Installation Procedure
- Paint the rear object sensor. Refer to «Basecoat/Clearcoat Paint Systems»(ref-610073-S03897088072014042100000) . NOTE: Do not refinish previously painted sensors. Excess paint build up will cause the sensor to be inoperative.
- Ensure the paint does not exceed 6 mils. Use a paint thickness gauge suitable for non-ferrous metals. Refer to «Paint Gauges»(ref-610073-S01803368532014042100000) .
- Insert the sensor into the housing. NOTE: Ensure the silicone decoupling ring is installed on the sensor to avoid sensor failure.
- Connect the electrical connector to the rear object sensor.
- Install the rear bumper fascia. Refer to «Rear Bumper Fascia Replacement (Acadia)»(ref-610046-S35754763492014042100000) , «Rear Bumper Fascia Replacement (Enclave)»(ref-610046-S04233693032014042100000) , «Rear Bumper Fascia Replacement (Traverse)»(ref-610046-S31700507292014042100000) .
Scheme 5
Scheme 5: Front View Camera Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the inside rearview mirror mount plate cover. Refer to Inside Rearview Mirror Mount Plate Replacement . |
| 1 | Front View Camera Procedure Using a suitable plastic tool, insert the tool between the edge of the front view camera retainers, turn the tool to release the retainers and the camera and rotate downward. Disconnect the electrical connector. Program and calibrate the front view camera. For programming and set up, refer to Front View Camera Module Calibration . |
Front View Camera Replacement
Scheme 6
Scheme 6: Rearview Driver Information Camera Replacement (Traverse)
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the liftgate outside handle. Refer to Liftgate Outside Handle Replacement (Acadia, Traverse) . |
| 1 | Rearview Camera Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in) |
| 2 | Rearview Camera TIP: Release tape to remove the wiring harness. |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Rearview Driver Information Camera Replacement (Traverse)
Scheme 7
Scheme 7: Rearview Driver Information Camera Replacement (Acadia, Enclave)
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the liftgate applique. Refer to Liftgate Applique Replacement (Acadia) . |
| 1 | Double Ended Stud with Collar (Qty: 2) TIP: Remove in order to remove the isolator from the applique. |
| 2 | Liftgate Applique Isolator TIP: Carefully release the isolator tab from the liftgate applique. |
| 3 | Rearview Camera Procedure Disengage the electrical harness from above the rear latch clips. Disconnect the camera electrical harness connector from the rear license plate lamp harness electrical connector. Ensure the electrical harness is properly positioned prior to installation of the liftgate applique isolator. |
Rearview Driver Information Camera Replacement (Acadia, Enclave)
