SPECIFICATIONS
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Bracket to Frame Nuts | 90 N.m | 67 lb ft |
| Differential Adjuster Lock Nut Bolt | 20 N.m | 15 lb ft |
| Differential Carrier Assembly Case Bolts | 47 N.m | 35 lb ft |
| Differential Carrier Assembly Mounting Bolts and Nuts | 100 N.m | 75 lb ft |
| Front Differential Carrier Shield Bolts | 20 N.m | 15 lb ft |
| Front Drive Axle Actuator | 20 N.m | 15 lb ft |
| Inner Shaft Housing to Bracket Nuts | 100 N.m | 75 lb ft |
| Inner Shaft Housing to Differential Carrier Assembly Bolts | 40 N.m | 30 lb ft |
| Pinion Shaft Lock Bolt, 9.25" axle | 53 N.m | 39 lb ft |
| Plug, Drain and Fill | 33 N.m | 24 lb ft |
| Ring Gear Bolts, 8.25" Axle | 120 N.m | 88 lb ft |
| Ring Gear Bolts, 9.25" Axle | 138 N.m | 102 lb ft |
| Stabilizer Link Nut | 18 N.m | 13 lb ft |
| Vent Hose Connector | 28 N.m | 21 lb ft |
| Wheel Drive Shaft Inboard Flange Bolts | 79 N.m | 58 lb ft |
| Wheel Drive Shaft to Front Hub Nut | 210 N.m | 155 lb ft |
| Yoke Retainer Bolts | 25 N.m | 18 lb ft |
Fastener Tightening Specifications
Scheme 319
Scheme 320
Scheme 321
Scheme 322
Scheme 323
Scheme 324
Scheme 325
Begin the system diagnosis by reviewing the system Description and Operation. Reviewing the Description and Operation information will help you determine the correct symptom diagnostic procedure when a malfunction exist. Reviewing the Description and Operation information will also help you determine if the condition described by the customer is normal operation. Refer to SYMPTOMS - FRONT DRIVE AXLE in order to identify the correct procedure for diagnosing the system and where the procedure is located.
