Cellular System, Entertainment System, and Navigation System: Specifications GMC Acadia I рестайлинг

Entertainment Systems 14 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Audio/Video Disc Player Adapter Screw2 N.m18 lb in
Front Floor Console Extension Accessory Upper Bezel Screws2 N.m18 lb in
Front Side Door Speaker Screw2.5 N.m22 lb in
Heater and A/C and Radio Control Module Screws2 N.m18 lb in
Radio Antenna Base Nut9 N.m80 lb in
Radio Front Floor Console Speaker Screws9 N.m80 lb in
Radio Front Speaker Screw2.5 N.m22 lb in
Radio Rear Quarter Trim Speaker Assembly Screw2.5 N.m22 lb in
Radio Speaker Amplifier Screw2.5 N.m22 lb in
Rear Side Door Speaker Screw2.5 N.m22 lb in
Video Display Assembly Screws2 N.m18 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Power, Ground, Serial Data, Antennas, Lighting and Vehicle Speed Signal
Scheme 1: Power, Ground, Serial Data, Antennas, Lighting and Vehicle Speed Signal

Scheme 2

Scheme 2: Audio Amplifier Power, Ground and Front and Rear Audio Inputs (UQA or UQS)
Scheme 2: Audio Amplifier Power, Ground and Front and Rear Audio Inputs (UQA or UQS)

Scheme 3

Scheme 3: Audio Amplifier Power, Ground and Front and Rear Audio Inputs (UQA or UQS with ULD)
Scheme 3: Audio Amplifier Power, Ground and Front and Rear Audio Inputs (UQA or UQS with ULD)

Scheme 4

Scheme 4: Audio Amplifier Center and Subwoofer Audio Inputs (UQS)
Scheme 4: Audio Amplifier Center and Subwoofer Audio Inputs (UQS)

Scheme 5

Scheme 5: Speakers (UQF)
Scheme 5: Speakers (UQF)

Scheme 6

Scheme 6: Speakers (UQF with ULD)
Scheme 6: Speakers (UQF with ULD)

Scheme 7

Scheme 7: Speakers - Door and A-Pillar (UQA or UQS)
Scheme 7: Speakers - Door and A-Pillar (UQA or UQS)

Scheme 8

Scheme 8: Speakers - Except Door and A-Pillar (UQA or UQS)
Scheme 8: Speakers - Except Door and A-Pillar (UQA or UQS)

Scheme 9

Scheme 9: Rear Audio Controls, Lighting, Data Communication and Infrared Module
Scheme 9: Rear Audio Controls, Lighting, Data Communication and Infrared Module

Scheme 10

Scheme 10: Digital Radio (U2K or UBS)
Scheme 10: Digital Radio (U2K or UBS)

Scheme 11

Scheme 11: Secondary Controls
Scheme 11: Secondary Controls

Scheme 12

Scheme 12: UE1
Scheme 12: UE1

Scheme 13

Scheme 13: U42
Scheme 13: U42

Scheme 14

Scheme 14: Headrest DVD (SPO Accessory)
Scheme 14: Headrest DVD (SPO Accessory)
