Speaker Replacement Reference
| Component | Repair Instruction |
|---|
| Center I/P Speaker | Refer to Radio Front Speaker Replacement |
| Front Door Speaker | Refer to Radio Front Side Door Speaker Replacement |
| Front Pillar Speaker (Tweeter Speaker) | Refer to Front Upper Speaker Replacement |
| Rear Compartment Speaker | Refer to Radio Rear Speaker Replacement |
| Rear Door Speaker | Refer to Radio Rear Side Door Speaker Replacement |
| Subwoofer Speaker | Refer to Radio Front Floor Console Speaker Replacement |
Speaker Replacement Reference
Radio Front Floor Console Speaker Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the front side door trim panel. Refer to Front Side Door Trim Panel Replacement - Left Side (Acadia or Traverse) , Front Side Door Trim Panel Replacement - Left Side (Enclave) or Front Side Door Trim Panel Replacement - Right Side (Enclave) , Front Side Door Trim Panel Replacement - Right Side (Acadia or Traverse) . |
| 1 | Front Side Door Speaker Screw CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in) |
| 2 | Front Side Door Speaker Procedure Disconnect the electrical connectors. |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Radio Front Floor Console Speaker Replacement
Scheme 16
Scheme 16: Radio Rear Speaker Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the front floor console assembly. Refer to Front Floor Console Replacement (Acadia) , Front Floor Console Replacement (Enclave) , Front Floor Console Replacement (Traverse) . |
| 1 | Radio Front Floor Console Speaker Screws (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 9 N.m (80 lb in) |
| 2 | Radio Front Floor Console Speaker Assembly Procedure Disconnect the electrical connector. |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Radio Rear Speaker Replacement
Scheme 17
Scheme 17: Radio Control Switch Replacement - Rear
| Callout | Component Name |
|---|
| Preliminary Procedures Remove the rear quarter lower trim panel. Refer to Quarter Lower Rear Trim Panel Replacement (Traverse with TB5) , Quarter Lower Rear Trim Panel Replacement (Traverse with TB4) , Quarter Lower Rear Trim Panel Replacement (Enclave with TB5) , Quarter Lower Rear Trim Panel Replacement (Enclave with TB4) , Quarter Lower Rear Trim Panel Replacement (Acadia with TB5) , Quarter Lower Rear Trim Panel Replacement (Acadia with TB4) . |
| 1 | AM/FM Stereo Radio Remote Control Assembly |
Radio Control Switch Replacement - Rear
Scheme 18
Scheme 18: Radio Rear Side Door Speaker Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the rear door inner trim panel. Refer to Rear Side Door Trim Panel Replacement (Enclave) , Rear Side Door Trim Panel Replacement (Acadia or Traverse) . |
| 1 | Rear Side Door Speaker Screw CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in) |
| 2 | Rear Side Door Speaker Procedure Disconnect the electrical connectors. |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Radio Rear Side Door Speaker Replacement
