbody) , «Front Wheelhouse Liner Replacement - Right Side (Chevrolet)»(/gmc/sierra-2500/2012-2012/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Remove the connector position assurance (CPA) retainer (5).
  3. Disconnect the HO2S electrical connector (6) from the engine wiring harness electrical connector (7).
  4. Remove the HO2S (3).
  1. If reinstalling the old sensor, coat the threads with anti-seize compound GM P/N 12377953, or equivalent.
  2. Install the HO2S (3). Tighten Tighten the sensor to 42 N.m (31 lb ft).
  3. Connect the HO2S electrical connector (6) to the engine wiring harness electrical connector (7).
  4. Install the CPA retainer (5).
  5. Lower the vehicle.
  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Remove the connector position assurance (CPA) retainer (5).
  3. Disconnect the engine wiring harness electrical connector (4) from the HO2S electrical connector (3).
  4. Remove the HO2S electrical connector clip from the engine harness clip (6).
  5. Remove the HO2S (3).
  1. If reinstalling the old sensor, coat the threads with anti-seize compound GM P/N 12377953, or equivalent.
  2. Install the HO2S (3). Tighten Tighten the sensor to 42 N.m (31 lb ft).
  3. Install the HO2S electrical connector clip to the engine harness clip (6).
  4. Connect the engine wiring harness electrical connector (4) to the HO2S electrical connector (3).
  5. Install the CPA retainer (5).
  6. Lower the vehicle.
  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Remove the connector position assurance (CPA) retainer (5).
  3. Disconnect the engine wiring harness electrical connector (4) from the HO2S electrical connector (3).
  4. Remove the HO2S electrical connector clip from the engine harness clip (6).
  5. Remove the HO2S (4).
  1. If reinstalling the old sensor, coat the threads with anti-seize compound GM P/N 12377953, or equivalent.
  2. Install the HO2S (4). Tighten Tighten the sensor to 42 N.m (31 lb ft).
  3. Install the HO2S electrical connector clip to the engine harness clip (6).
  4. Connect the engine wiring harness electrical connector (4) to the HO2S electrical connector (3).
  5. Install the CPA retainer (5).
  6. Lower the vehicle.
CAUTIONHandle the electronic throttle control components carefully. Use cleanliness in order to prevent damage. Do not drop the electronic throttle control components. Do not roughly handle the electronic throttle control components. Do not immerse the electronic throttle control components in cleaning solvents of any type.
  1. Push down the small tab and disconnect the accelerator pedal position (APP) sensor electrical connector (1).
  2. Remove the accelerator pedal bolts.
  3. Remove the accelerator pedal.
  1. Position the accelerator pedal to the accelerator pedal bracket.
  2. Install the accelerator pedal bolts and tighten to 9 N.m (80 lb in).
  3. Connect the APP sensor electrical connector (1).
  4. Connect a scan tool to the diagnostic port in order to test for proper throttle-opening and throttle-closing range.
  5. Operate the accelerator pedal and monitor the throttle angles. The accelerator pedal should operate freely, without binding, between a closed throttle, and a wide open throttle (WOT).
  6. Verify that the vehicle meets the following conditions: The vehicle is not in a reduced engine power mode. The ignition is ON. The engine is OFF.
CAUTIONHandle the electronic throttle control components carefully. Use cleanliness in order to prevent damage. Do not drop the electronic throttle control components. Do not roughly handle the electronic throttle control components. Do not immerse the electronic throttle control components in cleaning solvents of any type.
  1. Push down the small tab and disconnect the accelerator pedal position (APP) sensor electrical connector (1).
  2. Remove the accelerator pedal bolts.
  3. Remove the accelerator pedal.
  1. Position the accelerator pedal to the accelerator pedal bracket.
  2. Install the accelerator pedal bolts and tighten to 9 N.m (80 lb in).
  3. Connect the APP sensor electrical connector (1).
  4. Connect a scan tool to the diagnostic port in order to test for proper throttle-opening and throttle-closing range.
  5. Operate the accelerator pedal and monitor the throttle angles. The accelerator pedal should operate freely, without binding, between a closed throttle, and a wide open throttle (WOT).
  6. Verify that the vehicle meets the following conditions: The vehicle is not in a reduced engine power mode. The ignition is ON. The engine is OFF.
CAUTIONHandle the electronic throttle control components carefully. Use cleanliness in order to prevent damage. Do not drop the electronic throttle control components. Do not roughly handle the electronic throttle control components. Do not immerse the electronic throttle control components in cleaning solvents of any type.
CAUTIONDO NOT for any reason, insert a screwdriver or other small hand tools into the throttle body to hold open the throttle plate, as the wedge inside the throttle body could be damaged.
  1. Remove the air cleaner outlet duct. Refer to «Air Cleaner Resonator Outlet Duct Replacement»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Disconnect the engine wiring harness electrical connector (3) from the electronic throttle control.
  3. Remove the throttle body nuts (507) and bolts (538).
  4. Remove the throttle body (508).
  5. Remove and discard the throttle body gasket (509).
  1. Install a NEW throttle body gasket to the intake manifold. Align the tab of the gasket with the notch in the manifold.
  2. Install the throttle body (508), bolts (538), and nuts (507) and tighten to 10 N.m (89 lb in).
  3. Connect the engine wiring harness electrical connector (3) to the electronic throttle control.
  4. Install the air cleaner outlet duct. Refer to «Air Cleaner Resonator Outlet Duct Replacement»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  5. Connect a scan tool in order to test for proper throttle-opening and throttle-closing range.
  6. Operate the accelerator pedal and monitor the throttle angles. The accelerator pedal should operate freely, without binding, between a closed throttle, and a wide open throttle (WOT).
  7. Verify that the vehicle meets the following conditions: The vehicle is not in a reduced engine power mode. The ignition is ON. The engine is OFF.
  8. Perform the Throttle Learn Procedure. Refer to «Throttle/Idle Learn»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  9. Inspect for coolant leaks.

Throttle Body Cleaning

  1. Remove the air cleaner outlet duct. Refer to «Air Cleaner Resonator Outlet Duct Replacement»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) . WARNING: Turn OFF the ignition before inserting fingers into the throttle bore. Unexpected movement of the throttle blade could cause personal injury. CAUTION: Do not insert any tools into the throttle body bore in order to avoid damage to the throttle valve plate.
  2. Inspect the throttle body bore and the throttle plate for deposits. You will need to open the throttle plate in order to inspect all surfaces. CAUTION: Do not use any solvent that contains Methyl Ethyl Ketone (MEK). This solvent may damage fuel system components.
  3. Clean the throttle body bore and the throttle plate using a clean shop towel with GM Top Engine Cleaner, P/N 1052626, or AC-Delco Carburetor Tune-Up Conditioner, P/N X66-P, or an equivalent product.
  4. Install the air cleaner outlet duct. Refer to «Air Cleaner Resonator Outlet Duct Replacement»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  5. Perform the Throttle/Idle Learn procedure. Refer to «Throttle/Idle Learn»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .

Fuel Pressure Gauge Installation and Removal

Special Tools

CH-48027 Digital Pressure Gauge

WARNINGRemove the fuel tank cap and relieve the fuel system pressure before servicing the fuel system in order to reduce the risk of personal injury. After you relieve the fuel system pressure, a small amount of fuel may be released when servicing the fuel lines, the fuel injection pump, or the connections. In order to reduce the risk of personal injury, cover the fuel system components with a shop towel before disconnection. This will catch any fuel that may leak out. Place the towel in an approved container when the disconnection is complete.
  1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (Without CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-without-ch-48027) , «Fuel Pressure Relief (CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-ch-48027) .
  2. Connect the CH-48027-1 (1) to the CH-48027-2 (2).
  3. Remove the shop towel from around the fuel rail service port, and place in an approved gasoline container.
  4. Perform any tests and/or diagnostics as needed. For the proper usage of the CH-48027 digital pressure gauge, refer to the manufacture's directions.
  1. Relieve the fuel system pressure, if required. Perform the following steps: WARNING: Wrap a shop towel around the fuel pressure connection in order to reduce the risk of fire and personal injury. The towel will absorb any fuel leakage that occurs during the connection of the fuel pressure gauge. Place the towel in an approved container when the connection of the fuel pressure gauge is complete. Wrap a shop towel around the fuel rail service port. Place the hose on the CH-48027-2 (2) into an approved gasoline container. Open the valve on the CH-48027-2 (2) in order to bleed any fuel from the fuel rail. Close the valve on the CH-48027-2 (2). Remove the hose on the CH-48027-2 (2) from the approved gasoline container. Remove the shop towel from around the fuel rail service port, and place in an approved gasoline container.
  2. Disconnect the CH-48027-1 (1) from the CH-48027-2 (2).
  3. Disconnect the CH-48027-2 (2) from the CH-48027-3 (4).
  4. Disconnect the CH-48027-3 (4) from the fuel rail service port.
  5. Install the fuel rail service port cap.
  6. Tighten the fuel fill cap.

Fuel Pressure Relief (CH-48027)

Special Tools

CH-48027 Digital Pressure Gauge

  1. If the fuel system requires repair, prevent fuel spillage by removing the fuel pump fuse. Refer to «Electrical Center Identification Views»(/gmc/sierra-2500/2012-2012/remont/electrical-component-locations/#wiring-systems-and-power-management-component-locator-electrical-center-identification-views) .
  2. Remove the engine cover, if required.
  3. Loosen the fuel fill cap in order to relieve the fuel tank vapor pressure.
  4. Remove the fuel rail service port cap.
  5. Wrap a shop towel around the fuel rail service port.
  6. Connect the CH-48027-3 (4) to the fuel rail service port.
  7. Connect the CH-48027-2 (2) to the CH-48027-3 (4).
  8. Place the hose on the CH-48027-2 (2) into an approved gasoline container.
  9. Open the valve on the CH-48027-2 (2) in order to bleed any fuel from the fuel rail.
  10. Close the valve on the CH-48027-2 (2).
  11. Remove the hose on the CH-48027-2 (2) from the approved gasoline container.
  12. Disconnect the CH-48027-2 (2) from the CH-48027-3 (4).
  13. Disconnect the CH-48027-3 (4) from the fuel rail service port.
  14. Remove the shop towel from around the fuel rail service port, and place in an approved gasoline container.
  15. Install the fuel rail service port cap.
  16. Install the engine cover, if required.
  17. Tighten the fuel fill cap.

Fuel Pressure Relief (Without CH-48027)

WARNINGRemove the fuel tank cap and relieve the fuel system pressure before servicing the fuel system in order to reduce the risk of personal injury. After you relieve the fuel system pressure, a small amount of fuel may be released when servicing the fuel lines, the fuel injection pump, or the connections. In order to reduce the risk of personal injury, cover the fuel system components with a shop towel before disconnection. This will catch any fuel that may leak out. Place the towel in an approved container when the disconnection is complete.
  1. If the fuel system requires repair, prevent fuel spillage by removing the fuel pump fuse. Refer to «Electrical Center Identification Views»(/gmc/sierra-2500/2012-2012/remont/electrical-component-locations/#wiring-systems-and-power-management-component-locator-electrical-center-identification-views) .
  2. Loosen the fuel fill cap in order to relieve the fuel tank vapor pressure.
  3. Remove the engine cover, if required.
  4. Remove the fuel rail service port cap.
  5. Wrap a shop towel around the fuel rail service port and using a small flat-bladed tool, depress (open) the fuel rail test port valve.
  6. Remove the shop towel from around the fuel rail service port, and place in an approved gasoline container.
  7. Install the fuel rail service port cap.
  8. Install the engine cover, if required.
  9. Tighten the fuel fill cap.

Metal Collar Quick Connect Fitting Service

Special Tools

J-41769 Fuel Line Quick Disconnect Tool

Disconnect Procedure

  1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (Without CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-without-ch-48027) , «Fuel Pressure Relief (CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-ch-48027) .
  2. Remove the fuel line retainer.
  3. Using compressed air, blow any dirt or debris from around the connection.
  4. Using the correct tool from the J-41769 disconnect tool, insert the tool into the female connector end, then push inward in order to release the quick connect locking tabs.
  5. Pull the fuel line connection apart.
  6. Use a clean shop towel in order to wipe off the male connection end.
  7. Inspect both ends of the fitting for dirt and burrs. Clean or replace the components as required.

Connect Procedure

  1. Apply a few drops of clean engine oil to the male connection end.
  2. Push both sides of the fitting together in order to engage the retaining tabs.
  3. Once installed, pull on both sides of the connection in order to ensure the connection is secure.
  4. Install the fuel line retainer.
  1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (Without CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-without-ch-48027) , «Fuel Pressure Relief (CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-ch-48027) .
  2. Using compressed air, blow any dirt or debris from around the connection.
  3. This step applies to Bartholomew style connector ONLY. Squeeze the plastic quick connect fitting release tabs.
  4. This step applies to Release Tab style connector ONLY. Release the fitting by pushing the tab toward the other side of the slot in the fitting.
  5. This step applies to the Squeeze to Release style connector ONLY. Squeeze where indicated by the arrows shown above on both sides of the plastic ring surrounding the quick connect fitting.
  6. This step applies to the Sliding Retainer style connector ONLY. Release the fitting by pressing on one side of the release tab causing it to push in slightly. If the tab does not move try pressing the tab in from the opposite side. The tab will only move in one direction.
  7. This step applies to the Push Down TI style connector ONLY. Release the fitting by pressing on the tab indicated by the arrow.
  8. Pull the connection apart.
  1. Apply a few drops of clean engine oil to the male connection end.
  2. Push both sides of the quick-connect fitting together in order to cause the retaining feature to snap into place.
  3. Once installed, pull on both sides of the connection in order to make sure the connection is secure.

Scheme 53

Scheme 53: Fuel Pump Flow Control Module Replacement
Scheme 53: Fuel Pump Flow Control Module Replacement
CalloutComponent Name
Preliminary Procedure Remove the spare tire. Refer to Spare Wheel Hoist Replacement .
1Fuel Pump Flow Control Module Fastener (Qty: 3) CAUTION: Refer to Fastener Caution . Procedure Partially loosen the fasteners from the slotted bracket. Tighten 6 N.m (53 lb in)
2Fuel Pump Flow Control Module Procedure Disconnect the electrical connector. If replacing, reprogram the module. Refer to Control Module References .
CAUTION
Refer to Fastener Caution .

Fuel Pump Flow Control Module Replacement

Fuel Tank Draining

  1. Loosen the fuel fill cap in order to relieve the fuel tank vapor pressure.
  2. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  3. Loosen the fuel fill hose clamp (1).
  4. Remove the fuel fill hose from the fuel tank.
  5. Remove the flame arrester screen from the tank opening, if required.
  6. Insert the hose from the pump devise into the fuel tank.
  7. Using a hand or air operated pump device, drain as much fuel from the tank as possible.
  1. Disconnect the solenoid vent filter and hose from filler pipe.
  2. Remove the fuel tank filler housing to body TORX® screws (1) and pushpin retainer (2).
  3. Remove the fuel tank filler housing to fuel tank fill pipe bolts.
  4. Remove the fuel tank filler housing.
  5. Raise and suitably support the vehicle half way. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  6. Remove the fuel tank fill pipe ground wire bolt (3).
  7. Remove the fuel tank fill pipe ground wire (2) anti-rotation tab from the frame hole.
  8. Reposition the fuel tank fill pipe ground wire and chassis harness ground wire (1).
  9. Open the axle vent hose clip on the fuel fill pipe bracket.
  10. Remove the rear axle vent hose from the clip.
  11. Disconnect the fuel fill pipe recirculation line quick connect fitting (2) from the evaporative emission (EVAP) rear hose. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  12. Loosen the fuel tank fill pipe clamp (1) at the fuel tank.
  13. Remove the fuel tank fill pipe.
  14. Cap the opening on the fuel tank in order to prevent possible system contamination.
  1. Remove the cap from the opening on the fuel tank.
  2. Position the fuel tank fill pipe.
  3. Tighten the fuel tank fill pipe clamp (1) at the fuel tank. Tighten Tighten the clamp to 2.5 N.m (22 lb in).
  4. Connect the fuel fill pipe recirculation line quick connect fitting (2) to the EVAP rear hose. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  5. Install the rear axle vent hose to the clip on the fuel fill pipe bracket.
  6. Close the axle vent hose clip.
  7. Position the chassis harness ground wire (1) and the fuel tank fill pipe ground wire (2) to the frame bracket.
  8. Install the fuel tank fill pipe ground wire (2) anti-rotation tab into the frame hole.
  9. Install the fuel tank fill pipe ground wire bolt (3). Tighten Tighten the bolt to 9 N.m (80 lb in).
  10. Lower the vehicle.
  11. Install the fuel tank filler housing.
  12. Install the fuel tank filler housing to fuel tank fill pipe bolts. Tighten Tighten the screws to 2.3 N.m (20 lb in).
  13. Install the fuel tank filler housing to body TORX® screws (1) and pushpin retainer (2). Tighten Tighten the screws to 2.3 N.m (20 lb in).
  14. Disconnect the solenoid vent filter and hose from filler pipe.
  1. Disconnect the solenoid vent filter and hose from filler pipe.
  2. Remove the fuel tank filler housing to body TORX® screws (1) and retainer (2).
  3. Remove the fuel tank filler housing to fuel tank fill pipe bolts.
  4. Remove the fuel tank filler housing.
  5. Partially raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  6. Remove the fuel tank fill pipe ground wire bolt (3).
  7. Remove the fuel tank fill pipe ground wire (2) anti-rotation tab from the frame hole.
  8. Reposition the fuel tank fill pipe ground wire and chassis harness ground wire (1).
  9. Loosen the fuel tank fill pipe clamp (2) at the fuel tank.
  10. Disconnect the fuel tank evaporative emission (EVAP) line quick connect fitting (1) from the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  11. Remove the fuel tank fill pipe.
  12. Cap the opening on the fuel tank in order to prevent possible system contamination.
  1. Remove the cap from the opening on the fuel tank.
  2. Install the fuel tank fill pipe.
  3. Connect the fuel tank EVAP line quick connect fitting (1) to the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) . CAUTION: Refer to «Fastener Caution»(/gmc/sierra-2500/2012-2012/remont/oem-general-information/#dangers-warnings-and-cautions__fastener-caution) .
  4. Tighten the fuel tank fill pipe clamp (2) at the fuel tank. Tighten Tighten the clamp to 2.5 N.m (22 lb in).
  5. Position the fuel tank fill pipe ground wire (1) and the fuel tank fill pipe ground wire (2) to the frame bracket.
  6. Install the fuel tank fill pipe ground wire (2) anti-rotation tab into the frame hole.
  7. Install the fuel tank fill pipe ground wire bolt (3). Tighten Tighten the bolt to 9 N.m (80 lb in).
  8. Lower the vehicle.
  9. Install the fuel tank filler housing.
  10. Install the fuel tank filler housing to fuel tank fill pipe bolts. Tighten Tighten the bolts to 2.3 N.m (20 lb in).
  11. Install the fuel tank filler housing to body TORX® screws (1) and retainer (2). Tighten Tighten the screws to 2.3 N.m (20 lb in).
  12. Connect the solenoid vent filter and hose to the filler pipe.
  1. Disconnect the solenoid vent filter and hose from filler pipe.
  2. Remove the fuel tank filler housing to body TORX® screws (1) and pushpin retainer (2).
  3. Remove the fuel tank filler housing to fuel tank fill pipe bolts.
  4. Remove the fuel tank filler housing.
  5. Raise and suitably support the vehicle half way. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  6. Remove the fuel tank fill pipe ground wire bolt.
  7. Remove the fuel tank fill pipe ground wire anti-rotation tab from the frame hole.
  8. Reposition the fuel tank fill pipe ground wire.
  9. Open the axle vent hose clip on the fuel fill pipe bracket.
  10. Remove the rear axle vent hose from the clip.
  11. If equipped with 5 ft 8 in. bed, perform the following steps
  12. Disconnect the fuel tank evaporative emission (EVAP) line quick connect fitting (2) from the fuel fill pipe recirculation line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  13. Loosen the fuel tank fill pipe clamp (1) at the fuel tank.
  14. Remove the fuel tank fill pipe.
  15. Cap the opening on the fuel tank in order to prevent possible system contamination.
  16. If equipped with 6 ft 5 in. bed, perform the following steps
  17. Disconnect the fuel tank EVAP line quick connect fitting (1) from the fuel fill pipe recirculation line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  18. Loosen the fuel tank fill pipe clamp (2) at the fuel tank.
  19. Remove the fuel tank fill pipe.
  20. Cap the opening on the fuel tank in order to prevent possible system contamination.
  1. If equipped with 6 ft 5 in. bed, perform the following steps
  2. Remove the cap from the opening on the fuel tank.
  3. Position the fuel tank fill pipe.
  4. Tighten the fuel tank fill pipe clamp (2) at the fuel tank. Tighten Tighten the clamp to 2.5 N.m (22 lb in).
  5. Connect the fuel fill pipe recirculation line to the fuel tank EVAP line quick connect fitting (1). Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  6. If equipped with 5 ft 8 in. bed, perform the following steps
  7. Remove the cap from the opening on the fuel tank.
  8. Position the fuel tank fill pipe.
  9. Tighten the fuel tank fill pipe clamp (1) at the fuel tank. Tighten Tighten the clamp to 2.5 N.m (22 lb in).
  10. Connect the fuel fill pipe recirculation line to the fuel tank EVAP line quick connect fitting (2). Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  11. Install the rear axle vent hose to the clip on the fuel fill pipe bracket.
  12. Close the axle vent hose clip.
  13. Position the fuel tank fill pipe ground wire to the frame bracket.
  14. Install the fuel tank fill pipe ground wire anti-rotation tab into the frame hole.
  15. Install the fuel tank fill pipe ground wire bolt. Tighten Tighten the bolt to 9 N.m (80 lb in).
  16. Lower the vehicle.
  17. Install the fuel tank filler housing.
  18. Install the fuel tank filler housing to fuel tank fill pipe bolts. Tighten Tighten the screws to 2.3 N.m (20 lb in).
  19. Install the fuel tank filler housing to body TORX® screws (1) and pushpin retainer (2). Tighten Tighten the screws to 2.3 N.m (20 lb in).
  20. Connect the solenoid vent filter and hose from filler pipe.
  1. Disconnect the solenoid vent filter and hose from filler pipe.
  2. Remove the fuel tank filler housing to body TORX® screws (1) and retainer (2).
  3. Remove the fuel tank filler housing to fuel tank fill pipe bolts.
  4. Remove the fuel tank filler housing.
  5. Partially raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  6. Remove the fuel tank fill pipe ground wire bolt (3).
  7. Remove the fuel tank fill pipe ground wire (2) anti-rotation tab from the frame hole.
  8. Reposition the fuel tank fill pipe ground wire and chassis harness ground wire (1).
  9. Loosen the fuel tank fill pipe clamp (2) at the fuel tank.
  10. Disconnect the fuel tank evaporative emission (EVAP) line quick connect fitting (1) from the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  11. Remove the fuel tank fill pipe.
  12. Cap the opening on the fuel tank in order to prevent possible system contamination.
  1. Remove the cap from the opening on the fuel tank.
  2. Install the fuel tank fill pipe.
  3. Connect the fuel tank EVAP line quick connect fitting (1) to the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) . CAUTION: Refer to «Fastener Caution»(/gmc/sierra-2500/2012-2012/remont/oem-general-information/#dangers-warnings-and-cautions__fastener-caution) .
  4. Tighten the fuel tank fill pipe clamp (2) at the fuel tank to 4 N.m (35 lb in).
  5. Position the fuel tank fill pipe ground wire (1) and the fuel tank fill pipe ground wire (2) to the frame bracket.
  6. Install the fuel tank fill pipe ground wire (2) anti-rotation tab into the frame hole.
  7. Install the fuel tank fill pipe ground wire bolt (3) and tighten to 9 N.m (80 lb in).
  8. Lower the vehicle.
  9. Install the fuel tank filler housing.
  10. Install the fuel tank filler housing to fuel tank fill pipe bolts and tighten to 2.3 N.m (20 lb in).
  11. Install the fuel tank filler housing to body TORX® screws (1) and retainer (2). Tighten the screws to 2.3 N.m (20 lb in).
  12. Connect the solenoid vent filter and hose to the filler pipe.
  1. Remove the fuel tank filler housing to body fasteners (1) and filler housing (2).
  2. Remove the ground strap fastener.
  3. Disconnect the quick connect fitting (1). Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  4. Loosen the filler hose clamp (2).
  5. Cut the plastic zip tie (3).
  6. Remove the fuel tank filler pipe (4).
  1. Install the fuel tank filler pipe (4).
  2. Install a new zip tie (3).
  3. Tighten the fuel tank filler clamp (1) to 4 N.m(35 lb in) at the fuel tank.
  4. Connect the quick connect fitting (1). Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  5. Install the ground strap fastener.
  6. Install the filler housing (2) and tighten the fasteners (1) to 9 N.m(89 lb in).
  1. Remove the fuel tank filler housing to body fasteners (1) and filler housing (2).
  2. Remove the ground strap fastener.
  3. Loosen the filler hose clamp (1).
  4. Loosen the vent hose clamp (2).
  5. Remove the fuel tank filler pipe (4).
  1. Tighten the fuel tank filler clamp (1) to 4 N.m(35 lb in) at the fuel tank.
  2. Tighten the fuel tank vent hose clamp (2) to 4 N.m(35 lb in) at the fuel tank.
  3. Install the ground strap fastener.
  4. Install the filler housing (2) and tighten the fasteners (1) to 9 N.m (89 lb in).
  1. Partially raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Remove the solenoid vent filter and hose (1) from the filler pipe.
  3. Cut any retaining straps from the filler tube assemble.
  4. Remove the fuel tank filler housing to body TORX® screws (1) and retainer (2).
  5. Remove the fuel tank filler housing to fuel tank fill pipe bolts.
  6. Remove the fuel tank filler housing.
  7. Disengage the rear axle vent hose from the fuel filler pipe bracket retainer.
  8. Remove the fuel tank fill pipe ground wire bolt (3).
  9. Remove the fuel tank fill pipe ground wire (2) anti-rotation tab from the frame hole.
  10. Reposition the fuel tank fill pipe ground wire and chassis harness ground wire (1).
  11. Loosen the fuel tank fill pipe clamp (1) at the fuel tank.
  12. Disconnect the fuel tank evaporative emission (EVAP) line quick connect hose from the evaporative emission short pipe at the fuel tank fuel pump module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  13. Remove the fuel tank fill pipe (3).
  14. Cap the opening on the fuel tank in order to prevent possible system contamination.
  1. Remove the cap from the opening on the fuel tank.
  2. Install the fuel tank fill pipe (3) to the fuel tank.
  3. Connect the fuel tank evaporative emission (EVAP) line quick connect hose from the evaporative emission short pipe at the fuel tank fuel pump module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) . CAUTION: Refer to «Fastener Caution»(/gmc/sierra-2500/2012-2012/remont/oem-general-information/#dangers-warnings-and-cautions__fastener-caution) .
  4. Tighten the fuel tank fill pipe clamp (1) at the fuel tank. Tighten Tighten the clamp to 2.5 N.m (22 lb in).
  5. Position the fuel tank fill pipe ground wire (1) and the fuel tank fill pipe ground wire (2) to the frame bracket.
  6. Install the fuel tank fill pipe ground wire (2) anti-rotation tab into the frame hole.
  7. Install the fuel tank fill pipe ground wire bolt (3). Tighten Tighten the bolt to 9 N.m (80 lb in).
  8. Press the rear axle vent hose into the fuel filler pipe bracket retainer.
  9. Install the fuel tank filler housing.
  10. Install the fuel tank filler housing to fuel tank fill pipe bolts. Tighten Tighten the bolts to 2.3 N.m (20 lb in).
  11. Install the fuel tank filler housing to body TORX® screws (1) and retainer (2). Tighten Tighten the screws to 2.3 N.m (20 lb in).
  12. Install the solenoid vent filter and hose (1) to the fuel filler pipe.
  13. Replace any retaining straps that were cut off with New ones.
  14. Lower the vehicle.
  1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (Without CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-without-ch-48027) , «Fuel Pressure Relief (CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-ch-48027) .
  2. Drain the fuel tank. Refer to «Fuel Tank Draining»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-draining) .
  3. Remove the fuel tank shield bolts, if equipped.
  4. Remove the fuel tank shield from the fuel tank shield tabs (1), if equipped.
  5. Disconnect the fuel tank fuel feed line quick connect fitting (1) from the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  6. Disconnect the fuel tank EVAP line quick connect fitting (3) from the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  7. Cap the fuel and EVAP lines in order to prevent possible system contamination.
  8. Place a suitable adjustable jack under the fuel tank.
  9. Remove the fuel tank strap bolts.
  10. Remove the fuel tank straps.
  11. Lower the fuel tank half way. Loosen the fuel fill pipe clamp at the fuel tank. Separate the fuel fill pipe from the fuel tank.
  12. Disconnect the chassis wiring harness clip at the frame crossmember.
  13. Lower the fuel tank until the electrical connections are accessible.
  14. Disconnect the chassis wiring harness electrical connector from the fuel tank pressure sensor.
  15. Disconnect the chassis wiring harness electrical connector from the fuel tank module.
  16. Completely lower the fuel tank.
  17. With the aid of an assistant, place the fuel tank in a suitable work area.
  18. If replacing the fuel tank proceed to the next step, otherwise proceed to step 10 in the installation procedure.
  19. Remove the fuel tank shield push on retainers.
  20. Remove the fuel tank shield.
  21. Disconnect the fuel feed pipe quick connect fitting from the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  22. Remove the fuel feed pipe from the fuel tank clips (1).
  23. Disconnect the EVAP pipe quick connect fitting from the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  24. Remove the EVAP pipe from the fuel tank clips (1).
  25. Disconnect the EVAP pipe quick connect fittings from the rollover valve and the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  26. Remove the EVAP pipe from the fuel tank clips (1 and 2).
  27. Remove the fuel tank module. Refer to «Fuel Tank Fuel Pump Module Replacement (15 Ext/Crew Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  1. Install the fuel tank module. Refer to «Fuel Tank Fuel Pump Module Replacement (15 Ext/Crew Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  2. Position and connect the EVAP pipe quick connect fittings to the rollover valve and the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Install the EVAP pipe to the fuel tank clips (1 and 2).
  4. Position and connect the EVAP pipe quick connect fitting to the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  5. Install the EVAP pipe to the fuel tank clips (1).
  6. Position and connect the fuel feed pipe quick connect fitting to the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  7. Install the fuel feed pipe to the fuel tank clips (1).
  8. Position and install the fuel tank shield.
  9. Install the fuel tank shield push on retainers.
  10. With the aid of an assistant, place the fuel tank in a the adjustable jack.
  11. Raise the fuel tank until the electrical connections can be made.
  12. Connect the chassis wiring harness electrical connector to the fuel tank module.
  13. Connect the chassis wiring harness electrical connector from the fuel pressure sensor.
  14. Completely raise the fuel tank into position.
  15. Install the fuel tank straps.
  16. Install the fuel tank strap bolts. Tighten Tighten the bolts to 40 N.m (30 lb ft).
  17. Remove the adjustable jack from under the fuel tank.
  18. Remove the caps from the fuel and EVAP lines.
  19. Connect the fuel tank EVAP line quick connect fitting (3) to the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  20. Connect the fuel tank fuel feed line quick connect fitting (1) to the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  21. Position and install the fuel tank shield onto the fuel tank shield tabs (1), if equipped.
  22. Install the fuel tank shield bolts, if equipped. Tighten Tighten the bolts to 18 N.m (13 lb ft).
  23. Refill the fuel tank.
  24. Install the fuel cap.
  25. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection (TP2)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) , «Battery Negative Cable Disconnection and Connection (Single Battery)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  26. Perform the following procedure in order to inspect for leaks: Turn the ignition ON, with the engine OFF, for 2 seconds. Turn the ignition OFF for 10 seconds. Turn the ignition ON, with the engine OFF. Inspect for fuel leaks.
  1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (Without CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-without-ch-48027) , «Fuel Pressure Relief (CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-ch-48027) .
  2. Drain the fuel tank. Refer to «Fuel Tank Draining»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-draining) .
  3. Remove the fuel tank fill pipe. Refer to «Fuel Tank Filler Pipe Replacement (15 Reg Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  4. Disconnect the fuel tank fuel feed (1) and EVAP (2) line quick connect fittings from the chassis lines. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  5. Cap the fuel and EVAP lines in order to prevent possible system contamination.
  6. Remove the EVAP canister vent solenoid pipe clip (1) from the frame crossmember.
  7. Disconnect the EVAP canister pipe quick connect fitting (2) from the fuel tank EVAP pipe. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  8. Disconnect the EVAP canister vent solenoid pipe quick connect fitting (3) from the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  9. Disconnect the chassis wiring harness electrical connector from the EVAP canister vent solenoid.
  10. Remove the chassis wiring harness clip from the fuel tank shield.
  11. Insert a small flat bladed tool between the EVAP canister vent solenoid and the fuel tank bracket, disengaging the retainer (1).
  12. Slide the EVAP canister vent solenoid off the bracket towards the passenger side of the vehicle.
  13. Position and secure the EVAP canister vent solenoid out of the way.
  14. Place a suitable adjustable jack under the fuel tank.
  15. Remove the fuel tank strap bolts.
  16. Remove the fuel tank straps.
  17. Lower the fuel tank half way.
  18. Disconnect the chassis wiring harness clip at the frame crossmember.
  19. Lower the fuel tank until the electrical connections are accessible.
  20. Disconnect the chassis wiring harness electrical connector from the fuel tank pressure sensor.
  21. Disconnect the chassis wiring harness electrical connector from the fuel tank module.
  22. Completely lower the fuel tank.
  23. With the aid of an assistant, place the fuel tank in a suitable work area.
  24. If replacing the fuel tank proceed to the next step, otherwise proceed to step 10 in the installation procedure.
  25. Remove the fuel tank shield push on retainers.
  26. Remove the fuel tank shield.
  27. Disconnect the fuel feed pipe quick connect fitting from the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  28. Remove the fuel feed pipe from the fuel tank clip (1).
  29. Remove the EVAP canister purge pipe from the fuel tank clip (1).
  30. Disconnect the EVAP rear pipe quick connect fittings from the rollover valve and the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  31. Remove the EVAP rear pipe from the fuel tank clips (1 and 2).
  32. Disconnect the small EVAP rear pipe quick connect fittings from the rollover valve and the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  33. Remove the fuel tank module. Refer to «Fuel Tank Fuel Pump Module Replacement (15 Reg Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  1. Install the fuel tank module. Refer to «Fuel Tank Fuel Pump Module Replacement (15 Reg/Ext/Crew Cab w/34 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  2. Position and connect the small EVAP rear pipe quick connect fittings to the rollover valve and the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Position and connect the EVAP rear pipe quick connect fittings to the rollover valve and the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  4. Install the EVAP rear pipe to the fuel tank clips (1 and 2).
  5. Install the EVAP canister purge pipe to the fuel tank clip (1).
  6. Position and connect the fuel feed pipe quick connect fitting to the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  7. Install the fuel feed pipe to the fuel tank clip (1).
  8. Position and install the fuel tank shield.
  9. Install the fuel tank shield push on retainers.
  10. With the aid of an assistant, place the fuel tank in a the adjustable jack.
  11. Raise the fuel tank until the electrical connections can be made.
  12. Connect the chassis wiring harness electrical connector to the fuel tank module.
  13. Connect the chassis wiring harness electrical connector from the fuel pressure sensor.
  14. Completely raise the fuel tank into position.
  15. Install the fuel tank straps.
  16. Install the fuel tank strap bolts. Tighten Tighten the bolts to 40 N.m (30 lb ft).
  17. Remove the adjustable jack from under the fuel tank.
  18. Unsecure and position the EVAP canister vent solenoid to the fuel tank.
  19. Slide the EVAP canister vent solenoid onto the bracket towards the driver side of the vehicle.
  20. Ensure that the EVAP canister vent solenoid engages the fuel tank bracket retainer (1).
  21. Connect the EVAP canister vent solenoid pipe quick connect fitting (3) to the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  22. Connect the EVAP canister pipe quick connect fitting (2) to the fuel tank EVAP pipe. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  23. Install the EVAP canister vent solenoid pipe clip (1) to the frame crossmember.
  24. Connect the chassis wiring harness electrical connector to the EVAP canister vent solenoid.
  25. Install the chassis wiring harness clip to the fuel tank shield.
  26. Remove the caps from the fuel and EVAP lines.
  27. Connect the fuel tank fuel feed (1) and EVAP (2) line quick connect fittings to the chassis lines. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  28. Install the fuel tank fill pipe. Refer to «Fuel Tank Filler Pipe Replacement (15 Reg Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  29. Refill the fuel tank.
  30. Install the fuel cap.
  31. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection (TP2)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) , «Battery Negative Cable Disconnection and Connection (Single Battery)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  32. Perform the following procedure in order to inspect for leaks: Turn the ignition ON, with the engine OFF, for 2 seconds. Turn the ignition OFF for 10 seconds. Turn the ignition ON, with the engine OFF. Inspect for fuel leaks.
  1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (Without CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-without-ch-48027) , «Fuel Pressure Relief (CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-ch-48027) .
  2. Drain the fuel tank. Refer to «Fuel Tank Draining»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-draining) .
  3. Remove the fuel tank fill pipe. Refer to «Fuel Tank Filler Pipe Replacement (15 Reg/Ext/Crew Cab w/34 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  4. Remove the fuel tank shield bolts, if equipped.
  5. Remove the fuel tank shield from the fuel tank shield tabs (1), if equipped.
  6. Remove the EVAP canister vent solenoid pipe clip (1) from the frame crossmember.
  7. Disconnect the EVAP canister pipe quick connect fitting (2) from the fuel tank EVAP pipe. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  8. Disconnect the EVAP canister vent solenoid pipe quick connect fitting (3) from the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  9. Disconnect the chassis wiring harness electrical connector from the EVAP canister vent solenoid.
  10. Remove the chassis wiring harness clip from the fuel tank shield.
  11. Disengage the retainer (1) securing the EVAP canister vent solenoid.
  12. Slide the EVAP canister vent solenoid off the bracket towards the passenger side of the vehicle.
  13. Disconnect the fuel tank fuel feed line quick connect fitting (1) from the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  14. Disconnect the fuel tank EVAP line quick connect fitting (2) from the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  15. Cap the fuel and EVAP lines in order to prevent possible system contamination.
  16. Place a suitable adjustable jack under the fuel tank.
  17. Remove the fuel tank strap bolts.
  18. Remove the fuel tank straps.
  19. Lower the fuel tank half way.
  20. Disconnect the chassis wiring harness clip at the frame crossmember.
  21. Lower the fuel tank until the electrical connections are accessible.
  22. Disconnect the chassis wiring harness electrical connector (1) from the fuel tank pressure sensor.
  23. Disconnect the chassis wiring harness electrical connector (2) from the fuel tank module.
  24. Completely lower the fuel tank.
  25. With the aid of an assistant, place the fuel tank in a suitable work area.
  26. If replacing the fuel tank proceed to the next step, otherwise proceed to step 9 in the installation procedure.
  27. Remove the fuel tank shield push on retainers.
  28. Remove the fuel tank shield.
  29. Disconnect the fuel feed pipe quick connect fitting from the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  30. Remove the fuel feed pipe from the fuel tank clips (1).
  31. Remove the EVAP pipe from the fuel tank clips (1).
  32. Disconnect the EVAP pipe quick connect fittings from the rollover valve and the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  33. Remove the EVAP pipe from the fuel tank clips (1).
  34. Remove the fuel tank module. Refer to «Fuel Tank Fuel Pump Module Replacement (15 Reg/Ext/Crew Cab w/34 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  1. Install the fuel tank module. Refer to «Fuel Tank Fuel Pump Module Replacement (15 Reg/Ext/Crew Cab w/34 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  2. Position and connect the EVAP pipe quick connect fittings to the rollover valve and the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Install the EVAP pipe to the fuel tank clips (1).
  4. Install the EVAP pipe to the fuel tank clips (1).
  5. Position and connect the fuel feed pipe quick connect fitting to the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  6. Install the fuel feed pipe to the fuel tank clips (1).
  7. Position and install the fuel tank shield.
  8. Install the fuel tank shield push on retainers.
  9. With the aid of an assistant, place the fuel tank in a the adjustable jack.
  10. Raise the fuel tank until the electrical connections can be made.
  11. Connect the chassis wiring harness electrical connector (2) to the fuel tank module.
  12. Connect the chassis wiring harness electrical connector (1) from the fuel pressure sensor.
  13. Completely raise the fuel tank into position.
  14. Install the fuel tank straps.
  15. Install the fuel tank strap bolts and tighten to 40 N.m (30 lb ft).
  16. Remove the adjustable jack from under the fuel tank.
  17. Remove the caps from the fuel and EVAP lines.
  18. Connect the fuel tank EVAP line quick connect fitting (2) to the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  19. Connect the fuel tank fuel feed line quick connect fitting (1) to the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  20. Slide the EVAP canister vent solenoid onto the bracket towards the driver side of the vehicle.
  21. Ensure that the retainer (1) is engaged, securing the EVAP canister vent solenoid.
  22. Connect the EVAP canister vent solenoid pipe quick connect fitting (3) to the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  23. Connect the EVAP canister pipe quick connect fitting (2) to the fuel tank EVAP pipe. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  24. Install the EVAP canister vent solenoid pipe clip (1) to the frame crossmember.
  25. Connect the chassis wiring harness electrical connector to the EVAP canister vent solenoid.
  26. Install the chassis wiring harness clip to the fuel tank shield.
  27. Position and install the fuel tank shield onto the fuel tank shield tabs (1), if equipped.
  28. Install the fuel tank shield bolts, if equipped, and tighten to 12 N.m (106 lb in).
  29. Install the fuel tank fill pipe. Refer to «Fuel Tank Filler Pipe Replacement (15 Reg/Ext/Crew Cab w/34 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  30. Refill the fuel tank.
  31. Install the fuel cap.
  32. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection (TP2)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) , «Battery Negative Cable Disconnection and Connection (Single Battery)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  33. Perform the following procedure in order to inspect for leaks: Turn the ignition ON, with the engine OFF, for 2 seconds. Turn the ignition OFF for 10 seconds. Turn the ignition ON, with the engine OFF. Inspect for fuel leaks.
  1. Relieve the fuel system pressure. Refer to the «Fuel Pressure Relief (Without CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-without-ch-48027) , «Fuel Pressure Relief (CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-ch-48027) .
  2. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  3. Drain the fuel tank. Refer to «Fuel Tank Draining»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-draining) .
  4. Remove the fuel tank shield bolts (1) and the fuel tank shield (2).
  5. Loosen the fuel fill hose clamp (1).
  6. Support the fuel tank with a suitable jack.
  7. Remove the fuel tank strap fastener (1).
  8. Lower the tank enough to access the fuel pump module.
  9. Disconnect the electrical connector (1) and the evaporative emissions lines and the fuel lines (2). Refer to «Metal Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__metal-collar-quick-connect-fitting-service) , and «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions)
  10. Lower the fuel tank.
  11. If replacing the fuel tank, remove the fuel pump module from the fuel tank. Refer to «Fuel Tank Fuel Pump Module Replacement (25/35 Series)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  12. Cap the fuel and EVAP pipes in order to prevent possible fuel system contamination.
  1. If removed, install the fuel pump module. Refer to «Fuel Tank Fuel Pump Module Replacement (25/35 Series)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  2. Partially raise the fuel tank enough to access the fuel pump module.
  3. Connect the electrical connector (1) and fuel and evaporative emission lines. Refer to «Metal Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__metal-collar-quick-connect-fitting-service) , and «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions)
  4. Support the fuel tank with a suitable jack.
  5. Install the fuel tank strap fastener (1) and tighten to 40 N.m (30 lb ft).
  6. Tighten the fuel fill hose clamp (1) to 4 N.m (35 lb in).
  7. Install the fuel tank shield (2) and tighten the fuel tank shield bolts (1) to 18 N.m (21 lb ft).
  8. Refill the fuel tank.
  9. Install the fuel filler cap.
  10. Use the following procedure in order to inspect for leaks: Turn ON the ignition, with the engine OFF, for 2 seconds. Turn OFF the ignition for 10 seconds. Turn ON the ignition, with the engine OFF. Inspect for fuel leaks.
  1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (Without CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-without-ch-48027) , «Fuel Pressure Relief (CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-ch-48027) .
  2. Drain the fuel tank. Refer to «Fuel Tank Draining»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-draining) .
  3. Remove the fuel shield fasteners (1) and fuel shield (2).
  4. Loosen the filler hose clamp (1) and disconnect the filler hose.
  5. Disconnect the quick connect fitting (2). Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions)
  6. Disconnect the quick connect fitting (1). Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions)
  7. Disengage the plastic clips (2) from the frame.
  8. Disconnect the fuel pump wiring harness connector.
  9. If replacing the fuel tank proceed to the next step, otherwise proceed to step 9 in the installation procedure.
  10. Support the tank with a suitable jack.
  11. Remove the fuel tank strap fasteners (1).
  12. Remove the fuel tank (1).
  13. If replacing the tank, remove the fuel tank module. Refer to «Fuel Tank Fuel Pump Module Replacement (25/35 Series)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  14. Transfer components as necessary.
  1. If the tank was replaced, install the fuel tank module. Refer to «Fuel Tank Fuel Pump Module Replacement (25/35 Series)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  2. Using a suitable jack, install the fuel tank (1) into position.
  3. Install the fuel tank shield fasteners (1) and tighten to 40 N.m (30 lb ft).
  4. Engage the plastic clips (2) to the frame.
  5. Connect the quick connect fitting (1). Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions)
  6. Connect the fuel pump wiring harness connector.
  7. Tighten the filler hose clamp (1) to 4 N.m(35 lb in).
  8. Connect the quick connect fitting (2). Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions)
  9. Connect the EVAP canister pipe quick connect fitting (2) to the fuel tank EVAP pipe. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  10. Install the fuel tank shield (2) and fasteners (1) and tighten to 18Y (13 lb ft).
  11. Refill the fuel tank.
  12. Perform the following procedure in order to inspect for leaks: Turn the ignition ON, with the engine OFF, for 2 seconds. Turn the ignition OFF for 10 seconds. Turn the ignition ON, with the engine OFF. Inspect for fuel leaks.
  1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (Without CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-without-ch-48027) , «Fuel Pressure Relief (CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-ch-48027) .
  2. Drain the fuel tank. Refer to «Fuel Tank Draining»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-draining) .
  3. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection (TP2)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) , «Battery Negative Cable Disconnection and Connection (Single Battery)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  4. Disconnect the fuel tank fill pipe (3) from the fuel tank.
  5. Remove the fuel tank bolts, if equipped.
  6. Remove the fuel tank shield, if equipped. Refer to «Fuel Tank Shield Replacement»(/gmc/sierra-2500/2012-2012/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  7. Disconnect the fuel tank fuel feed line quick connect fitting (1) from the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  8. Disconnect the fuel tank EVAP line quick connect fitting (2) from the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  9. Cap the fuel and EVAP lines in order to prevent possible system contamination.
  10. Place a suitable adjustable jack under the fuel tank.
  11. Remove the fuel tank strap bolts.
  12. Remove the fuel tank straps.
  13. Lower the fuel tank half way.
  14. Disconnect the chassis wiring harness clip at the frame crossmember.
  15. Lower the fuel tank until the electrical connections are accessible.
  16. Disconnect the chassis wiring harness electrical connector (2) from the fuel tank pressure sensor.
  17. Disconnect the chassis wiring harness electrical connector (1) from the fuel tank module.
  18. Completely lower the fuel tank.
  19. With the aid of an assistant, place the fuel tank in a suitable work area.
  20. If replacing the fuel tank proceed to the next step, otherwise proceed to step 9 in the installation procedure.
  21. Remove the fuel tank shield push on retainers (2).
  22. Remove the fuel tank shield (1).
  23. Disconnect the fuel feed pipe (1) quick connect fitting from the fuel tank fuel pump module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  24. Remove the fuel feed pipe (1) from the fuel tank clips.
  25. Remove the EVAP pipe (2) from the fuel tank fuel pump module (1).
  26. Disconnect the EVAP pipe (3) quick connect fittings from the rollover valve and the fuel tank fuel pump module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  27. Remove the EVAP pipe from the fuel tank clips (1).
  28. Remove the fuel tank fuel pump module. Refer to «Fuel Tank Fuel Pump Module Replacement (25/35 Series)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) ,.
  1. Install the fuel tank fuel pump module. Refer to «Fuel Tank Fuel Pump Module Replacement (25/35 Series)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  2. Position and connect the EVAP pipe (3) quick connect fittings to the rollover valve and the fuel tank fuel pump module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Install the EVAP pipe (2) to the fuel tank clips.
  4. Install the EVAP pipe (2) to the fuel tank pump module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  5. Position and connect the fuel feed pipe quick connect fitting to the fuel tank pump module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  6. Install the fuel feed pipe (1) to the fuel tank clips.
  7. Position the fuel tank shield (1) to the fuel tank.
  8. Install the fuel tank shield push on retainers (2).
  9. With the aid of an assistant, place the fuel tank in a the adjustable jack.
  10. Raise the fuel tank until the electrical connections can be made.
  11. Connect the chassis wiring harness electrical connector (1) to the fuel tank module.
  12. Connect the chassis wiring harness electrical connector (2) from the fuel pressure sensor.
  13. Completely raise the fuel tank into position.
  14. Install the fuel tank straps.
  15. Install the fuel tank strap bolts. Tighten Tighten the bolts to 40 N.m (30 lb ft).
  16. Remove the adjustable jack from under the fuel tank.
  17. Remove the caps from the fuel and EVAP lines.
  18. Connect the fuel tank EVAP line quick connect fitting (2) to the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  19. Connect the fuel tank fuel feed line quick connect fitting (1) to the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  20. Install the fuel tank shield, if equipped. Refer to «Fuel Tank Shield Replacement»(/gmc/sierra-2500/2012-2012/remont/frames-subframes-crossmembers/#frame-and-underbody) .
  21. Install the fuel tank fill pipe (3) to the fuel tank and tighten the clamp.
  22. Refill the fuel tank.
  23. Install the fuel cap.
  24. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection (TP2)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) , «Battery Negative Cable Disconnection and Connection (Single Battery)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  25. Perform the following procedure in order to inspect for leaks: Turn the ignition ON, with the engine OFF, for 2 seconds. Turn the ignition OFF for 10 seconds. Turn the ignition ON, with the engine OFF. Inspect for fuel leaks.
  1. Remove the fuel tank. Refer to «Fuel Tank Replacement (15 Ext/Crew Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Remove the fuel tank pressure sensor by pulling straight up using a slight rocking motion.
  1. Install the fuel tank pressure sensor.
  2. Install the fuel tank pressure sensor cover.
  3. Install the fuel tank. Refer to «Fuel Tank Replacement (15 Ext/Crew Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  1. Remove the fuel tank. Refer to «Fuel Tank Replacement (15 Rec Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Remove the fuel tank pressure sensor by pulling straight up using a slight rocking motion.
  1. Install the fuel tank pressure sensor.
  2. Install the fuel tank pressure sensor cover.
  3. Install the fuel tank. Refer to «Fuel Tank Replacement (15 Rec Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  1. Remove the fuel tank. Refer to «Fuel Tank Replacement (15 Reg/Ext Cab w/34 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Remove the fuel tank pressure sensor by pulling straight up using a slight rocking motion.
  1. Install the fuel tank pressure sensor.
  2. Install the fuel tank pressure sensor cover.
  3. Install the fuel tank. Refer to «Fuel Tank Replacement (15 Reg/Ext Cab w/34 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  1. Remove the fuel tank. Refer to «Fuel Tank Replacement (25/35 Series)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Remove the fuel tank pressure sensor by pulling straight up using a slight rocking motion.
  1. Install the fuel tank pressure sensor.
  2. Install the fuel tank pressure sensor cover.
  3. Install the fuel tank. Refer to «Fuel Tank Replacement (25/35 Series)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .

Fuel Tank Fuel Pump Module Replacement (15 Ext/Crew Cab With 26 Gal Tank)

Special Tools

J 45722 Fuel Sender Lock Ring Wrench

  1. Remove the fuel tank. Refer to «Fuel Tank Replacement (15 Ext/Crew Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Disconnect the fuel tank fuel feed pipe quick connect fitting from the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Disconnect the fuel tank evaporative emission (EVAP) pipe quick connect fittings from the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  4. Reposition the fuel and EVAP pipes out of the way.
  5. Install the J 45722 fuel sender lock ring wrench (1) to the fuel tank module lock ring.
  6. Using the J 45722 fuel sender lock ring wrench and a long breaker bar, rotate the lock ring clockwise unlocking the fuel tank module lock ring.
  7. Remove the J 45722 fuel sender lock ring wrench.
  8. Remove the fuel tank module lock ring.
  9. Slowly raise the module until the fuel level sensor float arm is just visible.
  10. Tilt the module toward the rear of the fuel tank to allow the level sensor float arm to clear the tank opening. Remove the module from the tank.
  11. Carefully discard the fuel in the module reservoir bucket into an approved fuel container.
  12. Remove and discard the fuel tank module O-ring seal.
  13. Place the lock ring on a flat surface. Measure the clearance between the lock ring and the flat surface using a feeler gauge at 7 points.
  14. If warpage is less than 0.41 mm (0.016 in), the lock ring does not require replacement.
  15. If warpage is greater than 0.41 mm (0.016 in), the lock ring must be replaced.
  1. Install a NEW fuel tank module O-ring seal onto the fuel tank.
  2. Tilt the module toward the rear of the fuel tank to allow the fuel level sensor float arm to clear the tank opening. Install the module into the fuel tank.
  3. Lower the module assembly into the tank.
  4. Position and install the fuel tank module lock ring.
  5. Ensure that the module sealing surface is clean and free of contamination.
  6. Install the J 45722 fuel sender lock ring wrench to the fuel tank module lock ring.
  7. Using the J 45722 fuel sender lock ring wrench and a long breaker bar, rotate the lock ring counterclockwise locking the fuel tank module lock ring.
  8. Remove the J 45722 fuel sender lock ring wrench (1) from the fuel tank module lock ring.
  9. Position the fuel and EVAP pipes to the module.
  10. Connect the fuel tank EVAP pipe quick connect fittings to the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  11. Connect the fuel tank fuel feed pipe quick connect fitting to the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  12. Install the fuel tank. Refer to «Fuel Tank Replacement (15 Ext/Crew Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .

Fuel Tank Fuel Pump Module Replacement (15 Reg Cab With 26 Gal Tank)

Special Tools

J 45722 Fuel Sender Lock Ring Wrench

  1. Remove the fuel tank. Refer to «Fuel Tank Replacement (15 Reg Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Disconnect the fuel tank fuel feed pipe quick connect fitting from the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Disconnect the fuel tank evaporative emission (EVAP) pipe quick connect fittings from the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  4. Reposition the fuel and EVAP pipes out of the way.
  5. Install the J 45722 fuel sender lock ring wrench (1) to the fuel tank module lock ring.
  6. Using the J 45722 fuel sender lock ring wrench and a long breaker bar, rotate the lock ring clockwise unlocking the fuel tank module lock ring.
  7. Remove the J 45722 fuel sender lock ring wrench.
  8. Remove the fuel tank module lock ring.
  9. Slowly raise the module until the fuel level sensor float arm is just visible.
  10. Tilt the module toward the rear of the fuel tank to allow the level sensor float arm to clear the tank opening. Remove the module from the tank.
  11. Carefully discard the fuel in the module reservoir bucket into an approved fuel container.
  12. Remove and discard the fuel tank module O-ring seal.
  13. Place the lock ring on a flat surface. Measure the clearance between the lock ring and the flat surface using a feeler gauge at 7 points.
  14. If warpage is less than 0.41 mm (0.016 in), the lock ring does not require replacement.
  15. If warpage is greater than 0.41 mm (0.016 in), the lock ring must be replaced.
  1. Install a NEW fuel tank module O-ring seal onto the fuel tank.
  2. Tilt the module toward the rear of the fuel tank to allow the fuel level sensor float arm to clear the tank opening. Install the module into the fuel tank.
  3. Lower the module assembly into the tank.
  4. Position and install the fuel tank module lock ring.
  5. Ensure that the module sealing surface is clean and free of contamination.
  6. Install the J 45722 fuel sender lock ring wrench to the fuel tank module lock ring.
  7. Using the J 45722 fuel sender lock ring wrench and a long breaker bar, rotate the lock ring counterclockwise locking the fuel tank module lock ring.
  8. Remove the J 45722 fuel sender lock ring wrench (1) from the fuel tank module lock ring.
  9. Position the fuel and EVAP pipes to the module.
  10. Connect the fuel tank EVAP pipe quick connect fittings to the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  11. Connect the fuel tank fuel feed pipe quick connect fitting to the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  12. Install the fuel tank. Refer to «Fuel Tank Replacement (15 Rec Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .

Fuel Tank Fuel Pump Module Replacement (15 Reg/Ext/Crew Cab w/34 Gal Tank)

Special Tools

J 45722 Fuel Sender Lock Ring Wrench

  1. Remove the fuel tank. Refer to «Fuel Tank Replacement (15 Reg/Ext Cab w/34 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Disconnect the fuel tank fuel feed pipe quick connect fitting from the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Disconnect the fuel tank evaporative emission (EVAP) pipe quick connect fitting from the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  4. Reposition the fuel and EVAP pipes out of the way.
  5. Install the J 45722 fuel sender lock ring wrench (1) to the fuel tank module lock ring.
  6. Using the J 45722 fuel sender lock ring wrench and a long breaker bar, rotate the lock ring clockwise unlocking the fuel tank module lock ring.
  7. Remove the J 45722 fuel sender lock ring wrench.
  8. Remove the fuel tank module lock ring.
  9. Slowly raise the module until the fuel level sensor float arm is just visible.
  10. Tilt the module toward the rear of the fuel tank to allow the level sensor float arm to clear the tank opening. Remove the module from the tank.
  11. Carefully discard the fuel in the module reservoir bucket into an approved fuel container.
  12. Remove and discard the fuel tank module O-ring seal.
  13. Place the lock ring on a flat surface. Measure the clearance between the lock ring and the flat surface using a feeler gauge at 7 points.
  14. If warpage is less than 0.41 mm (0.016 in), the lock ring does not require replacement.
  15. If warpage is greater than 0.41 mm (0.016 in), the lock ring must be replaced.
  1. Install a NEW fuel tank module O-ring seal onto the fuel tank.
  2. Tilt the module toward the rear of the fuel tank to allow the fuel level sensor float arm to clear the tank opening. Install the module into the fuel tank.
  3. Lower the module assembly into the tank.
  4. Position and install the fuel tank module lock ring.
  5. Ensure that the module sealing surface is clean and free of contamination.
  6. Install the J 45722 fuel sender lock ring wrench to the fuel tank module lock ring.
  7. Using the J 45722 fuel sender lock ring wrench and a long breaker bar, rotate the lock ring counterclockwise locking the fuel tank module lock ring.
  8. Remove the J 45722 fuel sender lock ring wrench (1) from the fuel tank module lock ring.
  9. Position the fuel and EVAP pipes to the module.
  10. Connect the fuel tank EVAP pipe quick connect fitting to the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  11. Connect the fuel tank fuel feed pipe quick connect fitting to the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  12. Install the fuel tank. Refer to «Fuel Tank Replacement (15 Reg/Ext Cab w/34 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .

Fuel Tank Fuel Pump Module Replacement (25/35 Series)

Special Tools

J 45722 Fuel Sender Lock Ring Wrench

  1. Remove the fuel tank. Refer to «Fuel Tank Replacement (25/35 Series)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Disconnect the fuel tank fuel feed pipe quick connect fitting from the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Disconnect the fuel tank evaporative emission (EVAP) pipe quick connect fittings from the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  4. Reposition the fuel and EVAP pipes out of the way.
  5. Install the J 45722 fuel sender lock ring wrench (1) to the fuel tank module lock ring.
  6. Using the J 45722 fuel sender lock ring wrench and a long breaker bar, rotate the lock ring clockwise unlocking the fuel tank module lock ring.
  7. Remove the J 45722 fuel sender lock ring wrench.
  8. Remove the fuel tank module lock ring.
  9. Slowly raise the module until the fuel level sensor float arm is just visible.
  10. Tilt the module toward the rear of the fuel tank to allow the level sensor float arm to clear the tank opening. Remove the module from the tank.
  11. Carefully discard the fuel in the module reservoir bucket into an approved fuel container.
  12. Remove and discard the fuel tank module O-ring seal.
  13. Place the lock ring on a flat surface. Measure the clearance between the lock ring and the flat surface using a feeler gauge at 7 points.
  14. If warpage is less than 0.41 mm (0.016 in), the lock ring does not require replacement.
  15. If warpage is greater than 0.41 mm (0.016 in), the lock ring must be replaced.
  1. Install a NEW fuel tank module O-ring seal onto the fuel tank.
  2. Tilt the module toward the rear of the fuel tank to allow the fuel level sensor float arm to clear the tank opening. Install the module into the fuel tank.
  3. Lower the module assembly into the tank.
  4. Position and install the fuel tank module lock ring.
  5. Ensure that the module sealing surface is clean and free of contamination.
  6. Install the J 45722 fuel sender lock ring wrench to the fuel tank module lock ring.
  7. Using the J 45722 fuel sender lock ring wrench and a long breaker bar, rotate the lock ring counterclockwise locking the fuel tank module lock ring.
  8. Remove the J 45722 fuel sender lock ring wrench (1) from the fuel tank module lock ring.
  9. Position the fuel and EVAP pipes to the module.
  10. Connect the fuel tank EVAP pipe quick connect fittings to the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  11. Connect the fuel tank fuel feed pipe quick connect fitting to the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  12. Install the fuel tank. Refer to «Fuel Tank Replacement (25/35 Series)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  1. Remove the fuel tank module. Refer to «Fuel Tank Fuel Pump Module Replacement (15 Reg Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  2. Disconnect the fuel level sensor wiring pigtail electrical connector (1) from the module cover.
  3. Remove the fuel level sensor wiring pigtail from under the module clip (1).
  4. Gently push in the fuel level sensor retainers (2), disengaging them from the module reservoir.
  5. Slide the fuel level sensor up, in order to remove the sensor from the module slot.
  1. Position the fuel level sensor over the slot in the reservoir and slide the sensor down into the slot.
  2. Ensure that the fuel level sensor retainers (2) engage the module reservoir.
  3. Install the fuel level sensor wiring pigtail under the module clip (1) behind the fuel pump wires.
  4. Connect the fuel level sensor wiring pigtail electrical connector (1) to the module cover.
  5. Install the fuel tank module. Refer to «Fuel Tank Fuel Pump Module Replacement (15 Reg Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  1. Remove the fuel tank module. Refer to «Fuel Tank Fuel Pump Module Replacement (15 Ext/Crew Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  2. Disconnect the fuel level sensor wiring pigtail electrical connector (1) from the module cover.
  3. Remove the fuel level sensor wiring pigtail from under the module clip (2).
  4. Gently push in the fuel level sensor retainers (1), disengaging them from the module reservoir.
  5. Slide the fuel level sensor up, in order to remove the sensor from the module slot.
  1. Position the fuel level sensor over the slot in the reservoir and slide the sensor down into the slot.
  2. Ensure that the fuel level sensor retainers (1) engage the module reservoir.
  3. Install the fuel level sensor wiring pigtail under the module clip (2) behind the fuel pump wires.
  4. Connect the fuel level sensor wiring pigtail electrical connector (1) to the module cover.
  5. Install the fuel tank module. Refer to «Fuel Tank Fuel Pump Module Replacement (15 Ext/Crew Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  1. Remove the fuel tank module. Refer to «Fuel Tank Fuel Pump Module Replacement (15 Reg/Ext/Crew Cab w/34 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  2. Disconnect the fuel level sensor wiring pigtail electrical connector (1) from the module cover.
  3. Remove the fuel level sensor wiring pigtail from under the module clip (2).
  4. Gently push in the fuel level sensor retainers (1), disengaging them from the module reservoir.
  5. Slide the fuel level sensor up, in order to remove the sensor from the module slot.
  1. Position the fuel level sensor over the slot in the reservoir and slide the sensor down into the slot.
  2. Ensure that the fuel level sensor retainers (1) engage the module reservoir.
  3. Install the fuel level sensor wiring pigtail under the module clip (2) behind the fuel pump wires.
  4. Connect the fuel level sensor wiring pigtail electrical connector (1) to the module cover.
  5. Install the fuel tank module. Refer to «Fuel Tank Fuel Pump Module Replacement (15 Reg/Ext/Crew Cab w/34 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  1. Remove the fuel pump module. Refer to «Fuel Tank Fuel Pump Module Replacement (25/35 Series)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  2. Using two flat-bladed tools, carefully pull both locking tabs (1) outward while simultaneously lifting the level sensor.
  3. Using a small bladed tool, push in the electrical terminals (1) while simultaneously pulling out.
  1. Push in the electrical terminals (1) and ensure the terminals are secure.
  2. Carefully insert the level sensor until the locking tabs (1) snap into the locking position.
  3. Install the fuel pump module. Refer to «Fuel Tank Fuel Pump Module Replacement (25/35 Series)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  1. Relieve the fuel system pressure. Refer to the «Fuel Pressure Relief (Without CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-without-ch-48027) , «Fuel Pressure Relief (CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-ch-48027) .
  2. Disconnect the engine evaporative emission (EVAP) line (1) quick connect fitting from the chassis EVAP line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Disconnect the fuel feed line quick connect fitting (2) from the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__metal-collar-quick-connect-fitting-service) .
  4. Cap the fuel rail and EVAP pipes.
  5. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  6. Unbolt and reposition the front propeller shaft, if required. Refer to «Front Propeller Shaft Replacement»(/gmc/sierra-2500/2012-2012/remont/driveshaft-universal-joints/#propeller-shaft-and-universal-joints__front-propeller-shaft-replacement) .
  7. Unbolt and reposition the brake pressure modulator valve (BPMV). Refer to «Brake Pressure Modulator Valve Replacement»(/gmc/sierra-2500/2012-2012/remont/anti-locktraction-control/#antilock-brake-system-non-hybrid-less-than-3900-kg-8600-lb-gvw) .
  8. Remove the fuel pipe bracket nut from the bellhousing stud.
  9. Remove the fuel line clips (1) from the bracket on the automatic transmission.
  10. If equipped with 4-wheel drive (4WD), remove the fuel hose/pipe clip from the bracket on the transfer case.
  11. Remove the EVAP canister vent solenoid clip (1) from the chassis EVAP line and secure out of the way.
  12. Remove the EVAP canister vent solenoid pipe clip (2) from the chassis EVAP line.
  13. Disconnect the fuel tank fuel feed line quick connect fitting from the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  14. Disconnect the fuel tank EVAP line quick connect fitting from the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  15. Cap the fuel and EVAP lines in order to prevent possible fuel and/or EVAP system contamination.
  16. Remove the fuel/EVAP line clip nuts (1).
  17. Remove the fuel/EVAP line clips from the frame and crossmember.
  18. Remove the fuel/EVAP line assembly from the vehicle.
  1. Position and install the fuel/EVAP line assembly to the vehicle.
  2. Install the fuel/EVAP line bracket locator tab to the frame.
  3. Install the fuel/EVAP line clips to the frame and crossmember.
  4. Install the fuel/EVAP line clip nuts (1). Tighten Tighten the bolt to 20 N.m (15 lb ft).
  5. Remove the caps from the fuel and EVAP lines.
  6. Connect the fuel tank EVAP line quick connect fitting to the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  7. Connect the fuel tank fuel feed line quick connect fitting to the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  8. Unsecure and position the EVAP canister vent solenoid clip (1) to the chassis EVAP line.
  9. Install the EVAP canister vent solenoid pipe clip (2) from the chassis EVAP line.
  10. If equipped with 4WD, install the fuel hose/pipe clip to the bracket on the transfer case.
  11. Install the fuel line clip to the bracket on the automatic transmission.
  12. Install the fuel pipe bracket nut to the bellhousing stud. Tighten Tighten the nut to 25 N.m (18 lb ft).
  13. Position and install the BPMV. Refer to «Brake Pressure Modulator Valve Replacement»(/gmc/sierra-2500/2012-2012/remont/anti-locktraction-control/#antilock-brake-system-non-hybrid-less-than-3900-kg-8600-lb-gvw) .
  14. Position and install the front propeller shaft, if required. Refer to «Front Propeller Shaft Replacement»(/gmc/sierra-2500/2012-2012/remont/driveshaft-universal-joints/#propeller-shaft-and-universal-joints__front-propeller-shaft-replacement) .
  15. Lower the vehicle.
  16. Remove the caps from the fuel rail and EVAP line.
  17. Connect the EVAP line (1) quick connect fitting to the chassis EVAP line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  18. Connect the fuel feed line (2) quick connect fitting to the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__metal-collar-quick-connect-fitting-service) .
  19. Install the fuel fill cap.
  20. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection (TP2)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) , «Battery Negative Cable Disconnection and Connection (Single Battery)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  21. Use the following procedure in order to inspect for leaks: Turn the ignition ON, with the engine OFF, for 2 seconds. Turn the ignition OFF for 10 seconds. Turn the ignition ON, with the engine OFF. Inspect for fuel leaks.
  22. Install the intake manifold sight shield. Refer to «Upper Intake Manifold Sight Shield Replacement»(/gmc/sierra-2500/2012-2012/remont/mechanical/#engine-mechanical-48l-53l-60l-62l-repair-instructions-on-vehicle) .

Scheme 54

Scheme 54: Fuel Feed and Evaporative Emission Hose Replacement (Rear)
Scheme 54: Fuel Feed and Evaporative Emission Hose Replacement (Rear)

Fuel Feed and Evaporative Emission Hose Replacement (Rear)

Scheme 55

Scheme 55: Fuel Feed and Evaporative Emission Hose Replacement (Auxiliary)
Scheme 55: Fuel Feed and Evaporative Emission Hose Replacement (Auxiliary)

Fuel Feed and Evaporative Emission Hose Replacement (Auxiliary)

  1. Relieve the fuel system pressure. Refer to the «Fuel Pressure Relief (Without CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-without-ch-48027) , «Fuel Pressure Relief (CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-ch-48027) .
  2. Disconnect the engine evaporative emission (EVAP) line (1) quick connect fitting from the chassis EVAP line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Disconnect the fuel feed line quick connect fitting (2) from the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__metal-collar-quick-connect-fitting-service) .
  4. Cap the fuel rail and EVAP pipes.
  5. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  6. Unbolt and reposition the front propeller shaft, if required. Refer to «Front Propeller Shaft Replacement»(/gmc/sierra-2500/2012-2012/remont/driveshaft-universal-joints/#propeller-shaft-and-universal-joints__front-propeller-shaft-replacement) .
  7. Unbolt and reposition the brake pressure modulator valve (BPMV). Refer to «Brake Pressure Modulator Valve Replacement»(/gmc/sierra-2500/2012-2012/remont/anti-locktraction-control/#antilock-brake-system-non-hybrid-less-than-3900-kg-8600-lb-gvw) .
  8. Remove the fuel pipe bracket nut from the bellhousing stud.
  9. Remove the fuel line clip (1) from the bracket on the automatic transmission.
  10. If equipped with 4-wheel drive (4WD), remove the fuel hose/pipe clip from the bracket on the transfer case.
  11. Remove the EVAP canister vent solenoid clip (1) from the chassis EVAP line and secure out of the way.
  12. Remove the EVAP canister vent solenoid pipe clip (2) from the chassis line.
  13. Disconnect the fuel tank fuel feed line quick connect fitting from the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  14. Disconnect the chassis EVAP line quick connect fitting from the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  15. Cap the fuel and EVAP lines in order to prevent possible fuel and/or EVAP system contamination.
  16. Remove the fuel line bracket bolt (1).
  17. Remove the fuel/EVAP line clip nut (2).
  18. Remove the fuel/EVAP line clips from the frame and crossmember.
  19. Remove the fuel/EVAP line assembly from the vehicle.
  1. Position and install the fuel/EVAP line assembly to the vehicle.
  2. Install the fuel/EVAP line bracket locator tab to the frame.
  3. Install the fuel/EVAP line clips to the frame and crossmember.
  4. Install the fuel/EVAP line bracket bolt (1) and tighten to 9 N.m (80 lb in).
  5. Install the fuel/EVAP line clip nut (2). Tighten the bolt to 20 N.m (15 lb ft).
  6. Remove the caps from the fuel and EVAP lines.
  7. Connect the chassis EVAP line quick connect fitting to the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  8. Connect the fuel tank fuel feed line quick connect fitting to the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  9. Unsecure and position the EVAP canister vent solenoid clip (1) to the chassis EVAP line.
  10. Install the EVAP canister vent solenoid pipe clip (2) to the chassis line.
  11. If equipped with 4WD, install the fuel hose/pipe clip (1) to the bracket on the transfer case.
  12. Install the fuel line clip to the bracket on the automatic transmission.
  13. Install the fuel pipe bracket nut to the bellhousing stud. Tighten the nut to 25 N.m (18 lb ft).
  14. Position and install the BPMV. Refer to «Brake Pressure Modulator Valve Replacement»(/gmc/sierra-2500/2012-2012/remont/anti-locktraction-control/#antilock-brake-system-non-hybrid-less-than-3900-kg-8600-lb-gvw) .
  15. Position and install the front propeller shaft, if required. Refer to «Front Propeller Shaft Replacement»(/gmc/sierra-2500/2012-2012/remont/driveshaft-universal-joints/#propeller-shaft-and-universal-joints__front-propeller-shaft-replacement) .
  16. Lower the vehicle.
  17. Remove the caps from the fuel rail and EVAP line.
  18. Connect the EVAP line (1) quick connect fitting to the chassis EVAP line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  19. Connect the fuel feed line (2) quick connect fitting to the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__metal-collar-quick-connect-fitting-service) .
  20. Install the fuel fill cap.
  21. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection (TP2)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) , «Battery Negative Cable Disconnection and Connection (Single Battery)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  22. Use the following procedure in order to inspect for leaks: Turn the ignition ON, with the engine OFF, for 2 seconds. Turn the ignition OFF for 10 seconds. Turn the ignition ON, with the engine OFF. Inspect for fuel leaks.
  23. Install the intake manifold sight shield. Refer to «Upper Intake Manifold Sight Shield Replacement»(/gmc/sierra-2500/2012-2012/remont/mechanical/#engine-mechanical-48l-53l-60l-62l-repair-instructions-on-vehicle) .
  1. Relieve the fuel system pressure. Refer to the «Fuel Pressure Relief (Without CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-without-ch-48027) , «Fuel Pressure Relief (CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-ch-48027) .
  2. Disconnect the engine evaporative emission (EVAP) line (1) quick connect fitting from the chassis EVAP line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Disconnect the fuel feed line quick connect fitting (2) from the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__metal-collar-quick-connect-fitting-service) .
  4. Cap the fuel rail and EVAP pipes.
  5. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  6. Unbolt and reposition the front propeller shaft, if required. Refer to «Front Propeller Shaft Replacement»(/gmc/sierra-2500/2012-2012/remont/driveshaft-universal-joints/#propeller-shaft-and-universal-joints__front-propeller-shaft-replacement) .
  7. Remove the fuel pipe bracket nut from the bellhousing stud.
  8. Remove the fuel line clip from the bracket on the automatic transmission.
  9. If equipped with 4-wheel drive (4WD), remove the fuel hose/pipe clip from the bracket on the transfer case.
  10. Remove the EVAP canister vent solenoid clip (1) from the chassis EVAP line and secure out of the way.
  11. Remove the EVAP canister vent solenoid pipe clip (2) from the chassis EVAP line.
  12. Disconnect the fuel tank EVAP line quick connect fitting from the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  13. Disconnect the fuel tank fuel feed line quick connect fitting from the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  14. Cap the fuel and EVAP lines in order to prevent possible fuel and/or EVAP system contamination.
  15. Remove the fuel line bracket bolt (1).
  16. Remove the fuel/EVAP line clip nut (2).
  17. Remove the fuel/EVAP line clips from the frame and crossmember.
  18. Remove the fuel/EVAP line assembly from the vehicle.
  1. Position and install the fuel/EVAP line assembly to the vehicle.
  2. Install the fuel/EVAP line bracket locator tab to the frame.
  3. Install the fuel/EVAP line clips to the frame and crossmember.
  4. Install the fuel/EVAP line bracket bolt (1). Tighten Tighten the bolt to 9 N.m (80 lb in).
  5. Install the fuel/EVAP line clip nut (2). Tighten Tighten the bolt to 20 N.m (15 lb ft).
  6. Remove the caps from the fuel and EVAP lines.
  7. Connect the fuel tank EVAP line quick connect fitting to the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  8. Connect the fuel tank fuel feed line quick connect fitting to the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  9. Unscure and position the EVAP canister vent solenoid clip (1) to the chassis EVAP line.
  10. Install the EVAP canister vent solenoid pipe clip (2) to the chassis EVAP line.
  11. If equipped with 4WD, install the fuel hose/pipe clip to the bracket on the transfer case.
  12. Install the fuel line clip to the bracket on the automatic transmission.
  13. Install the fuel pipe bracket nut to the bellhousing stud. Tighten Tighten the nut to 25 N.m (18 lb ft).
  14. Position and install the front propeller shaft, if required. Refer to «Front Propeller Shaft Replacement»(/gmc/sierra-2500/2012-2012/remont/driveshaft-universal-joints/#propeller-shaft-and-universal-joints__front-propeller-shaft-replacement) .
  15. Lower the vehicle.
  16. Remove the caps from the fuel rail and EVAP line.
  17. Connect the EVAP line (1) quick connect fitting to the chassis EVAP line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  18. Connect the fuel feed line (2) quick connect fitting to the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__metal-collar-quick-connect-fitting-service) .
  19. Install the fuel fill cap.
  20. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection (TP2)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) , «Battery Negative Cable Disconnection and Connection (Single Battery)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  21. Use the following procedure in order to inspect for leaks: Turn the ignition ON, with the engine OFF, for 2 seconds. Turn the ignition OFF for 10 seconds. Turn the ignition ON, with the engine OFF. Inspect for fuel leaks.
  22. Install the intake manifold sight shield. Refer to «Upper Intake Manifold Sight Shield Replacement»(/gmc/sierra-2500/2012-2012/remont/mechanical/#engine-mechanical-48l-53l-60l-62l-repair-instructions-on-vehicle) .
  1. Relieve the fuel system pressure. Refer to the «Fuel Pressure Relief (Without CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-without-ch-48027) , «Fuel Pressure Relief (CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-ch-48027) .
  2. Disconnect the engine evaporative emission (EVAP) line (1) quick connect fitting from the chassis EVAP line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Disconnect the fuel feed line quick connect fitting (2) from the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__metal-collar-quick-connect-fitting-service) .
  4. Cap the fuel rail and EVAP pipes.
  5. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  6. Unbolt and reposition the front propeller shaft, if required. Refer to «Front Propeller Shaft Replacement»(/gmc/sierra-2500/2012-2012/remont/driveshaft-universal-joints/#propeller-shaft-and-universal-joints__front-propeller-shaft-replacement) .
  7. Remove the fuel pipe bracket nut from the bellhousing stud.
  8. Remove the fuel line clip from the bracket on the automatic transmission.
  9. If equipped with 4-wheel drive (4WD), remove the fuel hose/pipe clip from the bracket on the transfer case.
  10. Remove the EVAP canister vent solenoid clip (1) from the chassis EVAP line and secure out of the way.
  11. Remove the EVAP canister vent solenoid pipe clip (2) from the chassis EVAP line.
  12. If equipped with 2-wheel drive (2WD) perform the following steps, disconnect the fuel tank fuel feed line quick connect fitting from the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  13. Disconnect the fuel tank EVAP line quick connect fitting from the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  14. Cap the fuel and EVAP lines in order to prevent possible fuel and/or EVAP system contamination.
  15. Remove the fuel line bracket bolt (2).
  16. Remove the fuel/EVAP line clip nut (1).
  17. Remove the fuel/EVAP line clips from the frame and crossmember.
  18. Remove the fuel/EVAP line assembly from the vehicle.
  19. If equipped with 4WD perform the following steps, disconnect the fuel tank fuel feed line quick connect fitting from the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  20. Disconnect the fuel tank EVAP line quick connect fitting from the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  21. Cap the fuel and EVAP lines in order to prevent possible fuel and/or EVAP system contamination.
  22. Remove the fuel line bracket bolt (1).
  23. Remove the fuel/EVAP line clip nut (2).
  24. Remove the fuel/EVAP line clips from the frame and crossmember.
  25. Remove the fuel/EVAP line assembly from the vehicle.
  1. If equipped with 4WD perfrom the following steps, position and install the fuel/EVAP line assembly to the vehicle.
  2. Install the fuel/EVAP line bracket locator tab to the frame.
  3. Install the fuel/EVAP line clips to the frame and crossmember.
  4. Install the fuel/EVAP line bracket bolt (1). Tighten Tighten the bolt to 9 N.m (80 lb in).
  5. Install the fuel/EVAP line clip nut (2). Tighten Tighten the bolt to 20 N.m (15 lb ft).
  6. Remove the caps from the fuel and EVAP lines.
  7. Connect the fuel tank EVAP line quick connect fitting to the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  8. Connect the fuel tank fuel feed line quick connect fitting to the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  9. If equipped with 2WD perfrom the following steps, position and install the fuel/EVAP line assembly to the vehicle.
  10. Install the fuel/EVAP line bracket locator tab to the frame.
  11. Install the fuel/EVAP line clips to the frame and crossmember.
  12. Install the fuel/EVAP line bracket bolt (2). Tighten Tighten the bolt to 9 N.m (80 lb in).
  13. Install the fuel/EVAP line clip nut (1). Tighten Tighten the bolt to 20 N.m (15 lb ft).
  14. Remove the caps from the fuel and EVAP lines.
  15. Connect the fuel tank EVAP line quick connect fitting to the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  16. Connect the fuel tank fuel feed line quick connect fitting to the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  17. Unsecure and position the EVAP canister vent solenoid clip (1) to the chassis EVAP line.
  18. Install the EVAP canister vent solenoid pipe clip (2) from the chassis EVAP line.
  19. If equipped with 4WD, install the fuel hose/pipe clip to the bracket on the transfer case.
  20. Install the fuel line clip to the bracket on the automatic transmission.
  21. Install the fuel pipe bracket nut to the bellhousing stud. Tighten Tighten the nut to 25 N.m (18 lb ft).
  22. Position and install the front propeller shaft, if required. Refer to «Front Propeller Shaft Replacement»(/gmc/sierra-2500/2012-2012/remont/driveshaft-universal-joints/#propeller-shaft-and-universal-joints__front-propeller-shaft-replacement) .
  23. Lower the vehicle.
  24. Remove the caps from the fuel rail and EVAP line.
  25. Connect the EVAP line (1) quick connect fitting to the chassis EVAP line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  26. Connect the fuel feed line (2) quick connect fitting to the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__metal-collar-quick-connect-fitting-service) .
  27. Install the fuel fill cap.
  28. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection (TP2)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) , «Battery Negative Cable Disconnection and Connection (Single Battery)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  29. Use the following procedure in order to inspect for leaks: Turn the ignition ON, with the engine OFF, for 2 seconds. Turn the ignition OFF for 10 seconds. Turn the ignition ON, with the engine OFF. Inspect for fuel leaks.
  30. Install the intake manifold sight shield. Refer to «Upper Intake Manifold Sight Shield Replacement»(/gmc/sierra-2500/2012-2012/remont/mechanical/#engine-mechanical-48l-53l-60l-62l-repair-instructions-on-vehicle) .
  1. Raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Disconnect the chassis wiring harness electrical connector (1) from the fuel pressure sensor.
  3. Wrap a shop towel around the fuel pressure sensor fitting in order to absorb any fuel that may leak out.
  4. Remove the fuel pressure sensor from the fuel line.
  5. Remove and discard the fuel pressure sensor O-ring seal.
  1. Lubricate a NEW fuel pressure sensor O-ring seal with clean engine oil.
  2. Install the NEW fuel pressure sensor O-ring seal onto the fuel line fitting.
  3. Wrap a shop towel around the fuel pressure sensor fitting in order to absorb any fuel that may leak out.
  4. Install the fuel pressure sensor to the fuel line. Tighten Tighten the sensor to 15 N.m (11 lb ft).
  5. Connect the chassis wiring harness electrical connector (1) to the fuel pressure sensor.
  6. Lower the vehicle.
  7. Use the following procedure in order to inspect for leaks: Turn the ignition ON, with the engine OFF, for 2 seconds. Turn the ignition OFF for 10 seconds. Turn the ignition ON, with the engine OFF. Inspect for fuel leaks.

Fuel System Cleaning

IMPORTANTOnly use oil free compressed air to blow out the fuel pipes.
  1. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection (TP2)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) , «Battery Negative Cable Disconnection and Connection (Single Battery)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  2. Remove the fuel tank module. Refer to «Fuel Tank Fuel Pump Module Replacement (15 Reg Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) , «Fuel Tank Fuel Pump Module Replacement (25/35 Series)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) , «Fuel Tank Fuel Pump Module Replacement (15 Ext/Crew Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) , «Fuel Tank Fuel Pump Module Replacement (15 Reg/Ext/Crew Cab w/34 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  3. Inspect the fuel tank module strainer, if equipped. If the strainer is contaminated replace the fuel tank module.
  4. Inspect the fuel tank module inlet for dirt and debris. Replace the fuel tank module if you find dirt or debris in the fuel pump inlet.
  5. Flush the fuel tank with hot water.
  6. Pour the water out of the fuel module opening. Rock the tank to be sure that removal of the water from the tank is complete.
  7. Remove the fuel rail. Refer to «Fuel Injection Fuel Rail Assembly Replacement»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  8. Drain the fuel from the fuel rail. It will be necessary to remove the fuel injectors from the fuel rail to properly clear all debris from the fuel rail and fuel injectors. Refer to «Fuel Injector Replacement»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  9. Use light shop air to remove any debris from the fuel rail and injectors.
  10. Use light shop air in the opposite direction of the fuel flow in order to remove any debris from the fuel lines. Catch any fuel from the fuel lines with an approved gasoline container.
  11. Install the fuel injectors to the fuel rail. Refer to «Fuel Injector Replacement»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  12. Install the fuel rail. Refer to «Fuel Injection Fuel Rail Assembly Replacement»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  13. Install the fuel tank module. Refer to «Fuel Tank Fuel Pump Module Replacement (15 Reg Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) , «Fuel Tank Fuel Pump Module Replacement (25/35 Series)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) , «Fuel Tank Fuel Pump Module Replacement (15 Ext/Crew Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) , «Fuel Tank Fuel Pump Module Replacement (15 Reg/Ext/Crew Cab w/34 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-tank-fuel-pump-module-replacement) .
  14. Refill the fuel tank.
  15. Install the fuel fill cap.
  16. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection (TP2)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) , «Battery Negative Cable Disconnection and Connection (Single Battery)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  17. Purge the fuel tank module. Disconnect the fuel feed line quick connect fitting from the fuel tank to the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) . Connect a length of hose to the fuel feed pipe. Insert the other end of the hose into an empty 3.8 liter (1 gallon) approved gasoline container. Add 23 liters (6 gallons) of clean fuel into the fuel tank. Turn on the fuel pump using the scan tool until 2 liters (1/2 gallon) of fuel flows into the fuel container.
  18. Inspect for leaks. Turn the ignition switch ON for 2 seconds. Turn the ignition switch OFF for 10 seconds. Turn the ignition switch ON. Inspect for fuel leaks.

Note. An 8-digit identification number is located on the fuel rail. Refer to this identification number when servicing or when part replacement is required.

  1. Remove the air cleaner outlet duct. Refer to «Air Cleaner Resonator Outlet Duct Replacement»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (Without CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-without-ch-48027) , «Fuel Pressure Relief (CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-ch-48027) .
  3. Remove the engine wiring harness bracket nut (1).
  4. Disconnect the engine wiring harness electrical connector (2) from the evaporative emission (EVAP) purge solenoid.
  5. Disconnect the engine wiring harness electrical connector (3) from the generator.
  6. Disconnect the engine wiring harness electrical connector (4) from the manifold absolute pressure (MAP) sensor.
  7. Remove the connector position assurance (CPA) retainer (2).
  8. Disconnect the engine wiring harness electrical connector (1) from the ignition coil main electrical connector.
  9. Disconnect the engine wiring harness electrical connectors (3) from the fuel injectors, perform the following: Mark the connectors to their corresponding injectors to ensure correct reassembly. Pull the CPA retainer on the connector up 1 click. Push the tab on the connector in. Disconnect the fuel injector electrical connector.
  10. Remove the CPA retainer (2).
  11. Disconnect the engine wiring harness electrical connector (1) from the ignition coil main electrical connector.
  12. Disconnect the engine wiring harness electrical connector (3) from the electronic throttle control.
  13. Disconnect the engine wiring harness electrical connectors (7) from the fuel injectors, perform the following: Mark the connectors to their corresponding injectors to ensure correct reassembly. Pull the CPA retainer on the connector up 1 click. Push the tab on the connector in. Disconnect the fuel injector electrical connector.
  14. Remove the engine wiring harness clip (4) from the generator battery jumper cable.
  15. Remove the engine wiring harness clip (6) from the ignition coil bracket stud.
  16. Remove the negative battery cable stud (1) from the right cylinder head.
  17. Remove the negative battery cable terminal (2) and engine wiring harness ground terminal (3) from the cylinder head.
  18. Remove the engine wiring harness clip bolt (3) from the generator bracket.
  19. Gather the branches of the engine wiring harness and reposition the aside.
  20. Remove the positive crankcase ventilation (PCV) hose.
  21. Disconnect the chassis fuel feed pipe (2) quick connect fitting from the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__metal-collar-quick-connect-fitting-service) .
  22. Disconnect the EVAP tube quick connect fitting at the intake manifold. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  23. Disconnect the chassis EVAP tube quick connect fitting at the EVAP canister purge solenoid. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  24. Disengage the retainer securing the EVAP canister purge solenoid to the fuel rail.
  25. Remove the EVAP tube and purge solenoid.
  26. Remove the fuel rail bolts.
  27. Remove the fuel rail assembly.
  28. Remove the fuel injector retainers (1).
  29. Remove the fuel injectors (3) from the fuel rail.
  30. Remove and discard the fuel injector upper and lower O-ring seals (2 and 4).
  1. Lubricate the NEW fuel injector O-ring seals with clean engine oil.
  2. Install the NEW fuel injector upper and lower O-ring seals (2 and 4) onto the injectors.
  3. Install the fuel injectors (3) into the fuel rails.
  4. Install the fuel injector retainers (1).
  5. Ensure the fuel injector lower O-ring seals are adequately lubricated, if not lubricate the fuel injector lower O-ring seals with clean engine oil.
  6. Position the fuel rail onto the intake manifold.
  7. Firmly push down on both the centers of the left and right fuel rails, until the rails are fully seated against the intake manifold.
  8. Install the fuel rail bolts. Tighten Tighten the bolts to 10 N.m (89 lb in).
  9. Install the EVAP tube and purge solenoid.
  10. Install the EVAP canister purge solenoid to the fuel rail bracket and engage the retainer.
  11. Connect the chassis EVAP tube quick connect fitting at the EVAP canister purge solenoid. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  12. Connect the EVAP tube quick connect fitting at the intake manifold. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  13. Connect the chassis fuel feed pipe (2) quick connect fitting to the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__metal-collar-quick-connect-fitting-service) .
  14. Install the PCV hose.
  15. Gather the branches of the engine wiring harness and position over the top of the engine.
  16. Position the engine wiring harness clip to the generator bracket and install the clip bolt (3). Tighten Tighten the bolt to 9 N.m (80 lb in).
  17. Position the negative battery cable terminal (2) and engine wiring harness ground terminal (3) to the right cylinder head.
  18. Install the negative battery cable stud (1) to the cylinder head. Tighten Tighten the stud to 25 N.m (18 lb ft).
  19. Connect the engine wiring harness electrical connector (1) to the ignition coil main electrical connector.
  20. Install the CPA retainer (2).
  21. Connect the engine wiring harness electrical connector (3) to the electronic throttle control.
  22. Connect the engine wiring harness electrical connectors (7) to the fuel injectors, perform the following: Ensure that the CPA retainer is pulled out 1 click. Connect the electrical connectors to their corresponding injectors. Push the CPA retainer in 1 click. Ensure that the connector is secured.
  23. Install the engine wiring harness clip (4) to the generator battery jumper cable.
  24. Install the engine wiring harness clip (6) to the ignition coil bracket stud.
  25. Connect the engine wiring harness electrical connector (1) to the ignition coil main electrical connector.
  26. Install the CPA retainer (2).
  27. Connect the engine wiring harness electrical connectors (3) to the fuel injectors, perform the following: Ensure that the CPA retainer is pulled out 1 click. Connect the electrical connectors to their corresponding injectors. Push the CPA retainer in 1 click. Ensure that the connector is secured.
  28. Connect the engine wiring harness electrical connector (4) to the MAP sensor.
  29. Connect the engine wiring harness electrical connector (3) to the generator.
  30. Connect the engine wiring harness electrical connector (2) to the EVAP purge solenoid.
  31. Install the engine wiring harness bracket nut (1). Tighten Tighten the nut to 5 N.m (44 lb in).
  32. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection (TP2)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) , «Battery Negative Cable Disconnection and Connection (Single Battery)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  33. Use the following procedure in order to inspect for leaks: Turn the ignition ON, with the engine OFF for 2 seconds. Turn the ignition OFF for 10 seconds. Turn the ignition ON, with the engine OFF. Inspect for leaks.
  34. Install the air cleaner outlet duct. Refer to «Air Cleaner Resonator Outlet Duct Replacement»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
CAUTIONUse care in removing the fuel injectors in order to prevent damage to the fuel injector electrical connector pins or the fuel injector nozzles. Do not immerse the fuel injector in any type of cleaner. The fuel injector is an electrical component and may be damaged by this cleaning method.

Note. An 8-digit identification number is located on the fuel rail. Refer to this identification number when servicing or when part replacement is required. The engine oil may be contaminated with fuel if the fuel injectors are leaking.

  1. Remove the air cleaner outlet duct. Refer to «Air Cleaner Resonator Outlet Duct Replacement»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief (Without CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-without-ch-48027) , «Fuel Pressure Relief (CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-ch-48027) .
  3. Remove the engine wiring harness bracket nut (1).
  4. Disconnect the engine wiring harness electrical connector (2) from the evaporative emission (EVAP) purge solenoid.
  5. Disconnect the engine wiring harness electrical connector (3) from the generator.
  6. Disconnect the engine wiring harness electrical connector (4) from the manifold absolute pressure (MAP) sensor.
  7. Remove the connector position assurance (CPA) retainer (2).
  8. Disconnect the engine wiring harness electrical connector (1) from the ignition coil main electrical connector.
  9. Disconnect the engine wiring harness electrical connectors (3) from the fuel injectors, perform the following: Mark the connectors to their corresponding injectors to ensure correct reassembly. Pull the CPA retainer on the connector up 1 click. Push the tab on the connector in. Disconnect the fuel injector electrical connector.
  10. Remove the CPA retainer (2).
  11. Disconnect the engine wiring harness electrical connector (1) from the ignition coil main electrical connector.
  12. Disconnect the engine wiring harness electrical connector (3) from the electronic throttle control.
  13. Disconnect the engine wiring harness electrical connectors (7) from the fuel injectors, perform the following: Mark the connectors to their corresponding injectors to ensure correct reassembly. Pull the CPA retainer on the connector up 1 click. Push the tab on the connector in. Disconnect the fuel injector electrical connector.
  14. Remove the engine wiring harness clip (4) from the generator battery jumper cable.
  15. Remove the engine wiring harness clip (6) from the ignition coil bracket stud.
  16. Remove the negative battery cable stud (1) from the right cylinder head.
  17. Remove the negative battery cable terminal (2) and engine wiring harness ground terminal (3) from the cylinder head.
  18. Remove the engine wiring harness clip bolt (3) from the generator bracket.
  19. Gather the branches of the engine wiring harness and reposition the aside.
  20. Remove the positive crankcase ventilation (PCV) hose.
  21. Disconnect the chassis fuel feed pipe (2) quick connect fitting from the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__metal-collar-quick-connect-fitting-service) .
  22. Disconnect the EVAP tube quick connect fitting at the intake manifold. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  23. Disconnect the chassis EVAP tube quick connect fitting at the EVAP canister purge solenoid. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  24. Disengage the retainer securing the EVAP canister purge solenoid to the fuel rail.
  25. Remove the EVAP tube and purge solenoid.
  26. Remove the fuel rail bolts.
  27. Remove the fuel rail assembly.
  28. Remove the fuel injector retainers (1).
  29. Remove the fuel injectors (3) from the fuel rail.
  30. Remove and discard the fuel injector upper and lower O-ring seals (2 and 4).
  1. Lubricate the NEW fuel injector O-ring seals with clean engine oil.
  2. Install the NEW fuel injector upper and lower O-ring seals (2 and 4) onto the injectors.
  3. Install the fuel injectors (3) into the fuel rails.
  4. Install the fuel injector retainers (1).
  5. Ensure the fuel injector lower O-ring seals are adequately lubricated, if not lubricate the fuel injector lower O-ring seals with clean engine oil.
  6. Position the fuel rail onto the intake manifold.
  7. Firmly push down on both the centers of the left and right fuel rails, until the rails are fully seated against the intake manifold.
  8. Install the fuel rail bolts. Tighten Tighten the bolts to 10 N.m (89 lb in).
  9. Install the EVAP tube and purge solenoid.
  10. Install the EVAP canister purge solenoid to the fuel rail bracket and engage the retainer.
  11. Connect the chassis EVAP tube quick connect fitting at the EVAP canister purge solenoid. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  12. Connect the EVAP tube quick connect fitting at the intake manifold. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  13. Connect the chassis fuel feed pipe (2) quick connect fitting to the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__metal-collar-quick-connect-fitting-service) .
  14. Install the PCV hose.
  15. Gather the branches of the engine wiring harness and position over the top of the engine.
  16. Position the engine wiring harness clip to the generator bracket and install the clip bolt (3). Tighten Tighten the bolts to 9 N.m (80 lb in).
  17. Position the negative battery cable terminal (2) and engine wiring harness ground terminal (3) to the right cylinder head.
  18. Install the negative battery cable stud (1) to the cylinder head. Tighten Tighten the stud to 25 N.m (18 lb ft).
  19. Connect the engine wiring harness electrical connector (1) to the ignition coil main electrical connector.
  20. Install the CPA retainer (2).
  21. Connect the engine wiring harness electrical connector (3) to the electronic throttle control.
  22. Connect the engine wiring harness electrical connectors (7) to the fuel injectors, perform the following: Ensure that the CPA retainer is pulled out 1 click. Connect the electrical connectors to their corresponding injectors. Push the CPA retainer in 1 click. Ensure that the connector is secured.
  23. Install the engine wiring harness clip (4) to the generator battery jumper cable.
  24. Install the engine wiring harness clip (6) to the ignition coil bracket stud.
  25. Connect the engine wiring harness electrical connector (1) to the ignition coil main electrical connector.
  26. Install the CPA retainer (2).
  27. Connect the engine wiring harness electrical connectors (3) to the fuel injectors, perform the following: Ensure that the CPA retainer is pulled out 1 click. Connect the electrical connectors to their corresponding injectors. Push the CPA retainer in 1 click. Ensure that the connector is secured.
  28. Connect the engine wiring harness electrical connector (4) to the MAP sensor.
  29. Connect the engine wiring harness electrical connector (3) to the generator.
  30. Connect the engine wiring harness electrical connector (2) to the EVAP purge solenoid.
  31. Install the engine wiring harness bracket nut (1). Tighten Tighten the nut to 5 N.m (44 lb in).
  32. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection (TP2)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) , «Battery Negative Cable Disconnection and Connection (Single Battery)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  33. Use the following procedure in order to inspect for leaks: Turn the ignition ON, with the engine OFF for 2 seconds. Turn the ignition OFF for 10 seconds. Turn the ignition ON, with the engine OFF. Inspect for leaks.
  34. Install the air cleaner outlet duct. Refer to «Air Cleaner Resonator Outlet Duct Replacement»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .

Fuel Injector Cleaning

Special Tools

  1. J 35800-A Fuel Injector Cleaner
  2. J 37287 Fuel Line Shut-Off Adapters
  3. J 42873-1 3/8 Fuel Line Shut-Off Valve
  4. J 42873-2 5/16 Return Pipe Shut-Off Valve
  5. J 42964-1 3/8 Fuel Pipe Shut-Off Valve
  6. J 42964-2 5/16 Fuel Pipe Shut-Off Valve
CAUTIONGM Upper Engine and Fuel Injector Cleaner is the only injector cleaning agent recommended. DO NOT USE OTHER CLEANING AGENTS AS THEY MAY CONTAIN METHANOL, WHICH CAN DAMAGE FUEL SYSTEM COMPONENTS. Under NO circumstances should the GM Upper Engine and Fuel Injector Cleaner be added to the vehicle fuel tank, as it may damage the fuel pump and other system components. Do not exceed the recommended cleaning solution concentration. Higher concentrations may damage fuel system components. Testing has demonstrated that exceeding the recommended cleaning solution concentration does not improve the effectiveness of this procedure.

Note. Vehicles with less than 160 km (100 mi) on the odometer should not have the injectors cleaned. These vehicles should have the injectors replaced.

  1. Obtain J 35800-A fuel injector cleaner (2).
  2. For 4, 5, and 6 cylinder engines, empty two of the 30 ml (1 oz.) reservoirs of the GM Upper Engine and Fuel Injector Cleaner twin reservoir container into the J 35800-A fuel injector cleaner, injector cleaning tank, then add 420 ml (14 oz.) of regular unleaded gasoline. If you are using any other brand of cleaning tank, you will need a total of 60 ml (2 oz.) of GM Upper Engine and Fuel Injector Cleaner mixed with 420 ml (14 oz.) of regular unleaded gasoline.
  3. For 8 cylinder engines, empty two of the 30 ml (1 oz.) reservoirs of the GM Upper Engine and Fuel Injector Cleaner twin reservoir container into the J 35800-A fuel injector cleaner, injector cleaning tank, then add 420 ml (14 oz.) of regular unleaded gasoline. If you are using any other brand of cleaning tank, you will need a total of 60 ml (2 oz.) of GM Upper Engine and Fuel Injector Cleaner mixed with 420 ml (14 oz.) of regular unleaded gasoline. This procedure will need to be repeated for an 8 cylinder engine. The 8 cylinder engines receive 960 ml total fluid-120 ml (4 oz.) of GM Upper Engine and Fuel Injector Cleaner and 840 ml (28 oz.) of gasoline.
  4. Fill the injector cleaning tank with regular unleaded gasoline. Be sure to follow all additional instructions provided with the tool.
  5. Electrically disable the vehicle fuel pump by removing the fuel pump relay and disconnecting the oil pressure switch connector, if equipped.
  6. Disconnect the fuel feed and return line, if equipped, at the fuel rail. Plug the fuel feed and return line, if equipped, coming off the fuel rail with J 37287 fuel line shut-off adapters, or J 42964-1 3/8 fuel pipe shut-off valve, and J 42964-2 5/16 fuel pipe shut-off valve or J 42873-1 3/8 fuel line shut-off valve, and J 42873-2 5/16 return pipe shut-off valve as appropriate for the fuel system.
  7. Connect the J 35800-A fuel injector cleaner to the vehicle fuel rail.
  8. Pressurize the J 35800-A fuel injector cleaner to 510 kPa (75 psi).
  9. Start and idle the engine until it stalls due to lack of fuel. This should take approximately 15-20 minutes.
  10. Turn the ignition to the OFF position.
  11. Injectors should be flow-tested at this point. If further cleaning is needed, a repeat of the above procedure should be done. When the injector restriction returns to zero, proceed to step 12.
  12. Disconnect the J 35800-A fuel injector cleaner from the fuel rail.
  13. Reconnect the vehicle fuel pump relay and oil pressure switch connector, if equipped.
  14. Remove the J 37287 fuel line shut-off adapters, or J 42964-1 3/8 fuel pipe shut-off valve and J 42964-2 5/16 fuel pipe shut-off valve, or J 42873-1 3/8 fuel line shut-off valve J 42873-1 3/8 fuel line shut-off valve and reconnect the vehicle fuel feed and return lines.
  15. Start and idle the vehicle for an additional two minutes to ensure residual injector cleaner is flushed from the fuel rail and fuel lines.
  16. Pour the entire contents of GM Fuel System Treatment Plus, GM P/N 88861011 (Canadian P/N 88861012) into a nearly empty tank and advise the customer to refuel with up to 76 L (20 gal) of fuel.
  17. Advise the customer to use only a Top Tier Detergent gasoline and to add a bottle of GM Fuel System Treatment Plus to the fuel tank at every oil change. Regular use of GM Fuel System Treatment Plus should keep the customer from having to repeat the injector cleaning procedure.
  18. Road test the vehicle to verify that the customer concern has been corrected.
IMPORTANTClean all evaporative emission (EVAP) line connections and surrounding areas prior to disconnecting, in order to avoid possible EVAP system contamination.
  1. Remove the air cleaner outlet duct. Refer to «Air Cleaner Resonator Outlet Duct Replacement»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Disconnect the EVAP line quick connect fitting from the EVAP canister purge solenoid. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Disconnect the engine wiring harness electrical connector (2) from the EVAP canister purge solenoid.
  4. Disconnect the chassis EVAP line quick connect fitting from the EVAP canister purge solenoid. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  5. Disengage the retainer securing the EVAP canister purge solenoid to the fuel rail.
  6. Remove the EVAP canister purge solenoid.
  1. Install the EVAP canister purge solenoid.
  2. Install the EVAP canister purge solenoid to the fuel rail and engage the retainer.
  3. Connect the engine wiring harness electrical connector (2) to the EVAP canister purge solenoid.
  4. Connect the chassis EVAP line quick connect fitting to the EVAP canister purge solenoid. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  5. Connect the EVAP line quick connect fitting to the EVAP canister purge solenoid. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  6. Install the air cleaner outlet duct. Refer to «Air Cleaner Resonator Outlet Duct Replacement»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .

Note. Clean the evaporative emission (EVAP) connections and surrounding areas prior to disconnecting the fittings in order to avoid possible system contamination.

  1. Lift and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Disconnect the solenoid vent filter (1) from the fill pocket by squeezing the base of the solenoid vent filter to release the tabs.
  3. Remove the tie strap (1) that holds the solenoid vent line to the fuel fill pipe.
  4. Remove the 2 EVAP canister vent solenoid pipe clips (1) from the brake pipes.
  5. Disconnect the chassis wiring harness electrical connector from the EVAP canister vent solenoid.
  6. Disconnect the EVAP vent solenoid pipe quick connect fitting (1) from the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  7. Insert a small flat bladed tool between the EVAP canister vent solenoid and the fuel tank bracket, disengaging the retainer (1).
  8. Slide the EVAP canister vent solenoid (2) off the bracket towards the front of the vehicle.
  9. Remove the EVAP canister vent solenoid assembly (2) from the vehicle.
  1. Position and install the EVAP canister vent solenoid assembly (2) to the vehicle.
  2. Slide the EVAP canister vent solenoid (2) onto the bracket towards the rear of the vehicle.
  3. Ensure that the EVAP canister vent solenoid engages the fuel tank bracket retainer (1).
  4. Connect the EVAP vent solenoid pipe quick connect fitting (1) to the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  5. Connect the chassis wiring harness electrical connector to the EVAP canister vent solenoid.
  6. Install the 3 EVAP canister vent solenoid clips (1) to the brake pipes.
  7. Install the tie strap (1) that holds the solenoid vent line to the fuel fill pipe.
  8. Connect the solenoid vent filter (1) to the fill pocket by pressing the solenoid vent filter into the fill pocket slots to engage the locking tabs.
  9. Lower the vehicle.

Note. Clean the evaporative emission (EVAP) connections and surrounding areas prior to disconnecting the fittings in order to avoid possible system contamination.

  1. Lift and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Disconnect the solenoid vent filter (1) from the fill pocket by squeezing the base of the solenoid vent filter to release the tabs.
  3. Remove the tie strap (1) that holds the solenoid vent line to the fuel fill pipe.
  4. Disengage the clip (1) from the EVAP solenoid purge hose.
  5. Disconnect the chassis wiring harness electrical connector from the EVAP canister vent solenoid.
  6. Disconnect the EVAP vent solenoid pipe quick connect fitting (1) from the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  7. Push on the retaining tab (1) to release the EVAP canister vent solenoid (2).
  8. Slide the EVAP canister vent solenoid (2) off the bracket towards the passenger side of the vehicle.
  9. Position and secure the EVAP canister vent solenoid out of the way.
  10. Lower the fuel tank half way. Refer to «Fuel Tank Replacement (15 Reg/Ext Cab w/34 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) , «Fuel Tank Replacement (Cab/Chassis - Rear)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) , «Fuel Tank Replacement (Cab/Chassis - Front)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) , «Fuel Tank Replacement (15 Ext/Crew Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) , «Fuel Tank Replacement (15 Rec Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) , «Fuel Tank Replacement (25/35 Series)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  11. Remove the EVAP canister solenoid vent hose from the brake pipe clips (1).
  12. Remove the EVAP canister vent solenoid assembly from the vehicle.
  1. Position and install the EVAP canister vent solenoid to the vehicle.
  2. Install the EVAP canister solenoid vent hose from the brake pipe clips (1).
  3. Position and secure the EVAP canister vent solenoid out of the way.
  4. Reinstall the fuel tank. Refer to «Fuel Tank Replacement (15 Reg/Ext Cab w/34 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) , «Fuel Tank Replacement (Cab/Chassis - Rear)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) , «Fuel Tank Replacement (Cab/Chassis - Front)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) , «Fuel Tank Replacement (15 Ext/Crew Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) , «Fuel Tank Replacement (15 Rec Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) , «Fuel Tank Replacement (25/35 Series)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  5. Slide the EVAP canister vent solenoid (2) onto the bracket towards the drivers side of the vehicle.
  6. Ensure that the EVAP canister vent solenoid (2) engages the fuel tank bracket retainer (1).
  7. Connect the EVAP vent solenoid pipe quick connect fitting (1) to the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  8. Connect the chassis wiring harness electrical connector to the EVAP canister vent solenoid.
  9. Install the clip (1) to the EVAP solenoid purge hose.
  10. Install the tie strap (2) that holds the solenoid vent line to the fuel fill pipe.
  11. Connect the solenoid vent filter to the fill pocket by pressing the solenoid filter (1) into the fill pocket slots to engage the locking tabs.
  12. Lower the vehicle.
IMPORTANTClean all fuel and evaporative emission (EVAP) line connections and surrounding areas prior to disconnecting the lines in order to avoid possible fuel and/or EVAP system contamination.
  1. Remove the fuel tank. Refer to «Fuel Tank Replacement (15 Reg Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Remove the EVAP canister purge pipe from the fuel tank clip (1).
  3. Disconnect the EVAP rear pipe quick connect fittings from the rollover valve and the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  4. Remove the EVAP rear pipe from the fuel tank clips (1 and 2).
  5. Disconnect the small EVAP rear pipe quick connect fittings from the rollover valve and the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  1. Position and connect the small EVAP rear pipe quick connect fittings to the rollover valve and the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Position and connect the EVAP rear pipe quick connect fittings to the rollover valve and the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Install the EVAP rear pipe to the fuel tank clips (1 and 2).
  4. Install the EVAP canister purge pipe to the fuel tank clip (1).
  5. Install the fuel tank. Refer to «Fuel Tank Replacement (15 Rec Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
IMPORTANTClean all fuel and evaporative emission (EVAP) line connections and surrounding areas prior to disconnecting the lines in order to avoid possible fuel and/or EVAP system contamination.
  1. Remove the fuel tank. Refer to «Fuel Tank Replacement (15 Ext/Crew Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Disconnect the EVAP pipe quick connect fittings from the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Remove the EVAP pipe from the fuel tank clips (1).
  4. Disconnect the EVAP pipe quick connect fittings from the rollover valve and the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  5. Remove the EVAP pipe from the fuel tank clips (1 and 2).
  1. Position and connect the EVAP pipe quick connect fittings to the rollover valve and the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Install the EVAP pipe to the fuel tank clips (1 and 2).
  3. Position and connect the EVAP pipe quick connect fittings to the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  4. Install the EVAP pipe to the fuel tank clips (1).
  5. Remove the fuel tank. Refer to «Fuel Tank Replacement (15 Ext/Crew Cab With 26 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .

Note. Clean all fuel and evaporative emission (EVAP) line connections and surrounding areas prior to disconnecting the lines in order to avoid possible fuel and/or EVAP system contamination.

  1. Remove the fuel tank. Refer to «Fuel Tank Replacement (15 Reg/Ext Cab w/34 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Remove the EVAP pipe from the fuel tank clips (1).
  3. Disconnect the EVAP pipe quick connect fittings from the rollover valve and the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  4. Remove the EVAP pipe from the fuel tank clips (1).
  1. Position and connect the EVAP pipe quick connect fittings to the rollover valve and the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Install the EVAP pipe to the fuel tank clips (1).
  3. Install the EVAP pipe to the fuel tank clips (1).
  4. Install the fuel tank. Refer to «Fuel Tank Replacement (15 Reg/Ext Cab w/34 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
IMPORTANTClean all fuel and evaporative emission (EVAP) line connections and surrounding areas prior to disconnecting the lines in order to avoid possible fuel and/or EVAP system contamination.
  1. Remove the fuel tank. Refer to «Fuel Tank Replacement (25/35 Series)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Disconnect the EVAP canister purge pipe (1) from fuel tank fuel pump module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Detach the EVAP canister purge pipe (1) from the fuel tank retainer.
  4. Disconnect the small EVAP rear pipe (2) quick connect fittings from the rollover valve and the fuel tank fuel pump module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  1. Position and connect the small EVAP rear pipe (2) quick connect fittings to the rollover valve and the fuel tank module. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Attach the EVAP canister purge pipe (1) to the fuel tank retainer.
  3. Install the EVAP canister purge pipe (1) to the fuel tank fuel pump module.
  4. Install the fuel tank. Refer to «Fuel Tank Replacement (25/35 Series)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
IMPORTANTClean all evaporative emission (EVAP) line connections and surrounding areas prior to disconnecting the fittings in order to avoid possible system contamination.
  1. Remove the upper intake manifold sight shield. Refer to «Upper Intake Manifold Sight Shield Replacement»(/gmc/sierra-2500/2012-2012/remont/mechanical/#engine-mechanical-48l-53l-60l-62l-repair-instructions-on-vehicle) .
  2. Disconnect the EVAP line quick connect fitting at the intake manifold. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Disconnect the EVAP line quick connect fitting at the EVAP canister purge solenoid. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  1. Connect the EVAP line quick connect fitting at the EVAP canister purge solenoid. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Connect the EVAP line quick connect fitting at the intake manifold. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Install the upper intake manifold sight shield. Refer to «Upper Intake Manifold Sight Shield Replacement»(/gmc/sierra-2500/2012-2012/remont/mechanical/#engine-mechanical-48l-53l-60l-62l-repair-instructions-on-vehicle) .
  1. Relieve the fuel system pressure. Refer to the «Fuel Pressure Relief (Without CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-without-ch-48027) , «Fuel Pressure Relief (CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-ch-48027) .
  2. Disconnect the engine evaporative emission (EVAP) line (1) quick connect fitting from the chassis EVAP line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Disconnect the fuel feed line quick connect fitting (2) from the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__metal-collar-quick-connect-fitting-service) .
  4. Cap the fuel rail and EVAP pipes.
  5. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  6. Unbolt and reposition the front propeller shaft, if required. Refer to «Front Propeller Shaft Replacement»(/gmc/sierra-2500/2012-2012/remont/driveshaft-universal-joints/#propeller-shaft-and-universal-joints__front-propeller-shaft-replacement) .
  7. Remove the fuel pipe bracket nut from the bellhousing stud.
  8. Remove the fuel line clip from the bracket on the automatic transmission.
  9. If equipped with 4-wheel drive (4WD), remove the fuel hose/pipe clip from the bracket on the transfer case.
  10. Remove the EVAP canister vent solenoid clip (1) from the chassis EVAP line and secure out of the way.
  11. Remove the EVAP canister vent solenoid pipe clip (2) from the chassis EVAP line.
  12. Disconnect the fuel tank EVAP line quick connect fitting from the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  13. Disconnect the fuel tank fuel feed line quick connect fitting from the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  14. Cap the fuel and EVAP lines in order to prevent possible fuel and/or EVAP system contamination.
  15. Remove the fuel line bracket bolt (1).
  16. Remove the fuel/EVAP line clip nut (2).
  17. Remove the fuel/EVAP line clips from the frame and crossmember.
  18. Remove the fuel/EVAP line assembly from the vehicle.
  1. Position and install the fuel/EVAP line assembly to the vehicle.
  2. Install the fuel/EVAP line bracket locator tab to the frame.
  3. Install the fuel/EVAP line clips to the frame and crossmember.
  4. Install the fuel/EVAP line bracket bolt (1). Tighten Tighten the bolt to 9 N.m (80 lb in).
  5. Install the fuel/EVAP line clip nut (2). Tighten Tighten the bolt to 20 N.m (15 lb ft).
  6. Remove the caps from the fuel and EVAP lines.
  7. Connect the fuel tank EVAP line quick connect fitting to the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  8. Connect the fuel tank fuel feed line quick connect fitting to the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  9. Unscure and position the EVAP canister vent solenoid clip (1) to the chassis EVAP line.
  10. Install the EVAP canister vent solenoid pipe clip (2) to the chassis EVAP line.
  11. If equipped with 4WD, install the fuel hose/pipe clip to the bracket on the transfer case.
  12. Install the fuel line clip to the bracket on the automatic transmission.
  13. Install the fuel pipe bracket nut to the bellhousing stud. Tighten Tighten the nut to 25 N.m (18 lb ft).
  14. Position and install the front propeller shaft, if required. Refer to «Front Propeller Shaft Replacement»(/gmc/sierra-2500/2012-2012/remont/driveshaft-universal-joints/#propeller-shaft-and-universal-joints__front-propeller-shaft-replacement) .
  15. Lower the vehicle.
  16. Remove the caps from the fuel rail and EVAP line.
  17. Connect the EVAP line (1) quick connect fitting to the chassis EVAP line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  18. Connect the fuel feed line (2) quick connect fitting to the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__metal-collar-quick-connect-fitting-service) .
  19. Install the fuel fill cap.
  20. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection (TP2)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) , «Battery Negative Cable Disconnection and Connection (Single Battery)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  21. Use the following procedure in order to inspect for leaks: Turn the ignition ON, with the engine OFF, for 2 seconds. Turn the ignition OFF for 10 seconds. Turn the ignition ON, with the engine OFF. Inspect for fuel leaks.
  22. Install the intake manifold sight shield. Refer to «Upper Intake Manifold Sight Shield Replacement»(/gmc/sierra-2500/2012-2012/remont/mechanical/#engine-mechanical-48l-53l-60l-62l-repair-instructions-on-vehicle) .
  1. Relieve the fuel system pressure. Refer to the «Fuel Pressure Relief (Without CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-without-ch-48027) , «Fuel Pressure Relief (CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-ch-48027) .
  2. Disconnect the engine evaporative emission (EVAP) line (1) quick connect fitting from the chassis EVAP line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Disconnect the fuel feed line quick connect fitting (2) from the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__metal-collar-quick-connect-fitting-service) .
  4. Cap the fuel rail and EVAP pipes.
  5. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  6. Unbolt and reposition the front propeller shaft, if required. Refer to «Front Propeller Shaft Replacement»(/gmc/sierra-2500/2012-2012/remont/driveshaft-universal-joints/#propeller-shaft-and-universal-joints__front-propeller-shaft-replacement) .
  7. Unbolt and reposition the brake pressure modulator valve (BPMV). Refer to «Brake Pressure Modulator Valve Replacement»(/gmc/sierra-2500/2012-2012/remont/anti-locktraction-control/#antilock-brake-system-non-hybrid-less-than-3900-kg-8600-lb-gvw) .
  8. Remove the fuel pipe bracket nut from the bellhousing stud.
  9. Remove the fuel line clip (1) from the bracket on the automatic transmission.
  10. If equipped with 4-wheel drive (4WD), remove the fuel hose/pipe clip from the bracket on the transfer case.
  11. Remove the EVAP canister vent solenoid clip (1) from the chassis EVAP line and secure out of the way.
  12. Remove the EVAP canister vent solenoid pipe clip (2) from the chassis line.
  13. Disconnect the fuel tank fuel feed line quick connect fitting from the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  14. Disconnect the chassis EVAP line quick connect fitting from the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  15. Cap the fuel and EVAP lines in order to prevent possible fuel and/or EVAP system contamination.
  16. Remove the fuel line bracket bolt (1).
  17. Remove the fuel/EVAP line clip nut (2).
  18. Remove the fuel/EVAP line clips from the frame and crossmember.
  19. Remove the fuel/EVAP line assembly from the vehicle.
  1. Position and install the fuel/EVAP line assembly to the vehicle.
  2. Install the fuel/EVAP line bracket locator tab to the frame.
  3. Install the fuel/EVAP line clips to the frame and crossmember.
  4. Install the fuel/EVAP line bracket bolt (1) and tighten to 9 N.m (80 lb in).
  5. Install the fuel/EVAP line clip nut (2). Tighten the bolt to 20 N.m (15 lb ft).
  6. Remove the caps from the fuel and EVAP lines.
  7. Connect the chassis EVAP line quick connect fitting to the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  8. Connect the fuel tank fuel feed line quick connect fitting to the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  9. Unsecure and position the EVAP canister vent solenoid clip (1) to the chassis EVAP line.
  10. Install the EVAP canister vent solenoid pipe clip (2) to the chassis line.
  11. If equipped with 4WD, install the fuel hose/pipe clip (1) to the bracket on the transfer case.
  12. Install the fuel line clip to the bracket on the automatic transmission.
  13. Install the fuel pipe bracket nut to the bellhousing stud. Tighten the nut to 25 N.m (18 lb ft).
  14. Position and install the BPMV. Refer to «Brake Pressure Modulator Valve Replacement»(/gmc/sierra-2500/2012-2012/remont/anti-locktraction-control/#antilock-brake-system-non-hybrid-less-than-3900-kg-8600-lb-gvw) .
  15. Position and install the front propeller shaft, if required. Refer to «Front Propeller Shaft Replacement»(/gmc/sierra-2500/2012-2012/remont/driveshaft-universal-joints/#propeller-shaft-and-universal-joints__front-propeller-shaft-replacement) .
  16. Lower the vehicle.
  17. Remove the caps from the fuel rail and EVAP line.
  18. Connect the EVAP line (1) quick connect fitting to the chassis EVAP line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  19. Connect the fuel feed line (2) quick connect fitting to the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__metal-collar-quick-connect-fitting-service) .
  20. Install the fuel fill cap.
  21. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection (TP2)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) , «Battery Negative Cable Disconnection and Connection (Single Battery)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  22. Use the following procedure in order to inspect for leaks: Turn the ignition ON, with the engine OFF, for 2 seconds. Turn the ignition OFF for 10 seconds. Turn the ignition ON, with the engine OFF. Inspect for fuel leaks.
  23. Install the intake manifold sight shield. Refer to «Upper Intake Manifold Sight Shield Replacement»(/gmc/sierra-2500/2012-2012/remont/mechanical/#engine-mechanical-48l-53l-60l-62l-repair-instructions-on-vehicle) .
  1. Relieve the fuel system pressure. Refer to the «Fuel Pressure Relief (Without CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-without-ch-48027) , «Fuel Pressure Relief (CH-48027)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__fuel-pressure-relief-ch-48027) .
  2. Disconnect the engine evaporative emission (EVAP) line (1) quick connect fitting from the chassis EVAP line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Disconnect the fuel feed line quick connect fitting (2) from the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__metal-collar-quick-connect-fitting-service) .
  4. Cap the fuel rail and EVAP pipes.
  5. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  6. Unbolt and reposition the front propeller shaft, if required. Refer to «Front Propeller Shaft Replacement»(/gmc/sierra-2500/2012-2012/remont/driveshaft-universal-joints/#propeller-shaft-and-universal-joints__front-propeller-shaft-replacement) .
  7. Remove the fuel pipe bracket nut from the bellhousing stud.
  8. Remove the fuel line clip from the bracket on the automatic transmission.
  9. If equipped with 4-wheel drive (4WD), remove the fuel hose/pipe clip from the bracket on the transfer case.
  10. Remove the EVAP canister vent solenoid clip (1) from the chassis EVAP line and secure out of the way.
  11. Remove the EVAP canister vent solenoid pipe clip (2) from the chassis EVAP line.
  12. If equipped with 2-wheel drive (2WD) perform the following steps, disconnect the fuel tank fuel feed line quick connect fitting from the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  13. Disconnect the fuel tank EVAP line quick connect fitting from the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  14. Cap the fuel and EVAP lines in order to prevent possible fuel and/or EVAP system contamination.
  15. Remove the fuel line bracket bolt (2).
  16. Remove the fuel/EVAP line clip nut (1).
  17. Remove the fuel/EVAP line clips from the frame and crossmember.
  18. Remove the fuel/EVAP line assembly from the vehicle.
  19. If equipped with 4WD perform the following steps, disconnect the fuel tank fuel feed line quick connect fitting from the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  20. Disconnect the fuel tank EVAP line quick connect fitting from the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  21. Cap the fuel and EVAP lines in order to prevent possible fuel and/or EVAP system contamination.
  22. Remove the fuel line bracket bolt (1).
  23. Remove the fuel/EVAP line clip nut (2).
  24. Remove the fuel/EVAP line clips from the frame and crossmember.
  25. Remove the fuel/EVAP line assembly from the vehicle.
  1. If equipped with 4WD perfrom the following steps, position and install the fuel/EVAP line assembly to the vehicle.
  2. Install the fuel/EVAP line bracket locator tab to the frame.
  3. Install the fuel/EVAP line clips to the frame and crossmember.
  4. Install the fuel/EVAP line bracket bolt (1). Tighten Tighten the bolt to 9 N.m (80 lb in).
  5. Install the fuel/EVAP line clip nut (2). Tighten Tighten the bolt to 20 N.m (15 lb ft).
  6. Remove the caps from the fuel and EVAP lines.
  7. Connect the fuel tank EVAP line quick connect fitting to the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  8. Connect the fuel tank fuel feed line quick connect fitting to the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  9. If equipped with 2WD perfrom the following steps, position and install the fuel/EVAP line assembly to the vehicle.
  10. Install the fuel/EVAP line bracket locator tab to the frame.
  11. Install the fuel/EVAP line clips to the frame and crossmember.
  12. Install the fuel/EVAP line bracket bolt (2). Tighten Tighten the bolt to 9 N.m (80 lb in).
  13. Install the fuel/EVAP line clip nut (1). Tighten Tighten the bolt to 20 N.m (15 lb ft).
  14. Remove the caps from the fuel and EVAP lines.
  15. Connect the fuel tank EVAP line quick connect fitting to the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  16. Connect the fuel tank fuel feed line quick connect fitting to the chassis line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  17. Unsecure and position the EVAP canister vent solenoid clip (1) to the chassis EVAP line.
  18. Install the EVAP canister vent solenoid pipe clip (2) from the chassis EVAP line.
  19. If equipped with 4WD, install the fuel hose/pipe clip to the bracket on the transfer case.
  20. Install the fuel line clip to the bracket on the automatic transmission.
  21. Install the fuel pipe bracket nut to the bellhousing stud. Tighten Tighten the nut to 25 N.m (18 lb ft).
  22. Position and install the front propeller shaft, if required. Refer to «Front Propeller Shaft Replacement»(/gmc/sierra-2500/2012-2012/remont/driveshaft-universal-joints/#propeller-shaft-and-universal-joints__front-propeller-shaft-replacement) .
  23. Lower the vehicle.
  24. Remove the caps from the fuel rail and EVAP line.
  25. Connect the EVAP line (1) quick connect fitting to the chassis EVAP line. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  26. Connect the fuel feed line (2) quick connect fitting to the fuel rail. Refer to «Metal Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__metal-collar-quick-connect-fitting-service) .
  27. Install the fuel fill cap.
  28. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection (TP2)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) , «Battery Negative Cable Disconnection and Connection (Single Battery)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  29. Use the following procedure in order to inspect for leaks: Turn the ignition ON, with the engine OFF, for 2 seconds. Turn the ignition OFF for 10 seconds. Turn the ignition ON, with the engine OFF. Inspect for fuel leaks.
  30. Install the intake manifold sight shield. Refer to «Upper Intake Manifold Sight Shield Replacement»(/gmc/sierra-2500/2012-2012/remont/mechanical/#engine-mechanical-48l-53l-60l-62l-repair-instructions-on-vehicle) .

Scheme 56

Scheme 56: Evaporative Emission Rear Hose Replacement (Front Tank)
Scheme 56: Evaporative Emission Rear Hose Replacement (Front Tank)

Evaporative Emission Rear Hose Replacement (Front Tank)

Scheme 57

Scheme 57: Evaporative Emission Rear Hose Replacement (Rear Tank)
Scheme 57: Evaporative Emission Rear Hose Replacement (Rear Tank)

Evaporative Emission Rear Hose Replacement (Rear Tank)

  1. Raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Disconnect the EVAP canister pipe quick connect fitting (2) from the fuel tank EVAP pipe. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Disconnect the EVAP canister vent solenoid pipe quick connect fitting (3) from the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  4. Disconnect the EVAP canister pipe quick connect fitting (4) from the fuel tank EVAP pipe. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  5. Remove the EVAP canister nut. (body shown removed, for clarity).
  6. Remove the EVAP canister assembly.
  7. If replacing the EVAP canister perform the following steps, otherwise proceed to step 4 in the installation procedure.
  8. Remove the EVAP canister from the shield.
  9. Disconnect the EVAP canister pipes from the canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  1. If replacing the EVAP canister perform the following steps, otherwise proceed to step 4.
  2. Connect the EVAP canister pipes to the canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Install the EVAP canister to the shield.
  4. Install the EVAP canister assembly.
  5. Install the EVAP canister nut. Tighten Tighten the nut to 25 N.m (18 lb ft).
  6. Connect the EVAP canister pipe quick connect fitting (4) to the fuel tank EVAP pipe. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  7. Connect the EVAP canister vent solenoid pipe quick connect fitting (3) to the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  8. Connect the EVAP canister pipe quick connect fitting (2) to the fuel tank EVAP pipe. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  9. Lower the vehicle.
  1. Raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Disconnect the fuel tank EVAP pipe quick connect fitting (3) from the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Disconnect the chassis EVAP pipe quick connect fitting (2) from the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  4. Disconnect the EVAP canister vent solenoid pipe quick connect fitting (3) from the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  5. Remove the EVAP canister nut (1). (body shown removed, for clarity).
  6. Remove the EVAP canister assembly.
  7. If replacing the EVAP canister perform the following steps, otherwise proceed to step 3 in the installation procedure.
  8. Remove the EVAP canister bracket from the canister.
  1. If replacing the EVAP canister perform the following steps, otherwise proceed to step 3.
  2. Install the EVAP canister bracket to the canister.
  3. Install the EVAP canister assembly.
  4. Install the EVAP canister nut (1). Tighten Tighten the nut to 25 N.m (18 lb ft).
  5. Connect the EVAP canister vent solenoid pipe quick connect fitting (3) to the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  6. Connect the chassis EVAP pipe quick connect fitting (2) to the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  7. Connect the fuel tank EVAP pipe quick connect fitting (3) to the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  8. Lower the vehicle.
  1. Raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Disconnect the EVAP canister pipe quick connect fitting (2) from the fuel tank EVAP pipe. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Disconnect the EVAP canister vent solenoid pipe quick connect fitting (3) from the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  4. Disconnect the EVAP canister pipe quick connect fitting (4) from the fuel tank EVAP pipe. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  5. Remove the EVAP canister nut. (Body shown removed, for clarity.)
  6. Remove the EVAP canister assembly.
  7. If replacing the EVAP canister perform the following steps, otherwise proceed to step 4 in the Installation Procedure.
  8. Remove the EVAP canister bracket from the canister.
  9. Disconnect the EVAP canister pipe quick connect fittings from the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  1. If replacing the EVAP canister perform the following steps, otherwise proceed to step 4.
  2. Install the EVAP canister bracket to the canister.
  3. Connect the EVAP canister pipe quick connect fittings to the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  4. Install the EVAP canister assembly.
  5. Install the EVAP canister nut and tighten to 25 N.m (18 lb ft).
  6. Connect the EVAP canister pipe quick connect fitting (4) to the fuel tank EVAP pipe. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  7. Connect the EVAP canister vent solenoid pipe quick connect fitting (3) to the EVAP canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  8. Connect the EVAP canister pipe quick connect fitting (2) to the fuel tank EVAP pipe. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  9. Lower the vehicle.

Scheme 58

Scheme 58: Evaporative Emission Canister Replacement (Cab Chassis)
Scheme 58: Evaporative Emission Canister Replacement (Cab Chassis)
CalloutComponent Name
Preliminary Procedure Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Disconnect the quick connect fittings. Refer to Plastic Collar Quick Connect Fitting Service .
1Evaporative Emission Canister Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 40 N.m (30 lb ft)
2Evaporative Emission Canister Bracket (Qty: 2) Procedure Reuse the existing canister brackets.
3Evaporative Emission Canister
CAUTION
Refer to Fastener Caution .

Evaporative Emission Canister Replacement (Cab Chassis)

  1. Raise and suitably support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Disconnect the fuel tank evaporative emission pipe (2) from the evaporative emission canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Disconnect the EVAP canister vent solenoid pipe (3) from the evaporative emission canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  4. Disconnect the EVAP canister purge pipe (1) from the evaporative emission canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  5. Remove the evaporative emission canister fastener (2) and retainer (2).
  6. Remove the evaporative emission canister (3). Note the retaining features on the back of the evaporative emission canister bracket.
  1. Install the evaporative emission canister (3) Into the retaining feature in the evaporative emission canister bracket.
  2. Attach the evaporative emission canister retainer (1) and fastener (2) and tighten to 25 (18 lb ft).
  3. Connect the EVAP canister purge pipe (1) to the evaporative emission canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  4. Connect the EVAP canister vent solenoid pipe (3) to the evaporative emission canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  5. Connect the fuel tank evaporative emission pipe (2) to the evaporative emission canister. Refer to «Plastic Collar Quick Connect Fitting Service»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  6. Lower the vehicle.

Evaporative Emission System Cleaning

Tools Required

J 41413-200 Evaporative Emissions System Tester (EEST)

Inspection Procedure

IMPORTANTDo not perform this procedure unless instructed by an evaporative emission (EVAP) diagnostic.
  1. Turn OFF the ignition.
  2. Remove the EVAP canister purge solenoid valve. Refer to «Evaporative Emission Canister Purge Solenoid Valve Replacement»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  3. Lightly tap the EVAP canister purge solenoid valve on a clean hard surface.
  4. Inspect for carbon particles exiting either of the vacuum ports. If no carbon particles are found reinstall the EVAP canister purge solenoid valve and continue with the EVAP cleaning procedure. Refer to «Evaporative Emission Canister Purge Solenoid Valve Replacement»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) . If carbon particles are found during the inspection procedure, replace the EVAP canister purge solenoid valve and continue with the EVAP cleaning procedure. Refer to «Evaporative Emission Canister Purge Solenoid Valve Replacement»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) . If you were instructed to replace the EVAP canister purge solenoid valve, and no carbon particles are found, return to the EVAP diagnostic procedure. Do not perform the EVAP cleaning procedure.

EVAP Cleaning Procedure

  1. Remove the EVAP canister. Refer to «Evaporative Emission Canister Replacement (15 Ext/Crew Cab)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) , «Evaporative Emission Canister Replacement (15 Reg/Exe Cab w/34 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) , «Evaporative Emission Canister Replacement (15 Regular Cab)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) , «Evaporative Emission Canister Replacement (Cab Chassis)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) , «Evaporative Emission Canister Replacement (25/35 Series)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  2. Turn OFF the main valve on the J 41413-200 evaporative emissions system tester.
  3. Disconnect the hose from the diagnostic station pressure regulator.
  4. Using a section of vacuum hose, connect one end to the diagnostic station pressure regulator.
  5. Connect the other end of the vacuum hose to the canister side of the purge pipe.
  6. Turn ON the main nitrogen cylinder valve and continue to discharge nitrogen for 15 seconds.
  7. If the nitrogen does not dislodge the carbon particles, replace the purge pipe.
  8. Return the EVAP pressure/purge diagnostic station to the stations original condition.
  9. Install a new EVAP canister. Refer to «Evaporative Emission Canister Replacement (15 Ext/Crew Cab)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) , «Evaporative Emission Canister Replacement (15 Reg/Exe Cab w/34 Gal Tank)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) , «Evaporative Emission Canister Replacement (15 Regular Cab)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) , «Evaporative Emission Canister Replacement (Cab Chassis)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) , «Evaporative Emission Canister Replacement (25/35 Series)»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions) .
  10. Connect all previously disconnected EVAP pipe connectors.
  11. Lower the vehicle.
  12. Continue with the published service manual diagnostic DTC procedure.
  1. Remove the intake manifold sight shield. Refer to «Upper Intake Manifold Sight Shield Replacement»(/gmc/sierra-2500/2012-2012/remont/mechanical/#engine-mechanical-48l-53l-60l-62l-repair-instructions-on-vehicle) .
  2. Disconnect the ignition coil wiring harness electrical connector (1) from the ignition coil.
  3. Remove the spark plug wire from the ignition coil. Twist the spark plug wire boot a 1/2 turn. Pull only on the boot in order to remove the wire from the ignition coil.
  4. Remove the ignition coil bolts.
  5. Remove the ignition coil from the bracket. (left side shown, right side similar).
  6. There are 2 different manufacturers for the ignition coils and coil brackets. They are as follows
  7. The Melco® (1) ignition coil is a square design.
  8. The Delphi® (2) ignition coil is a round design.
  9. The Melco® ignition coil bracket (1) is a square design.
  10. The Delphi® ignition coil bracket (2) is a round design.
  1. Position the ignition coil to the ignition coil bracket. (left side shown, right side similar).
  2. Install the ignition coil bolts. Tighten Tighten the bolts to 10 N.m (89 lb in).
  3. Install the spark plug wire to the ignition coil.
  4. Inspect the spark plug wire for proper installation: Push sideways on each boot in order the inspect the seating. Reinstall any loose boot.
  5. Connect the ignition coil wiring harness electrical connector (1) to the ignition coil.
  6. Install the intake manifold sight shield. Refer to «Upper Intake Manifold Sight Shield Replacement»(/gmc/sierra-2500/2012-2012/remont/mechanical/#engine-mechanical-48l-53l-60l-62l-repair-instructions-on-vehicle) .

Spark Plug Wire Inspection

Spark plug wire integrity is vital for proper engine operation. A thorough inspection is necessary to accurately identify conditions that may affect engine operation. Inspect for the following conditions

  1. Correct routing of the spark plug wires, Incorrect routing may cause cross firing.
  2. Any signs of cracks or splits in the wires.
  3. Inspect each boot for any of the following conditions: Tearing Piercing Arcing Carbon tracking Corroded terminal

If corrosion, carbon tracking or arcing are indicated on a spark plug wire boot or terminal, replace the wire and the component connected to the wire.

  1. Remove the spark plug wire from the spark plug. Twist the spark plug wire boot a 1/2 turn. Pull only on the boot in order to remove the wire from the spark plug.
  2. Remove the spark plug wire from the ignition coil. Twist the spark plug wire boot a 1/2 turn. Pull only on the boot in order to remove the wire from the ignition coil.
  1. Install the spark plug wire to the ignition coil.
  2. Install the spark plug wire to the spark plug.
  3. Inspect the spark plug wire for proper installation: Push sideways on each boot in order to inspect the seating. Reinstall any loose boot.

Scheme 59

Scheme 59: Spark Plug Inspection
Scheme 59: Spark Plug Inspection
  1. Verify that the correct spark plug is installed. An incorrect spark plug causes driveability conditions. Refer to the Electronic Parts Catalog.
  2. Ensure that the spark plug has the correct heat range. An incorrect heat range causes the following conditions: Spark plug fouling, replace with a colder plug Pre-ignition causing spark plug and/or engine damage, replace with a hotter plug
  3. Inspect the terminal post (1) for damage. Inspect for a bent or broken terminal post (1). Test for a loose terminal post (1) by twisting and pulling the post. The terminal post (1) should not move.
  4. Inspect the insulator (2) for flashover or carbon tracking, or soot. This is caused by the electrical charge traveling across the insulator (2) between the terminal post (1) and ground. Inspect for the following conditions: Inspect the spark plug boot for damage. Inspect the spark plug recess area of the cylinder head for moisture, such as oil, coolant, or water. A spark plug boot that is saturated will cause arcing to ground. Inspect the insulator (2) for cracks. All or part of the electrical charge may arc through the crack instead of the electrodes (3, 4).
  5. Inspect for evidence of improper arcing. Measure the gap between the center electrode (4) and the side electrode (3). Refer to «Ignition System Specifications»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-specifications__ignition-system-specifications) . An excessively wide electrode gap can prevent correct spark plug operation. Inspect for the correct spark plug torque. Refer to «Ignition System Specifications»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-specifications__ignition-system-specifications) . Insufficient torque can prevent correct spark plug operation. An over torqued spark plug, causes the insulator (2) to crack. Inspect for signs of tracking that occurred near the insulator tip instead of the center electrode (4). Inspect for a broken or worn side electrode (3). Inspect for a broken, worn, or loose center electrode (4) by shaking the spark plug. A rattling sound indicates internal damage. A loose center electrode (4) reduces the spark intensity. Inspect for bridged electrodes (3, 4). Deposits on the electrodes (3, 4) reduce or eliminates the gap. Inspect for worn or missing platinum pads on the electrodes (3, 4), if equipped. Inspect for excessive fouling.
  6. Inspect the spark plug recess area of the cylinder head for debris. Dirty or damaged threads can cause the spark plug not to seat correctly during installation.

Visual Inspection

  1. Normal operation - Brown to grayish-tan with small amounts of white powdery deposits are normal combustion by-products from fuels with additives.
  2. Carbon fouled - Dry, fluffy black carbon, or soot caused by the following conditions: Rich fuel mixtures Leaking fuel injectors Excessive fuel pressure Restricted air filter element Incorrect combustion Reduced ignition system voltage output Weak ignition coils Worn ignition wires Incorrect spark plug gap Excessive idling or slow speeds under light loads can keep spark plug temperatures so low that normal combustion deposits may not burn off.
  3. Deposit fouling - Oil, coolant, or additives that include substances such as silicone, very white coating, reduces the spark plug intensity. Most powdery deposits will not affect spark plug intensity unless they form into a glazing over the electrode.
  1. Remove the spark plug wire from the spark plug. Twist the spark plug wire boot a 1/2 turn. Pull only on the boot in order to remove the wire from the spark plug.
  2. Brush or using compressed air, blow away any dirt from around the spark plug.
  3. Remove the spark plug. If removing more than one plug, place each plug in a tray marked with the corresponding cylinder number.
  1. Inspect the spark plug gap. Adjust the gap as needed. Refer to «Ignition System Specifications»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-specifications__ignition-system-specifications) .
  2. Hand start the spark plug in the corresponding cylinder.
  3. Tighten the spark plug to 15 N.m (11 lb ft).
  4. Install the spark plug wire to the spark plug.
  5. Inspect the spark plug wire for proper installation: Push sideways on each boot in order to inspect the seating. Reinstall any loose boot.

Note. Perform the Crankshaft Position System Variation Learn whenever the crankshaft position sensor is removed or replaced.

  1. Remove the starter. Refer to «Starter Replacement (V8)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  2. Working through the wheel well opening, disconnect the engine wiring harness electrical connector (1) from the crankshaft position (CKP) sensor.
  3. Clean the area around the CKP sensor before removal in order to avoid debris from entering the engine.
  4. Remove the CKP sensor bolt.
  5. Remove the CKP sensor.
  1. Install the CKP sensor.
  2. Install the CKP sensor bolt. Tighten Tighten the bolt to 25 N.m (18 lb ft).
  3. Connect the engine wiring harness electrical connector (1) to the CKP sensor.
  4. Install the starter. Refer to «Starter Replacement (V8)»(/gmc/sierra-2500/2012-2012/remont/charging-system/#battery-charging-system-and-starting-system) .
  5. Perform the CKP system variation learn procedure. Refer to «Crankshaft Position System Variation Learn»(/gmc/sierra-2500/2012-2012/remont/testing-diagnostics/#engine-controlsfuel-48l-53l-60l-62l-repair-instructions__crankshaft-position-system-variation-learn) .

Scheme 60

Scheme 60: Camshaft Position Sensor Replacement (With Actuator)
Scheme 60: Camshaft Position Sensor Replacement (With Actuator)
CalloutComponent Name
Preliminary Procedures Remove the water pump. Refer to Water Pump Replacement (V8)
1Camshaft Position Sensor Fastener (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 12 N.m (106 lb in)
2Camshaft Position Sensor Procedure Disconnect the electrical connectors.
CAUTION
Refer to Fastener Caution .

Camshaft Position Sensor Replacement (With Actuator)

Scheme 61

Scheme 61: Camshaft Position Sensor Replacement (Without Actuator)
Scheme 61: Camshaft Position Sensor Replacement (Without Actuator)
CalloutComponent Name
1Camshaft Position Sensor Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 12 N.m (106 lb in)
2Camshaft Position Sensor Procedure Disconnect the electrical connectors.
CAUTION
Refer to Fastener Caution .

Camshaft Position Sensor Replacement (Without Actuator)

  1. Lift and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Disconnect the engine wiring harness electrical connector (4) from knock sensor.
  3. Remove the knock sensor bolt (739) and knock sensor (718).
  1. Position the knock sensor (718) to the engine block and install the knock sensor bolt (739). Tighten the bolt to 25 N.m (18 lb ft)
  2. Connect the engine wiring harness electrical connector (4) to knock sensor.
  1. Lift and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/gmc/sierra-2500/2012-2012/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
  2. Disconnect the engine wiring harness electrical connector (2) from knock sensor.
  3. Remove the knock sensor bolt (739) and knock sensor (718).
  1. Position the knock sensor (718) to the engine block and install the knock sensor bolt (739). Tighten the bolt to 25 N.m (18 lb ft)
  2. Connect the engine wiring harness electrical connector (2) to knock sensor.

Scheme 62

Scheme 62: Air Cleaner Element Replacement
Scheme 62: Air Cleaner Element Replacement
CalloutComponent Name
1Air Cleaner Housing Cover Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 3 N.m (27 lb in)
2Air Cleaner Housing
3Air Cleaner Element
CAUTION
Refer to Fastener Caution .

Air Cleaner Element Replacement

Scheme 63

Scheme 63: Air Cleaner Assembly Replacement
Scheme 63: Air Cleaner Assembly Replacement
CalloutComponent Name
Preliminary Procedures If replacing, remove the mass airflow sensor. Refer to Mass Airflow Sensor with Intake Air Temperature Sensor Replacement . Disconnect the air cleaner outlet duct from the air cleaner assembly. Refer to Air Cleaner Resonator Outlet Duct Replacement .
1Air Cleaner Assembly TIP: Pull upward in a jerking manner in order to disengage the air cleaner housing from the insulators.

Air Cleaner Assembly Replacement

  1. Remove the intake manifold sight shield. Refer to «Upper Intake Manifold Sight Shield Replacement»(/gmc/sierra-2500/2012-2012/remont/mechanical/#engine-mechanical-48l-53l-60l-62l-repair-instructions-on-vehicle) .
  2. Remove the positive crankcase ventilation (PCV) line (1) from the air cleaner outlet duct.
  3. Remove the radiator inlet hose clamp retainer from the outlet duct.
  4. Loosen the air cleaner outlet duct clamp (1) at the mass air flow (MAF)/intake air temperature (IAT) sensor.
  5. Loosen the air cleaner outlet duct clamp (2) at the throttle body.
  6. Lift up the air cleaner outlet duct at the resonator tab in order to separate the resonator from the stud on the intake manifold.
  7. Remove the air cleaner outlet duct from the throttle body and MAF/IAT sensor.
  1. Install the air cleaner outlet duct to the throttle body and MAF/IAT sensor. Ensure that the resonator tab aligns with the stud on the intake manifold.
  2. Push down on the air cleaner outlet duct resonator directly over the resonator tab in order to secure the resonator to the stud on the intake manifold.
  3. Tighten the air cleaner outlet duct clamp (2) at the throttle body to 4 N.m(35 lb in).
  4. Tighten the air cleaner outlet duct clamp (1) to 4 N.m(35 lb in) at the MAF/IAT sensor.
  5. Install the radiator inlet hose clamp retainer to the outlet duct.
  6. Install the PCV line (1) to the air cleaner outlet duct.
  7. Install the intake manifold sight shield. Refer to «Upper Intake Manifold Sight Shield Replacement»(/gmc/sierra-2500/2012-2012/remont/mechanical/#engine-mechanical-48l-53l-60l-62l-repair-instructions-on-vehicle) .

See also:
• Control Module References
• Battery Negative Cable Disconnection and Connection (TP2)
• Diagnostic Trouble Code (DTC) List - Vehicle
• Cooling System Draining and Filling (Vac-N-Fill Gasoline)
• Cooling System Draining and Filling (Static Fill)
• Fastener Caution
• Upper Intake Manifold Sight Shield Replacement
• Heated Oxygen and Oxygen Sensor Caution
• Lifting and Jacking the Vehicle
• Front Propeller Shaft Replacement
• Excessive Force and Oxygen Sensor Caution
• Component Fastener Tightening Caution
• Front Wheelhouse Liner Replacement - Right Side (GMC)
• Gasoline/Gasoline Vapors Warning
• Electrical Center Identification Views
• Safety Glasses Warning
• Fuel and Evaporative Emission Hose/Pipe Connection Cleaning Caution
• Relieving Fuel Pressure Warning
• Fuel Pipe Fitting Warning
• Spare Wheel Hoist Replacement
• Brake Pressure Modulator Valve Replacement
• Ignition System Specifications
• Water Pump Replacement (V8)
• Air Cleaner Resonator Outlet Duct Replacement
• Fuel Pressure Relief (Without CH-48027)
• Fuel Pressure Relief (CH-48027)
• Fuel Tank Draining
• Fuel Tank Fuel Pump Module Replacement (15 Ext/Crew Cab With 26 Gal Tank)
• Metal Collar Quick Connect Fitting Service
• Crankshaft Position System Variation Learn

More articles — Engine Performance
