FASTENER TIGHTENING SPECIFICATIONS
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Cruise Control Module Mounting Nuts | 5 N.m | 44 lb in |
| Horn Contact Plate Screws | 5.5 | 50 lb in |
| Intermediate Shaft Bearing Bracket Retaining Nuts | 30 N.m | 22 lb in |
| Intermediate Shaft Bearing Lower Brace Retaining Nut | 30 N.m | 22 lb ft |
| Intermediate Shaft Seal Bolts | 2 N.m | 18 lb in |
| Knee Bolster Deflector Screws | 9 N.m | 80 lb in |
| Linear Shift Assembly to Steering Column Mounting Screws | 10 N.m | 89 lb in |
| Ignition Lock Cylinder Case Screws | 7 N.m | 62 lb in |
| Steering Column Trim Cover Screws Lower | 3.5 N.m | 31 lb in |
| Steering Column Trim Cover Screws Lower | 2 N.m | 18 lb in |
| Lower Intermediate Shaft to Intermediate Shaft Bearing Retaining Bolt | 30 N.m | 22 lb ft |
| Lower Intermediate Shaft to the Steering Gear Pinch Bolt | 61 N.m | 45 lb ft |
| Turn Signal Multifunction Switch Screws Side | 7 N.m | 62 lb in |
| Turn Signal Multifunction Switch Screws Top | 3 N.m | 30 lb in |
| Power Steering Reservoir Mounting Nuts | 6.5 N.m | 58 lb in |
| Shift Lever Screw | 1.5 N.m | 13 lb in |
| Steering Column Bracket Nuts | 30 N.m | 22 lb ft |
| Steering Column Bulkhead Connector Screw | 6 N.m | 53 lb in |
| Steering Column Seal Nuts | 3 N.m | 25 lb in |
| Steering Wheel Nut | 41 N.m | 30 lb ft |
| Steering Column Trim Cover Screw Upper | 1.5 N.m | 13 lb in |
| Upper Intermediate Shaft to Intermediate Shaft Bearing Retaining Bolt | 30 N.m | 22 lb ft |
| Intermediate Shaft to the Steering Column Pinch Bolt | 64 N.m | 47 lb ft |
| Steering Column Support Screws | 17 N.m | 13 lb ft |
Fastener Tightening Specifications
