Lighting Systems: Specifications GMC Envoy II

Exterior Lights 40 illustrations ~2783 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Backup Lamp to Fascia Nuts10 N.m88 lb in
Front Fog Lamp Bolts10 N.m88 lb in
High Mount Stop Lamp Lens Screws2.5 N.m22 lb in
Instrument Panel Compartment Lamp Screws1.9 N.m17 lb in
License Plate Lamp Lens to Liftgate Screws1.4 N.m12 lb in
Tail Lamp Assembly to Vehicle Screws1.9 N.m17 lb in

Fastener Tightening Specifications

Lighting Systems Schematic Icons Icon Icon Definition CAUTION: When performing service on or near the SIR components or the SIR wiring, the SIR system must be disabled. Refer to SIR Disabling and Enabling Zones. Failure to observe the correct procedure could cause deployment of the SIR components, personal injury, or unnecessary SIR system repairs

Scheme 1

Scheme 1: Headlights/Daytime Running Lights (DRL) Schematics
Scheme 1: Headlights/Daytime Running Lights (DRL) Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3: Fog Lights Schematics
Scheme 3: Fog Lights Schematics

Scheme 4

Scheme 4: Headlight Leveling Schematics
Scheme 4: Headlight Leveling Schematics

Scheme 5

Scheme 5: Exterior Lights Schematics
Scheme 5: Exterior Lights Schematics

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14: Interior Lights Schematics
Scheme 14: Interior Lights Schematics

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19: Interior Lights Dimming Schematics
Scheme 19: Interior Lights Dimming Schematics

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23: Lighting Systems Component Views
Scheme 23: Lighting Systems Component Views
CalloutComponent Name
1Headlamp - Low Beam - Right
2Headlamp - High Beam - Right
3Cellular Antenna
4Headlamp - High Beam - Left
5Headlamp - Low Beam - Left
6Outside Rearview Mirror - Driver
7Marker Lamp - LF
8Park/Turn Signal Lamp - LF
9Cornering Lamp - Left (T87)
10Fog Lamp - LF (T96)
11Fog Lamp - R (T96)
12Cornering Lamp - Right)
13Park/Turn Signal Lamp - RF
14Marker Lamp - RF
15Radio Antenna
16Outside Rearview Mirror - Passenger

Scheme 24

Scheme 24
Scheme 24
CalloutComponent Name
1Radio Antenna
2Headlamp - High Beam - Right
3Headlamp - Low Beam - Right
4Headlamp - Low Beam - Left
5Cellular Antenna
6Headlamp - High Beam - Left
7Outside Rearview Mirror - Driver
8Marker Lamp - LF
9Park/Turn Signal lamp - LF
10Fog Lamp - LF (T96)
11Fog Lamp - RF (T96)
12Park/Turn Signal lamp - RF
13Marker Lamp - RF
14Outside Rearview Mirror - Passenger

Scheme 25

Scheme 25
Scheme 25
CalloutComponent Name
1Radio Antenna
2Digital Radio Antenna
3Cellular Antenna
4Outside Rearview Mirror - Driver
5Park Lamp - LF
6Park Lamp - LF
7Headlamp - High Beam - Left
8Marker Lamp - LF
9Cornering Lamp - Left (T87)
10Fog Lamp - LF (T96)
11Headlamp - Low Beam - Left
12Turn Signal Lamp - LF
13Turn Signal Lamp - RF
14Headlamp - Low Beam - Right
15Fog Lamp - RF (T96)
16Cornering Lamp - Right (T87)
17Marker Lamp - RF
18Headlamp - High Beam - Right
19Park Lamp - RF
20Park Lamp - RF
21Outside Rearview Mirror - Passenger

Scheme 26

Scheme 26
Scheme 26
CalloutComponent Name
1Headlamp Leveling Actuator - Left (TR6)
2Hood Ajar Switch (UA2)

Scheme 27

Scheme 27
Scheme 27
CalloutComponent Name
1Headlamp Leveling Actuator - Right (TR6)

Scheme 28

Scheme 28
Scheme 28
CalloutComponent Name
1Vanity Mirror Lamp - Left

Scheme 29

Scheme 29
Scheme 29
CalloutComponent Name
1Courtesy/Reading Lamp - Front
2Sunroof Switch (CF5)
3Garage Door Opener (UG1)

Scheme 30

Scheme 30
Scheme 30
CalloutComponent Name
1Vanity Mirror Lamp - Right

Scheme 31

Scheme 31
Scheme 31
CalloutComponent Name
1Headlamp Switch
2Headlamp Switch C1
3Instrument Panel Harness
4Headlamp Switch C2

Scheme 32

Scheme 32
Scheme 32
CalloutComponent Name
1Speaker - LF I/P (UQA)
2Ambient Light Sensor (CJ3)/Ambient Light/Sunload Sensor Assembly (CJ2)
3Speaker - RF I/P (UQA)

Scheme 33

Scheme 33
Scheme 33
CalloutComponent Name
1Steering Wheel Control Switch Assembly - Upper Left (STW)
2Passlock Sensor Connector
3Ignition Key Alarm Switch
4Ignition Lock Cylinder Control Actuator
5Ignition Lock Cylinder Control Actuator Connector
6Ignition Switch
7Ignition Key Cylinder
8Steering Wheel Control Switch Assembly - Upper Right (STW)
9Horn Switch
10Steering Wheel Control Switch Assembly - Lower Right (STW)
11C277
12Steering Wheel Control Switch Assembly - Lower Left (STW)
13Turn Signal/Multifunction Switch

Scheme 34

Scheme 34
Scheme 34
CalloutComponent Name
1Turn Signal/Hazard Flasher Module
2Instrument Panel Harness
3Data Link Connector (DLC)
4Splice Pack SP205

Scheme 35

Scheme 35
Scheme 35
CalloutComponent Name
1Instrument Panel Harness
2Accelerator Pedal Position (APP) Sensor
3Accelerator Pedal
4Brake Pedal
5Stop Lamp Switch

Scheme 36

Scheme 36
Scheme 36
CalloutComponent Name
1Cargo Lamp
2Courtesy/Reading Lamp - Center

Scheme 37

Scheme 37
Scheme 37
CalloutComponent Name
1Cargo Lamp - LR
2Body Harness

Scheme 38

Scheme 38
Scheme 38
CalloutComponent Name
1Cargo Lamp - RR
2Body Harness

Scheme 39

Scheme 39
Scheme 39
CalloutComponent Name
1Center High Mounted Stop Lamp (CHMSL)
2License Lamp - Left
3License Lamp - Right
4Tail Lamp Circuit Board - Right
5Backup Lamp - Right (Z88)
6Trailer Connector
7Backup Lamp - Left (Z88)
8Tail Lamp Circuit Board - Left

Scheme 40

Scheme 40
Scheme 40
CalloutComponent Name
1Endgate Harness
2Center High Mounted Stop Lamp (CHMSL) Connector
3Endgate
4Center High Mounted Stop Lamp (CHMSL)

Ambient Light Sensor (CJ3) Connector Part Information 12047662 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A WH 278 Ambient Light Sensor Signal B BK 279 Ambient Light Sensor Low Reference

Backup Lamp - Left (Z88) Connector Part Information 15435155 3-Way Lamp Socket Wedge Base W3 (GY) Pin Wire Color Circuit No. Function A L-GN 24 Backup Lamp Supply Voltage B - - Not Used G BK 2450 Ground

Backup Lamp - Right (Z88) Connector Part Information 15435155 3-Way Lamp Socket Wedge Base W3 (GY) Pin Wire Color Circuit No. Function A L-GN 24 Backup Lamp Supply Voltage B - - Not Used G BK 2450 Ground

Cargo Lamp - LR (XUV) Connector Part Information 12146418 2-Way F Lamp Socket (L-GY) Pin Wire Color Circuit No. Function A BK 1550 Ground B GY/BK 690 Courtesy Lamp Supply Voltage

Cargo Lamp - RR (XUV) Connector Part Information 12146418 2-Way F Lamp Socket (L-GY) Pin Wire Color Circuit No. Function A BK 1650 Ground B GY/BK 690 Courtesy Lamp Supply Voltage

Cargo Lamp (Except XUV/Y92) Connector Part Information 12047662 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A BK 1350 Ground B GY/BK 690 Courtesy Lamp Supply Voltage

Cargo Lamp (Y92) Connector Part Information 12047781 3-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A GY/BK 690 Courtesy Lamp Supply Voltage B BK 1550 Ground C OG 1732 Courtesy Lamp Supply Voltage

Center High Mounted Stop Lamp (CHMSL) (Except XUV) Connector Part Information 12047663 2-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A YE 820 CHMSL Supply Voltage B BK 1550 Ground

Center High Mounted Stop Lamp (CHMSL) (XUV) Connector Part Information 15326801 2-Way F GT 150 Series (BK) Pin Wire Color Circuit No. Function A YE 820 CHMSL Supply Voltage B BK 1650 Ground

Clearance Lamp - Left (Y92) Connector Part Information 12047663 2-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A BN/WH 2609 Park Lamps Supply Voltage B BK 1350 Ground

Clearance Lamp - Right (Y92) Connector Part Information 12047663 2-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A BN/WH 2609 Park Lamps Supply Voltage B BK 1350 Ground

Cornering Lamp - Left (T87) Connector Part Information 15326291 2-Way Lamp Socket Wedge Base W3 Sealed Right Angle (WH) Pin Wire Color Circuit No. Function A OG 57 Left Cornering Lamp Supply Voltage G BK 350 Ground

Cornering Lamp - Right (T87) Connector Part Information 15326291 2-Way Lamp Socket Wedge Base W3 Sealed Right Angle (WH) Pin Wire Color Circuit No. Function A BK 58 Right Cornering Lamp Supply Voltage G BK 250 Ground

Courtesy/Reading Lamp - Center Connector Part Information 12047781 3-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A GY/BK 690 Courtesy Lamp Supply Voltage B BK 1350 Ground C OG 1732 Courtesy Lamps Supply Voltage

Courtesy/Reading Lamp - Front Connector Part Information 12047781 3-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A GY/BK 690 Courtesy Lamp Supply Voltage B BK 1350 Ground C OG 1732 Courtesy Lamps Supply Voltage

Courtesy/Reading Lamp (3rd Row) - Left Connector Part Information 12047781 3-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A GY/BK 690 Courtesy Lamp Supply Voltage B BK 1350 Ground C OG 1732 Courtesy Lamps Supply Voltage

Courtesy/Reading Lamp (3rd Row) - Right Connector Part Information 12047781 3-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A GY/BK 690 Courtesy Lamp Supply Voltage B BK 1350 Ground C OG 1732 Courtesy Lamps Supply Voltage

Fog Lamp - LF (Except W49 w/T96) Connector Part Information 12020599 2-Way F Metri-Pack 280 Series (BK) Pin Wire Color Circuit No. Function A PU 34 Fog Lamps Supply Voltage B BK 350 Ground

Fog Lamp - LF (W49 w/T96) Connector Part Information 12124819 2-Way F Metri-Pack 280 Series (BK) Pin Wire Color Circuit No. Function A PU 34 Fog Lamps Supply Voltage B BK 350 Ground

Fog Lamp - RF (Except W49 w/T96) Connector Part Information 12020599 2-Way F Metri-Pack 280 Series (BK) Pin Wire Color Circuit No. Function A PU 34 Fog Lamps Supply Voltage B BK 250 Ground

Fog Lamp - RF (W49 w/T96) Connector Part Information 12124819 2-Way F Metri-Pack 280 Series (BK) Pin Wire Color Circuit No. Function A PU 34 Fog Lamps Supply Voltage B BK 250 Ground

Headlamp - High Beam - Left Connector Part Information 12059183 2-Way F Metri-Pack 280 Series, Sealed (BK) Pin Wire Color Circuit No. Function A YE - Left Headlamp High Beam Supply Voltage B D-GN - Ground

Headlamp - High Beam - Right Connector Part Information 12059183 2-Way F Metri-Pack 280 Series, Sealed (BK) Pin Wire Color Circuit No. Function A YE - Right Headlamp High Beam Supply Voltage B D-GN - Ground

Headlamp - Low Beam - Left Connector Part Information 12059183 2-Way F Metri-Pack 280 Series, Sealed (BK) Pin Wire Color Circuit No. Function A OG - Left Headlamp Low Beam Supply Voltage B WH - Ground

Headlamp - Low Beam - Right Connector Part Information 12059183 2-Way F Metri-Pack 280 Series, Sealed (BK) Pin Wire Color Circuit No. Function A OG - Right Headlamp Low Beam Supply Voltage B WH - Ground

Headlamp Leveling Actuator - Left (TR6) Connector Part Information 12186467 3-Way F (BK) Pin Wire Color Circuit No. Function 1 BK 350 Ground 2 D-GN 189 Headlamp Leveling Motor Supply Voltage 3 PK 639 Ignition 1 Voltage

Headlamp Leveling Actuator - Right (TR6) Connector Part Information 12186467 3-Way F (BK) Pin Wire Color Circuit No. Function 1 BK 250 Ground 2 D-GN 189 Headlamp Leveling Motor Supply Voltage 3 PK 639 Ignition 1 Voltage

Headlamp Switch C1 Connector Part Information 15332161 12-Way F GT 150 Series (BK) Pin Wire Color Circuit No. Function A GY 705 5-Volt Reference B BN/WH 230 Instrument Panel Lamps Dimming Control C BK 2250 Ground D WH 103 Headlamp Switch Headlamps On Signal E GY/BK 308 Park Lamp Switch On Signal F L-GN 5462 DRL Defeat Switch Signal G OG/BK 2090 Courtesy Lamps Dimming Input H GY/BK 2226 Instrument Panel Lamps Dimmer Switch Low Reference J D-BU/WH 1495 Courtesy Lamp On Signal K PU/WH 1382 LED Dimming Signal L PK 1348 Headlamp On Indicator Control M PU 328 Interior Lamp Defeat Switch Signal

Headlamp Switch C2 Connector Part Information 15332145 8-Way F GT 150 Series (BK) Pin Wire Color Circuit No. Function A OG 192 Front Fog Lamp Switch Signal (T96) B L-BU 187 Rear Fog Lamp Switch Signal (T79) C D-GN/WH 1317 Front Fog Lamp Relay and Indicator Control (T96) D YE 1977 Rear Fog Lamp Relay and Indicator Control (T79) E TN 5463 Daytime Running Lamp Override Indicator F D-GN 189 Headlamp Leveling Motor Supply Voltage (TR6) G PK 639 Ignition 1 Voltage (TR6) H BN/WH 1871 Headlamp Washer Switch Signal (CE4)

License Lamp - Left (Except XUV) Connector Part Information 12146418 2-Way Lamp Socket (L-GY) Pin Wire Color Circuit No. Function A BN 2509 Left Rear Park Lamps and License Lamps Supply Voltage B BK 1550 Ground

License Lamp - Left (XUV) Connector Part Information 12110053 2-Way Lamp Socket Wedge Base W2 (L-GY) Pin Wire Color Circuit No. Function A BN 2509 Left Rear Park Lamps and License Lamps Supply Voltage B BK 1650 Ground

License Lamp - Right (Except XUV) Connector Part Information 12146418 2-Way Lamp Socket (L-GY) Pin Wire Color Circuit No. Function A BN 2509 Left Rear Park Lamps and License Lamps Supply Voltage B BK 1550 Ground

License Lamp - Right (XUV) Connector Part Information 12110053 2-Way Lamp Socket Wedge Base W2 (L-GY) Pin Wire Color Circuit No. Function A BN 2509 Left Rear Park Lamps and License Lamps Supply Voltage B BK 1650 Ground

Marker Lamp - LF (X88) Connector Part Information 15326801 2-Way F GT 150 Series (BK) Pin Wire Color Circuit No. Function A BN 2309 Front Park Lamps Supply Voltage B L-BU 2114 Left Turn Signal Lamps Supply Voltage (w/o WX7) BK 350 Ground (w/WX7)

Marker Lamp - LF (Z88/Z88/W49) Connector Part Information 12110053 2-Way F/Lamp Socket Wedge Base W2 (L-GY) Pin Wire Color Circuit No. Function A BN 2309 Front Park Lamps Supply Voltage B L-BU 2114 Left Turn Signal Lamps Supply Voltage

Marker Lamp - RF (X88) Connector Part Information 15326801 2-Way F GT 150 Series (BK) Pin Wire Color Circuit No. Function A BN 2309 Front Park Lamps Supply Voltage B D-BU 2115 Right Turn Signal Lamps Supply Voltage (w/o WX7) BK 250 Ground (w/WX7)

Marker Lamp - RF (Z88/Z89/W49) Connector Part Information 12110053 2-Way F/Lamp Socket Wedge Base W2 (L-GY) Pin Wire Color Circuit No. Function A BN 2309 Front Park Lamps Supply Voltage B D-BU 2115 Right Turn Signal Lamps Supply Voltage

Park Lamp - LF (W49) Connector Part Information 15326801 2-Way GT 150 Series BK) Pin Wire Color Circuit No. Function A BN 2309 Front Park Lamps Supply Voltage B BK 350 Ground

Park Lamp - LF (W49) Connector Part Information 15326801 2-Way GT 150 Series BK) Pin Wire Color Circuit No. Function A BN 2309 Front Park Lamps Supply Voltage B BK 350 Ground

Park Lamp - RF (W49) Connector Part Information 15326801 2-Way GT 150 Series (BK) Pin Wire Color Circuit No. Function A BN 2309 Front Park Lamps Supply Voltage B BK 250 Ground

Park Lamp - RF (W49) Connector Part Information 15326801 2-Way GT 150 Series (BK) Pin Wire Color Circuit No. Function A BN 2309 Front Park Lamps Supply Voltage B BK 250 Ground

Park/Turn Signal Lamp - LF (X88) Connector Part Information 15355377 3-Way F GT 150 Series (GY) Pin Wire Color Circuit No. Function A BK 350 Ground B BN 2309 Front Park Lamps Supply Voltage (w/o WX7) C L-BU 2114 Left Turn Signal Lamps Supply Voltage

Park/Turn Signal Lamp - LF (Z88/Z89) Connector Part Information 12160395 3-Way Lamp Socket Wedge Base W3 Right Angle (GY) Pin Wire Color Circuit No. Function A L-BU 2114 Left Turn Signal B BN 2309 Front Park Lamp Supply Voltage G BK 350 Ground

Park/Turn Signal Lamp - RF (X88) Connector Part Information 15355377 3-Way F GT 150 Series (GY) Pin Wire Color Circuit No. Function A BK 250 Ground B BN 2309 Front Park Lamps Supply Voltage (w/o WX7) C D-BU 2115 Left Turn Signal Lamps Supply Voltage

Park/Turn Signal Lamp - RF (Z88/Z89) Connector Part Information 12160395 3-Way Lamp Socket Wedge Base W3 Right Angle (GY) Pin Wire Color Circuit No. Function A D-BU 2115 Right Turn Signal Lamps Supply Voltage B BN 2309 Front Park Lamps Supply Voltage G BK 250 Ground

Stop Lamp Switch Connector Part Information 12040551 6-Way F Metri-Pack 480 Series (BK) Pin Wire Color Circuit No. Function A WH 17 Stop Lamp Switch Signal WH 17 Stop Lamp Switch Signal B OG 1540 Battery Positive Voltage C PU 420 TCC Brake/Cruise Control Release Signal D PK 639 Ignition 1 Voltage E D-GN/WH 1135 A/T Shift Lock Control Solenoid Supply Voltage F L-GN/BK 584 A/T Shift Lock Control Switch Supply Voltage

Tail Lamp Circuit Board - Left (T79) Connector Part Information 15355208 5-Way F GT 150 Series Sealed 4.0 (BK) Pin Wire Color Circuit No. Function A BN 2509 Left Rear Park Lamps and License Lamp Supply Voltage B L-BU 2114 Left Turn Signal Lamps Supply Voltage C RD 122 Rear Fog Lamp Supply Voltage D L-BU 1320 Stop Lamp Supply Voltage E BK 1550 Ground

Tail Lamp Circuit Board - Left (w/o T79) Connector Part Information 15355207 5-Way F GT 150 Series Sealed 4.0 (BK) Pin Wire Color Circuit No. Function A BN 2509 Left Rear Park Lamps and License Lamps Supply Voltage (X88/W49/Z89) L-BU 1320 Stop Lamp Supply Voltage (Z88) B L-BU 2114 Left Turn Signal Lamps Supply Voltage (X88/W49/Z89) C L-GN 24 Backup Lamp Supply Voltage (X88/W49/Z89) BN 2509 Left Rear Park Lamps and License Lamps Supply Voltage (Z88) D L-BU 1320 Stop Lamp Supply Voltage (X88/W49/Z89) L-BU 2114 Left Turn Signal Lamps Supply Voltage (Z88) E BK 1550 Ground

Tail Lamp Circuit Board - Right Connector Part Information 15355207 5-Way F GT 150 Series Sealed 4.0 (BK) Pin Wire Color Circuit No. Function A BN/WH 2609 Right Rear Park Lamps Supply Voltage (X88/W49/Z89) L-BU 1320 Stop Lamp Supply Voltage (Z88) B D-BU 2115 Right Turn Signal Lamps Supply Voltage (X88/W49/Z89) C L-GN 24 Backup Lamp Supply Voltage (X88/W49/Z89) BN/WH 2609 Right Rear Park Lamps Supply Voltage (Z88) D L-BU 1320 Stop Lamp Supply Voltage (X88/W49/Z89) D-BU 2115 Right Turn Signal Lamps Supply Voltage (Z88) E BK 1650 Ground

Trailer Connector Connector Part Information 15354653 7-Way F Metri-Pack 280 Series Sealed (BK) Pin Wire Color Circuit No. Function A L-GN 1624 Trailer Backup Lamps Supply Voltage B WH 22 Ground C D-BU 47 Trailer Auxiliary Supply Voltage D D-GN 1619 Trailer Right Rear Turn/Stop Lamp Supply Voltage E RD 742 Battery Positive Voltage F BN 2109 Trailer Park Lamps Supply Voltage G YE 1618 Trailer Left Rear Turn/Stop Lamp Supply Voltage

Turn Signal Lamp - LF (W49) Connector Part Information 15355377 3-Way F GT 150 Series (GY) Pin Wire Color Circuit No. Function A BK 350 Ground B - - Not Used C L-BU 2114 Left Turn Signal Lamps Supply Voltage

Turn Signal Lamp - RF (W49) Connector Part Information 15355377 3-Way F GT 150 Series (GY) Pin Wire Color Circuit No. Function A BK 250 Ground B - - Not Used C D-BU 2115 Left Turn Signal Lamps Supply Voltage

Turn Signal/Hazard Flasher Module Connector Part Information 15359360 10-Way F GT 280 Series (GY) Pin Wire Color Circuit No. Function A L-GN 1427 Right Turn Signal Switch Signal B WH 17 Stop Lamp Switch Signal C YE 18 Left Rear Stop/Turn Lamp Supply Voltage D D-GN 19 Right Rear Stop/Turn Lamp Supply Voltage E BK 2250 Ground F D-GN 1428 Left Turn Signal Switch Signal G WH 111 Hazard Switch Signal H YE 685 Left Turn Signal Flasher Signal J TN 686 Right Turn Signal Flasher Signal K OG 140 Battery Positive Voltage

Turn Signal/Multifunction Switch C1 Connector Part Information 12064862 8-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A L-GN 1427 Right Turn Signal Switch Signal B PK 639 Ignition 1 Voltage C D-GN 1428 Left Turn Signal Switch Signal D OG 57 Left Cornering Lamp Supply Voltage (T87) E BN 2309 Front Park Lamps Supply Voltage F BK 58 Right Cornering Lamp Supply Voltage (T87) G BK/YE 28 Horn Relay Control H WH 111 Hazard Switch Signal

Turn Signal/Multifunction Switch C2 Connector Part Information 12059800 5-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A TN 751 Ground B YE/BK 307 Flash To Pass Signal C L-GN 11 Headlamp High Beam Supply Voltage D-E - - Not Used

Turn Signal/Multifunction Switch C3 Connector Part Information 15339058 7-Way F Metri-Pack 150 Series (GY) Pin Wire Color Circuit No. Function G - - Not Used H PK 94 Windshield Washer Switch Signal 1 J GY 478 Windshield Wiper Switch Supply Voltage K D-BU/WH 477 Windshield Wiper Switch High Signal L-N - - Not Used

Turn Signal/Multifunction Switch C4 (K34) Connector Part Information 12047786 4-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A BN 341 Ignition 3 Voltage B GY/WH 397 Cruise Control Switch On Signal C GY/BK 87 Cruise Control Resume/Accel Switch Signal D D-BU 84 Cruise Control Set/Coast Switch Signal

Vanity Mirror Lamp - Left (DH2) Connector Part Information 12047662 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A OG 1732 Courtesy Lamps Supply Voltage B BK 1350 Ground

Vanity Mirror Lamp - Right (DH2) Connector Part Information 12047662 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A OG 1732 Courtesy Lamps Supply Voltage B BK 1350 Ground
