Accessory Power Socket: Overview GMC Envoy II

Body Electrical 6 illustrations

Scheme 1

Scheme 1: Cigar Lighter/Auxiliary Outlets Schematics
Scheme 1: Cigar Lighter/Auxiliary Outlets Schematics

Scheme 2

Scheme 2: Power Outlet Component Views
Scheme 2: Power Outlet Component Views
CalloutComponent Name
1Rear Window Wiper/Washer Switch (CD6)
2Transfer Case Shift Control Switch (NP8)/Traction Control Switch (NW7)
3Instrument Panel Harness
4Auxiliary Power Outlet - Front
5Cigar Lighter

Scheme 3

Scheme 3
Scheme 3
CalloutComponent Name
1Rear Window Wiper/Washer Switch (CD6)
2Auxiliary Power Outlet - Front
3Cigar Lighter
4Auxiliary Power Outlet - Front
5Transfer Case Shift Control Switch (NP8)/Traction Control Switch (NW7)
6Instrument Panel Harness

Scheme 4

Scheme 4
Scheme 4
CalloutComponent Name
1Cigar Lighter
2Rear Window Wiper/Washer Switch (CD6)
3Instrument Panel Harness
4Auxiliary Power Outlet - Front

Scheme 5

Scheme 5
Scheme 5
CalloutComponent Name
1Lower Console
2HVAC Control Module - Auxiliary
3Auxiliary Power Outlet - Console
4Console Mode Actuator - Auxiliary
5C309
6C307

Scheme 6

Scheme 6
Scheme 6
CalloutComponent Name
1Body Side Lower Trim Panel
2Auxiliary Power Outlet - Rear
