Transfer Case - Nvg 246-NP8 (Two Speed Automatic): Specifications GMC Sierra 1500 HD

Transfer Case 17 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Crossmember Bolt70 N.m52 lb ft
Encoder Motor Bolt20 N.m15 lb ft
Transfer Case Adapter Bolt50 N.m37 lb ft
Transfer Case Adapter Nut50 N.m37 lb ft
Transfer Case Drain/Fill Plug20 N.m15 lb ft
Transfer Case Shield Bolt/Screw20 N.m15 lb ft
Transfer Case Speed Sensor15 N.m11 lb ft
Transmission Mount Bolt47 N.m35 lb ft
Transmission Mount Nut40 N.m30 lb ft

Fastener Tightening Specifications

Scheme 472

Scheme 472: Capacities - Approximate Fluid
Scheme 472: Capacities - Approximate Fluid

Scheme 473

Scheme 473: Transfer Case Control Schematics
Scheme 473: Transfer Case Control Schematics

Scheme 474

Scheme 474
Scheme 474

Scheme 475

Scheme 475
Scheme 475

Scheme 476

Scheme 476: Transfer Case Control Component Views
Scheme 476: Transfer Case Control Component Views

Scheme 477

Scheme 477
Scheme 477

Scheme 478

Scheme 478
Scheme 478

Scheme 479

Scheme 479
Scheme 479

Scheme 480

Scheme 480: Transfer Case Control Connector End Views
Scheme 480: Transfer Case Control Connector End Views

Scheme 481

Scheme 481
Scheme 481

Scheme 482

Scheme 482
Scheme 482

Scheme 483

Scheme 483
Scheme 483

Scheme 484

Scheme 484
Scheme 484

Scheme 485

Scheme 485
Scheme 485

Scheme 486

Scheme 486
Scheme 486

Scheme 487

Scheme 487
Scheme 487

Scheme 488

Scheme 488
Scheme 488
