Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Spare Wheel Hoist Assembly Mounting Bolts | 50 N.m | 37 lb ft |
| Wheel Nut | 140 N.m | 103 lb ft |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Tire Diagnosis - Irregular or Premature Wear
| Callout | Component Name |
|---|
| 1 | Under-inflation, Hard Cornering, Lack of Regular Rotation |
| 2 | Incorrect Wheel Alignment, Hard Cornering, Lack of Regular Rotation |
| 3 | Incorrect Wheel Alignment, Shock Absorber Failure |
| 4 | Over-inflation, Heavy Acceleration, Lack of Regular Rotation |
| 5 | Normal Wear to the Wear Indicator |
