Transfer Case - Nvg 263-NP1 (Selectable): Specifications GMC Sierra 1500 HD

Transfer Case 15 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Crossmember Bolt70 N.m52 lb ft
Transfer Case Adapter Bolt50 N.m37 lb ft
Transfer Case Adapter Nut50 N.m37 lb ft
Transfer Case Drain/Fill Plug20 N.m15 lb ft
Transfer Case Encoder Motor Bolt20 N.m15 lb ft
Transfer Case Shield Bolt20 N.m15 lb ft
Transfer Case Speed Sensor15 N.m11 lb ft
Transmission Mount Bolt47 N.m35 lb ft
Transmission Mount Nut40 N.m30 lb ft

Fastener Tightening Specifications

Scheme 684

Scheme 684: Capacities - Approximate Fluid
Scheme 684: Capacities - Approximate Fluid

Scheme 685

Scheme 685: Transfer Case Control Schematics
Scheme 685: Transfer Case Control Schematics

Scheme 686

Scheme 686
Scheme 686

Scheme 687

Scheme 687
Scheme 687

Scheme 688

Scheme 688: Transfer Case Control Component Views
Scheme 688: Transfer Case Control Component Views

Scheme 689

Scheme 689
Scheme 689

Scheme 690

Scheme 690
Scheme 690

Scheme 691

Scheme 691
Scheme 691

Scheme 692

Scheme 692: Transfer Case Control Connector End Views
Scheme 692: Transfer Case Control Connector End Views

Scheme 693

Scheme 693
Scheme 693

Scheme 694

Scheme 694
Scheme 694

Scheme 695

Scheme 695
Scheme 695

Scheme 696

Scheme 696
Scheme 696

Scheme 697

Scheme 697
Scheme 697

Scheme 698

Scheme 698
Scheme 698
