Object Detection System and Pedestrian Protection System: Other GMC Acadia I рестайлинг

Conditions for Clearing

1. The DTC will transition to history when the fault is no longer present.
2. A history DTC will clear after 100 malfunction-free ignition cycles.

Reference Information

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Rearview Camera, UVC) , Object Detection Description and Operation (with Park Assist, UD7) , Object Detection Description and Operation (with Side Blind Zone Alert, UFT) , Object Detection Description and Operation (with Rear Cross Traffic Alert, UFT) , Object Detection Description and Operation (with Lane Departure Warning, UFL) , Object Detection Description and Operation (with Forward Collision Alert, UEU)

Electrical Information Reference

1. «Circuit Testing»(ref-610066-S15766520632014042100000)
2. «Connector Repairs»(ref-610066-S09830970062014042100000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Repair Instructions

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

Control Module References for BCM replacement, setup and programming

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Rearview Camera, UVC) , Object Detection Description and Operation (with Park Assist, UD7) , Object Detection Description and Operation (with Side Blind Zone Alert, UFT) , Object Detection Description and Operation (with Rear Cross Traffic Alert, UFT) , Object Detection Description and Operation (with Lane Departure Warning, UFL) , Object Detection Description and Operation (with Forward Collision Alert, UEU)

Electrical Information Reference

1. «Circuit Testing»(ref-610066-S15766520632014042100000)
2. «Connector Repairs»(ref-610066-S09830970062014042100000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

Circuit/System Verification

1. Ignition ON.
2. Verify that B094B 45 or B094C 45 is not set. If DTC is set Program the appropriate B218 Side Object Sensor Module. Verify the DTC does not set. If the DTC sets, replace the appropriate B218 Side Object Sensor Module. If the DTC does not set All OK. If DTC is not set
3. Verify that B094B 00, B094C 00, B094B 08, B094C 08, B094B 54 or B094C 54 is not set. If DTC is set Replace the appropriate B218 Side Object Sensor Module. If the DTC is not set
4. Verify that B094B 58 or B094C 58 is not set. If DTC is set Verify the area in front of the sensor is clean, unobstructed and damage-free. If not clean, unobstructed and damage-free, clean or repair as necessary. If clean, unobstructed and damage-free, replace the appropriate B218 Side Object Sensor Module. If DTC is not set
5. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for side object sensor module replacement, programming and setup

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Rearview Camera, UVC) , Object Detection Description and Operation (with Park Assist, UD7) , Object Detection Description and Operation (with Side Blind Zone Alert, UFT) , Object Detection Description and Operation (with Rear Cross Traffic Alert, UFT) , Object Detection Description and Operation (with Lane Departure Warning, UFL) , Object Detection Description and Operation (with Forward Collision Alert, UEU)

Electrical Information Reference

1. «Circuit Testing»(ref-610066-S15766520632014042100000)
2. «Connector Repairs»(ref-610066-S09830970062014042100000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition OFF, ignition ON.
2. Verify the side blind zone alert system indicators located in the outside rearview mirrors briefly turn ON and then OFF during the system self test. If only the right side blind zone alert indicator briefly turns ON and OFF Refer to «Circuit/System Testing»(ref-610100-S01841010842014042100000) - Left Side Object Sensor Malfunction If only the left side blind zone alert indicator briefly turns ON and OFF Refer to «Circuit/System Testing»(ref-610100-S01841010842014042100000) - Right Side Object Sensor Malfunction If both side blind zone alert system indicators do not briefly turn ON and OFF Refer to «Circuit/System Testing»(ref-610100-S01841010842014042100000) - Side Object Indicator Malfunction If both side blind zone alert indicators briefly turn ON and OFF
3. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

1. «Front Side Door Window Switch Replacement - Left Side (Traverse)»(ref-610044-S11005472952014042100000)
2. «Front Side Door Window Switch Replacement - Right Side (Traverse)»(ref-610044-S21010501942014042100000)
3. «Outside Rearview Mirror Glass Replacement»(ref-610085-S23310203702014042100000)
4. «Control Module References»(ref-610060-S10098619762014042100000) for Side Object Sensor Module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Rearview Camera, UVC) , Object Detection Description and Operation (with Park Assist, UD7) , Object Detection Description and Operation (with Side Blind Zone Alert, UFT) , Object Detection Description and Operation (with Rear Cross Traffic Alert, UFT) , Object Detection Description and Operation (with Lane Departure Warning, UFL) , Object Detection Description and Operation (with Forward Collision Alert, UEU)

Electrical Information Reference

1. «Circuit Testing»(ref-610066-S15766520632014042100000)
2. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
3. «Wiring Repairs»(ref-610066-S23061455012014042100000)
4. «Connector Repairs»(ref-610066-S09830970062014042100000)

Scan Tool Reference

Control Module References for scan tool information

1. Verify that DTC B1405 is not set. If DTC is set, refer to «DTC B1405»(ref-610100-S19651946662014042100000) .
2. Verify that DTC B0958 3A, DTC B0959 3A, DTC B0960 3A or DTC B0961 3A is not set. If DTC is set, replace the appropriate object alarm sensor.
3. Transmission in REVERSE, verify the parking assist system is enabled and one audible beep sounds.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Rear Parking Assist Alarm Sensor Replacement»(ref-610100-S35542855782014042100000)
2. «Control Module References»(ref-610060-S10098619762014042100000) for object alarm module replacement, setup and programming

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Rearview Camera, UVC) , Object Detection Description and Operation (with Park Assist, UD7) , Object Detection Description and Operation (with Side Blind Zone Alert, UFT) , Object Detection Description and Operation (with Rear Cross Traffic Alert, UFT) , Object Detection Description and Operation (with Lane Departure Warning, UFL) , Object Detection Description and Operation (with Forward Collision Alert, UEU)

Electrical Information Reference

1. «Circuit Testing»(ref-610066-S15766520632014042100000)
2. «Connector Repairs»(ref-610066-S09830970062014042100000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition ON.
2. Verify that DTC B356A is not set. If the DTC is set Refer to «DTC B356A»(ref-610100-S24790547992014042100000) . If the DTC is not set
3. Verify the lane departure warning indicator turns ON and OFF while pressing and releasing the lane departure warning switch. If the indicator does not turn ON and OFF Refer to «Circuit/System Testing»(ref-610100-S36936163542014042100000) . If the indictor turns ON and OFF
4. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

1. «Hazard Warning Switch Replacement»(ref-610047-S05181511732014042100000)
2. «Control Module References»(ref-610060-S10098619762014042100000) for frontview camera module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Rearview Camera, UVC) , Object Detection Description and Operation (with Park Assist, UD7) , Object Detection Description and Operation (with Side Blind Zone Alert, UFT) , Object Detection Description and Operation (with Rear Cross Traffic Alert, UFT) , Object Detection Description and Operation (with Lane Departure Warning, UFL) , Object Detection Description and Operation (with Forward Collision Alert, UEU)

Electrical Information Reference

1. «Circuit Testing»(ref-610066-S15766520632014042100000)
2. «Connector Repairs»(ref-610066-S09830970062014042100000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

1. Verify no DTC is set. If a DTC is present, diagnose this first. Refer to «Diagnostic Trouble Code (DTC) List - Vehicle»(ref-610038-S14557891142014042100000) .
2. Verify the scan tool Vehicle Direction Camera System parameter is NORMAL. If not the specified value, refer to «Lane Departure Warning System Malfunction»(ref-610100-S25968226972014042100000) and «Forward Collision Alert System Malfunction»(ref-610100-S39922187342014042100000) .
3. Verify the scan tool Vehicle Direction Camera Calibration Status parameter is CALIBRATED. If not the specified value, calibrate the K109 Frontview Camera Module. Refer to «Front View Camera Module Calibration»(ref-610100-S01541169832014042100000) .

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for front view camera module programming and setup

1. The DTC will transition to history when the fault is no longer present.
2. A history DTC will clear after 100 malfunction-free ignition cycles.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Rearview Camera, UVC) , Object Detection Description and Operation (with Park Assist, UD7) , Object Detection Description and Operation (with Side Blind Zone Alert, UFT) , Object Detection Description and Operation (with Rear Cross Traffic Alert, UFT) , Object Detection Description and Operation (with Lane Departure Warning, UFL) , Object Detection Description and Operation (with Forward Collision Alert, UEU)

Electrical Information Reference

1. «Circuit Testing»(ref-610066-S15766520632014042100000)
2. «Connector Repairs»(ref-610066-S09830970062014042100000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

Verify that DTC B1015 is not set.

1. If the DTC is set, program the object alarm module. If the DTC resets, replace the object alarm module. Refer to «Rear Object Alarm Control Module Replacement»(ref-610100-S00468972552014042100000)

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

Control Module References for Object Alarm Module replacement, setup and programming.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Rearview Camera, UVC) , Object Detection Description and Operation (with Park Assist, UD7) , Object Detection Description and Operation (with Side Blind Zone Alert, UFT) , Object Detection Description and Operation (with Rear Cross Traffic Alert, UFT) , Object Detection Description and Operation (with Lane Departure Warning, UFL) , Object Detection Description and Operation (with Forward Collision Alert, UEU)

Electrical Information Reference

1. «Circuit Testing»(ref-610066-S15766520632014042100000)
2. «Connector Repairs»(ref-610066-S09830970062014042100000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON, transmission in REVERSE, observe the scan tool Sensor Feed Voltage Output parameter. The reading should be between 6.3-10.4 V.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Rear Parking Assist Alarm Sensor Replacement»(ref-610100-S35542855782014042100000)
2. «Control Module References»(ref-610060-S10098619762014042100000) for rear object alarm module replacement, setup and programming

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Rearview Camera, UVC) , Object Detection Description and Operation (with Park Assist, UD7) , Object Detection Description and Operation (with Side Blind Zone Alert, UFT) , Object Detection Description and Operation (with Rear Cross Traffic Alert, UFT) , Object Detection Description and Operation (with Lane Departure Warning, UFL) , Object Detection Description and Operation (with Forward Collision Alert, UEU)

Electrical Information Reference

1. «Circuit Testing»(ref-610066-S15766520632014042100000)
2. «Connector Repairs»(ref-610066-S09830970062014042100000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition ON.
2. Verify the scan tool Lane Departure Warning Switch Status parameter while pressing and releasing the lane departure warning switch. The parameter should change between Open and Closed. If the parameter does not change Refer to «Circuit/System Testing»(ref-610100-S23119510912014042100000) . If the parameter changes
3. Verify the driver information center displays and adjusts forward collision alert setting while repeatedly pressing and releasing the forward collision switch. The setting should change cycle between far, medium, near and off. If the display does not change Refer to «Circuit/System Testing»(ref-610100-S23119510912014042100000) . If the display changes
4. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

1. «Hazard Warning Switch Replacement»(ref-610047-S05181511732014042100000)
2. «Control Module References»(ref-610060-S10098619762014042100000) for frontview camera module replacement, programming and setup.

Symptoms - Object Detection

Note. The following steps must be completed before using the symptom tables

1. Perform the «Diagnostic System Check - Vehicle»(ref-610038-S36414632882014042100000) before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link. Note: The rear vision camera does not communicate on the serial data bus.
2. Review the system operation in order to familiarize yourself with the system functions. Refer to «Object Detection Description and Operation (with Rearview Camera, UVC)»(ref-610100-S07454247062014042100000) , «Object Detection Description and Operation (with Park Assist, UD7)»(ref-610100-S37315043662014042100000) , «Object Detection Description and Operation (with Side Blind Zone Alert, UFT)»(ref-610100-S13710342552014042100000) , «Object Detection Description and Operation (with Rear Cross Traffic Alert, UFT)»(ref-610100-S37141796902014042100000) , «Object Detection Description and Operation (with Lane Departure Warning, UFL)»(ref-610100-S00318566902014042100000) , «Object Detection Description and Operation (with Forward Collision Alert, UEU)»(ref-610100-S34241884012014042100000) .

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Rearview Camera, UVC) , Object Detection Description and Operation (with Park Assist, UD7) , Object Detection Description and Operation (with Side Blind Zone Alert, UFT) , Object Detection Description and Operation (with Rear Cross Traffic Alert, UFT) , Object Detection Description and Operation (with Lane Departure Warning, UFL) , Object Detection Description and Operation (with Forward Collision Alert, UEU)

Electrical Information Reference

1. «Circuit Testing»(ref-610066-S15766520632014042100000)
2. «Connector Repairs»(ref-610066-S09830970062014042100000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

Note. Refer to Diagnostic Aids before performing Circuit/System Verification.

1. Ignition ON.
2. Verify the scan tool Forward Collision Alert Function Status parameter is Off, Disabled, Not Ready To Assist or Ready To Assist. If the parameter is Malfunction Refer to «Circuit/System Testing»(ref-610100-S40493567982014042100000) - Frontview Camera Module Malfunction If the parameter is not Malfunction
3. Verify the driver information center displays and adjusts forward collision alert setting while repeatedly pressing and releasing the forward collision switch. The setting should cycle between far, medium, near and off. If the display does not change Refer to «Circuit/System Testing»(ref-610100-S40493567982014042100000) - Forward Collision Alert Switch Malfunction. If the display changes
4. Turn Ignition Off and then On.
5. Verify the Collision Alert Indicators illuminate briefly during the bulb check. If the indicators do not illuminate Refer to «Circuit/System Testing»(ref-610100-S40493567982014042100000) - Forward Collision Alert Indicator Malfunction If the indicators illuminate
6. Verify the K109 Frontview Camera Module has good visibility to the road ahead. If visibility is poor Clean windshield. If visibility is good
7. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

1. «Forward Collision Alert Display Replacement»(ref-610100-S22791718702014042100000)
2. «Hazard Warning Switch Replacement»(ref-610047-S05181511732014042100000) - Driver Information Center Switch replacement
3. «Control Module References»(ref-610060-S10098619762014042100000) for frontview camera module replacement, programming and setup

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Rearview Camera, UVC) , Object Detection Description and Operation (with Park Assist, UD7) , Object Detection Description and Operation (with Side Blind Zone Alert, UFT) , Object Detection Description and Operation (with Rear Cross Traffic Alert, UFT) , Object Detection Description and Operation (with Lane Departure Warning, UFL) , Object Detection Description and Operation (with Forward Collision Alert, UEU)

Electrical Information Reference

1. «Circuit Testing»(ref-610066-S15766520632014042100000)
2. «Connector Repairs»(ref-610066-S09830970062014042100000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition ON, verify the park assist system is enabled through the DIC. If the park assist system is manually disabled, enable the system. Refer to the vehicle owner's manual for instructions on enabling the system.
2. Transmission in REVERSE, verify one audible beep sounds and the scan tool Park Assist System Status parameter is Enable. NOTE: After completing the next step the vehicle might need to be driven at speed greater than 40 km/h (25 mph). If not the specified values, refer to «Diagnostic Aids»(ref-610100-S37449561342014042100000) and the scan tool Park Assist Disable History parameters to determine the cause of the inhibit.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Rearview Camera, UVC) , Object Detection Description and Operation (with Park Assist, UD7) , Object Detection Description and Operation (with Side Blind Zone Alert, UFT) , Object Detection Description and Operation (with Rear Cross Traffic Alert, UFT) , Object Detection Description and Operation (with Lane Departure Warning, UFL) , Object Detection Description and Operation (with Forward Collision Alert, UEU)

Electrical Information Reference

1. «Circuit Testing»(ref-610066-S15766520632014042100000)
2. «Connector Repairs»(ref-610066-S09830970062014042100000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition ON.
2. Verify the scan tool can communicate with the right side object sensor. If the scan tool can not communicate with the right side object sensor Refer to «Circuit/System Testing»(ref-610100-S30409742772014042100000) - Right Side Object Sensor Malfunction. If the scan tool can communicate with the right side object sensor
3. Verify the scan tool can communicate with the left side object sensor. If the scan tool can not communicate with the left side object sensor Refer to «Circuit/System Testing»(ref-610100-S30409742772014042100000) - Left Side Object Sensor Malfunction. If the scan tool can communicate with the left side object sensor
4. Verify that the rear cross traffic indicators alerts turn ON and then turn OFF when commanding the Object Detection Alert Indicators ON and OFF with a scan tool. If alert indicators do not turn ON and OFF Verify the system is enabled. If disabled, refer to «Diagnostic Aids»(ref-610100-S12263319732014042100000) for cause of disable. If enabled, test or replace the radio. If indicators turn ON and OFF
5. All OK.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

1. «Front Side Door Window Switch Replacement - Left Side (Traverse)»(ref-610044-S11005472952014042100000)
2. «Front Side Door Window Switch Replacement - Right Side (Traverse)»(ref-610044-S21010501942014042100000)
3. «Outside Rearview Mirror Glass Replacement»(ref-610085-S23310203702014042100000)
4. «Control Module References»(ref-610060-S10098619762014042100000) Side Object Sensor Module replacement, programming and setup

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Rearview Camera, UVC) , Object Detection Description and Operation (with Park Assist, UD7) , Object Detection Description and Operation (with Side Blind Zone Alert, UFT) , Object Detection Description and Operation (with Rear Cross Traffic Alert, UFT) , Object Detection Description and Operation (with Lane Departure Warning, UFL) , Object Detection Description and Operation (with Forward Collision Alert, UEU)

Electrical Information Reference

1. «Circuit Testing»(ref-610066-S15766520632014042100000)
2. «Connector Repairs»(ref-610066-S09830970062014042100000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

1. Inspect the rearview camera and verify there is no debris on the lens and that the bezel or bezel seal is not damaged. If debris is found on the lens, clean the lens. If the lens, bezel or bezel seal are damaged, replace as necessary.
2. Engine running, vehicle in PARK, verify the backup lamps are off. If the backup lamps are illuminated, refer to «Circuit/System Testing»(ref-610100-S28119333332014042100000) - Rearview Camera System Always On.
3. Vehicle is REVERSE, engine running, verify backup lamps are on. If the backup lamps are not illuminated, refer to «Backup Lamps Malfunction»(ref-610090-S03724507112014042100000) .
4. Vehicle in REVERSE, engine running, verify a clear rear vision image is displayed on the radio. If a clear image is not displayed, refer to «Circuit/System Testing»(ref-610100-S28119333332014042100000) - Rearview Camera System Does Not Display.

Perform the Diagnostic Repair Verification after completing the repair.

1. «Rearview Driver Information Camera Replacement (Traverse)»(ref-610100-S12701129992014042100000) , «Rearview Driver Information Camera Replacement (Acadia, Enclave)»(ref-610100-S27505598152014042100000)
2. «Control Module References»(ref-610060-S10098619762014042100000) for radio replacement, programming and setup

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Rearview Camera, UVC) , Object Detection Description and Operation (with Park Assist, UD7) , Object Detection Description and Operation (with Side Blind Zone Alert, UFT) , Object Detection Description and Operation (with Rear Cross Traffic Alert, UFT) , Object Detection Description and Operation (with Lane Departure Warning, UFL) , Object Detection Description and Operation (with Forward Collision Alert, UEU)

Electrical Information Reference

1. «Circuit Testing»(ref-610066-S15766520632014042100000)
2. «Connector Repairs»(ref-610066-S09830970062014042100000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

1. Verify there are no debris on the rearview camera lens. If debris are found on the lens Clean the debris from the lens. If no debris are found on the lens
2. Engine running, transmission in park.
3. Verify the backup lamps are not ON. If the backup lamps are ON Refer to «Circuit/System Testing»(ref-610100-S10139925842014042100000) - Rearview Camera System Always On If the backup lamps are not ON
4. Engine running with the drive wheels chocked, set the park brake and place the transmission in reverse.
5. Verify backup lamps are ON. If the backup lamps are not ON Refer to «Backup Lamps Malfunction»(ref-610090-S03724507112014042100000) . If the backup lamps are ON
6. Verify a clear rear vision image is displayed on the inside rearview mirror. If a clear image is not displayed Refer to «Circuit/System Testing»(ref-610100-S10139925842014042100000) - Rearview Camera System Does Not Display. If a clear image is displayed
7. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

1. «Rearview Driver Information Camera Replacement (Traverse)»(ref-610100-S12701129992014042100000) , «Rearview Driver Information Camera Replacement (Acadia, Enclave)»(ref-610100-S27505598152014042100000)
2. «Control Module References»(ref-610060-S10098619762014042100000) for BCM replacement, programming and setup

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Rearview Camera, UVC) , Object Detection Description and Operation (with Park Assist, UD7) , Object Detection Description and Operation (with Side Blind Zone Alert, UFT) , Object Detection Description and Operation (with Rear Cross Traffic Alert, UFT) , Object Detection Description and Operation (with Lane Departure Warning, UFL) , Object Detection Description and Operation (with Forward Collision Alert, UEU)

Electrical Information Reference

1. «Circuit Testing»(ref-610066-S15766520632014042100000)
2. «Connector Repairs»(ref-610066-S09830970062014042100000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

1. Ignition ON.
2. Verify the scan tool can communicate with the right side object sensor. If the scan tool can not communicate with the right side object sensor Refer to «Circuit/System Testing»(ref-610100-S30438078442014042100000) - Right Side Object Sensor Malfunction. If the scan tool can communicate with the right side object sensor
3. Verify the scan tool can communicate with the left side object sensor. If the scan tool can not communicate with the left side object sensor Refer to «Circuit/System Testing»(ref-610100-S30438078442014042100000) - Left Side Object Sensor Malfunction. If the scan tool can communicate with the left side object sensor
4. Ignition OFF, ignition ON.
5. Verify that both side blind zone alert system indicators located in the outside rearview mirrors briefly turn ON and then turn OFF during the system self test when ignition is turned ON. If both side blind zone alert indicators do not briefly turn ON and OFF Verify the system is enabled If disabled, refer to «Diagnostic Aids»(ref-610100-S31123286382014042100000) for cause of disable. If enabled, refer to «Circuit/System Testing»(ref-610100-S30438078442014042100000) - Side Object Indicator Malfunction. If only one indicator does not briefly illuminate during the self test Refer to «Circuit/System Testing»(ref-610100-S30438078442014042100000) - Side Object Indicator Malfunction. If both side blind zone alert indicators briefly turn ON and OFF
6. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

1. «Front Side Door Window Switch Replacement - Left Side (Traverse)»(ref-610044-S11005472952014042100000)
2. «Front Side Door Window Switch Replacement - Right Side (Traverse)»(ref-610044-S21010501942014042100000)
3. «Outside Rearview Mirror Glass Replacement»(ref-610085-S23310203702014042100000)
4. «Control Module References»(ref-610060-S10098619762014042100000) for side object sensor module replacement, programming and setup.

Schematic Reference

Object Detection Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Object Detection Description and Operation (with Rearview Camera, UVC) , Object Detection Description and Operation (with Park Assist, UD7) , Object Detection Description and Operation (with Side Blind Zone Alert, UFT) , Object Detection Description and Operation (with Rear Cross Traffic Alert, UFT) , Object Detection Description and Operation (with Lane Departure Warning, UFL) , Object Detection Description and Operation (with Forward Collision Alert, UEU)

Electrical Information Reference

1. «Circuit Testing»(ref-610066-S15766520632014042100000)
2. «Connector Repairs»(ref-610066-S09830970062014042100000)
3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

Note. Refer to Diagnostic Aids before performing Circuit/System Verification.

1. Ignition ON.
2. Verify that DTC B356A is not set. If the DTC is set Refer to «DTC B356A»(ref-610100-S24790547992014042100000) . If the DTC is not set
3. Verify that DTC B0987 is not set. If the DTC is set Refer to «DTC B0987»(ref-610100-S18906885562014042100000) . If the DTC is not set
4. Verify the scan tool Frontview Camera System Status parameter is Normal. If the parameter is Undefined or Malfunction Refer to «Diagnostic Aids»(ref-610100-S14809411402014042100000) . If the parameter is Normal
5. Verify the scan tool Lane Departure Warning Switch Status parameter changes between Open and Closed while pressing and releasing the lane departure warning switch. If the parameter does not change between Open and Closed Refer to «Circuit/System Testing»(ref-610100-S35345831812014042100000) - Lane Departure Warning Switch Malfunction. If the parameter changes between Open and Closed
6. Verify the scan tool Lane Departure Warning Switch indicator turns on and off while pressing and releasing the lane departure warning switch. If the indicator does not turn on and off Refer to «Circuit/System Testing»(ref-610100-S35345831812014042100000) - Lane Departure Warning Switch Indicator Malfunction. If the indicator turns on and off
7. Verify the area of the K109 Frontview Camera Module for contamination. If it needs to be cleaned Clean the windshield. If it does not need to be cleaned
8. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

1. «Hazard Warning Switch Replacement»(ref-610047-S05181511732014042100000)
2. «Control Module References»(ref-610060-S10098619762014042100000) for frontview camera module replacement, programming and setup.

Scheme 8

Forward Collision Alert Display Replacement

Scheme 9

Rear Object Alarm Control Module Replacement

Scheme 10

Side Object Sensing Alert Module Replacement

Scheme 11

1. Remove rear bumper fascia. Refer to «Rear Bumper Fascia Replacement (Acadia)»(ref-610046-S35754763492014042100000) , «Rear Bumper Fascia Replacement (Enclave)»(ref-610046-S04233693032014042100000) , «Rear Bumper Fascia Replacement (Traverse)»(ref-610046-S31700507292014042100000) .
2. Disconnect electrical from the rear object sensor.
3. Lift the locking tabs on the housing and remove the rear object sensor. NOTE: The rear object sensor is a one piece design. Do NOT twist the sensor cap to try and remove the painted cap. Replacement sensor requires painting to match fascia/bumper body color.

Rear Parking Assist System DIC Messages

SERVICE PARK ASSIST

The driver information center (DIC) displays SERVICE PARK ASSIST when the object alarm module detects a malfunction in the parking assist system and the system is disabled. The DIC also displays SERVICE PARK ASSIST when a loss of communication occurs with the object alarm module.

PARK ASSIST OFF

The PARK ASSIST OFF message is displayed in the DIC when the parking assist system is disabled manually through the DIC.

PARK ASST BLOCKED SEE OWNER'S MANUAL

The PARK ASST BLOCKED SEE OWNER'S MANUAL message is displayed in the DIC when the parking assist system is disabled due to conditions that disable or inhibit the system.

Scheme 12

Side Blind Zone Alert System Components

The side blind zone alert system is made up of the following components

1. Left side object sensor module (also used for rear cross traffic alert)
2. Right side object sensor module (also used for rear cross traffic alert)
3. Driver outside rearview mirror
4. Passenger outside rearview mirror

Side Object Sensor Modules

The side object sensor modules are located on each side of the vehicle behind the rear fascia and are not directly visible from outside the vehicle. The sensors use radar to determine the presence of objects nearby. When an object is detected in the side blind zone, the side object sensor module supplies voltage to illuminate the visual indicator on the appropriate side rear view mirror. Each sensor is supplied B+ and ground. The right sensor receives an additional ground. Both sensors communicate independently on the serial data line. The serial data enters the left sensor in a pass-thru configuration, that connects to the right sensor. The scan tool is able to individually communicate with each sensor.

Outside Rearview Mirrors

The outside rearview mirrors contain an icon that is backlit with high intensity, amber-colored LED's located on the mirror surface. The display brightness adapts to day/night conditions. The side blind zone alert indicator icon in the left or right outside rearview mirror is illuminated if the left or right side object sensor module detects a vehicle in the side blind zone to inform the driver that there is a vehicle driving in the blind spot zone.

Side Blind Zone Alert Driver Information Center Messages

SIDE BLIND ZONE ALERT OFF

This message indicates that the system has been disabled through the driver information center. Refer to the vehicle owner's manual for instructions on how to set personalization options on the driver information center.

SERVICE SIDE DETECTION SYSTEM

This message indicates that the system requires service. When the message is displayed, the indicators will remain illuminated at all times, notifying the driver that the side blind zone system should not be relied upon when changing lanes. Since the sensors are also used for rear cross traffic alert, this feature will also be inoperative.

SIDE DETECTION SYSTEM UNAVAILABLE

This message indicates that the system has been temporarily disabled because the sensor is blocked or can otherwise not accurately detect vehicles or objects. Such instances may be mud, dirt, snow, ice or slush build-up on the rear fascia, heavy rainfall, excessive road spray, fascia damage or stickers.

The rear cross traffic alert system will read the GPS latitude and longitude on the serial data bus and calculate if the vehicle is within a Radio Astronomy zone. These zones are located in Europe and Japan and require the sensors to be turned off. The "Side Detection System Unavailable" message will be displayed to the driver when this occurs.

Rear Cross Traffic Alert System Components

The side blind zone alert system is made up of the following components

1. Left side object sensor module (also used for side blind zone alert)
2. Right side object sensor module (also used for side blind zone alert)
3. Visual Display Icons located on the rear vision display screen
4. Audio System chime or Haptic Seat notification

Side Object Sensor Modules

The side object sensor modules are located on each side of the vehicle behind the rear fascia and are not directly visible from outside the vehicle. The sensors use radar to determine the presence of objects nearby. When an object is detected in the rear cross traffic zone, the module will send out a signal through serial data communication to turn on the visual icons and also audio chime notification. Each sensor is supplied B+ and ground. The right sensor receives an additional ground. Both sensors communicate independently on the serial data line. The serial data enters the left sensor in a pass-thru configuration, that connects to the right sensor. The scan tool is able to individually communicate with each sensor.

Display Icons

The rear cross traffic alert system visual alert display consists of two visual icons, one on each side of the display screen of the rear vision camera, that are used to alert the driver on rear cross traffic from each side of the host vehicle respectively.

Rear Cross Traffic Alert Driver Information Center Messages

REAR CROSS TRAFFIC ALERT OFF

This message indicates that the system has been disabled through the driver information center. Refer to the vehicle owner's manual for instructions on how to set personalization options on the driver information center.

SERVICE SIDE DETECTION SYSTEM

This message indicates that the system requires service. Since the sensors are also used for side blind zone alert, this feature will also be inoperative.

SIDE DETECTION SYSTEM UNAVAILABLE

This message indicates that the system has been temporarily disabled because the sensor is blocked or can otherwise not accurately detect vehicles or objects. Such instances may be mud, dirt, snow, ice or slush build-up on the rear fascia, heavy rainfall, excessive road spray, fascia damage or stickers.

The rear cross traffic alert system will read the GPS latitude and longitude on the serial data bus and calculate if the vehicle is within a Radio Astronomy zone. These zones are located in Europe and Japan and require the sensors to be turned off. The "Side Detection System Unavailable" message will be displayed to the driver when this occurs.

Lane Departure Warning System Driver Information Center Messages

The front view camera module can command the driver information center to display the various messages to alert the driver of a system concern or status information. For detailed information about the possible messages please refer to the user's manual.

Forward Collision Alert System Driver Information Center Messages

The front view camera module can command the driver information center to display the various messages to alert the driver of a system concern or status information. For detailed information about the possible messages please refer to the owner's manual.

1. FORWARD COLLISION ALERT OFF
2. SERVICE FRONT CAMERA
