REMOVAL & INSTALLATION
| CAUTION | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION section before disconnecting battery. |
- Disconnect negative battery cable. Remove door handle bezel screw. Prying at rear of bezel with lever in locked position, remove door handle bezel from trim panel.
- On models equipped with window regulator handle, insert Door Handle Remover (J-9886-01) between handle and bearing plate. Align tool parallel with door handle, and push to disengage clip. Pull handle from door. Remove bearing plate.
- On all models, use flat-bladed tool to carefully remove power accessory switch panel. Pry off cover and remove armrest screw. Remove door trim panel screws. Using Trim Panel Remover (J-38778), remove trim panel. Remove mirror access hole plugs. Remove power mirror mounting screws. Disconnect harness connector from power mirror. Remove power mirror assembly.
- To install, reverse removal procedure. Tighten power mirror mounting screws to 53 INCH lbs. (6.0 N.m). Tighten handle bezel and door trim panel screws to 17 INCH lbs. (1.9 N.m).
- Place tape over mirror glass. Cover mirror face with cloth and break mirror lens. Wearing gloves, clean broken glass from inside mirror frame.
- To install, remove adhesive backing from back of new mirror lens. Firmly press mirror lens into mirror housing.
Scheme 1: Power Mirror System Wiring Diagram
Automatic Day/Night Mirror System Wiring Diagram (Blazer, Bravada, Envoy & Jimmy). Scheme 1
Scheme 1: Automatic Day/Night Mirror System Wiring Diagram (Blazer, Bravada, Envoy & Jimmy)
