Transfer Case - Servicing: Specifications GMC Savana H2500

Transfer Case 3 illustrations

FLUID CAPACITIES

ApplicationQts. (L)
BW-44731.5 (1.4)
(1) Approximate capacity is listed.
(1)Approximate capacity is listed.

TRANSFER CASE FLUID CAPACITIES (1)

TORQUE SPECIFICATIONS

ApplicationSpecification
MetricEnglish
Adapter Bolts to Transmission50 N.m37 lb ft
Adapter Studs31 N.m23 lb ft
Drain Plug25 N.m18 lb ft
Fill Plug25 N.m18 lb ft
Mounting Nuts to Transfer Case50 N.m37 lb ft
Vehicle Speed Sensors17 N.m13 lb ft
Vent6 N.m53 lb in

Torque Specifications

Scheme 1

Scheme 1: SEALERS, ADHESIVES & LUBRICANTS
Scheme 1: SEALERS, ADHESIVES & LUBRICANTS

Scheme 2

Scheme 2: SPECIAL TOOLS
Scheme 2: SPECIAL TOOLS

Scheme 3

Scheme 3
Scheme 3
