Transfer Case Nvg 246-NP8: Specifications GMC Sierra 2500

Transfer Case 4 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Case Bolts37 N.m27 lb ft
Clutch Lever Pivot Pins40 N.m30 lb ft
Drain Plug20 N.m15 lb ft
Encoder Motor Bolts20 N.m15 lb ft
Fill Plug20 N.m15 lb ft
Shift Detent Spring Bolt17 N.m13 lb ft
Vehicle Speed Sensors15 N.m11 lb ft

Fastener Tightening Specifications

Scheme 388

Scheme 388: Capacities - Approximate Fluid
Scheme 388: Capacities - Approximate Fluid

Scheme 389

Scheme 389: Transfer Case Disassembled View
Scheme 389: Transfer Case Disassembled View

Scheme 390

Scheme 390
Scheme 390

Scheme 391

Scheme 391
Scheme 391
